Crestron Electronics TSS-70 Series User manual

TSS-70 Series
7 in. and 10.1 in. Room Scheduling Touch
Screens
Product Manual
Crestron Electronics, Inc.

The original language version of this document is U.S. English.
All other languages are a translation of the original document.
Regulatory Model: M201923002, M201923003
Crestron product development software is licensed to Crestron dealers and Crestron Service Providers (CSPs) under a
limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating
system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement.
Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_
agreement.
The product warranty can be found at www.crestron.com/warranty.
The specific patents that cover Crestron products are listed online at www.crestron.com/legal/patents.
Certain Crestron products contain open source software. For specific information, please visit
www.crestron.com/opensource.
Crestron, the Crestron logo, Crestron Fusion, Crestron Home, Crestron Toolbox, PinPoint, Rava, Smart Graphics, and
XiOCloud are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other
countries. 2N is either a trademark or a registered trademark of 2N Telekomunikace in the United States and/or other
countries. 22 Miles is either a trademark or a registered trademark or 22 Miles, Inc. in the United States and/or other
countries. Appspace and the Appspace logo are either trademarks or registered trademarks of Appspace, Inc. in the
United States and/or other countries. AskCody is either a trademark or a registered trademark of AskCody in the United
States and/or other countries. Bluetooth is either a trademark or registered trademark of Bluetooth SIG, Inc. in the
United States and/or other countries. EMS Software and the EMS logo are either trademarks or registered trademarks
of EMS Software, LLC in the United States and/or other countries. Gingco.net is either a trademark or a registered
trademark of Gingco.net in the United States and/or other countries. Envoy is either a trademark or a registered
trademark of Envoy, Inc. in the United States and/or other countries. G Suite, Google, and Google Calendar are either
trademarks or registered trademarks of Google, Inc. in the United States and/or other countries. Indoor Finders is either
a trademark or a registered trademark of IntelliGroups, LLCin the United States and/or other countries. iOffice is either
a trademark or a registered trademark of iOffice, LPin the United States and/or other countries. Kardham Digital is
either a trademark or a registered trademark of Kardham Digital in the United States and/or other countries. Matrix
Booking is either a trademark or a registered trademark of Matrix Booking in the United States and/or other countries.
Active Directory, Microsoft, Microsoft Teams, and Office 365 are either trademarks or registered trademarks of
Microsoft Corporation in the United States and/or other countries. New Wave Apps is either a trademark or a registered
trademark of New Wave Apps in the United States and/or other countries. NFS is either a trademark or a registered
trademark of NFS Technology Group in the United States and/or other countries. OfficeSpace is either a trademark or a
registered trademark of OfficeSpace Software Inc. in the United States and/or other countries. Pepperdash is either a
trademark or a registered trademark of Pepperdash Technology Corporation in the United States and/or other
countries. Door Tablet is either a trademark or a registered trademark of Public.Class Limited in the United States
and/or other countries. Korbyt is either a trademark or registered trademark of RMGEnterprise Solutions, Inc. in the
United States and/or other countries. Robin and the Robin logo are either trademarks or registered trademarks of Robin
Powered, Inc. in the United States and/or other countries. SharingCloud is either a trademark or a registered trademark
of SharingCloud in the United States and/or other countries. Smartway2 is either a trademark or a registered trademark
of Smartway2 Ltd. in the United States and/or other countries. Sonos is either a trademark or a registered trademark of
Sonos, Inc. in the United States and/or other countries. Space Connect is either a trademark or a registered trademark
of Spaceconnect Pty Ltd in the United States and/or other countries. SpaceIQ is either a trademark or a registered
trademark of Space IQ, LLC in the United States and/or other countries. Telelogos is either a trademark or a registered
trademark of Telelogos SASin the United States and/or other countries. EventBoard, Teem, and the Teem logo are
either trademarks or registered trademarks of Teem, LLC in the United States and/or other countries. Zoom and Zoom
Rooms are either trademarks or registered trademarks of Zoom Video Communications, Inc. in the United States and/or
other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to
either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the
marks and names of others. Crestron is not responsible for errors in typography or photography.
©2023 Crestron Electronics, Inc.

Contents
Overview 1
Features 2
TSS-770 Features 3
TSS-770-T Features 7
TSS-770-Z Features 11
TSS-1070 Features 15
TSS-1070-T Features 19
TSS-1070-Z Features 23
Physical Description 27
Specifications 28
TSS-770 Specifications 29
Product Specifications 29
Dimension Drawings 32
TSS-770-T Specifications 34
Product Specifications 34
Dimension Drawings 37
TSS-770-Z Specifications 39
Product Specifications 39
Dimension Drawings 42
TSS-1070 Specifications 44
Product Specifications 44
Dimension Drawings 47
TSS-1070-T Specifications 49
Product Specifications 49
Dimension Drawings 52
TSS-1070-Z Specifications 53
Product Specifications 53
Dimension Drawings 56
Installation 57
Install the Mounting Bracket 57
Electrical Box Mounting 58
Drywall Mounting 59
Install the Security Bracket (Optional) 59
Connect the Touch Screen 60
Mount the Touch Screen 61
Configure the Touch Screen 62
Access the Device Setup Screens 63
Access the Web Configuration Interface 63
Create an Admin Account 64
Set the Time Zone 65
Product Manual — Doc. 8745H Contents • iii

Select an Application 65
Configure Microsoft Teams Panels 66
Configure the Zoom Rooms Application 68
Configuration 70
Local Configuration 72
Access the Setup Screens 72
Ethernet Setup 73
ApplicationSelection 80
Wi-Fi Setup 81
Bluetooth Beacon 88
Virtual Toolbar 89
Diagnostics &Advanced 91
About 96
Web Configuration 97
Actions Menu 98
Status 101
Settings 106
Security 123
802.1x Configuration 131
Application Selection 134
Operation 136
Resources 138
Crestron Support and Training 138
Programmer and Developer Resources 138
Related Documentation 138
iv • Contents Product Manual — Doc. 8745H

Product Manual — Doc. 8745H TSS-70 Series • 1
Overview
The Crestron® TSS-770 and TSS-1070 are wall mount touch screens designed specifically for room
scheduling applications. The touch screens install near the entrance of a meeting room or huddle space
to provide a clear indication of the room availability and schedule, and they integrate seamlessly with a
variety of popular scheduling services.
NOTE:The TSS-770 and TSS-1070 are functionally similar. For simplicity within this documentation,
the term "touch screen"is used except where otherwise noted.
Crestron offers the following variations for its standard touch screen models. Certain settings described
in this document are not applicable to these models.
lThe TSS-770-T and TSS-1070-T series touch screens are designed to specifically run the Microsoft
Teams® Panels scheduling application.
lThe TSS-770-Z and TSS-1070-Z series touch screens are designed to specifically run the Zoom
Rooms® scheduling application.

2 • TSS-70 Series Product Manual — Doc. 8745H
Features
Refer to the following sections for more information on the features provided by various TSS-70 Series
models.
lTSS-770 Features on page 3
lTSS-770-T Features on page 7
lTSS-770-Z Features on page 11
lTSS-1070 Features on page 15
lTSS-1070-T Features on page 19
lTSS-1070-Z Features on page 23

Product Manual — Doc. 8745H TSS-70 Series • 3
TSS-770 Features
Crestron® TSS-770 series touch screens are designed to enhance and simplify room scheduling across an
enterprise. TheTSS-770 installs near a meeting room or huddle space to provide a clear indication of its
availability and scheduling while integrating seamlessly with a variety of popular scheduling services.
The TSS-770 is also sold as part of a kit that includes one TSW-770-LBseries room availability light bar,
providing a complete room scheduling solution out of the box.
Key features include:
lTouch screen designed specifically for enterprise room scheduling applications
lDelivers a superior and cost-effective alternative to consumer tablet devices
lIntegrates directly with various room scheduling services
l7in. (178mm) widescreen capacitive touch screen display
lStandard U.S., U.K., and European electrical box installation with additional mounting options
available
lSingle wire Ethernet connection with PoEor PoE+ power
lWi-Fi® network connectivity
lDual USB2.0 ports for room availability accessories
lEnterprise grade security and authentication
lChoice of white or black smooth finish
Crestron Room Scheduling App
The native Crestron Scheduling app helps to maximize productivity and manage usage for meeting
spaces. If desired, the room can be reserved on the spot for an ad hoc meeting. ACEN-ODT-C-POE

4 • TSS-70 Series Product Manual — Doc. 8745H
occupancy sensor (sold separately)can also be paired to the touch screen, allowing for occupancy
status to be reported instantly to the scheduling app for no-shows and unscheduled room usage.1
Crestron room scheduling also offers three levels of customization—ranging from simply configuring
settings in the web user interface to modifying the application source code for a completely unique
appearance—depending on the needs of an enterprise.
Running the Crestron Scheduling App, the TSS-770 integrates directly with Crestron Fusion® software,
Microsoft Exchange Server® software (for users of Outlook® software and Office365® software), the
Google Calendar™ calendaring app (including G Suite™ software), CollegeNET® 25Live® scheduling
software, or Ad Astra® software. IBM® Notes® software is also supported through a Crestron Fusion
on-premises server.
Third-Party Scheduling Apps
The TSS-770 includes support various third-party scheduling applications. New providers are made
available via firmware updates. Whatever provider you choose, setup is as simple as connecting the
touch screen to the network and choosing an app from the web-based setup menu or built-in setup
screens. The selected app downloads from the cloud and installs on the touch screen without any
programming or control system required.1,2,3
Built for Enterprise Scheduling
The TSS-770 is engineered to meet the demands of a corporate office, conference center, or education
environment. Its 7in. (178mm) capacitive display provides an intuitive user interface. The UI can be
customized and branded with your choice of background images and logos.1A larger 10.1in. (257mm)
version (TSS-1070 series) is also available.
lFunctional: The TSS-770 provides a compact unit for scheduling applications that mounts over a
standard electrical box or cutout. The TSS-770 offers high-speed Ethernet and PoE/PoE+
connectivity, or, for deployments without access to Ethernet, can connect to the network over
Wi-Fi® communications via a local wireless access point (WAP).
lVersatile: Crestron offers a variety of mounting options for mounting the TSS-770 to drywall,
masonry, glass, mullions, and other surfaces. Optional light bar and hallway sign accessories are
available to increase the visibility of the room availability status.
lReliable: The TSS-770 is purpose-built for permanent installation and years of reliable 24/7
operation in a commercial environment. To ensure the latest features are available, the TSS-770
checks nightly for app updates and loads the latest version automatically.
lSecure: The TSS-770 employs enterprise-grade networking with robust security features such as
802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory® service
integration. These features protect your network against service interruptions and malicious
intrusions.
lManageable: The TSS-770 features cloud-based provisioning and management, which
streamlines configuring, monitoring, and updating the touch screen on the network. The TSS-770
also supports SNMP, so it can be monitored by your IT administrator.
Status Indicator Options
The TSS-770 provides dual high-speed USB2.0 ports for connecting Crestron room scheduling
accessories (sold separately) to the touch screen that enhance an enterprise room scheduling solution.

Product Manual — Doc. 8745H TSS-70 Series • 5
NOTE: The touch screen supports the use of a single light bar or status indicator accessory only. The
RFID-USBcard reader accessory can be connected to the second USBport.
lThe optional TSW-770-LB series light bars provide a 180° visual indication of a room’s availability
status, illuminating green if the room is available and red when reserved, with options for custom
color mixing and programming.4
lThe optional SSW-EL and SSC-EL series hallway signs feature a twosided acrylic sign face that
can be custom engraved with the room name or number. The SIW-100 offers a lower profile wall
mount status indicator.4
Bluetooth Beacon
The built-in Bluetooth® proximity detection beacon works with the Crestron Go App and Crestron App
to determine when a mobile device is in or near the same room as the beacon, and signals the mobile
app to automatically display the appropriate controls and information for the room.5
Proximity Sensor and Brightness Controls
The TSS-770 provides abuilt-in proximity sensor that wakes the screen without requiring any user
interaction, and automatic brightness controls ensure optimal visibility under varying lighting conditions.
Power over Ethernet
PoE (Power over Ethernet) eliminates the need for a local power supply or any dedicated power wiring.
Crestron PoE switches (sold separately) offer a total networking solution with built-in PoE for multiple
touch screens. A PoE Injector (PWE-4803RU, sold separately) is also available to support a single touch
screen.
NOTE: Refer to the “Power” specifications for more details.
XiOCloud Service
The TSS-770 is compatible with the XiO Cloud® service, which remotely provisions, monitors, and
manages Crestron devices across an enterprise or an entire client base. Built on the Microsoft® Azure®
software platform and utilizing Microsoft's Azure IoT Hub technology, XiO Cloud enables installers and
IT managers to deploy and manage thousands of devices simultaneously. Unlike other virtual
machine-based cloud solutions, Azure services provide unlimited scalability. For more information, visit
www.crestron.com/xiocloud.
Wall Mount Options
Using the bracket provided, the TSS-770 is easily installed over a 2-gang or 3-gang US electrical box, or a
2-gang European or UK electrical box. A security latch option is included to deter unauthorized removal
of the touch screen.
Additional wall mounting options are available using the optional TSW-UMB-70 universal mounting
bracket, TSW-UMB-70-PMK preconstruction mounting kit, and TSW-UMB-70-BBI back box (sold
separately).6

6 • TSS-70 Series Product Manual — Doc. 8745H
Optional Mounting Accessories
The TSS-770 supports numerous optional mounting accessories (sold separately) that allow the touch
screen to be installed in all kinds of installations:
lThe TSW-770-MSMK multisurface mount kit allows a TSS-770 touch screen to be mounted
directly to virtually any flat surface, which is ideal for mounting at a meeting space entrance for
room scheduling applications.
lThe TSW-770/1070-MUMKallows the touch screen to be attached to the mullion of an interior
glass wall, window, or partition.
lThe TSW-770/1070-RMB-1 andTSW-770/1070-RMB-2 retrofit mounting brackets allow for
retrofit installations in place of an older Crestron touch screen (APAD, CT-1000, LC-1000,
TPS-4L, or TPS-2000L) without having to tear out the old mounting hardware or patch the wall.
lThe TSW-770-FP face plate hides the electrical box from view when replacing a TSW-760 or
TSS-7 series touch screen with a TSS-770 series touch screen.
lThough not typical for most scheduling applications, the TSW-570/770-RMK-1 rack mount kit can
be used to mount the touch screen into a 19in. rack. When installed, the touch screen occupies
three rack spaces.
The TSS-770 is also compatible with Wall-Smart® flush wall mount products via a partnership with
Crestron. For more information on supported Wall-Smart hardware, click here.
Notes:
1. Actual functionality and on-screen appearance varies based on which scheduling app is in use and how the app is set up.
The functionality described in this spec sheet generally refers to the Crestron Scheduling app. Each third-party provider
determines the functionality and appearance of their respective app. Additionally, CollegeNET® 25Live® scheduling
software and Ad Astra™ software do not support scheduling ad hoc meetings from the touch screen. Refer to each
provider’s website for more information.
2. Refer to the firmware release notes for a list of all scheduling apps that are supported by that firmware release.
3. Additional subscriptions and/or licenses may be required. Refer to each provider’s website for details about the
capabilities and requirements of its scheduling application and services. Third-party apps typically run on the TSS-770 as
they do on a tablet device. The TSS-770 runs only one app, which is selected at setup. Only the apps approved and
delivered by Crestron can run on the TSS-770. The TSS-770 cannot be interfaced with a control system and cannot be
custom programmed for any other functionality. An internet connection is required.
4. The TSS-770 may be powered by either a PoEor PoE+power source when a light bar or hallway sign is connected. Refer to
the Accessories section for a list of all available options. Refer to each accessory’s spec sheet for further information.
5. Bluetooth technology is used solely for proximity detection and does not transmit or receive any control, multimedia, or
personal data. Crestron Bluetooth beacons are only visible to Bluetooth enabled devices that are specifically programmed
and configured to work with them.
6. The TSW-UMB-70 is also compatible with older TSW-UMB-PMK series preconstruction mounting kits and TSW-BBI series
back boxes, allowing the TSS-770 to be installed in place of a previous generation touch screen.

Product Manual — Doc. 8745H TSS-70 Series • 7
TSS-770-T Features
Crestron® TSS-770-T series touch screens are designed to enhance and simplify room scheduling across
an enterprise. TheTSS-770-T installs near a meeting room or huddle space to provide a clear indication
of its availability and scheduling while integrating seamlessly with the Microsoft Teams® Panels
scheduling application. Support for additional room scheduling services is also provided.
The TSS-770-T is sold as part of a kit that includes one TSW-770-LBseries room availability light bar,
providing a complete room scheduling solution out of the box.
Key features include:
lTouch screen designed specifically to run the Microsoft Teams® Panels scheduling application
lDelivers a superior and cost-effective alternative to consumer tablet devices
l7in. (178mm) widescreen capacitive touch screen display
lStandard U.S., U.K., and European electrical box installation with additional mounting options
available
lSingle wire Ethernet connection with PoEor PoE+ power
lWi-Fi® network connectivity
lDual USB2.0 ports for room availability accessories
lEnterprise grade security and authentication
lChoice of white or black smooth finish

8 • TSS-70 Series Product Manual — Doc. 8745H
Microsoft Teams Panels
The native Microsoft Teams Panels scheduling application helps to maximize productivity and manage
usage for meeting spaces via Microsoft Teams. The touch screen can be configured to use the Microsoft
Teams scheduling calendar, allowing users to book meetings through their Microsoft Teams account. If
desired, the room can be reserved on the spot for an ad hoc meeting.1,2
NOTE: For more information on Microsoft Teams Panels, refer tohttps://docs.microsoft.com/en-
us/microsoftteams/devices/teams-panels.
Built for Enterprise Scheduling
The TSS-770-T is engineered to meet the demands of a corporate office, conference center, or
education environment. Its 7in. (178mm) capacitive display provides an intuitive user interface. A larger
10.1in. (257mm) version (TSS-1070 series) is also available.
lFunctional: The TSS-770-T provides a compact unit for scheduling applications that mounts over
a standard electrical box or cutout. The TSS-770-T offers high-speed Ethernet and PoE/PoE+
connectivity, or, for deployments without access to Ethernet, can connect to the network over
Wi-Fi® communications via a local wireless access point (WAP).
lVersatile: Crestron offers a variety of mounting options for mounting the TSS-770-T to drywall,
masonry, glass, mullions, and other surfaces. Optional light bar and hallway sign accessories are
available to increase the visibility of the room availability status.
lReliable: The TSS-770-T is purpose-built for permanent installation and years of reliable 24/7
operation in a commercial environment. To ensure the latest features are available, the TSS-770-
T checks nightly for app updates and loads the latest version automatically.
lSecure: The TSS-770-T employs enterprise-grade networking with robust security features such
as 802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory® service
integration. These features protect your network against service interruptions and malicious
intrusions.
lManageable: The TSS-770-T features cloud-based provisioning and management, which
streamlines configuring, monitoring, and updating the touch screen on the network. The TSS-770-
T also supports SNMP, so it can be monitored by your IT administrator.
Status Indicator Options
The TSS-770-T provides dual high-speed USB2.0 ports for connecting Crestron room scheduling
accessories (sold separately) to the touch screen that enhance an enterprise room scheduling solution.
NOTE: The touch screen supports the use of a single light bar or status indicator accessory only. The
RFID-USBcard reader accessory can be connected to the second USBport.
lThe included TSW-770-LB series light bar provides a 180° visual indication of a room’s availability
status, illuminating green if the room is available and red when reserved, with options for custom
color mixing and programming.3
lThe optional SSW-EL and SSC-EL series hallway signs feature a twosided acrylic sign face that
can be custom engraved with the room name or number. The SIW-100 offers a lower profile wall
mount status indicator.3

Product Manual — Doc. 8745H TSS-70 Series • 9
Bluetooth Beacon
The built-in Bluetooth® proximity detection beacon works with the Crestron Go App and Crestron App
to determine when a mobile device is in or near the same room as the beacon, and signals the mobile
app to automatically display the appropriate controls and information for the room.4
Proximity Sensor and Brightness Controls
The TSS-770-T provides abuilt-in proximity sensor that wakes the screen without requiring any user
interaction, and automatic brightness controls ensure optimal visibility under varying lighting conditions.
Power over Ethernet
PoE (Power over Ethernet) eliminates the need for a local power supply or any dedicated power wiring.
Crestron PoE switches (sold separately) offer a total networking solution with built-in PoE for multiple
touch screens. A PoE Injector (PWE-4803RU, sold separately) is also available to support a single touch
screen.
NOTE: Refer to the “Power” specifications for more details.
XiOCloud Service
The TSS-770-T is compatible with the XiO Cloud® service, which remotely provisions, monitors, and
manages Crestron devices across an enterprise or an entire client base. Built on the Microsoft® Azure®
software platform and utilizing Microsoft's Azure IoT Hub technology, XiO Cloud enables installers and
IT managers to deploy and manage thousands of devices simultaneously. Unlike other virtual
machine-based cloud solutions, Azure services provide unlimited scalability. For more information, visit
www.crestron.com/xiocloud.
Wall Mount Options
Using the bracket provided, the TSS-770-T is easily installed over a 2-gang or 3-gang US electrical box,
or a 2-gang European or UK electrical box. A security latch option is included to deter unauthorized
removal of the touch screen.
Additional wall mounting options are available using the optional TSW-UMB-70 universal mounting
bracket, TSW-UMB-70-PMK preconstruction mounting kit, and TSW-UMB-70-BBI back box (sold
separately).5
Optional Mounting Accessories
The TSS-770-T supports numerous optional mounting accessories (sold separately) that allow the touch
screen to be installed in all kinds of installations:
lThe TSW-770-MSMK multisurface mount kit allows a TSS-770-T touch screen to be mounted
directly to virtually any flat surface, which is ideal for mounting at a meeting space entrance for
room scheduling applications.
lThe TSW-770/1070-MUMKallows the touch screen to be attached to the mullion of an interior
glass wall, window, or partition.
lThe TSW-770/1070-RMB-1 andTSW-770/1070-RMB-2 retrofit mounting brackets allow for
retrofit installations in place of an older Crestron touch screen (APAD, CT-1000, LC-1000,
TPS-4L, or TPS-2000L) without having to tear out the old mounting hardware or patch the wall.

10 • TSS-70 Series Product Manual — Doc. 8745H
lThough not typical for most scheduling applications, the TSW-570/770-RMK-1 rack mount kit can
be used to mount the touch screen into a 19in. rack. When installed, the touch screen occupies
three rack spaces.
Notes:
1. Microsoft determines the functionality and appearance of the Microsoft Teams room scheduling application. Refer to the
Microsoft website for more information.
2. Additional subscriptions and/or licenses may be required. Refer to the Microsoft website for details about the capabilities
and requirements of its scheduling application and services. The TSS-770-T cannot be interfaced with a control system
and cannot be custom programmed for any other functionality. An internet connection is required.
3. The TSS-770-T may be powered by either a PoEor PoE+power source when a light bar or hallway sign is connected. Refer
to the Accessories section for a list of all available options. Refer to each accessory’s spec sheet for further information.
4. Bluetooth technology is used solely for proximity detection and does not transmit or receive any control, multimedia, or
personal data. Crestron Bluetooth beacons are only visible to Bluetooth enabled devices that are specifically programmed
and configured to work with them.
5. The TSW-UMB-70 is also compatible with older TSW-UMB-PMK series preconstruction mounting kits and TSW-BBI series
back boxes, allowing the TSS-770-T to be installed in place of a previous generation touch screen.

Product Manual — Doc. 8745H TSS-70 Series • 11
TSS-770-Z Features
Crestron® TSS-770-Z series touch screens are designed to enhance and simplify room scheduling across
an enterprise. TheTSS-770-Z installs near a meeting room or huddle space to provide a clear indication
of its availability and scheduling while integrating seamlessly with the Zoom Rooms® scheduling
application. Support for additional room scheduling services is also provided.
The TSS-770-Z is sold as part of a kit that includes one TSW-770-LBseries room availability light bar,
providing a complete room scheduling solution out of the box.
Key features include:
lTouch screen designed specifically to run the Zoom Rooms® scheduling application
lDelivers a superior and cost-effective alternative to consumer tablet devices
l7in. (178mm) widescreen capacitive touch screen display
lStandard U.S., U.K., and European electrical box installation with additional mounting options
available
lSingle wire Ethernet connection with PoEor PoE+ power
lWi-Fi® network connectivity
lDual USB2.0 ports for room availability accessories
lEnterprise grade security and authentication
lChoice of white or black smooth finish

12 • TSS-70 Series Product Manual — Doc. 8745H
Zoom Rooms Application
The native Zoom Rooms scheduling application helps to maximize productivity and manage usage for
meeting spaces. The touch screen can be configured to use the Zoom Rooms scheduling calendar,
allowing users to check meeting room availability and book meetings through their organization's Zoom
Rooms deployment. If desired, the room can be reserved on the spot for an ad hoc or future meeting1,2
Aprovided USB drive boots the touch screen directly into Zoom Rooms scheduling mode for fast
deployment.
NOTE: For more information on Zoom Rooms scheduling, refer tohttps://support.zoom.us/hc/en-
us/articles/115003336806-Using-Zoom-Rooms-scheduling-display.
Built for Enterprise Scheduling
The TSS-770-Z is engineered to meet the demands of a corporate office, conference center, or
education environment. Its 7in. (178mm) capacitive display provides an intuitive user interface. A larger
10.1in. (257mm) version (TSS-1070 series) is also available.
lFunctional: The TSS-770-Z provides a compact unit for scheduling applications that mounts over
a standard electrical box or cutout. The TSS-770-Z offers high-speed Ethernet and PoE/PoE+
connectivity, or, for deployments without access to Ethernet, can connect to the network over
Wi-Fi® communications via a local wireless access point (WAP).
lVersatile: Crestron offers a variety of mounting options for mounting the TSS-770-Z to drywall,
masonry, glass, mullions, and other surfaces. Optional light bar and hallway sign accessories are
available to increase the visibility of the room availability status.
lReliable: The TSS-770-Z is purpose-built for permanent installation and years of reliable 24/7
operation in a commercial environment. To ensure the latest features are available, the TSS-770-
Z checks nightly for app updates and loads the latest version automatically.
lSecure: The TSS-770-Z employs enterprise-grade networking with robust security features such
as 802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory® service
integration. These features protect your network against service interruptions and malicious
intrusions.
lManageable: The TSS-770-Z features cloud-based provisioning and management, which
streamlines configuring, monitoring, and updating the touch screen on the network. The TSS-770-
Z also supports SNMP, so it can be monitored by your IT administrator.
Status Indicator Options
The TSS-770-Z provides dual high-speed USB2.0 ports for connecting Crestron room scheduling
accessories (sold separately) to the touch screen that enhance an enterprise room scheduling solution.
NOTE: The touch screen supports the use of a single light bar or status indicator accessory only. The
RFID-USBcard reader accessory can be connected to the second USBport.
lThe included TSW-770-LB series light bar provides a 180° visual indication of a room’s availability
status, illuminating green if the room is available and red when reserved, with options for custom
color mixing and programming.3

Product Manual — Doc. 8745H TSS-70 Series • 13
lThe optional SSW-EL and SSC-EL series hallway signs feature a twosided acrylic sign face that
can be custom engraved with the room name or number. The SIW-100 offers a lower profile wall
mount status indicator.3
Bluetooth Beacon
The built-in Bluetooth® proximity detection beacon works with the Crestron Go App and Crestron App
to determine when a mobile device is in or near the same room as the beacon, and signals the mobile
app to automatically display the appropriate controls and information for the room.
Proximity Sensor and Brightness Controls
The TSS-770-Z provides abuilt-in proximity sensor that wakes the screen without requiring any user
interaction, and automatic brightness controls ensure optimal visibility under varying lighting conditions.
Power over Ethernet
PoE (Power over Ethernet) eliminates the need for a local power supply or any dedicated power wiring.
Crestron PoE switches (sold separately) offer a total networking solution with built-in PoE for multiple
touch screens. A PoE Injector (PWE-4803RU, sold separately) is also available to support a single touch
screen.
NOTE: Refer to the “Power” specifications for more details.
XiOCloud Service
The TSS-770-Z is compatible with the XiO Cloud® service, which remotely provisions, monitors, and
manages Crestron devices across an enterprise or an entire client base. Built on the Microsoft® Azure®
software platform and utilizing Microsoft's Azure IoT Hub technology, XiO Cloud enables installers and
IT managers to deploy and manage thousands of devices simultaneously. Unlike other virtual
machine-based cloud solutions, Azure services provide unlimited scalability. For more information, visit
www.crestron.com/xiocloud.
Wall Mount Options
Using the bracket provided, the TSS-770-Z is easily installed over a 2-gang or 3-gang US electrical box,
or a 2-gang European or UK electrical box. A security latch option is included to deter unauthorized
removal of the touch screen.
Additional wall mounting options are available using the optional TSW-UMB-70 universal mounting
bracket, TSW-UMB-70-PMK preconstruction mounting kit, and TSW-UMB-70-BBI back box (sold
separately).5
Optional Mounting Accessories
The TSS-770-Z supports numerous optional mounting accessories (sold separately) that allow the touch
screen to be installed in all kinds of installations:
lThe TSW-770-MSMK multisurface mount kit allows a TSS-770-Z touch screen to be mounted
directly to virtually any flat surface, which is ideal for mounting at a meeting space entrance for
room scheduling applications.
lThe TSW-770/1070-MUMKallows the touch screen to be attached to the mullion of an interior
glass wall, window, or partition.

14 • TSS-70 Series Product Manual — Doc. 8745H
lThe TSW-770/1070-RMB-1 andTSW-770/1070-RMB-2 retrofit mounting brackets allow for
retrofit installations in place of an older Crestron touch screen (APAD, CT-1000, LC-1000,
TPS-4L, or TPS-2000L) without having to tear out the old mounting hardware or patch the wall.
lThough not typical for most scheduling applications, the TSW-570/770-RMK-1 rack mount kit can
be used to mount the touch screen into a 19in. rack. When installed, the touch screen occupies
three rack spaces.
Notes:
1. Zoom determines the functionality and appearance of the Zoom Rooms® room scheduling application. Refer to the Zoom®
website for more information.
2. Additional subscriptions and/or licenses may be required. Refer to the Zoom website for details about the capabilities and
requirements of its scheduling application and services. The TSS-770-Z cannot be interfaced with a control system and
cannot be custom programmed for any other functionality. An internet connection is required.
3. The TSS-770-Z may be powered by either a PoEor PoE+power source when a light bar or hallway sign is connected. Refer
to the Accessories section for a list of all available options. Refer to each accessory’s spec sheet for further information.
4. Bluetooth technology is used solely for proximity detection and does not transmit or receive any control, multimedia, or
personal data. Crestron Bluetooth beacons are only visible to Bluetooth enabled devices that are specifically programmed
and configured to work with them.
5. The TSW-UMB-70 is also compatible with older TSW-UMB-PMK series preconstruction mounting kits and TSW-BBI series
back boxes, allowing the TSS-770-Z to be installed in place of a previous generation touch screen.

Product Manual — Doc. 8745H TSS-70 Series • 15
TSS-1070 Features
Crestron® TSS-1070 series touch screens are designed to enhance and simplify room scheduling across
an enterprise. TheTSS-1070 installs near a meeting room or huddle space to provide a clear indication
of its availability and scheduling while integrating seamlessly with a variety of popular scheduling
services.
The TSS-1070 is also sold as part of a kit that includes one TSW-1070-LBseries room availability light
bar, providing a complete room scheduling solution out of the box.
Key features include:
lTouch screen designed specifically for enterprise room scheduling applications
lDelivers a superior and cost-effective alternative to consumer tablet devices
lIntegrates directly with various room scheduling services
l10.1in. (257mm) widescreen capacitive touch screen display
lStandard U.S., U.K., and European electrical box installation with additional mounting options
available
lSingle wire Ethernet connection with PoEor PoE+ power
lWi-Fi® network connectivity
lDual USB2.0 ports for room availability accessories
lEnterprise grade security and authentication
lChoice of white or black smooth finish

16 • TSS-70 Series Product Manual — Doc. 8745H
Crestron Room Scheduling App
The native Crestron Scheduling app helps to maximize productivity and manage usage for meeting
spaces. If desired, the room can be reserved on the spot for an ad hoc meeting. ACEN-ODT-C-POE
occupancy sensor (sold separately)can also be paired to the touch screen, allowing for occupancy
status to be reported instantly to the scheduling app for no-shows and unscheduled room usage.1
Crestron room scheduling also offers three levels of customization—ranging from simply configuring
settings in the web user interface to modifying the application source code for a completely unique
appearance—depending on the needs of an enterprise.
Running the Crestron Scheduling App, the TSS-1070 integrates directly with Crestron Fusion® software,
Microsoft Exchange Server® software (for users of Outlook® software and Office365® software), the
Google Calendar™ calendaring app (including G Suite™ software), CollegeNET® 25Live® scheduling
software, or Ad Astra® software. IBM® Notes® software is also supported through a Crestron Fusion
on-premises server.
Third-Party Scheduling Apps
The TSS-1070 includes support various third-party scheduling applications. New providers are made
available via firmware updates. Whatever provider you choose, setup is as simple as connecting the
touch screen to the network and choosing an app from the web-based setup menu or built-in setup
screens. The selected app downloads from the cloud and installs on the touch screen without any
programming or control system required.1,2,3
Built for Enterprise Scheduling
The TSS-1070 is engineered to meet the demands of a corporate office, conference center, or education
environment. Its 10.1in. (257mm) capacitive display provides an intuitive user interface. The UI can be
customized and branded with your choice of background images and logos.1A smaller 7in. (178mm)
version (TSS-770 series) is also available.
lFunctional: The TSS-1070 provides a compact unit for scheduling applications that mounts over a
standard electrical box or cutout. The TSS-1070 offers high-speed Ethernet and PoE/PoE+
connectivity, or, for deployments without access to Ethernet, can connect to the network over
Wi-Fi® communications via a local wireless access point (WAP).
lVersatile: Crestron offers a variety of mounting options for mounting the TSS-1070 to drywall,
masonry, glass, mullions, and other surfaces. Optional light bar and hallway sign accessories are
available to increase the visibility of the room availability status.
lReliable: The TSS-1070 is purpose-built for permanent installation and years of reliable 24/7
operation in a commercial environment. To ensure the latest features are available, the TSS-1070
checks nightly for app updates and loads the latest version automatically.
lSecure: The TSS-1070 employs enterprise-grade networking with robust security features such as
802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory® service
integration. These features protect your network against service interruptions and malicious
intrusions.
lManageable: The TSS-1070 features cloud-based provisioning and management, which
streamlines configuring, monitoring, and updating the touch screen on the network. The TSS-1070
also supports SNMP, so it can be monitored by your IT administrator.
