Johnson Controls S1-TTSCC01 Quick start guide

TOUCH SCREEN
COMMUNICATING CONTROL
MODEL: S1-TTSCC01
TECHNICAL
GUIDE
TECHNICAL
GUIDE
Energy Saver
662812-UTG-D-1013
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
Johnson Controls, Unitary Products specializes in creating a
customized home comfort system tailored to the homeowner’s
needs with our broad selection of residential heating and cool-
ing products. The Communicating Control System is the ulti-
mate control center for all of your system components. When
you add a Touch Screen Communicating Control to a compati-
ble modulating variable-speed furnace or air handler, and a pre-
mium air-conditioner or heat pump, you'll enjoy longer heating
and cooling cycles at lower fan speeds for a more consistent
temperature throughout your home, better humidity control, as
well as a more energy-efficient comfort system.
WARRANTY
Standard 5-year limited parts warranty.
FEATURES & BENEFITS
• High definition color, touch screen user interface.
• Incorporates graphics and animation.
• 4-wire installation from each component in the system.
• Intuitive on-screen prompts for ease of installation and ser-
vice.
• Automatic system configuration – plug & play.
• System diagnostics for ease of troubleshooting.
• Detailed system forced operation.
• Complete integration of temperature control, humidity con-
trol, and ventilation in every season.
• Ventilation limits to ensure outside air is not introduced in
extreme hot or cold conditions - no extra heating or cooling
load
• Automatic Humidity Control – set it and forget it. No longer
requiring manual setting for humidification or dehumidifica-
tion – can be switched to be used in manual mode
• Programmable or non-programmable mode selection
- Advanced or normal programmable mode view selection
• 7-day programmability with 2, 3, or 4 periods per day
• Patented pending Quick Heat/Quick Cool functionality
• Day-at-a-glance programming for simplified ease of use
• Seasonal programming
• Easy timed-override schedule
• Simplified vacation schedules
• Programmable fan by period
• Fan speed adjustability - as low as 17% to 100% in 1% incre-
ments
• Energy saving opportunity
• Indoor Air Quality pop-up replacement reminders
• General maintenance reminder messaging
• Comfort Studio software to allow programming the Commu-
nicating Control with the use of a thumb drive
- Allows the dealer to display the company logo

662812-UTG-D-1013
2Johnson Controls Unitary Products
MODEL NUMBER NOMENCLATURE
S1 - T TS C C 01 A
PRODUCT DATA INFORMATION
Physical Characteristics
Dimensions:
See drawing
Appearance:
Plastic, white color, textured
Electrical Characteristics/Communication
Input Volts/Amps 24VAC:
Each device in the communicating system has a four-pin con-
nector labeled A+, R, C, B-. It is recommended that the follow-
ing color code be used when wiring each device:
A+ Green = Data A+
R Red = 24VAC (Hot)
C Black = 24VAC (Com)
B- White = Data B-
Environmental Requirements
Operating Temperature/Relative Humidity:
User interface and all sensors: 32F to 104F / 0C to 40C, 95%
RH non-condensing.
Storage Temperature/Relative Humidity:
User interface: -40F to 134F /-40C to 56.7C, 95% RH non-
condensing.
Wiring Requirements
Power supply:
Dedicated 24VAC, 40 va, 60 Hz, via indoor equipment A+, R, C,
B- Connector. Isolated transformer, field supplied.
Wiring material:
Standard thermostat wire 18 to 24 gauge.
Feature Specifications
• Temperature set point range: 40F to 90F / 4.4C to 32.2C
• Separate heat and cool setpoints
• Programming days: 7 day
• Programming periods:
2 Periods: Day, Away
3 Periods: Day, Away, Sleep
4 Periods: Awake, Away, Return, Sleep
• Non-Programmable
• Auto changeover (may be disabled)
• Programmable fan (installer selectable)
• Humidity Sensor Offsets
• Smart Recovery (in heating and cooling)
• Copy functions: Copy period, day and zone
• Permanent memory
• Humidity display and control
• Temperature sensor offsets (indoor and outdoor)
S1 Source 1
T Tag in a bag
TS Touch Screen
C Communicating
C Control
01 1st Generation
A Revision A
Compatible Communicating Products
Model Description YORK COLEMAN LUXAIRE
Air Conditioning CZE, CZF, CZH AC5, AC6, AC8 AL5, AL6, AL8
Heat Pumps YZB, YZE, YZF, YZH HC5, HC6, HC8 HL5, HL6, HL8
Gas Furnaces YPLC, YP9C, TM9V, TM8V CPLC, CP9C, TM9V, TM8V LPLC, LP9C, TM9V, TM8V
Air Handlers MV, AV*, AHV MV, AV*, AHV MV, AV*, AHV

662812-UTG-D-1013
Johnson Controls Unitary Products 3
PRODUCT DIMENSIONS
EQUIPMENT
5.50 .93
4.36
1.38
Equipment
PART NUMBER DESCRIPTION
S1-TTSCC01 Touch Screen Communicating Control
Repair Parts
PART NUMBER DESCRIPTION
S1-02815904000 Face Plate
S1-02815905000 Rear Housing
S1-02815906000 Mounting Plate
Optional Accessories
PART NUMBER DESCRIPTION
S1-02815909000 Hard Surface Mounting Plate and Decorative Backplate
S1-03102965000 USB Adapter
S1-33102953000 Non-Communicating Furnace and Air Handler Auxiliary Board
S1-02542694000 Wire Harness
S1-CVENTDEH01 ERV/HRV, Ventilation Control Damper and Whole Home Dehudmidifier Auxilliary Board
S1-02543570000 6’ Service Wire Harness

Subject to change without notice. Published in U.S.A. 662812-UTG-D-1013
Copyright © 2013 by Johnson Controls, Inc. All rights reserved. Supersedes: 662812-UTG-C-0212
York International Corp.
5005 York Drive
Norman, OK 73069
