Crestron CNXRMIRD User manual

Crestron CNXRMIRD
Infrared Detector
Operations Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON

Crestron CNXRMIRD IR Detector
Contents
Infrared Detector: CNXRMIRD ....................................... 1
Description ........................................................................ 1
Functional Description ............................................. 1
Physical Description................................................. 1
Setup.................................................................................. 2
Leading Specifications ...................................................... 4
Problem Solving................................................................ 5
Troubleshooting ....................................................... 5
Further Inquiries....................................................... 6
Future Updates ......................................................... 6
Return and Warranty Policies............................................ 7
Merchandise Returns / Repair Service ..................... 7
CRESTRON Limited Warranty ............................... 7
Operations Guide - DOC. 8165 Contents •i

Crestron CNXRMIRD IR Detector
Infrared Detector: CNXRMIRD
Description
Functional Description
The Crestron Infrared (IR) Detector (CNXRMIRD) is used by Crestron's
CNXRMC (Room Solution Box) and CNXRMCLV (Room Solution Box
with Local Video) to detect fixed low frequency (38KHz) type IR
formats generated by typical hand-held remote devices. Commands
received by the detector can either be processed locally to control video
or audio, or sent to a host control system.
NOTE: Any universal remote transmitting RC5 code (and some Sharp
codes) can communicate with the CNXRMIRD. The Philips Pronto
contains built-in RC5 commands for out-of-box use. If you use the
Philips Pronto, select RC5 code communication. For more information
regarding code verification and mapping a universal remote, refer to the
latest versions of the CNXRMC (Doc. 8162) and CNXRMCLV (Doc.
8161) Operations Guides. Creston IR remotes require the CNIRGWA IR
gateway for communication and are not supported by the CNXRMIRD
detector.
Physical Description
The IR Detector contains an IR receiver, which is connected to a mini
phone jack by a six-foot cable. The IR receiver is housed in a black
enclosure. The IR receiver window is located on the front of the detector.
NOTE: The receiver window must be kept away from obstructions,
direct sunlight and high frequency fluorescent light while it is receiving
IR signals.
Operations Guide - DOC. 8165 Infrared Detector: CNXRMIRD •1

IR Detector Crestron CNXRMIRD
CNXRMIRD, Physical Views
6 ft
(1.89 m)
1.00 in
(2.51 cm)
1.00 in
(2.51 cm)
1.00 in
(2.51 cm)
Setup
Plug the mini phone jack into the IR IN port on the CNXRMC or
CNXRMCLV, and place the IR receiver in a convenient location free of
obstructions to receive IR signals. Secure it with the supplied dual lock
fasteners.
CNXRMC, IR IN Port
G
SENS
CONNECT TO
CNXRMIRD
C
RS-232 IR
TCSER ELENOR
IN
ORTSCINKCOR.CNIIEL
IR OUT
ABCD
N,H 74670.J.ASU
NETPWR SETUP
GY24 Z
NET
2 •Infrared Detector: CNXRMIRD Operations Guide - DOC. 8165

Crestron CNXRMIRD IR Detector
Example
The following is an example of a typical CNXRMIRD connection as part
of a Crestron control system.
CNXRMIRD Connection Example
LOCAL SPEAKERS
COMPOSITE
IR/RS-232 CONTROL
COMPONENT
UNIVERSAL
REMOTE
IR
CLOSURE
S-VIDEO
CNXRMCS
120 VAC
TV or
VIDEO
PROJECTOR
CNXRMCLV LOCAL
SOURCES
IR/RS-232
CRESTRON CONTROL SYSTEM
(INCLUDING WIRED AND WIRELESS
TOUCHPANELS AS USER INTERFACES)
SOURCE
DEVICES
CRESNET
(CAT 5)
VIDEO
CRESNET
CRESNET
AUDIO
CNX-PVID
COMPONENT
S-VIDEO
COMPOSITE
CNX-BIPAD8
or CNX-PAD8
CNAMPX
R1L1 R8L8
R1L1 R8L8
ROOM
HEADEND
A
U
D
I
O
CNX-PBAR4
AUDIO
(CAT 5)
FOR CNX-PAD8 ONLY
FOR CNX-BIPAD8 ONLY
COMPONENT
S-VIDEO
COMPOSITE
TO
CNXRMCLV
COMPONENT
S-VIDEO
COMPOSITE
FROM
LOCAL
SOURCES
SPEAKER
AUDIO
LEVEL
CNXRMIRD
Operations Guide - DOC. 8165 Infrared Detector: CNXRMIRD •3

IR Detector Crestron CNXRMIRD
Leading Specifications
The table below provides a summary of leading specifications for the
CNXRMIRD.
Leading Specifications of the CNXRMIRD
SPECIFICATIONS DESCRIPTION
Dimensions and
Weight
IR Detector Housing
Height: 1.00 in (2.54 cm)
Width: 1.00 in (2.54 cm)
Depth: 1.00 in (2.54 cm)
Weight: 0.15 lb (0.055 kg)
Cable and Mini Jack Length:
6.00 ft (1.83 m)*
Detection Range Depends on distance and
angle from detector,
obstructions, IR interference
and IR remote signal strength.
Typically, the detection range
is up to 50 ft./line of sight.
* Can be extended up to 500 ft.
As of the date of manufacture, the CNXRMIRD has been tested and
found to comply with specifications for CE marking.
NOTE: This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
4 •Infrared Detector: CNXRMIRD Operations Guide - DOC. 8165

Crestron CNXRMIRD IR Detector
Problem Solving
Troubleshooting
The following table provides corrective action for possible trouble
situations. If further assistance is required, please contact a Crestron
customer service representative.
CNXRMIRD Troubleshooting
TROUBLE POSSIBLE CAUSE(S) CORRECTIVE
ACTION
No response from
commands sent to
CNXRMC or
CNXRMCLV.
Universal remote is not
communicating with the
CNXRMC or
CNXRMCLV.
Verify that
CNXRMIRD is
connected to IR IN
port on the CNXRMC
or CNXRMCLV.
Remove any
obstructions between
CNXRMIRD and
CNXRMC or
CNXRMCLV.
Universal remote is not
emitting a format
compatible with the
CNXRMC/CNXRMCLV.
Refer to the latest
versions of the
CNXRMC (Doc.
8162) and
CNXRMCLV (Doc.
8161) Operations
Guides.
Operations Guide - DOC. 8165 Infrared Detector: CNXRMIRD •5

IR Detector Crestron CNXRMIRD
Further Inquiries
If after reviewing this Operations Guide, you cannot locate specific
information or have questions, please take advantage of Crestron's award
winning customer service team by calling:
• In the US and Canada, call Crestron’s corporate headquarters at
1-888-CRESTRON [1-888-273-7876].
• In Europe, call Crestron International at [phone].
• In Asia, call Crestron Asia at [phone].
• In Latin America, call Crestron Latin America at
[phone].
• In Australia and New Zealand, call Creston Control Solutions at
[phone].
Future Updates
As Crestron improves functions, adds new features, and extends the
capabilities of the CNXRMIRD, additional information may be made
available as manual updates. These updates are solely electronic and
serve as intermediary supplements prior to the release of a complete
technical documentation revision.
Check the Crestron website (www.crestron.com) periodically for manual
update availability and its relevance. Updates are available from the
Download | Product Manuals section and are identified as an
“Addendum” in the Download column.
6 •Infrared Detector: CNXRMIRD Operations Guide - DOC. 8165
