Architectural & Engineering Specifications
Macro-Tech 1202 (120 V, 60 Hz models)
The power amplifier shall be a solid-state two-
channel model employing multi-mode®(AB+B)
grounded bridge™ output circuitry.
The outputs shall be switchable as stereo,
bridged-mono or parallel-mono modes of
operation. The bridged-mono mode shall bridge
the outputs to provide increased output volt-
age. The parallel-mono mode shall parallel the
outputs to provide increased output current.
The output impedance of each channel shall be
less than 10 milliohms in series with less than
2 microhenries in stereo mode.
The amplifier shall contain protection circuitry
which limits the drive level placed on the output
devices before their SOA (Safe Operating Area)
is exceeded. This protection circuitry shall
calculate the instantaneous voltage across and
current through the output devices while factor-
ing in their simulated junction temperatures to
predict how close they are to their operating
limits. This protection shall be called “ODEP.”
The amplifier shall contain protection from
shorted, open and mismatched loads, general
overheating, DC, high-frequency overloads, and
internal faults. This protection shall be called
“Quad-Mute.”
The amplifier shall contain controlled slew-
rate voltage circuitry to protect it against radio
frequency interference burnouts. It shall also
be protected from current overload at its output
stage. The slew rate of the amplifier shall be
greater than 13 volts per microsecond in stereo
mode.
The amplifier shall temporarily go into a stand-
by mode if its power transformer becomes
excessively hot and shall automatically resume
normal operation once it has cooled to a safe
operating temperature.
The amplifier shall be safe when driving any
kind of load, including highly reactive ones.
Front-panel controls shall include an enable
on/off switch and a detented input level control
for each channel.
Rear-mounted controls shall include a ground
lift switch to isolate the signal ground from the
chassis ground, a switch which selects be-
tween stereo, bridged-mono and parallel-mono
modes of operation and a reset switch for each
channel’s circuit breaker.
Internal controls shall include an input sensitiv-
ity switch to select between 0.775 V, 1.4 V or a
fixed voltage gain of 26 dB for full rated output.
The amplifier shall be fully compatible with and
shall provide appropriate input cables and con-
nectors for Crown®PIP2™ input modules. An
optional input adapter shall be available so the
amplifier can also accept standard Crown PIP™
input modules. The amplifier shall be fully
compatible with Harman Pro System Architect
and the Crown IQ System®.
Front panel indicators shall include an amber
power enable indicator, an amber protection
system indicator for each channel which shall
normally be illuminated to confirm the availabil-
ity of reserve thermodynamic energy and which
shall dim in proportion to limiting when the
power demands of the output stages have been
exceeded, and a green dual-function signal
presence/input-output comparator indicator
for each channel which shall normally flash at
moderate intensity to show the presence of an
audio signal and shall flash brightly if distortion
of any kind equals or exceeds 0.05%.
The power amplifier shall meet or exceed the
following performance criteria. Input sensitivity
for rated output: 26 dB voltage gain (unbal-
anced). Rated FTC output in stereo mode with
less than 0.1% THD: 685 watts per channel
(20 Hz to 20 kHz) into 4 ohms; 495 watts per
channel (20 Hz to 20 kHz) into 8 ohms. Rated
FTC output in bridged-mono mode with less
than 0.1% THD: 1355 watts (20 Hz to 20 kHz)
into 8 ohms; 955 watts (20 Hz to 20 kHz) into
16 ohms. Hum and noise: at least 105 dB (A
weighted) below full rated output power. Phase
response: ±10 degrees from 10 Hz to 20 kHz
at 1 watt. Frequency response: 20 Hz to 20
kHz, ±0.1 dB at 1 watt into 8 ohms per chan-
nel in stereo mode. Damping factor: greater
than 1000 from 10 to 400 Hz into 8 ohms.
Intermodulation distortion (SMPTE): less than
0.05% from 163 milliwatts to rated power into
8 ohms in stereo mode. Harmonic distortion at
rated power into 8 ohms per channel (stereo
mode): less than 0.05% from 20 Hz to 1 kHz
and increasing linearly to less than 0.1% at 20
kHz.
The power requirements shall be 120 VAC at 60
Hz. At idle, the amplifier shall draw 100 watts
or less.
The amplifier chassis shall be constructed of
steel with a durable black finish and shall be
designed for flow-through fan-assisted ventila-
tion from the front panel to the side panels. The
amplifier shall have an aluminum front panel
with Lexan overlay and air filter media.
The dimensions of the amplifier shall allow
for 19 inch (48.3 cm) EIA standard (RS-310-
B) rack mounting. The amplifier shall be 3.5
inches (8.9 cm) tall, 16 inches (40.6 cm) deep
behind the rack-mounting surface, and 2.5
inches (6.4 cm) in front of the rack-mounting
surface.
The amplifier shall weigh 51 pounds, 12 ounces
(23.5 kg) and shall have a center of gravity
approximately 6 inches (15.2 cm) behind the
front panel.
The amplifier shall be designated the Crown
Macro-Tech 2402.
