The pictures/drawings are illustrations. All data can be changed without notification.
INSTRUCTIONMANUAL
SASL-G0332-700
GAS SANDWICH GRILL - MODEL: SASL-G0332-700
-PLEASE readtheseinstructionscarefullybeforeoperatingthisappliance.
SAFETY
-Install your equipment in area well ventilated, to eliminate the gases generated by the
combustion.
-It’srecommendedtoleaveatleast6inches(15cm)offreespacearoundtheequipment.
-DONOTinstalltheequipmentnext tocombustiblematerials.
-Theinstallationhastocomplytothesafetystandards.
-The equipment is supplied with a Gas Tap which can adjust the flame (turn 1/4 to
maximum flame and turn 1/2 to minimum flame).
-Incorporated to the Tap there is a safety device that will let open the gas only if it is
pressed and turned counterclockwise.
-Beforeusingtheapplianceforthefirsttime,removetheprotectioncoatingwithadampcloth,
light the burner and allow griddle to heat for +/- 30 minutes. You will notice some smoke
appearingduetotheprotectioncoating burning,whichisnormal.
- After 30 minutes heating, adjust the gas tap to operating desired temperature and grease
plate, generously with butter or oil. Never allow excess of fat or oil to buildup as this will
result in build-up of carbon on the plates, which should be removed with a scraper.
-Appliance is provided with grease drawer that receives grease and food scraped residues.
-This appliance should be preheated before daily operation.Always allow 15 minutes
preheat time before loading griddle with food to give griddle surface time to saturate.
-To turn off your appliance turn the gas tap knob completely towards left.
CLEANING PROCEDURE
-Always ensure that the gas taps are in off position before cleaning.
-Try to scrape as much grease and residues from cooking surface as possible while the
unit is still hot.
-After appliance has cooled, clean cooking surface and body using only a damp cloth.
Never use water jet or immerse appliance in water.
-Wipe off appliance with a dry cloth and wait at least half an hour before start operation
again.
OPERATION
CROYDON CROYDONMAQ INDUSTRIAL LTDA.
Estrada São Lourenço, 891 - Capivari
Duque de Caxias- RJ / Brasil - CEP 25243-150
Phone: [phone] / Fax: [phone]
e-mail: [email protected] - www.croydon.com.br

Burner
Nut
Shaft
Arm
Nut
Burner Regulator
Handle
Screw (3/16”)
Lid
Spring Support
Washer (1/4”)
Orifice
Spring Regulator
Upper Heating Plate
Lid Regulator
Regulator Locker
Screw (1/4”)
Screw (3/16")
Gas Tap
Connection 1/8”
Arm Support
Spring
Locker Washer (1/4”)
Gas Pipe
Tube Seal
Collector Pipe
Shaft
Screw
Foot
Bottom Cover Plate
Grease Collector
Screw
Burner Support
Knob
Body
Lower Heating Plate
Rubber Protection
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
CROYDON
16.074-3
621
2.646-3
1.971-3
601
16.076-3
15.000-3
481
2.032-3
2.654-3
642
16.243-3
2.631-3
2.471-3
2.467-3
2.466-3
332
385
16.165-3
16.237-3
1.959-3
2.044-3
597
16.242-3
16.217-3
16.246-3
15.024-3
552
1.917-3
1.963-3
1.970-3
566
16.240-3
1.965-3
16.241-3
2.472-3
2.113-3
Item Code Description
SASL-G0332-700
Power(BTU/h)
Consumption(g/h)
Weight(kg/lbs)
DimensionsW x HxD (cm/in)
9.000
225
11,7/ 25,7
39/15,4x30/11,9 x 49/19,3
8
9
27
4
37 3
2
21
5
23
11
17
22
13
5
11
15
16
10
2
27
27
14
33
31
32
36
35
34
18
28
32
20 19
1
6
12
24 25
26
29
28
30
Technical Data
