SANDWICH GRILL - MODEL: SASQ-10412-700
ATTENTION:
-PLEASEreadtheseinstructionscarefullybeforeoperatingthisappliance.
-Thetemperatureisthermostaticallycontrolledbetweentherangeof50ºCto300ºC(122ºF
to572ºF).Asignallampadjacenttothethermostatindicateswhentheheatingelementsare
energized.
IMPORTANT:
-These units are designed to operate on alternating current (A.C.) only.
-DO NOT CONNECT TO DIRECT CURRENT (D.C.).
-Care should be taken when operating this appliance as HOT SURFACES may cause
burns.
-Ensurethatthepowersupplycorddoesnotcomeintocontactwithhotsurfaces.
-Donotleaveunitinoperationwithoutanattendant.
-Whennotinuseforlongperiodunplugtheappliance.
INSTALLATION AND OPERATION:
-Check if voltage of your power system corresponds to the same specified on the machine
label.
-Before using the appliance for the first time, turn the control knob to 300ºC (572ºF), close
the lid and allow the appliance to heat for + / - 30 minutes. You will notice smoke appearing
duetotheinternalinsulationburning,whichisnormal.
-After30minutesheating,turntemperaturecontrol downtooperatingdesiredtemperature,
keep knob in this position until pilot light turns off, at this point the unit will be ready to be
used.
-Toturnofftheunitturnknobcompletelytowardsleft.
CLEANING PROCEDURE
-Always ensure that the appliance is disconnected from the main power supply before
cleaning.
-Afterappliancehascooledcleancookingsurfaceandbodyusingonlyadampcloth.Never
usewaterjetorimmerseapplianceinwater.
-Wipe off appliance with a dry cloth and wait at least half an hour before re-connecting to
mainpoweroutlet.
INSTRUCTIONMANUAL
The pictures/drawings are illustrations. All data can be changed without notification.
(STAINLESS STEEL ARM)

Heating Element (550W)
Nut (1/4”)
Shaft
Arm
Nut
Heating Element (1000W)
Handle
Screw (3/16”)
Lid
Spring Support
Washer 1/4”
Heating Fixed
Spring Regulator
Checkered Upper Heating Plate
Lid Regulator
Regulator Locker
Screw 1/4”
Screw 3/16"
Nut 3/16"
Special Screw
Arm Support
Spring
Locker Washer (1/4”)
Cord Connection
Cord Retainer
Wire Connector
Shaft
Screw
Foot
Bottom Cover Plate
Grease Collector
Screw
Pilot Light
Screw
Knob
Body
Thermostat
Heating Element Protection Plate
Insulation
Heating Element Retainer
Checkered Lower Heating Plate
Thermostat Bulb Retainer
Rubber Protector
Rubber Protection
Protection Sleeve
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
CROYDON
CROYDON
32
26
25
29
28
3033
32
35
34
37
36
18
39
12
32
1
38
39
8
9
19
42
40
32
31
2
7
4
45 3
2
21
5
23
11
17
22
13
5
11
15
16
10
44
2
27
43
27
24
2.034-3
621
2.646-3
1.971-3
601
2.025-3
15.000-3
481
2.032-3
2.654-3
642
1.964-3
2.631-3
40.028-3
2.467-3
2.466-3
332
385
604
330
1.959-3
2.044-3
597
2.096-3
9.413-3
2.085-3
15.024-3
552
1.917-3
1.963-3
1.970-3
566
3.509-3
329
2.009-B
1.900-3
2.009-3
2.057-3
2.073-3
2.062-3
40.022-3
2.091-3
2.007-3
2.105-3
2.113-3
20
14
SANDWICH GRILL (SASQ) SANDWICH GRILL (SASQ)
Technical Data
Amperage(A)
DimensionsWxH xD (cm/in)
Weight(kg/lbs)
Power(W) 1.550
14,1
14,0/30,8
33,7/13,3x 36,3/14,3x 49,5/19,5
Voltage(V) 110
SASQ-10412-700
32
6
Item Code Description
41
Wiring Diagram
G
L2
L1
