Creality CR-Scan 01 User manual

Quick Guide
CR-Scan 01
scanner equipment. This paper introduces the connection method of hardware
> This installation manual is simple and easy for users who first contact with 3D
equipment, accessories description and software operation. For details, see
digital user manual and video.

> Power plug AC 100V-240V, the other end is connected to the scanner
DC port
USB3.0 cable with one end connected to the scanner and the other end >
connected to the computer USB3.0 port
Instructions for use of accessories
AC100V-240V
Power adapters
DC12V/3V
Plug
TypeA USB3.0 TypeB USB3.0
DC12V/3A
Socket
Mainframe USB
Quick Lock
Connector
Standard kit
Product Name:CR-Scan 01
Model:CRS1

Turntable data cable
MICRO USB
Plug
to fix the angle
> Mounting the scanner to the set screws
Adjust the tripod height and rotate the height locking ring to lock>
> Open the tripod as shown in the top picture, rotate the tripod stabilizer ring
> Adjust the scanner angle and tighten the universal ball joint screw to lock
Universal ball joint
Height adjustment
locking ring
Height adjustment
Tripod Stabilizer Ring
Upgrade kit
Turntable Mode (Tripod)

Turntable mode (Turntable)

> The power supply head is connected to 100V-240V AC, and the other end is
connected to the scanner DC port
USB3.0 cable with one end connected to the scanner and the other end >
connected to the computer USB3.0 port
The turntable is connected to the MIRCO USB and the other end is connected>
to the scanner DC2.0 interface
Hardware Installation
Plug bump aligned
with socket recess
Pinch the pattern
to pull out the plug
Turntable mode
Handheld mode

> This product is a high precision measuring equipment, please do not
> The lens is a sensitive optical device, if the lens is stained, please use
> The lens is a sensitive optical device, please do not contact
> The lens is a sensitive optical device, if not in use, please place it in
the random airtight box for storage
switch
> This product is a high precision measuring equipment, please place
carefully to avoid external force image imaging accuracy
pure water, do not use with alcohol solvent wipe
> This product in a long time standby premise, please turn off the power
with water, grease or sharp objects
use in solid smoke or heavy dust environment for a long time
Precautions and maintenance

Software usage instructions
1.4 Panning Model
1.5 Scaling models
Shortcut Keys
Main UI
1. Main shortcut keys
2.2 De-selection model
(Press and hold to move)
(Scroll wheel)
1.1 Handheld models - start/stop acquisition
1.2 Select the model rotation center
1.3 Rotating models
2. Edit Mode
(click)
Alt
S
(Press and hold to move)
2.1 Selection of models
(Press and hold to move)A lt
(Press and hold to move)
a. Function module page, showing the main function buttons
b. Module switch button, you can switch between different
functional modules
c. Model display area, displaying model data in real time
d. Data management list, used to manage scanning data results
e. Log display window, used to display the software operation log

First start up
Turntable mode
1.Preview adjust Perspective
a. Click the Preview button to start the preview
b. Adjust the distance from the scanner to the turntable to between 600-800mm
c. Rotate the scanner so that the center of the camera image covers the turntable
and is aligned with the scanned object
d. Adjust the brightness to make the photo brightness appropriate
a. Click button，Select the Calib.txt file on the device's USB drive in Calib file
b. Check if the SN number on the bottom of the device and the imported SN number match
c. Click button,Complete the Calib file import and the software restarts automatically
im port

3.Start scanning
a. Placing the scanned object on the center of the turntable
b. Click the Start button to start automatic target scanning
c. After an object is scanned in one pose, the object can be flipped and
scanned in multiple poses to get a complete model without missing
Automatic rotary scanning of turntable
2.Initializing the turntable
a. Removal of scanned objects and debris from around the turntable
b. Click the initialize button, and when only the turntable turns red, click the stop button
Turntable turns red overall

4.Automatic data processing
a. Click on the processing button to start the fully automatic processing
b. Check whether the data and corresponding parameters involved in the processing are
appropriate and click the processing button
c. Check whether the multi-positional alignment structure is correct, if not, enter manual
alignment mode
d. Complete the model data processing automatically and export the model result data
(STL format can be directly 3D printed, OBJ format with color texture)

Handheld mode
1.Start scanning
2.Automatic data processing
a. Align with the object, the distance to maintain 500mm-900mm, start scanning
b. As shown in the picture, take the lens on top of the scanner as the scanning center and
align the scanned object
c. After scanning the object in one pose, you can flip the object to scan multiple poses to
get the complete model without missing
a. Click the processing button to start fully automatic processing
b. Enter the base-removal interface, use the shortcut keys to select 2-3 base-areas,
click the calculate base-button, the base-area turns red
c. Start fully automatic processing of model data of one or more poses, and get a
complete model without missing data

Usersshouldcomplywiththelawsandregulationsofthecorresponding
countriesandregionswheretheequipmentislocated(used) andethical
principles,fulfillsafetyobligations,andstrictlyprohibittheuseofour
productsorequipmentforanyillegalpurposes.Crealitywillnotbe
responsibleforanyviolators'legalliabilityunderanycircumstance.
