Cruisers Yachts 350 express series User manual

V2569800 (Rev. 0) 350 Express Series
350 Express Series
Table of Contents
1. Introduction........................................................................................................ 1-1
2. Model Specific Information............................................................................... 2-1
3. Controls and Indicators.................................................................................... 3-1
4. Basic Systems Operation................................................................................. 4-1
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

350 Express Series
350 Express Series
This Page Intentionally Left Blank
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

1-1 350 Express Series
Section 1
Introduction
Welcome Aboard!! ........................................................ 1-2
Skipper’s Kit .................................................................. 1-2
Owner’s Manual................................................................. 1-2
Safety................................................................................. 1-3
Owner’s Manuals for Onboard Systems
and Components............................................................. 1-4
Warranty Information ................................................... 1-5
Dealership Responsibilities ................................................ 1-5
Your Responsibilities ......................................................... 1-5
Warranty Service ............................................................... 1-5
Safety Label Location Layout....................................... 1-6
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 1
1-2
350 Express Series
WELCOME ABOARD!!
Welcome to the Cruisers Yachts family of happy yacht owners.
We wish to thank you for making our 350 Express Series your
recreational choice for boating enjoyment. Extensive design and
engineering research went into the development of all Cruisers
Yachts. We feel there is a beautiful balance between structural
integrity and creature comforts.
Your yacht was manufactured by trained craftsmen in the tradition of
meeting or exceeding existing safety and quality standards
established by the United States Coast Guard and the Boating
Industry of America.
Cruisers Yachts has been manufacturing boats for more than 50
years. We take pride in our craftsmanship and hull performance. We
are confident you will enjoy the ride. The Cruisers Yachts name is
yourassurance that your yacht will hold its value while providing many
years of boating pleasure. We have made a commitment to this
industry and are glad to have you as a partner.
Congratulations on your choice – let us know if we can be of further
service.
SKIPPER’S KIT
The Skipper’s Kit contains the 350 Express Series owner’s manual,
as well as information about onboard systems and components
furnished by suppliers other than Cruisers Yachts.
Owner’s Manual
The owner’s manual contains specific information concerning the
operation of the 350 Express Series. The descriptions contained
within this manual will introduce you to features of the 350 Express
Series, and provide you with general knowledge of how the
equipment works. This manual is divided into several sections, and
each section is introduced by a table of contents to help you quickly
find needed information.
The Getting Started owner’s manual contains additional general
information concerning operation and the necessary information for
boating safety and care of your yacht. The Getting Started manual is
also divided in the same manner as the owner’s manual to help you
quickly find needed information. Become familiar with the material in
each section of both manuals. Always keep both manuals together
and with your yacht for future use, and for anyone who may operate
your yacht. The following are the topics found in the Getting Started
manual:
INTRODUCTION
BOATING SAFETY
GENERAL CONTROLS AND INDICATORS
BASIC OPERATION OF SYSTEMS
GENERAL ACCESSORY ITEMS
GETTING UNDERWAY
GENERAL MAINTENANCE
STORAGE AND EXTENDED LAY-UP
TROUBLESHOOTING
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

1-3 350 Express Series
Introduction
Safety
In emergency situations, it may be necessary to resort to measures
which are not normally practiced. Always determine that no one
aboard the boat is in danger before attempting to salvage equipment.
Keep a sound mind during an emergency and always think safety.
SAFETY SYMBOLS
The following precautions are used throughout this manual.
The signal words “DANGER,” “WARNING” and “CAUTION” have
specific meaning to alert you to the level of the hazard.
Section 1 contains a description of the Skipper’s Kit and information
about the warranty.
Section 2 contains your yacht specifications such as dimensions and
capacities. There are also layout diagrams to introduce you to
floorplans as well as the locations of various components.
Section 3 contains descriptions of all the controls and indicators on
the dash of the helm.
Section 4 contains principles of operation for the major systems on
the 350 Express Series.
AThe Safety Alert Symbol means
ATTENTION! Be alert to the
possibility of personal injury or death.
DANGER
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if
not avoided, could result in minor or moderate injury.
CAUTION
Indicates the presence of a hazard which may result in
damage to property or equipment.
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 1
1-4
350 Express Series
Owner’s Manuals for Onboard Systems and
Components
Spend some time becoming familiar with all the information contained
in theSkipper’s Kit. Besides containing separate warranty information,
the kit also contains literature which provides important safety
information, operating and maintenance instructions for those
systems and components not manufactured by Cruisers Yachts.
Depending on the options you choose, the kit may contain some or all
of the following literature:
• Engine and Drive System
• RACOR Fuel Filter/Water Separator
• Electric Stove
• Battery Charger
• Water Heater
• Trim Tabs
• Refrigerator/Freezer
• Generator
• Electric Anchor Windlass
• Air Conditioner/Heater
•StereoSystem
• Compass
•Microwave
• Marine Toilet
• Fire Suppression System
• Carbon Monoxide (CO) Detector
• Searchlight Operation
• Television, DVD Player, FM Radio, CD Player
• Coffee Maker
• VHF Radio
• Navigation Systems
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

1-5 350 Express Series
Introduction
WARRANTY INFORMATION
Warranties for onboard systems and components furnished by
suppliers other than Cruisers Yachts are located inside the Skipper’s
Kit. Your Cruisers Yachts Dealer will go through these with you. It is
your responsibility to fill out any warranty registration that may be
required.
The warranty provided by Cruisers Yachts is printed on the last page
of this manual. You and your Cruisers Yachts Dealer have certain
responsibilities to fulfill to keep the warranty in force.
Dealership Responsibilities
1. The dealer will discuss the terms of all warranties and stress the
importance of registering warranties with the appropriate
manufacturers.
2. The dealer will provide instruction for obtaining warranty service.
3. The dealer will go over the predelivery service record with you and
then sign it to certify that all work has been performed.
4. The dealer will provide you with thorough instructions in the
operation of your yacht and all its systems.
Your Responsibilities
1. Sit down with the dealer and go over all warranties. Fill in the
Cruisers Yachts Limited Warranty Registration card which is
located inside the Skipper’s Kit. Keep a record of the hull number
for future reference.
2. Inspect the boat at the time of delivery to ensure that all systems
are operating properly.
3. Sit down with the dealer and go over the predelivery service
record. Sign this record to indicate that it has been explained to
you.
4. Operate all equipment per the manufacturers’ instructions.
5. Cruisers Yachts recommends that you refer to your engine
warranty for initial inspection and service requirements.
6. Perform the appropriate periodic maintenance as outlined in the
owner’s manuals and service guides.
Warranty Service
You are entitled to all the benefits and services outlined in the
warranties. If a problem arises with your 350 Express Series as a
result of workmanship or materials, contact your Cruisers Yachts
Dealer as soon as possible. Please have your hull identification
number and necessary model numbers on hand for the items that
may need service or repair. Your hull identification number is located
below the rub rail on the starboard side of the transom.
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 1
1-6
350 Express Series
SAFETY LABEL LOCATION LAYOUT
350 LABEL LOC
For modelswith optional
foredeck chaise lounge
CAUTION
TO PREVENT EXHAUST FUMESFROM ENTERING CABIN,
KEEP CLOSED WHEN ENGINE OR GENERATOR ARE RUNNING.
DANGER
DISCHARGE OF OIL PROHIBITED
The Federal Water Pollution Control Act
prohibitsthe discharge of oil or oily waste into
or upon the navigable watersand contiguous
zone of the United Statesif such discharge
causesa film or sheen upon, or discoloration
of, the surface of the water, or causesa sludge
or emulsion beneath the surface of the water.
Violatorsare subject to a penalty of $5,000.
FUEL VALVES
NOTE: ValvesOpen When
In Line With Flow
OPERATION
NORMAL: Open Outside Valves
and Close Center
EMERGENCY: Close Valve to
Empty or Contaminated
Tank and Open Center
Do Not Open All Three Valves
(CaliforniaOnly)
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

2-1 350 Express Series
Section 2
Model Specific Information
Specifications................................................................. 2-2
Deck Hardware General Layout.................................... 2-3
Interior General Layout - Stereo................................... 2-4
Cockpit Light Plan Layout - Stereo.............................. 2-5
Cockpit Light and Outlet Plan Layout.......................... 2-6
Interior Light and Outlet Plan Layout........................... 2-7
Head Ventilation Layout................................................ 2-8
A/C Ducting Layout and Plan........................................ 2-9
Plumbing Hardware..................................................... 2-11
Gas Engine General Layout and Genset -
V-Drive Models .......................................................... 2-12
Engine Room General Layout - V-Drive..................... 2-14
Fuel Tank Fittings........................................................ 2-15
Fuel Tanks.................................................................... 2-16
Fuel Crossover Assembly - Diesel............................. 2-18
Forward Engine Room Bulkhead - V-Drive................ 2-19
Gas Engine General Layout and Genset -
I/O Models.................................................................. 2-20
Engine Room Electrical Panel - V-Drive Models....... 2-22
Engine Room Bulkhead - I/O Models......................... 2-23
Freshwater Layout....................................................... 2-24
Waste Layout w/Macerator......................................... 2-26
Waste Layout w/o Macerator...................................... 2-28
Raw Water Layout ....................................................... 2-29
A/C Plumbing Layout .................................................. 2-30
Genset/Engine Seacock/Strainer Access Hatch -
V-Drive ....................................................................... 2-31
Dinette Tables.............................................................. 2-31
Sky Hatch (Not Shown)............................................... 2-32
Aft Settee...................................................................... 2-32
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 2
2-2
350 Express Series
SPECIFICATIONS
Measurements (US / Metric)
L.O.A. Hull with Integrated Swim Platform......................35'6" / 10.8 m
Beam ................................................................................11'8" / 3.5 m
Approximate Weight*, Gas Engines..................... 16,500 lbs / 7030 kg
Approximate Weight*, Diesel Engines................. 17,500 lbs / 7938 kg
Fuel Capacity.................................................................232 gal / 878 l
Fresh Water Capacity......................................................40 gal / 151 l
Holding Tank Capacity.....................................................30 gal / 113 l
Cabin Headroom.................................................................6'4" / 1.9 m
Height - Keel to Top of Windshield......................................9'7" / 2.9 m
Height - Keel to Top of Arch..............................................12'0" / 3.7 m
Draft: Stern Drive Down......................................................44"/ 1.12 m
Draft: Inboard........................................................................34"/ .86 m
Draft: Stern Drive Up ............................................................29"/ .74 m
Dead Rise..........................................................................16 Degrees
Bridge Clearance with Arch..............................................10'3" / 3.1 m
Bridge Clearance without Arch.........................................7'9" / 2.33 m
Sleeping Accommodations...................................................4 persons
*Weights are estimates and can vary from options and equipment
added.
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

2-3 350 Express Series
Model Specific Information
DECK HARDWARE GENERAL LAYOUT
47-R003D
5
15
1
29
21
31
33
12
2
24
27
9
7
20
12
721
4306
21
19
25
16
17
21 31
12 11 1324 9 82732327 12 32727 22 14 21 28 10 621
37,
3819
18
25
26 34
35
36
35
1. City Water Receptacle
2. Pull, Hatch, T-Handle
3. Cold Faucet
4. Compass
5. Ladder
6. Navigation Side Light
7. Drink Holder
8. Washdown/Shower System
9. Speaker
10. Round Hatch
11. Access Door
12. Courtesy Light
13.Drink Holder
14. Windshield
15. Transom Light
16. Cleat
17. Bow Roller
18.Windlass
Kit
19. Windlass Deck Switch
20. Drink Holder
21. Cleat
22. Cabin Door
23. Waste Basket
24. Cleat
25. Horn
26. Snubber Chain Cable
27. Grab Rail
28. D-Shaped Hatch
29. Fender Holder
30. Walk-ThruWindshield Rail
31. Gas Fill Deck Plate
32. Subwoofer
33.Speaker
34. Spotlight
35.
Hinge
36.
Slam Latch
37.
Gas Spring
Bracket
38. Gas Spring
Purple = optional equipment
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 2
2-4
350 Express Series
INTERIOR GENERAL LAYOUT - STEREO
153
4264
3
47-R014BA
1. Stereo Amplifier
2. CD Changer
3. TV
4. Speaker
5. DVD Player
6. Stereo
Purple = optional equipment
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

2-5 350 Express Series
Model Specific Information
COCKPIT LIGHT PLAN LAYOUT - STEREO
1. Subwoofer
2. Speaker
3.Stereo Remote
4. Speaker
Purple
= optional equipment
421
324
47-R014BB
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 2
2-6
350 Express Series
COCKPIT LIGHT AND OUTLET PLAN LAYOUT
123
447-R008DA
1. Courtesy Light
2. Dual Receptacle Box-GFCI
w/Weatherproof Cover
3. Dual Receptacle Box
4. Lighter Receptacle
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

2-7 350 Express Series
Model Specific Information
INTERIOR LIGHT AND OUTLET PLAN LAYOUT
1. Fireboy
Carbon Monoxide Detector
2. Florescent Light
3. Closet Light
4. Reading Light
5. Overhead Light
6. Florescent Light
7. Dual Receptacle Box
8.Dual GFI Receptacle Box
9.
10. Phone Module
11. Switch
12.
13.
14.
3414 61387727973175 4
4793107
14 11
384121 47-R008DB
1-Module Switch
1-Module Switch, 3-Way
3-Module Switch
2-Module Switch
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 2
2-8
350 Express Series
HEAD VENTILATION LAYOUT
314 2
2413
1. Inline Blower
2. Grill Vent
3. Grill Vent
4. Vent Hose
47-R024B
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

2-9 350 Express Series
Model Specific Information
A/C DUCTING LAYOUT AND PLAN
110 5 6 92784
PLAN VIEW
3
47-R009DA
1. Air Conditioner
2. Salon Vent
6. Plenum to Aft Stateroom Vent
7. Plenum to Head Vent
8. Plenum to Forward Stateroom Vent
9. Plenum to Salon Vent
10. A/C Cold Air Return Grill
3. Head Vent
4. Forward Stateroom Vent
5. Aft Stateroom Vent
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 2
2-10
350 Express Series
A/C DUCTING LAYOUT AND PLAN (CON’T.)
TO HEAD MODULE
TO OTHERSIDE OF BOAT
PORT PROFILE
STBD PROFILE
47-R009DB
1. Air Conditioner
2. Salon Vent
3. Forward Stateroom Vent
4. Plenum Box
5. Plenum to Aft Stateroom Vent
6. A/C Unit to Plenum
32461 5 2
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

2-11 350 Express Series
Model Specific Information
PLUMBING HARDWARE
Purple = optional equipment
1. Waste Tank
2. Head
3.Waste Deck Plate
4. Vent
5. ThruHull Seacock
6. Macerator Pump
7. Water Tank
8.Freshwater Pump
9. Water Deck Plate
10. Cold Faucet
11. Washdown/Shower System
12. Head Faucet
13. Galley Faucet
14. Shower Mixer
15. City Water Receptacle
16. Water Heater
17. Bilge Pump
18. Aft Bilge Pump
19. High Water Alarm
20. Intake Strainer/Seacock
21. Strainer
22. Air Conditioning Pump
23. Air Conditioner
24. Shower Sump Pump
25. Head Drain w/Trap
Galley Drain w/Trap
26.
11 10 387 6514 2 1225 20 2613
41
21
22
24
23174918191615 47-R002DA
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com

Section 2
2-12
350 Express Series
GAS ENGINE GENERAL LAYOUT AND GENSET - V-DRIVE MODELS
1. Port Fuel Tank
2. Starboard Fuel Tank
3. Gas Fill Deck Plate
4. Generator
5. Genset Vented Loop
6. Port Fuel Tank Vent Hose
7. Starboard Fuel Tank Vent Hose
8. Port Fuel Tank Fill Hose
9. Starboard Fuel Tank Fill Hose
10. Port Tank to Port Engine Fuel Feed
11. Starboard Tank to Starboard Engine Fuel Feed
12. Port Tank to Genset Feed
13. Genset to and from Vented Loop
Purple = optional equipment
3812 10 16
211973
13
5
4
47-R005DA
Downloaded from CruisersOwnersForum
http://www.CruisersOwnersForum.com
