Cromtech TFT150DE User manual

CROMTECH DIESEL PUMPS
OPERATION MANUAL
DIESEL WATER PUMPS

Pg. 2
Thank you for purchasing a Cromtech Diesel Pump.
This manual provides understanding of the operaon
and maintenance of your pump. Please read this
manual carefully before operang.
For any quesons regarding operaon or maintenance,
please consult your local service agent. Find your local
service agent at www.crommelins.com.au.
IMPORTANT ICONS
Important informaon is disnguished by the nocaons
below. The Safety Alarm Symbol ( !) alerts you to
potenal hazards. Please obey all safety informaon in the
symbol to avoid any possible injury or even death.
!DANGER: - Indicates a hazardous situaon which, if
not strictly complied with, will result in substanal property
damage, serious injury or DEATH.
!WARNING: Indicates a hazardous situaon which, if
not strictly complied with, may result in property damage,
!CAUTION: Indicates a hazardous situaon which, if
not strictly complied with, could result in property damage
or injury.
!NOTE: Indicates important informaon to simplify
operaon and understanding.
!WARNING: PLEASE READ AND UNDERSTAND THIS
MANUAL BEFORE OPERATING THE PUMP.
!NOTE: We connually seek advancements in product
design and quality. Therefore, there may be minor
discrepancies in actual machine and the printed manual.

INDEX:
Warranty ..................................................................... 4
Safety Warnings .......................................................... 5
Diesel Twin Impeller Pump Features (Model TFT150DE) 7
Diesel Clear Water Pump Features (Model CTD301E) ... 8
Pump Specicaons .................................................... 9
Features ..................................................................... 9
Operang Checklist ...................................................... 10
Operang area ........................................................... 10
Operang condion ................................................... 10
Check engine oil ......................................................... 11
Check fuel levels ........................................................ 12
Check air cleaner element ......................................... 13
Low oil warning system/stop device ............................ 13
Break-in Operaon ...................................................... 14
Priming the Pump ....................................................... 14
Starng the Pump ....................................................... 14
Electric start .............................................................. 14
Recoil start ................................................................ 14
Running the Pump ...................................................... 15
During Operaon ........................................................ 16
Stopping the Pump ..................................................... 16
General Maintenance ................................................. 16
Maintenance schedule .............................................. 17
Pump maintenance ................................................... 17
Fuel lter .................................................................. 17
Baery uid / Charging baery ................................ 17
Storage and Transport ................................................ 18
Storage ..................................................................... 18
Long term storage .................................................... 18
Starng posion ....................................................... 18
Troubleshoong ......................................................... 19
Pg. 3

WARRANTY
CROMTECH™and CROMMELINS™ are a registered trademark of The
Crommelin Group. Crommelins warrants their goods against defects in
materials and workmanship under normal use and service.
The Crommelin Group warranty does not cover fair wear commensurate
with the age of the product, any damage caused by accident, abuse, misuse,
neglect or failure to observe proper operang instrucons or proper
machinery maintenance as described in the instrucon manual.
It is the owner’s responsibility to regularly maintain a product in accordance
with the owner’s manual and only use the equipment for its designed
purpose.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entled to a replacement or refund for
a major failure and for compensaon for any other reasonably foreseeable
loss or damage. You are also entled to have goods repaired or replaced if
the goods fail to be of acceptable quality and the failure does not amount to
a major failure.
CONSUMER ADVICE
Any claim under these warranes must be made in the warranty period
from the date of purchase of the product.
There are over 185 naonal authorised service/repair agents available, visit
www.crommelins.com.au for their details and locaons.
To make a claim under the warranty, you must return the product (with
proof of purchase) to the closest warranty agent or to the place of purchase.
Where a failure does not amount to a major failure, Crommelins Machinery
is entled to choose between providing you with a repair, replacement or
refund. To obtain compensaon, you would need to provide documentary
evidence of the loss or damage suered, and documentary evidence that
such loss or damage was a reasonably foreseeable consequence of a failure
by The Crommelins Group to comply with a consumer guarantee under the
Australian Consumer Law.
Crommelins Operaons Pty Ltd trading as The Crommelin Group,
Crommelins Australia and Crommelins Machinery
THE CROMMELIN GROUP:
Ph: [phone] Fax: [phone]
recep[e-mail]
www.crommelins.com.au
PO Box 352, BENTLEY WA 6982
ABN 11 008 889 656
Pg. 4

SAFETY WARNINGS
! WARNING: DO NOT Operate this pump unl you have
read ALL safety, operaon, and maintenance instrucons
listed in this manual.
• Failure to follow the instrucons may result in property
damage, INJURY or DEATH.
• The warnings and precauons discussed in this manual
cannot cover all possible condions and situaons that
may occur. It must be understood by the operator that
common sense and cauon are factors which cannot
be built into this product, but must be supplied by the
operator.
! WARNING: Modicaons to any part of the pump is
not allowed and may void your warranty.
! WARNING: This pump is intended for is designed
for pumping clean water for the agriculture, forestry or
garden area. This pump is not designed for a permanent
applicaon.
! WARNING: Before each use, check for loose or
damaged parts, signs of oil or fuel leaks, and any other
condion that may aect proper operaon. Repair or
replace all damaged or defecve parts immediately.
• Locate all operang controls and safety labels.
• Operate only on level surfaces.
• DO NOT expose pump to excessive dust, or dirt.
• Keep all safety guards in place and in proper working
order at all mes.
• DO NOT allow any material to block the cooling slots.
• DO NOT allow children or untrained persons to operate
the pump.
• DO NOT run the pump unaended. Turn o the pump
before leaving the area.
!DANGER: FIRE OR EXPLOSION - Diesel fuel is ammable
and explosive.
• Fire or explosion can cause severe burns or death.
• Keep ammable items away while handling fuel.
• Fill fuel tank outdoors and in a well-venlated area.
Ensure the pump is stopped before lling.
• Always wipe o spilled fuel and wait unl the fuel has
dried before starting the pump.
• DO NOT operate pump with known leaks in fuel system.
• Use proper fuel storage and handling procedures. DO
NOT store fuel or other ammable materials nearby.
Pg. 5

• Empty the fuel tank before storing or transporng the
pump.
• Keep re exnguisher handy and be prepared if a re
starts.
!DANGER: TOXIC FUMES - The exhaust of the engine
contains carbon monoxide, an odorless, colorless, poison
gas. Using engine indoors CAN KILL YOU!
• NEVER use pump inside any building or any kind of
enclosure, EVEN IF doors and windows are open.
• Place the pump in a well-venlated area and consider
wind and air currents when posioning the pump
!DANGER: MOVING PARTS - Moving parts can cause
severe injury. Keep hands and feet away.
• DO NOT operate with covers, shrouds, or guards
removed.
• DO NOT wear loose-ng clothing, dangling drawstrings
or items that could become caught. Tie up long hair and
remove jewelry.
• NEVER place ngers, hands, or body near the engine
when it is running.
!DANGER: KICKBACK - Rapid retracon of the starter
cord will pull hand and arm towards the engine faster than
you can let go.
• Unintenonal startup could result in an injury.
!WARNING: HOT SURFACE - The running pump produces
heat. Severe burns can occur on contact.
• DO NOT touch pump while operang or just aer
stopping. Avoid contact with hot exhaust gases.
• Maintain at least one metre of clearance on all sides to
ensure adequate cooling.
• Combusble material can catch re on contact. Maintain
at least one metre of clearance from combusble
materials.
!WARNING: ACID (For types equipped with baery) - Be
careful when using any baery.
• Keep away from open ame, heat or spark.
• Baery will exhaust hydrogen while charging. Only
charge a baery in a well venlated place.
• Avoid spilled baery acid. If contact with skin is made,
wash immediately with clean water.
Pg. 6

Pg. 7
DIESEL TWIN IMPELLER FEATURES
❶ Fuel cap
❷ Fuel tank
❸ Decompression Lever
❹ Muer guard
❺ Frame
❻ Priming cap
❼ 1.5inch Outlet
❽ 1 inch Outlet/s
❾ 1.5inch Inlet
❿ Engine mount
⓫ Oil drain
⓬ Oil dipsck
⓭ Engine throle control
⓮ Recoil start
⓯ Recoil handle
⓰ Fuel connecon nut
⓱ Electric Key Start
⓲ Baery mount locaon/s
⓳ Air cleaner element
Model TFT150DE

DIESEL CLEAR WATER PUMP FEATURES
Pg. 8
❶ Fuel cap
❷ Fuel gauge
❸ Fuel tank
❹ Frame
❺ Air cleaner
❻ Muer
❼ Recoil start
❽ Engine mount
❾ Starter motor (Electric start model)
❿ Oil dipsck
⓫ Pump casing
⓬ 3 inch outlet
⓭ 3 inch inlet
⓮ Fuel tap
⓯ Electric start key
⓰ Baery mount locaon/s
Model CTD301E

Pg. 9
PUMP SPECIFICATIONS
Model TFT150DE CTD301E
Max. Water Flow (L/min) 250L/min 833L/min
Max. Total Head (m) 75m 25m
Max. Sucon Depth 8m 8m
Engine
5.3HP Cromtech 178
Max. Power 4.0kW (296cc) 4.0kW (296cc)
Max. Speed (rpm) 3600rpm 3600rpm
Decibels (at 7m) 86db 86db
Fuel Tank 3.5L 12.0L
Oil Capacity 1.1L 1.1L
Outlet 1.5 inch, 1 inch
outlet (2x)
3 inch outlet
Inlet 1.5 inch 3 inch inlet
Weight (kg) 45kg 49kg
Dimensions (LxWxH) 560x460x565mm 560x475x690mm
FEATURES
• Steel frame with rubber engine mount
• Mechanical seal (ceramic carbon)
• Diesel powered
• Electric start
• 1 Year Cromtech warranty
5.3HP Cromtech 178

OPERATING CHECKLIST
1. OPERATING AREA - This pump is for outdoor use.
• Only use OUTSIDE and place the pump in a
well-venlated area.
• Only operate the pump on a at, level surface and in
a clean, dry operang environment.
• Allow one metre clearance on all side of the pump
while operang outdoors.
• Pumps used for construcon sites may be subject to
addional rules and regulaons.
• When operang wear ear protecon
! DANGER: TOXIC FUMES - The exhaust of the
generang set contains carbon monoxide, an odorless,
colourless, poison gas. Using engine indoors CAN KILL
YOU.
• NEVER use inside any building or any kind of
enclosure, EVEN IF doors and windows are open.
• Place the pump in a well-venlated area and
carefully consider wind and air currents when
posioning pump.
2. OPERATING CONDITION - Check for loose or damaged
parts, signs of oil or fuel leaks, and any other condion
that may aect proper operaon. Repair or replace all
damaged or defecve parts immediately.
• Remove any excessive dirt or debris, especially
around the muer and recoil starter.
• DO NOT move or p the pump during operaon.
Use pump only for intended uses. If you have quesons
about intended use, ask your local dealer.
! DANGER: Failing to correct problem(s) before
operaon could result in property damage, serious
injury or DEATH.
Pg. 10

3. CHECK ENGINE OIL
! WARNING: This engine is not lled with oil. Any
aempt to crank or start the engine before it has
been properly lled (with the recommended type and
amount of oil) may result in engine damage and void
your warranty.
1. ENGINE OIL - Place the pump on a level surface with
engine stopped.
• Remove the dipsck and wipe it clean.
• Reinstall dipsck into tube; rest on oil ll neck, DO
NOT thread cap into tube.
2. Remove the dipsck again and check oil level. Level
should be at top of indicator on dipsck.
3. If lower, ll to the upper limit (marked with “H”) of
the dipsck with the recommended oil. Reinsert and
fully ghten the dipsck.
! WARNING: Oil is a major factor aecng
performance and service life of an engine. Use SAE30
oil.
! CAUTION: LEVEL GROUND - Operate only on level
surface. The engine is equipped with a low oil sensor
(applicable types) that will automacally stop the
engine when the oil level falls below the safe limit. To
avoid the inconvenience of an unexpected shutdown,
ll to the upper limit and check the oil level regularly.
Pg. 11

4. CHECK FUEL LEVELS
! CAUTION: Only diesel fuel can be used. The fuel
must be ltered. Fuel should be free of water or dust as
this can result in problems with the fuel injecon pump
and nozzle.
FILLING THE FUEL TANK - With the engine stopped,
check the fuel level gauge. Rell the fuel tank if
necessary.
• Use clean, fresh, regular diesel fuel only.
• DO NOT mix with other fuels.
• Be sure not to ll above the upper limit mark,
always ll to the level indicator, or ll to 25mm
below full level (to allow room for fuel expansion in
hot temperatures).
! DANGER: FIRE OR EXPLOSION - Diesel is ammable
and explosive. A re or explosion can cause severe
burns or death.
• Keep ammable items away while handling
gasoline.
• Fill fuel tank outdoors and in a well-venlated area
with the engine stopped.
• Always wipe o spilled fuel and wait unl the fuel
has dried before starng the engine.
• DO NOT operate the engine with known leaks in
the fuel system.
• Use proper fuel storage and handling procedures.
DO NOT store fuel or other ammable materials
nearby.
• Empty the fuel tank before storing or transporng
this engine.
• Keep re exnguisher handy and be prepared if a
re starts.
! CAUTION: To insure easy starng, do not use fuel
le over from the previous season.
5. CHECK AIR CLEANER ELEMENT
! WARNING: Never run the pump without the
air cleaner element as damage to the engine may
occur.
• The air cleaner must be changed when the output
of engine decreases or if the exhaust colour looks
darker than normal. See page 19.
Pg. 12

LOW OIL WARNING SYSTEM/STOP DEVICE
! NOTE: The device works automacally to stop the
engine when the oil pressure falls below the regulatory
level to prevent engine seizure
• The oil temperature will rise too high if the engine is
operated with insucient oil.
• Too much oil is dangerous as it may cause sudden
excessive engine revs.
• Be sure to check oil is at opmum specied levels.
BREAK-IN OPERATION
! WARNING: While your pump is sll new, over working
the pump may shorten the life of the engine. Follow the
break-in procedures during the rst 20-30 hours.
1. Avoid over working the pump with heavy loads during
break-in period
2. Change engine oil regularly (Every 20 hours or one
month aer inial use, and every 3 months or 100 hours
thereaer).
PRIMING THE PUMP
! CAUTION: Operang a pump with no water will
damage the seals, which may void the warranty.
• PRIME THE PUMP - Fill the pump with water before
starng it. Remove the water inlet cap and ll pump
head with water.
Pg. 13

PRE-START INSTRUCTIONS
! NOTE: When startng the pump for the frst tme,
restarng the engine aer it stopped due to fuel shortage
or starng the engine aer fuel lter cleaning. Follow these
steps.
• Always check that there is no air trapped in the fuel
line. Trapped air needs to be cleared before starng.
1. To clear air in the fuel line,
loosen the fuel connecon
nut that is between the
injecng pump and fuel
line (See page 7).
2. Ensure the ignion is in the
‘OFF’ posion.
3. Bleed the fuel line by pulling the recoil starter slowly
to start the fuel pumping acon.
4. Connue unl there is no air bubbles coming out
and the fuel is owing freely.
5. Tighten fuel connecon nut
STARTING THE PUMP
! WARNING: Be sure to turn on the main switch before
starng the pump.
ELECTRIC STARTING
! NOTE: Always keep the starng key turned to ‘ON’
while the engine is running.
1. The preparaon for starng the engine is the same
as the recoil start
2. Open the fuel tap to the ‘ON’ posion.
3. Set the engine speed lever to ‘RUN’ posion.
Throle speed
control
Pg. 14

4. Push down the decompression lever (It will return
automacally when the recoil starter is pulled)
5. Turn the starng key clockwise to ‘START’ posion
As soon as it starts, release your hand and let the key
automacally return to its inial posion. If the pump
doesn’t start aer 10 seconds, please wait at least 15
seconds before aempng again.
RECOIL STARTING (MANUAL START)
! NOTE: Rapid retracon of the starter cord will pull
hand and arm towards the engine faster than you can
let go.
• Unintenonal startup could result in an injury.
• Never pull out the recoil start when the diesel
engine is running, as damage may occur.
1. Open the fuel tap to the ‘ON’ posion
2. Set the throle speed control to ‘START’ posion.
3. Set ignion key switch to ‘ON’ posion
4. Pull out the recoil start handle and prepare to start
the pump.
5. Pull the rope to the point where resistance is felt.
Return the recoil handle to the inial posion
6. Push down the decompression lever (It will return
automacally when the recoil starter is pulled)
7. Grip the recoil handle rmly and pull quickly and
briskly (Two hand might be needed).
8. Return the recoil gently back to prevent damaging
the starter. Do not allow the handle grip to snap
back.
RUNNING THE PUMP
! CAUTION: Operang a pump with no water will
damage the seals, which may void the warranty.
• Once the pump is started you can adjust the water ow
with the throle speed control.
• The engine will need to be warmed for about 3 minutes
! NOTE: LOW OIL WARNING SYSTEM - The pump is ed
with a low oil warning system and will automacally stop in
case of low oil pressure or lubricaon shortage.
• If started again, it will immediately stop. Check the oil
level, ll to correct level and try again.
Pg. 15

• If insucient oil, the oil temperature will rise too high
and damage may occur.
• Too much oil is dangerous as it may cause sudden
excessive engine rpm.
• Be sure to check oil is at opmum specied levels.
DURING OPERATION
! WARNING: Check for unusual sounds or vibraons
during operaon.
• Check for misring or the engine running rough
• If you noce any above problems, stop the engine and
consult you local service agent.
STOPPING THE PUMP
1. Turn the throle lever to low speed and run the engine
for 1-2 minutes more.
2. ELECTRIC START - Switch the ignion switch to the ‘OFF’
posion. Turn the fuel tap to the ‘OFF’ posion.
3. RECOIL START - Turn the fuel tap to the ‘OFF’ posion.
! CAUTION: If the engine connues to run even aer the
speed lever is moved to the ‘STOP’ posion, turn the fuel
tap to the ‘OFF’ posion to stop the engine. DO NOT stop
the engine with the decompression lever.
GENERAL MAINTENANCE
! NOTE: It’s the operator’s responsibility to complete all
scheduled maintenance in a mely manner. Correct any
issues before operang the pump. Always follow
the inspecon and maintenance schedule in this manual.
• Before servicing the pump, stop the pump, disconnect
all hoses and allow the pump to cool.
MAINTENANCE SCHEDULE - Service your pump more
frequently when operang in adverse condions.
• Contact your local service agent for parts or engine
maintenance needs.
• See maintenance schedule on next page
Pg. 16

PUMP MAINTENANCE
! WARNING: DO NOT modify the pump in any way.
CHECK/CHANGE AIR CLEANER ELEMENT
! WARNING: Never run the pump without the air
cleaner element as damage to the engine may occur.
• The air cleaner must be changed when the output of
engine decreases or if the exhaust colour looks darker
than normal.
1. Loosen the wing nut, detach the cover and remove
the air cleaner
element.
2. Wash in warm
water. DO NOT
wash with
detergent.
3. Squeeze
thoroughly and dry
with a clean cloth.
4. Saturate in clean engine oil. Squeeze in a clean,
absorbent cloth to remove all excessive oil.
5. Place element back in the air cleaner and reaach
the cover. Tighten
wing nut.
Pg. 17

CHECK/CHANGE FUEL FILTER
! WARNING: Change lter regularly to insure maximum
engine output.
• CLEAN FILTER - Every 6 months or 300 hours
• REPLACE FILTER - Every year or 1000 hours
CHECK BATTERY FLUID / CHARGING BATTERY
! NOTE: Before starng, check for physical damage to
baery and also electrolyte levels. Replenish with dislled
water to the upper mark.
• The diesel engine uses a 12V baery. The baery
uid will be lost through connuous charging and
discharging.
• CHECK BATTERY FLUID LEVELS - Check monthly. If
baery is damaged or not holding charge. Replace
baery.
STORAGE AND TRANSPORT
! DANGER: FIRE OR EXPLOSION - Diesel fuel is ammable
and explosive. Empty the fuel tank and shut o fuel tap
before storing or transportng this pump
1. STORAGE - The pump should be cleaned and placed in
the starng posion.
2. LONG TERM STORAGE - Follow the instrucons below
for if the pump is not being used with in the next 2
months or longer.
I. Clean the pump according to the instrucons in the
maintenance secon (pg 19).
Ii. Run the pump for 3 minutes and stop it.
Iii. Drain old oil and replace with fresh oil.
Iv. Turn o the fuel supply at the fuel valve.
V. Change the oil.
Vi. Slowly pull the recoil start handle unl pressure is
felt (that is, to the point in the compression stroke
where the intake and exhaust valves are closed),
and leave the recoil in that posion. This prevents
moisture forming while the engine in not in use/
storage.
Vii. Store the unit in a clean, dry area out of direct
sunlight.
Pg. 18

Pg. 19
3. STARTING POSITION
I. MANUAL STARTING - Press the decompression lever
(non-compression posion), pull the recoil handle 2-3
mes. Do not start the diesel engine.
II. ELECTRIC STARTING - When the decompression lever
is in the non-compression posion, turn the switch
to the ‘ON’ posion for 2-3 seconds. Do not start the
engine.
TROUBLE SHOOTING
! WARNING: Turn o the pump before starng
maintenance work.
FAULT POSSIBLE CAUSE REMEDY
Engine can
hardly start
or cannot
start /Low
power
1. Throle speed control closed
2. Stop switch closed
3. Inferior oil or fuel is used.
4. Engine works over loaded or
over heated
5. Insucient oil
1. Open the throle governor
2. Turn the switch to ON posion
3. Change new fuel or oil
4. Check the engine work condion
5. Add oil to standard level
Pump cannot
work or low
water ow
aer engine
start
1. Impuries lter blocked
2. Insucient water in pump
3. Problem with water pipe
like block, loose, leak and pipe,
length too long or diameter
too narrow.
4. Input pipe is not in the
water.
5. Input pipe leak
6. Pump mounng too high
7. Speed of pump is too low
8. Pump will not draw water
9. There is air in the output
hose/outlet
1. Check and remove the impuries
2. Unscrew the priming plug and ll with
enough water
3. Check the water pipe and adjust
4. Check and put it into water
5. Check the connecon
6. Lower the mounng height
7. Turn the throle speed control to
high speed
8.Check max. depth of sucon hose and
ensure it is in the working parameters.
9. Seal may be broken or damaged.
Repair seal.
Power
consumpon
of pump is
too high
1. There is wear between
impeller and the diuser
2. The impeller is obstructed by
weed or debris
1. Listen carefully to hear if impeller
is grinding with pump case. Repair if
needed.
2. Open the pump casing (while stopped)
and clear obstrucon
Pump ow
suddenly
stopped
1. The connector on the inlet
has come loose or is leaking
2. The connector on the outlet
pipe has come loose or is
leaking
3. Sucon head is too high and
causing capitaons
4. There is an obstrucon in
the inlet pump/casing
1. Reconnect the inlet pipe
2. Reconnect the outlet pipe
3. Check sucon head and lower posion
of pump
4. Check and clear obstrucon
There is
vibraons or
noise
1. Sucon head is high and
causing cavitaons
2. There is an obstrucon in
the inlet pump/casing
3. Pump is not stable or on
angle
4. There is air in the pump
or hoses
5. Impeller is damaged
1. Check sucon head and lower posion
of pump
2. Check and clear obstrucon
3. Stop machine. Adjust to a level surface
and restart
4. Check pump and hose seals for air
leaks
5. Stop machine, change with new one.

CROMTECH DIESEL PUMPS
OPERATION MANUAL
DIESEL WATER PUMPS
