crystal fires CF1L BOSTON Assembly Instructions

Aa
!ISSUE 11
1 VALENTINES BUILDINGS
Bechers drive
Aintree racecourse Business Park
L9 5ay
CF1L BOSTON & CF1L WIDE BOSTON
GAS APPLIANCE
INSET CONVENTIONAL FLUED GAS FIRE
INSTALLATION & USERS INSTRUCTIONS
FOR USE WITH NATURAL GAS
CATEGORY I2H
G20 @ 20 mbar
For use in GB and IE
THESE INSTRUCTIONS MUST BE LEFT WITH THE USER FOR FUTURE REFERENCE

!ISSUE 12
THE CF1L BOSTON & CF1L WIDE BOSTON
CONTENTS
SECTION
INFORMATION & REQUIREMENTS
PAGE
1.0
IMPORTANT NOTES
3
2.0
INSTALLATION REQUIREMENTS
4
3.0
APPLIANCE INFORMATION
6
4.0
FLUES AND BUILDERS OPENING REQUIREMENTS
7
5.0
FIREPLACE OPENING SIZES AND CATCHMENT
SPACE
8
6.0
INSTALLING THE CONVECTOR BOX
9
7.0
CONNECTING THE GAS AND TESTING
10
8.0
INSTALLING THE FUEL PIECES
10
9.0
LIGHTING THE APPLIANCE (USERS INSTRUCTIONS)
18
LIGHTING THE APPLIANCE MANUAL VERSION
26
10.0
INSTRUCT THE USER
27
11.0
MAINTENANCE
27
12.0
SERVICING
28

!ISSUE 13
1:1
This fire should be installed and serviced every 12months in accordance with current gas safety
(Installation and uses) regulations by a competent person who is a member of a recognised gas installer’s
Organisation (e.g. Gas safe) and in accordance with the installation instructions.
1:2
The flue should be inspected before your appliance is installed and checked annually to ensure continuous
Clearance of combustion products and safe operation.
The chimney must be swept before installation.
1:3
UNDER NO CIRCUMSTANCES must the fire be used if the glass door panel is broken cracked or
Damaged
1:4
IMPORTANT.
The glass panel door and other outer parts, (e.g. outer frame and door) will become hot in use; clothes
Etc. should not be wrapped over or near the fire and we recommend that a ‘fire guard conforming to BS
8423 should be used for the protection of young children the elderly the infirm and pets’.
1:5
DO NOT burns paper or rubbish in the fire.
1:6
It is important for the safe operation and to maintain efficiency that the fire is not operated with damaged or
Broken fuel effect pieces or ceramics.
UNDER NO CIRCUMSTANCES should extra fuel effect pieces be used.
1:7
When the fire is first used it may emit a slight odour or smoke, this is due to the newness and will
Disappear. DO NOT WASH OR VACUUM the Fuel Effect ceramic pieces.
1:8
The fire MUST be installed into a Builders Opening in line with the Installation Instructions.
No combustible material should be placed within 150mm of the appliance
Any combustible material above the opening should be removed up to a height of
300 mm. any shelf above the fire should not project more than 150mm forward.
For deeper shelves allow a 15mm increase in height for every 25mm in depth.
1:9
These instructions are intended to assist you in the correct operation of your appliance and
Should be kept safe for future reference
1: IMPORTANT NOTES
The Benchmark Scheme
Benchmark places responsibilities on both manufacturers and installers. The purpose is to ensure
that customers are provided with the correct equipment for their needs, that it is installed,
commissioned and serviced in accordance with the manufacturer’s instructions by competent
persons and that it meets the requirements of the appropriate Building Regulations. The Benchmark
Checklist can be used to demonstrate compliance with Building Regulations and should be
provided to the customer for future reference.
Installers are required to carry out installation, commissioning and servicing work in accordance
with the Benchmark Code of Practice which is available from the Heating and Hotwater Industry
Council who manage and promote the Scheme. Visit www.centralheating.co.uk for more
information.

!ISSUE 14
burner
FUMES
flue diverter
convected heated air out
Fumes up flue
Principle workings of a gas fire with a diverter or flue break
Ambient air
from room being
drawn up flue will
only work if flue is
completely sealed in
This is what takes the
fumes up the
chimney
convected air in
gas controls
FLOOR
lintel
ambient air in room enters the appliance some of this air is used to feed gas burner with primary
and secondary air
the ambient air warms as it circulates the
as the ambient air warms and rises it gets hotter and comes back into the room as convected heat
KEYS
Fumes from appliance travel from burner through hole in top of appliance down the diverter and up
the flue this will only work if the flue is sealed and can only pull through the diverter
ambient air is pulled in through the diverter only if flue is sealed ,this has to happen or
the fire will spill products of combustion into the room
TO ASSIST INSTALLER
This diagram shows the appliance and how it
basically works
The air for the appliance convection and
combustion enter the appliance at the bottom of
the appliance ,the combustion air enters the
burner at the injector and the secondary air
around the burner ,this must be kept clear at all
times
The convected air travels up the rear of the
appliance warming up and finally over the hottest
part of the appliance at the top and then back into
the room as convected hot air to heat the room
The fumes leave the flames from the burner and
enter the diverter at the top of the appliance ,with
the ambient air from the room entering the
diverter also due to the natural draught of the
flue they will be drawn up the flue and safely into
the atmosphere
if the flue is not completely sealed this process
may not work and dangerous fumes can enter the
room and be dangerous or even fatal
SEAL THE BASE
SEAL THE BACK
SEAL THE SIDES
SEAL BRICKWORK
SEAL ANY AIR GAPS
SEAL PLASTERBOARD
SEAL FLUE LINER
SEAL WHERE PIPE ENTERS
A SMOKE TEST TESTS THE FLUE
A SPILLAGE TEST CHECKS THE FUMES ARE
BEING PULLED THROUGH THE DIVERTER
2 DIFFERENT TESTS
IMPORTANT
INSTALLATION
INFORMATION
PLEASE READ THIS
THE ABOVE DIAGRAM SHOWS THE WAY THE CF1L BOSTON
& CF1L WIDE BOSTON WORKS ,FOLLOW THIS CAREFULLY
THE FIRE MUST BE SEALED IN AIRTIGHT FOR THE SAFE
OPERATION AND USE OF THIS APPLIANCE
THE ONLY PLACE THE FLUE SHOULD PULL IS THROUGH THE
DIVERTER
2: INSTALLATION REQUIREMENTS

!ISSUE 15
BS
BS
BS
BS
BS
5871
8303
5440 PART 1
5440 PART 2
6891
2:3
IMPORTANT: This appliance is fitted with a spillage monitoring system, (ODS) and must not be adjusted,
bypassed or
Put out of operation, by the user or installer. Any parts of this system should only be exchanged for genuine
crystal
Manufacture parts.
This fire must not be installed in a room that contains a bath or shower.
This fire cannot be installed onto a combustible wall. All combustible materials must be removed from the
area shown in section 11-appliance location
2:4
No combustible materials must be present in the builders opening.
These Instructions must be left with the User.
2:5
VENTILATION: GB
For installation in Great Britain additional ventilation is not normally required unless indicated as being required by the
‘Spillage Test’
2:6
VENTILATION: IE
For installation in Southern Ireland ventilation must be in accordance with I.S813 Domestic Gas Installations.
2:7
FLUE AND CHIMNEY SUITABILITY
This appliance is designed for use with conventional brick built or lined chimneys and fabricated flues and metal flue
boxes conforming to BS715 / BS EN 1856-2 .all flues must conform to the following minimum dimensions
2:8
Minimum diameter circular flues 125 mm
Minimum effective height of all class 1 (175mm) flues 3 metres
Minimum effective height of all class 2 (125mm) flues 4 metres
2:9
ENSURE THAT IF INSTALLING THIS PRODUCT INTO A BRICK BUILT CHIMNEY, THE CHIMNEY
HAS BEEN FULLY SWEPT PRIOR TO PROCEEDING WITH THE INSTALLATION
2:1
In your own interest and that of safety, it is law, that a competent person who is a member of a recognised gas
installation organisation must install all gas appliances (E.g. Gas safe) In accordance with Current Gas Safety
(INSTALLATION AND USE) Regulations.
2:2
Before installation, ensure that the local distribution conditions (identification of the gas and pressure) and the
adjustment of the appliance are compatible.
The installation must be in accordance with these installation instructions and all relevant parts of the Local and
National Building Regulations, the Building Standards (Scotland) Regulations and the relevant recommendations of
current editions of the following British Standards: -

!ISSUE 16
3: APPLIANCE INFORMATION
CF1L BOSTON & CF1L WIDE BOSTON
WIDE
MANUAL
WIDE
REMOTE
STANDARD
MANUAL
STANDARD
REMOTE
GAS G20
NG
NG
NG
NG
INJECTOR SIZE
420
500
380
500
HEAT INPUT HIGH
6.3kW
6.3kW
5.7kW
5.7kW
HEAT INPUT LOW
4.0kW
4.0kW
2.7kW
2.7kW
PRESSURE
20 +/- 1mbar
20 +/- 1mbar
20 +/- 1mbar
20 +/- 1mbar
IGNITION SEQUENCE
Manual
Automatic
Manual
Automatic
SPARK GAP
4mm
4mm
4mm
4mm
WEIGHT FULLY PACKED
Kg
Kg
Kg
Kg
GAS SUPPLY PIPE SIZE
8mm
8mm
8mm
8mm
870 mm
80 mm
315 mm
35 mm
240 mm
80 mm
465 mm
290 mm
546 mm
ABOVE CF1L BOSTON WIDE BOX SIZES ,BELOW CF1L BOSTON STANDARD BOX SIZES
NOT SHOWING TRIMS
465 mm
290 mm
546 mm
720 mm
80 mm
40 mm
240 mm
35 mm
240 mm
80 mm

!ISSUE 17
4:FLUES AND BUILDERS OPENING REQUIREMENTS
4.1
Prior to creating the builders opening the flue must be checked.
No restrictor plate or flue damper is permitted.
The flue must be swept prior to installation.
The flue must be free of any obstructions.
The flue must be checked to ensure it only serves the fireplace opening to be used for the fire.
The flue must have a positive up-draught and checked as follows before the builders-opening is constructed
Any under floor air supply to the fireplace must be completely sealed off
Before installing the fire a simple smoke test should be carried out on the flue to check its condition. Light a smoke
Generator, hold it at the top of the fireplace opening and observe that the smoke is being drawn up the flue, if so,
proceed with installation. If not, pre heat the Flues for a few minutes and recheck, if smoke still fails to be drawn up the
flue, further Investigation is required and the appliance MUST NOT BE FITTED.
Minimum diameter circular flues 125 mm
Minimum effective height of all class 1 (175mm) flues 3 metres
Minimum effective height of all class 2 (125mm) flues 4 metres
WARNING PASSING A SMOKE TEST IS NOT AN INDICATION THE APPLIANCE HAS PASSED A SPILLAGE TEST
BOTH TESTS ARE A SEPARATE PROCEDURE
4:2
Purpose Made Builders Opening With a Conventional Stone Flue.
With a minimum cross sectional dimension of 175mm (7”) and minimum effective height of 3 meters.
The base of the builders opening must be a non-combustible material and at least 12mm thick. The Builders
Opening must be at least 300mm off the floor for a wall mounted fire installation.
It is recommended that a qualified builder construct the builder’s enclosure.
A lintel should be used to support the chimney breast above the
Builders opening.
Any gaps around the Builders Opening, as may be the case with a dry liner wall must be sealed.
4:3
Additional Requirements for a Purpose Made Builders Opening with a Flexible Flue Liner or
A 125mm (5”) diameter flexible gas flue liner with effective height of 4 metres
Conforming to B.S 715, and connected to a Register Plate fitted and sealed above the Builders Opening.
4:4
A solid flue pipe 125mm(5”) diameter and metal flue box conforming to B S 715 with effective height of 4
metres
4:5
SHELF POSITION
If the fire is to be installed into a suitable fire surround it must have a fire rating of 150C.
If the fire surrounds has a combustible shelf it must be at least 300mm above the top of the fire
And protrude from the wall be no more than 150mm
For every 25mm increase in depth of combustible Shelf the position of the shelf must be raised by a further
15mm.

!ISSUE 18
5:2
When installed into a brick built chimney, you must ensure that there is sufficient depth to accommodate any
debris, which may fall from the chimney, this depth must be sufficient to accommodate 12 litres of volumetric
space in a conventional brick built chimney
5:3
This appliance is not suitable for use in fireplaces fitted with an existing chair brick , the chair brick must be
removed
CF1L STANDARD AND CF1L WIDE OPENING SIZES
5:1
ONCE THE BUILDERS OPENING HAS BEEN PREPARED AS SIZES ABOVE ,THE BASE MUST BE
LEVELLED OFF AND FILLED IN COMPLETELY ,TO SEAL ALL GAPS ,
SEE PAGE 4 SHOWING DIAGRAM ON INSTALLATION
ALSO SEE 6:1 FOR SEALING IN APPLIANCE
THE BUILDERS OPENING AS
SHOWN ON LEFT ,
CRYSTAL FIRES SUPPLY A FIXING
FRAME FOR THE BOSTON RANGE
OF FIRES THIS MUST BE
INSTALLED TO THE WALL AND
SECURED ,
BOTH SIDES TOP AND BASE
MUST THEN BE SEALED IN
COMPLETELY
THE APPLIANCE GETS ITS AIR
FOR COMBUSTION FROM
UNDERNEATH THE TRIM SO
THIS MUST STAY UNBLOCKED
COMBUSTION AIR KEEP CLEAR
OPENING SIZES
WIDTH
HEIGHT
DEPTH
CF1L STANDARD BOSTON
770mm
490mm
340mm
CF1L WIDE BOSTON
920mm
490mm
340mm

!ISSUE 19
6:1
mark position in the wall for installation following the current rules in force, and form an opening to the sizes
stated in section 5,
6:2
It is important when installing the convector box that all
gaps around the inside of the fireplace opening are
sealed .the base both sides left and right and the rear
may even need pointing in between the brickwork it is
important that the flue can only pull through the flue
tunnel for the appliance to clear its products and work
correctly
A spillage test will deem this to be correct if a spillage
test fails it will be due to the appliance not being sealed
in correct
6:3
With the opening being made correctly and the fitting frame secured and sealed in place the appliance can be
removed from its packaging and the glass panel removed by unscrewing the 6 screws , 3 on each side to remove
black glass cover and then the 3 brackets holding in the glass panel and the glass frame can be removed ensuring the
glass is supported at all times
Always place the glass panel somewhere safe away from damage
THE FITTING FRAME IS SUPPLIED IN A SEPARATE BOX WITH
THE FIRE TRIM
The gas pipe is located to the left of the appliance and can be installed during the building
work it should be wrapped to protect it from corrosion

!ISSUE 110
Once the glass panel has been removed and placed somewhere safe ,and the fire opening has been done the
gate that allows the gas pipe to enter the appliance can be fixed open to make ease of locating it when the
fire is slid into place ,
Fit the foam strips around the fixing frame
The gas appliance can now be slid into place guiding the gas pipe through the gate ,once the fire is fully
pushed in secure using the screws supplied
Close the fixing gate to secure the gas pipe and stop any unwanted air going up this point
Connect the gas to the appliance and test for soundness
7.0 CONNECTING THE GAS AND TESTING
8.0 Installing the fuel pieces
AVAILABLE FUEL CHOICES
LOGS
PEBBLES
DRIFTWOOD
CF1L STANDARD BOSTON
YES
YES
YES
CF1L WIDE BOSTON
YES
X
X
CF1L STANDARD BOSTON LOG SETUP
The wide rear log can be placed to the back of the appliance ,
ensuring it is BEHIND the aeration slot at the back of the burner do
not put it over the aeration slot ,the 2 sides of the log should wrap
around the edge of the burner sides and sit flat ,!
Once the rear log is fitted the stones can be placed around the edge
of the tray but not not the burner ,!
The mica fill can then be placed into the burner and levelled off!
Only put the amount supplied into the burner
8:1

!ISSUE 111
Left log can now be placed ,as shown in picture above keeping the
front left as possible .
Next log vertical as shown above
The branch log sits just to the left of centre resting on stainless base !
And the big log vertical in the centre

!ISSUE 112
The thinnest curved log sits to the right
The final wide branched log sits to the right with the outer branch virtually touching right side ,!
Once all logs are placed in position turn on the appliance before fitting the glass .check
the pilot is clear ,and check when on full the flames are coming between the logs to
allow the flames to burn clean see below shown with white shapes

!ISSUE 113
Cf1l standard Boston logs setup
The wide rear log can be placed to the back of the appliance ,
ensuring it is BEHIND the aeration slot at the back of the burner do
not put it over the aeration slot ,the 2 sides of the log should wrap
around the edge of the burner sides and sit flat ,!
Once the rear log is fitted the stones can be placed around the edge
of the tray but not not the burner ,!
The mica fill can then be placed into the burner and levelled off!
Only put the amount supplied into the burner

!ISSUE 114
Left log sits to left as shown above
Second log sits right of first log above & branch log below

!ISSUE 115
4th LOG SITS TO RIGHT OF BRANCH AND FINAL LOG TO RIGHT
BEFORE FITTING GLASS CHECK FLAMES BURN BETWEEN LOGS ,TAP BURNER TO LEVEL MICA FIL IF NECESSARY
CF1L STANDARD BOSTON PEBBLE LAYOUT
The cf1l Boston standard can have pebbles positioned around the burner as shown below ,under no
circumstances must the pebbles go in the flames or on the burner
There must be a space left so as not to cover the pilot light

!ISSUE 116
DRIFTWOOD (standard version only )
spread the granules around the base
WARNING DO NOT BLOCK AIR RELIEF AT
FRONT AND BACK OF BURNER
PLACE 2 LARGE LOGS CENTRAL TO THE
REAR OF THE FIRE
DO NOT COVER OVER AIR RELIEF SLOT
TWO SMALL LOGS REST AT SIDES ON
TOP OF LARGE LOGS AND RESTING ON
GRANULES
RIGHT SIDE BRANCH LOG RESTS ON
SIDE LOG AND GRANULES AT FRONT
LEFT SIDE BRANCH LOG RESTS ON SIDE
LOG AND GRANULES AT FRONT
CENTRE BRANCH LOG SITS BETWEEN
TWO AS SHOWN ABOVE
RIGHT TOP BRANCH SITS ON REAR LOG
& ON FRONT RIGHT BRANCH LOG AS
ABOVE
LEFT TOP BRANCH SITS ON REAR LOG
& ON FRONT LEFT LOG AS ABOVE
FRONT CENTRE TOP LOG SITS AS
ABOVE
REAR CENTRE TOP LOG SITS AS ABOVE
1
2
3
4
5
6
7
8
9
10

!ISSUE 117
8.1
After installing the fuel pieces the glass panel can be refitted by placing the glass panel in place and refitting the 3
brackets for holding the glass and screwing them in place, The glass doorframe can now be refitted using the 6 screws
The fire can now be turned on and a spillage test performed
If spillage persists, the flue is not functioning correctly and a fault exists. If after investigation the fault cannot be traced
and rectified, the fire must be disconnected from the gas supply and expert advice obtained.
IMPORTANT: IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU
MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE
ATTEMPTING TO RE-LIGHT THE FIRE
At the time of commissioning the appliance ,complete all relevant sections of the benchmark
checklist on the inside back pages of this document
Crystal fires ltd is a licensed member of the benchmark scheme which aims to improve the standards of
installation and commissioning of domestic heating and hot water systems in the uk and to encourage
regular servicing to optimise safety , efficiency and performance .
Benchmark is managed and promoted by the heating and hot water industry council, for more information
visit www.centralheating.co.uk

!ISSUE 118
LIGHTING THE APPLIANCE (USERS INSTRUCTIONS)
9:1
Fire Control
This control is situated on your fire. The drawing shows the main features of the control.
With this appliance this valve will sit beneath the fire and the handset will be used to operate
This appliance is fully remote control so the handset must be used also to operate
the appliance , 3 batteries are installed in the gas valve and 2 in the handset ,
The batteries in the gas valve must be alkaline
The handset will show a wifi logo in the top right of the handset when connected

!ISSUE 119
Handset
Ensure the power isolator switch on the front corner of Fire Control is in the on position I.NOTE: For safety reasons
a button must be pressed and released for the command to be recognised. Keeping hold of a button when pressing
(unless other wise instructed) will not be recognised as a command press.
Grasp around the handset to unlock its functions. The green unlock light will illuminate to show when the handset is
unlocked and ready to accept commands. (N.B. Keep a grip of handset to keep it unlocked, to continue to operate
the command buttons.)
Power button – To start the fire, (after following the instructions of the previous page), with one hand grasp around the rear of both sides of
the button area control. The green unlock light will illuminate. Keep the handset held to keep the control unlocked, to enable operation of
the buttons. Then with the other hand touch and hold a finger on the power button for about 3 seconds. (A short beep and a flash of the
unlock light will happen upon touching.) When the word “pilot” appears at the bottom left hand corner of the display, immediately release
the power button. (A second flash of the unlock light and a longer beep will also sound at the time to release the power button). The Fire
should be lit within a few seconds. ( N.B. If power button is held for more than a few seconds after second flash/beep/word pilot appears,
the command is ignored for safety reasons. Similarly if it is released too soon before the word pilot appears, the command is also ignored.
With this system, the control has been designed to ensure that only intended ignition of the fire occurs.)To stop – with handset held to
unlock it, press then release power button.

!ISSUE 120
Operating instruction (detailed)
Upon successful insertion of the batteries in the Handset the
display will be as shown. The handset will be supplied paired
to the fire and all that is required is to set the time of day and
select if a 24h hour clock or 12 hour clock display is required and
if temperature display is on Celsius or Fahrenheit.
Setting the time
Holding the handset as described previously to
unlock the keypad, press and hold “SET” for a
few seconds and the display will be as shown
Setting the display for 12 or 24 Hour display
As always when pressing the remote control buttons
keep the control held to keep the green light on and
therefore handset safety feature, unlocked. The H
indicates that it is time to set the timer to either 24 hour
display or 12 Hour (AM or PM ) display. Press the + or
– button on the handset to toggle between the two
settings. When you are ready to confirm the setting
you want press the “SET” button to progress to setting
the day of the week.
