Crestron V24R-C

V-Panel™

24” HD Touch Screen Displays

Operations Guide

This document was prepared and written by the Technical Documentation department at:

Regulatory Compliance

Federal Communications Commission (FCC) Compliance Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Industry Canada (IC) Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:

(1) This device may not cause harmful interference and (2) this device must accept any interference received,

including interference that may cause undesired operation.

CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance

could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna

Increase the separation between the equipment and receiver

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

Consult the dealer or an experienced radio/TV technician for help

As of the date of manufacture, the V24R-C has been tested and found to comply with specifications for CE

marking and standards per EMC and Radiocommunications Compliance Labelling.

The specific patents that cover Crestron products are listed at www.crestronpatents.com.

Crestron, the Crestron logo, Crestron Toolbox, Core 3, Core 3 UI, DigitalMedia, DigitalMedia 8G, DigitalMedia 8G+, DM, DM

8G+, SmartObjects, SmartScaling and V-Panel are either trademarks or registered trademarks of Crestron Electronics, Inc. in the

United States and/or other countries. Adobe, Acrobat and Flash are either trademarks or registered trademarks of Adobe Systems

Incorporated in the United States and/or other countries. Blu-ray Disc is a registered trademark of the Blu-ray Disc Association.

HDMI is either a trademark or registered trademark of HDMI Licensing LLC in the United States and/or other countries. Java is

a trademark or registered trademark of Oracle America, Inc. in the United States and/or other countries. Microsoft, Excel,

Internet Explorer, PowerPoint and Windows Media are either trademarks or registered trademarks of Microsoft Corporation in

the United States and/or other countries. Netflix is either a trademark or registered trademark of Netflix, Inc. in the United States

and/or other countries. YouTube is either a trademark or registered trademark of Google Inc. in the United States and/or other

countries. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and

names or their products. Crestron disclaims any proprietary interest in the marks and names of others.

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

Contents

V-Panel™ 24”HD Touch Screen Displays: V24R-C 1

Introduction ...............................................................................................................................1

Features and Functions................................................................................................1

Applications.................................................................................................................5

Specifications ..............................................................................................................6

Physical Description....................................................................................................9

Setup ........................................................................................................................................17

Configuring the V-Panel............................................................................................17

Hardware Hookup ..................................................................................................... 17

Recommended Cleaning............................................................................................17

Resources.................................................................................................................................18

Reference Documents................................................................................................18

Further Inquiries ........................................................................................................ 18

Future Updates .......................................................................................................... 18

Return and Warranty Policies ..................................................................................................19

Merchandise Returns / Repair Service ...................................................................... 19

Crestron Limited Warranty........................................................................................19

Operations Guide – DOC. 7327A Contents •i

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

V-Panel™ 24”HD

Touch Screen Displays: V24R-C

Introduction

The V-Panel™ V24R-C merges high definition Crestron®touch screen control and

HD video in one stylish and versatile 24” touch screen display. Its generous

WUXGA screen delivers stunning video performance even at extreme viewing

angles, providing an exceptional HDTV or computer display solution with integrated

touch screen functionality powered by the groundbreaking Core 3 UI™.

The V24R-C suits a broad range of residential and commercial applications,

excelling as a home controller and television display for a luxury kitchen or

bedroom, as a presentation control panel for a university lecture hall or as a video

control surface for corporate and government command centers. The choice of flush

in-wall, lectern or VESA mounting affords a clean, modern appearance for any

custom installation.

The V24R-C replaces separate touch screens, TV displays and computer monitors

with one gorgeous device. Whether mounted flush in a wall or on a wall bracket,

desk stand or articulating arm, its streamlined design allows it to be installed

virtually anywhere. Complete connectivity is provided through a simple, one wire

interface that allows for long wire runs while affording a clean appearance. Together

with a DGE-2 Digital Graphics Engine (sold separately), the V24R-C delivers a

powerful and elegant touch screen control solution featuring advanced Core 3 UI

touch screen graphics, dual window HD video, high performance H.264 streaming

video*, onboard multimedia and Web browsing and built-in annotation.

Features and Functions

• High definition 24” (610 mm) widescreen touch display

• 1920 x 1200 WUXGA display resolution

• High definition 24-bit graphics powered by Core 3™

• High performance S-PVA display technology

• Rich, accurate color reproduction

• High speed 6 ms response

• High contrast ratio, high aperture, high color gamut

• Ultra-wide 178 degree viewing angles

(Continued on following page)

* Support for H.264 video is a future feature of the DGE-2 only, which will be enabled through a future

firmware release. Current streaming video support using a DGE-1 or DGE-2 includes MJPEG and

Windows Media®Player.

Operations Guide – DOC. 7327A V-Panel™ 24” HD Touch Screen Displays: V24R-C •1

V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C

Features and Functions

(Continued)

• Fully HDCP compliant

• Digital Graphics Engine (DGE-2) installs up to 330 feet (~101 meters)

away1, 2

• Also works with DVPHD and DVPHD-GB Digital Video Processors1, 2, 3

• Single wire DigitalMedia 8G+™ connectivity

• Compatible with DigitalMedia switchers and transmitters

• Built-in HD scaler enables full screen video without a DGE

• USB keyboard/mouse port

• VESA 100 x 200 mounting option

• Stylish flush wall and lectern mount options

• Available in white or black

Beyond High Definition Video

With a display resolution of 1920 x 1200, the V24R-C provides substantial real

estate for all kinds of custom controls and icons with true feedback and real time

status display, full motion video windows and advanced navigation of digital media

servers, tuners and other devices. The 16:10 aspect ratio allows a full HD 1080p

video image to appear full size along with a custom control bar, providing immediate

access to AV and lighting controls, clock and weather widgets, scrolling text and

other objects while simultaneously watching TV or viewing a video camera.

The V24R-C employs high performance S-PVA display technology to deliver an

optimum HD experience with rich, accurate color reproduction, high speed response

and excellent black depth and contrast. Ultra-wide 178 degree horizontal and vertical

viewing angles ensure consistent picture quality on and off axis, alleviating the need

to be directly in front of the screen when reaching for an on-screen control or just

catching the morning news.

Digital Graphics Engine

For a typical control application using the V24R-C, a DGE-2 Digital Graphics

Engine (sold separately) is also required. The DGE-2 can be installed at the central

equipment location, dramatically reducing all the wiring from the head end AV

sources, switchers and the control network. A single CAT5e or DigitalMedia 8G™

cable connects the V24R-C to the DGE-2 over a wiring distance of up to 330 feet

(~101 meters), affording exceptional flexibility while minimizing wiring cost and

complexity.2

1. Item(s) sold separately.

2. The V24R-C features a DM 8G+™ type input. Connection to a DGE-2 or DVPHD requires a DM

8G+ transmitter or DM®switcher (all sold separately). For wiring cable up to 330 feet (~101 meters)

in length, use Crestron DM-CBL-8G DigitalMedia 8G cable or generic CAT5e (or better) UTP or

STP. Shielded cable and connectors are recommended to safeguard against unpredictable

environmental electrical noise, which may impact performance. Refer to the latest version of the

Crestron DigitalMedia Infrastructure Guide (Doc. 4556) for DM wiring guidelines and the latest

version of the Crestron DigitalMedia Design Guide (Doc. 4789) for DM system design guidelines.

Both are available from the Crestron Web site (www.crestron.com/dmresources). The V24R-C and

V24RL-C models each include (1) V-CBL-SC6 six foot (~1.8 meter) V-Cable and V24-IMCW-C

wall mount interface module. The V24R-WALL-C model includes no cable or interface module.

3. An Ethernet enabled control system and DM 8G+ interface are required for use with a DVPHD. Be

advised, DVPHD does not support streaming media, Web browser or other embedded PC

functionality.

2 •V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

Crestron touch screens have always offered the ultimate user experience. With Core

3™, they also deliver the ultimate value, enabling the creation of dynamically rich

user interfaces with incredible efficiency and unparalleled functionality. Using Core

3 UI, programmers can swiftly integrate fluid gesture driven controls, animated

feedback, metadata, embedded apps and full motion video for a deeply engaging and

ultra-intuitive touch screen experience.

Some Core 3 UI enhancements:

• Cool looking graphical buttons, sliders, knobs and gauges are intuitive and

fun to use.

• Kinetic effects enhance the feeling of realism with lists and toolbars that

scroll with momentum at the flick of a fingertip.

• Drag and drop objects snap into place offering an easy way to assign AV

sources to rooms.

• Desktop widgets personalize the touch screen with animated clocks,

calendars, weather, news and other information.

• Customizable themes allow a completely different look and feel for every

user, event or season.

• Fully developed SmartObjects™ enable sophisticated control over complex

devices with minimal programming.

• SmartScaling™ resizes objects perfectly and instantly for faster GUI

development, even across different sized touch screens.

Embedded PC Applications

In combination with a DGE-2 graphics engine, the V24R-C provides everything you

need to enjoy online music and videos, browse the Internet and even review digital

documents without a separate computer. With Microsoft®Internet Explorer®

embedded, you have full access to the entire World Wide Web including sites that

use Flash®or Java™. Windows Media®Player ensures broad compatibility for

playing most types of digital media. Adobe®Acrobat®Reader and Microsoft

PowerPoint®, Word and Excel®document viewers complete the online experience,

allowing you to download and view documents and presentations.

In addition, VNC Viewer support delivers enhanced cross-platform interaction with

computers over the network or Internet, allowing remote access and control of

desktop applications to unleash a host of possibilities for system integration and

multimedia presentation.

HD Streaming Video

High definition streaming video1capability makes it possible to view security

cameras and other video sources over the network. Native support for H.2641and

MJPEG formats allows the V24R-C and DGE-2 (sold separately) to display live

video images from Web cameras and servers such as the Crestron CEN-NVS200

Network Video Streamer (sold separately). Also, through the embedded Web

browser and media player, they support a wide variety of other streaming and

downloadable video formats, enabling access to all kinds of content from media

servers and Web sites like YouTube®and Netflix®2.

1. Support for H.264 video is a future feature of the DGE-2 only, which will be enabled through a future

firmware release. Current streaming video support using a DGE-1 or DGE-2 includes MJPEG and

Windows Media®Player.

2. Accessing Netflix content requires an active Netflix account. Refer to www.netflix.com for details.

Operations Guide – DOC. 7327A V-Panel™ 24” HD Touch Screen Displays: V24R-C •3

V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C

HDMI and Analog Video

In addition to handling streaming video, the V24R-C can simultaneously display up

to two fully scalable full motion video windows, each supporting HD or SD video

and high resolution computer signals from external sources. All connections are

made at the DGE-2 using conventional HDMI®,VGA and BNC type cables.

HDCP Support

Industry leading support for HDCP (High-bandwidth Digital Content Protection)

ensures seamless compatibility with content protected DVD, Blu-ray Disc®, digital

HDTV and multimedia computer sources.

Keyboard/Mouse Options

On-screen keyboard and mouse capabilities enable complete control of the

embedded Web browser and other applications. A USB port is also provided on the

V24R-C, allowing for the connection of a physical keyboard and mouse.

Real Time Annotation

Whether conducting a high level boardroom meeting, training seminar or watching

sports in your home theater, annotation helps put the fine point on any presentation.

Built-in annotation provides the ability to illustrate your thoughts on the fly, letting

you draw and write over high definition video and computer images and sketch out

ideas on a whiteboard screen, without leaving the podium or your favorite chair

while other viewers watch on the big screen.

Remote Annotation

Remote annotation capability allows multiple touch screen users to draw with their

fingertips over the same video image or whiteboard screen, enabling enhanced

interaction between several participants in a courtroom, classroom or council

chamber.

Presentation Output

Through an HDMI or DigitalMedia connection at the DGE-2, the V24R-C screen

image can be sent to additional display devices, allowing videos, PowerPoint

presentations, annotation and other on-screen media to be shared with a live

audience. Audio can also be enabled, using powered speakers or a larger audio

system connected to the DGE-2’s HDMI, DigitalMedia or analog audio outputs.

DigitalMedia

DigitalMedia (DM®) connectivity opens up new ways to configure a touch screen

control system. For instance, using a DM switcher such as the DM-MD8X8*,

multiple V24R-C touch screens can be connected to a single DGE-2, providing a

simple, cost effective way for multiple participants to view and control the same

graphical interface. DigitalMedia also provides a versatile means for distributing

touch screen content to additional displays and sound systems to serve a larger

audience.

* Item(s) sold separately.

4 •V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

The V24R-C features a DM 8G+™ type input, supporting the connection to a Digital

DGE-2 Digital Graphics Engine1via a DM 8G+ transmitter (DM-TX-201-C or

equivalent1). It can also connect directly to any DM switcher equipped with a DM

8G+ output. A single CAT5e or DigitalMedia 8G cable carries all video, audio,

Ethernet, USB, control and power signals up to 330 feet (~101 meters).2

DVPHD Integration

In addition to the DGE-2, V-Panel is also compatible with the award winning

DVPHD High Definition Digital Video Processor1, enabling the display of up to

eight simultaneous video windows along with HD touch screen graphics and

annotation. The DVPHD supports high definition video and computer signals from a

wide variety of digital and analog sources. Its DVI output connects to the V24R-C

via a DM 8G+ transmitter or DigitalMedia™ switcher.2, 3

Applications

The following diagram shows a V24R-C in a typical application.

V24R-C in a Typical Application

1. Item(s) sold separately.

2. The V24R-C features a DM 8G+™ type input. Connection to a DGE-2 or DVPHD requires a DM

8G+ transmitter or DM switcher (all sold separately). For wiring cable up to 330 feet (~101 meters) in

length, use Crestron DM-CBL-8G DigitalMedia 8G cable or generic CAT5e (or better) UTP or STP.

Shielded cable and connectors are recommended to safeguard against unpredictable environmental

electrical noise, which may impact performance. Refer to the latest version of the Crestron

DigitalMedia Infrastructure Guide (Doc. 4556) for DM wiring guidelines and the latest version of the

Crestron DigitalMedia Design Guide (Doc. 4789) for DM system design guidelines. The V24R-C and

V24RL-C models each include (1) V-CBL-SC6 six foot (~1.8 meter) V-Cable and V24-IMCW-C

wall mount interface module. The V24R-WALL-C model includes no cable or interface module.

3. An Ethernet enabled control system and DM 8G+ interface are required for use with a DVPHD. Be

advised, DVPHD does not support streaming media, Web browser or other embedded PC

functionality.

Operations Guide – DOC. 7327A V-Panel™ 24” HD Touch Screen Displays: V24R-C •5

V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C

Specifications

Specifications for the V24R-C are listed in the following table.

V24R-C Specifications

SPECIFICATION DETAILS

Touch Screen Display

Display Type TFT Active Matrix Color LCD

Size 24 inch (610 mm) diagonal

Aspect Ratio 16:10 WUXGA

Resolution 1920 x 1200 pixels

Brightness 300 nits

Contrast 1000:1

Color Depth 24-bit, 16.7 million colors

Illumination Backlit fluorescent

Viewing Angle ±89º horizontal, ±89º vertical

Touch Screen Resistive

Communications

DigitalMedia DM 8G+, HDCP, EDID, 100 Mbps Ethernet

USB Supports USB HID (Human Interface Device)

class devices

Video Refer to DGE-2 or DVPHD specifications for

additional information. They are available in the

latest version of the DGE-2 Digital Graphics

Engine Operations Guide (Doc. 6809) and the

DVPHD High Definition Digital Video Processor

Operations Guide (Doc. 6545), respectively.

Input Signal Type DM 8G+ (DigitalMedia over one CAT5e twisted

pair copper)

Input Resolutions 1920 x 1200 @ 60 Hz native or any other

progressive resolution up to

1920 x 1200 @ 60 Hz

Power Requirements

Power Pack 3.7 Amps @ 24 Volts DC

100-240 Volt AC, 50/60 Hz power pack

included1

Environmental

Temperature 41º to 113º F (5º to 45º C)

Humidity 10% to 90% RH (non-condensing)

Heat Dissipation 291 BTU/Hr

Enclosure

V24R-C Plastic case, VESA 100 x 200 mm mountable

V24R-WALL-C Includes metal rear enclosure with plastic front

bezel, additional mounting accessory required2 ,3

V24RL-C Includes metal rear enclosure with plastic front

bezel, fan cooled, additional mounting

accessory recommended2, 3

(Continued on following page)

6 •V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

V24R-C Specifications (Continued)

SPECIFICATION DETAILS

Dimensions

V24R-C

Height 15.52 in (395 mm)

Width 23.09 in (587 mm)

Depth 2.81 in (72 mm)

V24R-WALL-C

Height 16.79 in (427 mm)

Width 24.44 in (621 mm)

Depth 3.43 in (87 mm)

V24RL-C

Height 16.79 in (427 mm)

Width 24.44 in (621 mm)

Depth 3.43 in (87 mm)

Weight

V24R-C 21.5 lbs (9.8 kg)

V24R-WALL-C 24.0 lbs (10.9 kg)

V24RL-C 24.6 lbs (11.2 kg)

Available Models

V24R-C-B V-Panel 24” VESA Mount HD Touch Screen

Display, DM 8G+, Black

V24R-C-W V-Panel 24” VESA Mount HD Touch Screen

Display, DM 8G+, White

V24R-WALL-C-B V-Panel 24” Wall Mount HD Touch Screen

Display, DM 8G+, Black

V24R-WALL-C-W V-Panel 24” Wall Mount HD Touch Screen

Display, DM 8G+, White

V24RL-C-B V-Panel 24” Lectern Mount HD Touch Screen

Display, DM 8G+, Black

V24RL-C-W V-Panel 24” Lectern Mount HD Touch Screen

Display, DM 8G+, White

Included Accessories

Power Pack 3.7 Amps @ 24 Volts DC;

100-240 Volt AC, 50/60 Hz, Universal

V-CBL-S6C V-Cable Siamese Cable, DM-8G+, 6 feet (~1.8

meters) (included with V24R-C and V24RL-C

models only)

V24-IMCW-C V-Panel Interface Module for V-24R-C,

DM 8G+(included with V24R-C and V24RL-C

models only)

(Continued on following page)

Operations Guide – DOC. 7327A V-Panel™ 24” HD Touch Screen Displays: V24R-C •7

V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C

V24R-C Specifications (Continued)

SPECIFICATION DETAILS

Available Accessories

BB-V24 Pre-Construction Wall Mount Back Box for

V24R-WALL-C

BBI-V24 Wall Mount Back Box for V24R-WALL-C –

International Version

DGE-2 Digital Graphics Engine with HDMI and

DigitalMedia CAT Connectivity

(Requires DM-TX-201-C)

DM-8G-CONN DigitalMedia 8G Cable Connector

DM-8G-CRIMP Crimp Tool for DM-8G-CONN

DM-CBL-8G DigitalMedia 8G Cable

DM-TX-201-C DigitalMedia 8G+ Transmitter 201

PMK-V24 Pre-Construction Wall or Lectern Mounting

Kit for V24R-WALL-C and V24RL-C

V-CBL-SC V-Cable Siamese Cables, DM 8G+

V24-IMCW-C V-Panel Interface Module for V24R-C,

DM 8G+

1. V24R-C and V24RL-C models include power pack, which connects to the included V24-IMCW-C

interface module. V24R-WALL-C models include power pack, which connects directly to touch

screen.

2. Item(s) sold separately.

3. V24R-WALL-C model must be installed in an upright position with the screen perpendicular to the

floor. V24RL-C model may be mounted in an angled lectern or table top. Allow adequate space at the

top and bottom of the rear housing for proper ventilation.

8 •V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

Physical Description

This section provides information on the connections, controls and indicators

available on your V24R-C.

V24R-C Physical View (Shown in Black)

Operations Guide – DOC. 7327A V-Panel™ 24” HD Touch Screen Displays: V24R-C •9

V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C

V24RL-C Physical View (Shown in White – V24R-WALL-C is Physically Identical)

V24R-C Physical View (Rear Showing Connector Ports)

10 •V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

V24R-C Overall Dimensions (Front and Side Views)

23.09 in

(587 mm)

15.44 in

(392 mm)

15.52 in

(395 mm)

2.81 in

(72 mm)

2.77 in

(71 mm)

V24R-C Overall Dimensions (Rear View)

7.61 in

(194 mm)

3.94 in

(100 mm)

3.94 in

(100 mm)

5.75 in

(146 mm)

3.94 in

(100 mm)

NOTE: In the illustration above, the V24R-C is shown with the rear cover removed.

When making cable connections to the V24R-C, it will be necessary to remove the

cover by first removing the four screws holding it in place. Replace the cover when

connections have been made.

Operations Guide – DOC. 7327A V-Panel™ 24” HD Touch Screen Displays: V24R-C •11

V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C

V24R-WALL-C Overall Dimensions (Front View – Without Bezel)

24.14 in

(613 mm)

16.48 in

(419 mm)

12 •V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

V24R-WALL-C Overall Dimensions (Front, Side and Bottom Views – With Bezel)

24.44 in

(621 mm)

16.79 in

(427 mm)

15.78 in

(401 mm)

3.43 in

(87 mm)

23.49 in

(597 mm)

0.23 in

(6 mm)

3.32 in

(85 mm)

V24R-WALL-C (Rear View)

Operations Guide – DOC. 7327A V-Panel™ 24” HD Touch Screen Displays: V24R-C •13

V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C

V24RL-C Overall Dimensions (Front, Side and Bottom Views)

24.44 in

(621 mm)

16.79 in

(427 mm)

15.78 in

(401 mm)

3.43 in

(87 mm)

23.49 in

(597 mm)

0.23 in

(6 mm)

3.32 in

(85 mm)

V24RL-C (Rear View)

14 •V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A

Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays

V24R-C Connectors (V24R-C Shown)

Connectors, Controls & Indicators

# CONNECTORS1,

CONTROLS &

INDICATORS

DESCRIPTION

1 Hard Key

(1) Programmable push button, illuminates

green to indicate power is on, also reboots

the DGE if held for five seconds

2 24VDC 3.7A

(1) 2-pin 5 mm detachable terminal block,

24 Volt DC power input2

(power pack included)

3 DM 8G IN

Green

LED

Amber

LED

Pin 8 Pin 1

(1) 8-pin RJ-45 female, shielded DM 8G+

input2, 3, 4, 5, 6;

Green LED indicates DM link status,

Solid amber LED indicates HDCP video,

Blinking amber LED indicates non-HDCP

video

4 USB HID

(1) USB Type A female;

USB 1.1 host port for connection of a

mouse/keyboard or other HID (Human

Interface Device) compliant device

5 Unused This port is not used

1. An interface connector for the 24 VDC port is provided with the unit.

2. On V24R-C and V24RL-C models, connects to V24-IMCW-C interface module via included

V-CBL-SC cable.

3. On V24R-WALL-C model, connects to DM 8G+ output of a DM transmitter or switcher via CAT5e

or Crestron CM-CBL-8G.

4. The V24R-C features a DM 8G+™ type input. Connection to a DGE-2 or DVPHD requires a DM
