croydon GR2E User manual

GR2E-200001 B1
ELECTRICAL GRIDDLE - MODEL GR2E-200001 B1
-PLEASE readtheseinstructionscarefullybeforeoperatingthisappliance.
-The temperature is thermostatically controlled between the range of 50ºC to 300ºC (122ºF
to 572ºF). A signal lamp adjacent to the thermostat indicates when heating element is
energized.
IMPORTANT
-Thisunitisdesigned tooperateonalternativecurrent(A.C.)only.
-DONOTCONNECTTODIRECTCURRENT(D.C.)
-Care should be taken when operating this appliance as HOT SURFACES may cause
burns.
-Ensurethatthepower supplycorddoesnotcomeintocontactwithhotsurfaces.
-Donotleaveunitinoperationwithoutanattendant.
-Whennotinuseforlongperiodunplugtheappliance.
INSTALLATION AND OPERATION
-Check if voltage of your power system corresponds to the same specified on the
appliance label.
-Before using the appliance for the first time, remove the protection coating (MEDICINAL
VASELINE) with a damp cloth and turn the control knobs to 300ºC (572ºF), allow griddle
to heat for +/- 30 minutes. You will notice some smoke appearing due to the protection
coating and internal insulation burning, which is normal.
-After 30 minutes heating, turn temperature controls down to operating desired
temperature and grease plate, generously with butter or oil. Never allow excess of fat or
oil to buildup as this will result in build-up of carbon on the plates, which should be
removed with a scraper.
-Appliance is provided with grease drawer that receives grease and food scraped
residues.
-This appliance should be preheated before daily operation.Always allow 15 minutes
preheat time before loading griddle with food to give griddle surface time to saturate.
-To turn off your appliance turn thermostat knobs completely towards left.
CLEANING PROCEDURE
-Always ensure that the appliance is disconnected from the main power supply before
cleaning.
-Try to scrape as much grease and residues from cooking surface as possible while the
unit is still hot.
-After appliance has cooled, clean cooking surface and body using only a damp cloth.
Never use water jet or immerse appliance in water.
-Wipe off appliance with a dry cloth and wait at least half an hour before re-connecting to
main power outlet.
INSTRUCTIONMANUAL
50
250
200
150
010
DESL
ºC
0
32
122
1
2 2
302
392
482
0
68
ºF
OFF
50
250
200
150
100
DESL
ºC
0
32
122
1
2 2
302
392
482
06 8
ºF
OFF
The pictures/drawings are illustrations. All data can be changed without notification.
CROYDON
CROYDON CROYDONMAQ INDUSTRIAL LTDA.
Estrada São Lourenço, 891 - Capivari - Duque de Caxias.
RJ - Brasil - CEP 25243-150 Fax: [phone]
Phone: [phone]
e-mail: [email protected]
CROYDON

Screw (4,8)
Cooking Plate
Thermostat Bulb Retainer
Heating Element (2800W)
Heating Element Support
Nut
Insulation
Heating Plate Protection
Body
Thermostat
Nut (3/16")
Cord Connection
Plate
Wire Connector
Screw
Foot
Screw (3/16")
Knob
Pilot Light
Screw
Grease Drawer
Bottom Cover Plate
Screw (3,5)
Rubber Finishing
Retainer Adapter
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
566
2.755-3
2.065-3
2.830-3
2.826-3
635
3.503-3
2.843-3
2.804-3
2.009-3
604
2.115-3
1.343-3
2.085-3
329
1.918-3
385
2.009-B
3.509-3
330
3.506-3
18.111-3
552
9.421-3
2.805-3
5
6
7
8
23
4
1
9
6
11
17
16
19
15
10
21
22
23
ELECTRICAL GRIDDLE (GR2E) ELECTRICAL GRIDDLE (GR2E)
Item Code Description
Wiring diagram
G
L2
L1
Voltage(V)
Power(W)
Amperage(A)
Weight(kg/lbs)
Dimensions Wx H x D (cm/in)
Technical Data
220
5600
25.5
45/99
80/31.5x 36/14.2 x 56/22.1
14
24
12
25
GR2E-200001 B1
18
13
20
