Crystal Screen S80V2.5P User manual

ASSEMBLY AND USER GUIDE
www.crystalscreens.com
Models: S80V2.5P, S92V2.5P, S100V2.5P, S106V2.5P, S80V2.5C, S92V2.5C,
S100V2.5C, S106V2.5C
Record the model and serial number of your Crystal Screen for future
reference. This information is located on the rear of the frame assembly.
Mode:#_______________________________________________________
Serial #:_______________________________________________________

2 |Crystal Screens Assembly and User Guide
IMPORTANT SAFETY INSTRUCTIONS
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operation and maintenance (servicing)
instructions in the literature accompanying the appliance.
When using your projection screen, basic safety precautions should always be
followed, including the following:
1. Read and understand all instructions before using.
2. Close supervision is necessary when any appliance is used by or near children.
Do not leave any appliance unattended while in use.
3. The use of an accessory attachment not recommended by the manufacturer
may cause a risk of injury to persons.
4. This projection screen is intended to be mounted on a wall or other solid,
stable vertical surface.
THIS UNIT MUST BE SECURELY MOUNTED BEFORE USE! DO NOT USE UNTIL
MOUNTED AS SPECIFIED IN THIS GUIDE. IMPROPER MOUNTING MAY CAUSE
SERIOUS INJURY OR DEATH.
5. Follow the assembly instructions provided in this guide.
6. Use only the wall mount provided with the screen, or one recommended by
the manufacturer and carefully follow the mounting instructions.
Do not allow children to climb on or play with this product. Do not place
frame on furniture that could tip over and cause injury. This product is
intended to be mounted on a wall surface. Care should be taken to ensure
that children cannot climb on or attempt to play with the screen and/or
frame. Crystal Screens strongly recommends that mounting be performed
by a professional installer.
A minimum of two people is required for proper installation. If you choose
to mount the screen, use the mount supplied by the manufacturer and
follow these instructions. If you have any doubts about your ability to safely
install this frame, contact the retailer or dealer from which it was purchased.
Make sure that the wall where you are mounting this frame can support the
weight. The included wall mount is designed for standard drywall.

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |3
Warning: To avoid danger of choking or suocation, keep any plastic bags
contained with this product away from babies and children.
3D Warning!
1. Some viewers may experience various types of discomfort during or after viewing 3D
visual images including symptoms like dizziness, disorientation, eye strain/fatigue, blurry
vision, headaches and/or nausea. If a viewer notices any of these or other symptoms of
discomfort while using the screen to view 3D visual images, the aected viewer should
immediately stop watching the screen until symptoms have disappeared for at least 30
minutes. If any such symptoms are particularly severe or persist for hours or days after
using the TV to view 3D visual images, the aected viewer should consult a qualied
physician.
2. It is strongly recommended that individuals with epilepsy, people with history (or family
history) of seizures, individuals with heart disease, pregnant women, and anyone who
becomes nauseated easily should refrain from using the screen to view 3D visual images
unless they have consulted with a qualied physician.
3. Children and teenagers should be carefully supervised while viewing 3D imagery.
Because the visual development of children 6 years and younger may be incomplete and
could be adversely aected by exposure to 3D visual images, it is not recommended that
they use the screen to view 3D visual images unless their parent or guardian has rst
consulted with a qualied physician.
4. Using the screen to view 3D visual images for extended periods of time is not
recommended, even if none of the above symptoms have been experienced. All viewers
should take regular breaks from such viewing.
Recycle Responsibly: This product can be recycled. For product recycling and disposal
information, contact your local government agency or https://www.cta.tech/Consumer-
Resources/Greener-Gadgets.aspx, www.eRecycle.org (in California), the Electronic
Industries Alliance at www.ecycyclingcentral.com (in the U.S.), or the Electronic Product
Stewardship Canada at www.epsc.ca (in Canada).
Warranty: Crystal Screens comes with a 1-year limited warranty on manufactured
defective parts.
Inside the Package: The following pages contain a list of parts required to assemble
the screen. Please ensure that all parts are included. If any part is missing or damaged,
contact Crystal Screens.

4 |Crystal Screens Assembly and User Guide
A. Bottom Tube x1 B. Side Support Tube x1
C. Top Tube x1 D. Top Tension Tube X1
E. Bottom Tension Tube x1 F. Guide Support x1

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |5
G. Center Post x2 H. Tension Support Tube x1
I. Center Bracket x8 J. Sliding Corner Bracket x4
K. Spring Guide Assembly x3 L. Compression Spring x3

6 |Crystal Screens Assembly and User Guide
M. Nylon Flat Washer x3 N. Adjustment Tube x3
O. Wing Nut, ¼”-20 x3 P. Phillips Flat-head Screws 10-32 x
3/8” x3
Q. Pan Head Phillips Screws 10-32 x
3/8” x3
R. Button-head Socket Cap Screws
¼-20 x 3/8” x3

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |7
S. Pan Head Phillip Screws (small) x3 T. Pan Head Phillips Screws 8-32 x 3/8”
x3
U. Metal Washers x3
V. Two Screen Pressure Strips x3

8 |Crystal Screens Assembly and User Guide
FRAME
ASSEMBLY
INSTRUCTIONS

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |9
Congratulations on purchasing the most technologically
advanced projection screen in the world. Please take a
moment to review these assembly instructions. Neither
Crystal Screens nor Luminit LLC will be held responsible for
faulty installation. To avoid ngerprints, leave the screen
inside of the protective tube until the frame has been
assembled. Fingerprints will not aect the projected
image. When handling the screen, wear the included gloves
to minimize contact with the front side (gray, matted side) of
the Crystal Screen.
NOTE: When laying out the frame, take special care to face
the tubes in the correct direction as noted by the diagrams.
Tubes with holes should be positioned on the same side.

10 |Crystal Screens Assembly and User Guide
1
Insert Side Support Tube (B) into
Bottom Tube (A) and fasten with 2
Phillips Flat Head Screws (P).
NOTE: Side support tubes should
be installed facing outward. These
two tubes can be identied by the
multiple screw holes on the
outer side.

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |11
2
Insert Top Tube (C) into Side
Support Tube (B) and fasten it with
2 Phillips Flat Head Screws (P).

12 |Crystal Screens Assembly and User Guide
3
Insert Top Tension Tube (D) into Top
Tube (C) and fasten with 4 Phillips
Flat Head Screw

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |13
4
Insert Bottom Tension Tube (E) into
Bottom Tube (A) and fasten it with 4
Phillips Flat Head Screws (P).

14 |Crystal Screens Assembly and User Guide
5
Fasten the Guide Support (F) to the
top and bottom frames (D) and (E)
using 2 Pan-head Phillips Screws (Q)
on eachend.

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |15
6
Attach the Center Posts (G) to the
inside of the frame by fastening
them with the Center Brackets (I)
and Pan-head Phillips Screws (T) at
each end. Include Metal Washers
(U). Be sure that both center posts
are installed with mounting holes
facing the same direction as the side
bars, see illustration above.
NOTE: Make sure that holes are
located on the same side!

16 |Crystal Screens Assembly and User Guide
7
Insert the short end of the Sliding
Corner Brackets (J) to each end of
the Tension Support Tube (H) and
fasten each side with Phillips Flat
Head Screws (P).

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |17
8
Screw the 3 Spring Guide
Assemblies (K) into the Tension
Support Tube (H). Tighten the
Jam Nut completely to lock the
3 Spring Guide Assemblies into
place – you may need to adjust the
thumb screw in order to tighten the
Jam Nuts. Once the Jam Nut is in
position, tighten the thumb screw
so that it is touching the jam nut, as
shown in the illustration above.

18 |Crystal Screens Assembly and User Guide
9
Place a Nylon Flat Washer (M) and
a Compression Spring (L) onto each
of the Spring Guide Assemblies (K).
Carefully insert the assembly from
step 8 into the frame from step
6 through the pre-inserted nylon
ange bearings.

CRYSTAL SCREENS ASSEMBLY AND USER GUIDE
Crystal Screens Assembly and User Guide |19
10
Place an Adjustment Tube (N)
over each of the 3 Spring Guide
Assemblies (K) and tighten each
evenly with a Wing Nut (O) until
the springs are COMPRESSED
to prepare for Crystal
Screenmounting.

20 |Crystal Screens Assembly and User Guide
CRYSTAL SCREEN
MOUNTING
