CREE LIGHTING SmartCast CSC-CPS-120V User manual

CSC-CPS-120V
SmartCast® POE Power Supply
Junction Box Mounting
LPN00654X0001A0_B
1 of 2
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D’INSTALLATION
INCLUDED IN KIT:
• Power Supply
• Din Rail
• RJ45 Socket Harness
SUPPLIED BY CUSTOMER:
• UL Listed Junction box - dimensions
4-11/16 x 4-11/16 x 3 inches or greater. Metal or
other plenum rated material
• Junction cover
• Mounting and ground screws
• CAT5e Plenum rated cable with RJ45
termination. – length as needed
• UL Listed conduit, tubing and fittings that
comply with UL514B (as necessary)
• UL Listed Strain reliefs (as necessary)
INSTALLATION
STEP 1:
Use customer supplied screws to mount customer
supplied junction box and DIN Rail section to wall,
stud, or other mounting surface. See Figure 1.
1
DIN Rail
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before installation.
DANGER – Risque de choc – Couper l’alimentation avant
l’installation.
2. Must be installed in accordance with the NEC or your local
electrical code. If you are not familiar with these codes and
requirements, consult a qualied electrician.
Ce produit doit être installé conformément à NEC ou votre
code électrique local. Si vous n’êtes pas familier avec ces
codes et ces exigences, veuillez contacter un électricien
qualié.
3. Indoor use only.
Pour usage interieur seulement.
4. For use with Cree Lighting SmartCast Wireless Gateway
Model CSC-GW-CWC-W only.
5. For installation in a max. 40°C environment.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE

LPN00654X0001A0_B
2 of 2
www.creelighting.com
© 2019 Cree Lighting, A company of IDEAL INDUSTRIES. All rights reserved. For informational purposes only. Content
is subject to change. See www.creelighting.com/warranty for warranty and specifications. Cree®and the Cree logo are
registered trademarks and the Cree SmartCast Technology logo is a trademark of Cree, Inc. SmartCast®, is a registered
trademark and OneButtonTM is a trademark of Cree Lighting, A company of IDEAL INDUSTRIES.
STEP 2:
Connect provided harness to the power supply at
the V+ and V- terminals. Connect AC Power to L
and N terminals of the power supply. Use Copper
Conductors that are suitable for at least 60C/75C.
See Figure 2.
STEP 3:
Install power supply into junction box by mounting to
the DIN Rail. Bring the power supply to the Din Rail
and snap it into place. See
Figure 3.
STEP 4:
Lock power supply onto rail by pressing down on tab
on the top of the power supply until you hear a click.
See Figure 3.
STEP 5:
Properly ground the J-Box enclosure using a
customer provided green hex machine screw.
Screw AC Ground lead to box housing using
customer provided ground screw. See
Figure 2.
STEP 6:
Connect customer supplied CAT5 cable to RJ45
socket. CAT5 may be routed to any point outside of
the junction box. Connect other end of CAT5 cable to
the load device. See Figure 3.
NOTE: If CAT5 cable is not routed in conduit, then
strain relief is required at the junction box access
point as required by local and federal codes. Make
sure wiring is separated per NEC or local codes.
STEP 7:
Install the cover customer supplied junction box
cover lid over the junction box.
