FART PRODUKT Standard SCREEN User manual

Standard and Basic SCREEN, ZIP guidance
Installation instruction
19.08.2022

Standard and Basic SCREEN, ZIP guidance
01
1.
2.
C. guiding ZIP insert
B. revision profile of the guide
A. profile of the guide
Construction of a 3-part guide in a ZIP-System:
A. profile of the guide
C. guiding
ZIP insert
B. revision profile of the guide
The delivery should include:
1. Cassette with cover.
2. Sideguides.

02
1. Before assembling the cassette and guides, disassemble the revision profiles of the guides
and remove the ZIP guide inserts.
2. Insert the cassette into the guides.
Assembling the cassette and guides.
Standard and Basic SCREEN, ZIP guidance

03
Installation of guides with using of the screws.
The guides should be screwed with the use of appropriately selected mounting accessories.
They already have the mounting holes prepared in accordance with the selected mounting type
(frontal / lateral mounting).
Frontal mounting. Lateral mounting.
Mounting the SCREEN blind (remember to connect the power cable!).
Warning! Make sure that the rails are screwed vertically parallel to each other; that the cassette
is mounted horizontally and the diagonals between the guides are equal.
Standard and Basic SCREEN, ZIP guidance

04
Then screw the guide's revision profile to the guide.
After slipping on the guides, lower the fabric to insert it into the guiding ZIP insert.
Preparing of the ZIP system and putting the guides together.
about 150 mm
After lowering the fabric, insert it into the guiding ZIP insert and place the insert in the guide.
Standard and Basic SCREEN, ZIP guidance
