CRL ASR1 User manual

C.R. LAURENCE CO., INC.
Visit us at crlaurence.com for international toll free information
Tools Needed
(Not Included)
Parts Included
AVDB3082_12/12
Cat. No. ASR1 Adjustable Shower Rod Mounting Instructions
1
Screw Driver
A) 2-Wall Mounting Brac ets
C) 4-Drywall Anchors D) 4-Mounting Screws
E) 2-Sets Fasteners to Attach Rod to Brac ets
Pencil Measuring Tape Electric Drill
B) 1-Two-Pieced Curved Rod
F) 1-Allen Wrench

C.R. LAURENCE CO., INC.
Visit us at crlaurence.com for international toll free information
ASR1 Mounting Instructions
2
1. 2. 3.
4. 5. 6.
7. 8. 9.
With a pencil and tape measure, mark
the wall above the center o tub edge
at the desired height or installation o
the curved Shower Rod. Be sure to
make each side at the same height.
With a pencil, mark the desired spots
where the holes will be made to attach
the brackets to mount on the wall.
Drill holes in the marked location or
the mounting screw (D) and insert the
drywall anchor (C). Note: I the screws
will be going directly into the wall
studs, wall anchors will not be
necessary
Fasten brackets to the wall with the
mounting screws provided.
With the bracket secured to the wall,
the installation o the Shower Rod is
next.
You will need to use two screws on
each side to lock the Shower Rod to
the bracket.
Insert one Shower Rod tube into the
mounting bracket and tighten it by
screwing in two screws through the
holes on each side. Repeat this step
or the other bracket once the bracket
has been mounted into the wall.
Slide the second Shower Rod tube
onto the irst tube that has already
been mounted to the wall bracket. (as
in drawing #7).
Secure the second side o the Shower
Rod tube in place into the other wall
mounted bracket.
