Crystal VAPURE Manual

INSTALLATION & OPERATING INSTRUCTIONS
SALT AND MINERAL CHLORINATOR
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

1.1 Important Warnings................................................................................................................................4
2.
POWER PACK AND CELL INSTALLATION...........................................................................................................8
1. IMPORTANT WARNINGS AND SAFETY INSTRUCTIONS............................................................................4
.
TABLE OF CONTENTS
CLOCK/TIMER
SALT TEST
BACKWASH
POWER/MODE
CHLOR BOOST
WINTER MODE
5.1 Initial Start Up...............................................................................................................................................
5.2 Start Up Clock Set.......................................................................................................................................10
5.3 Start Up Run Period....................................................................................................................................
5.4 Start Up Information..................................................................................................................................10
5.5 Mineral or Salt Mix......................................................................................................................................11
5.6 Default Display Screen..............................................................................................................................11
1.2 Important Safety Instructions..........................................................................................................4
1.3 General Warnings.....................................................................................................................................4
GENERAL OVERVIEW.......................................................................................................................................................5
2.1 Recommendations and Helpful Hints.........................................................................................6
2.2 Contents..........................................................................................................................................................6
2.2 Tools Needed...............................................................................................................................................6
3. POOL PREPARATION.......................................................................................................................................................7
4.
4.1 Power Pack Installation..........................................................................................................................
8
4.2 Cell Electrode Installation....................................................................................................................8
4.3 Installation Diagram................................................................................................................................9
INITAL START UP OF YOUR UNIT..........................................................................................................................10
5.
1010
10
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

6.1 ................................................................................................................................................12OK BUTTON..
6 ...............................................................................................................13
6.3 CHLOR BOOST 13
6.4 WINTER MODE 14
6.5 CLOCK/TIMER ............................................................................................................................................ 14
6.6 ..................................................................................................................................................... SALT TEST
6.51 ..............................................................................................................................14Clock Settings
6.52 ...............................................................................................................................15Timer Settings
6. CONTROL PANEL OPERATION ................................................................................................................................12
6.7 17 BACKWASH ....................................................................................................................................................
7.1 Backwash ......................................................................................................................................................18
7.2 Brightness......................................................................................................................................................18
7.3 Cell Cleaning ................................................................................................................................................18
7.4 Chlor Boost ...................................................................................................................................................18
7.6 Clock/Timer..................................................................................................................................................
7. UNIT MENU GUIDE ..........................................................................................................................................................18
6.2 POWER/MODE .................
............................................................................................................................................
7.5 Chlor Setting.................................................................................................................................................19
7.7 Contrast ...........................................................................................................................................................19
7.8 Power/Mode..................................................................................................................................................
7.9 Pump Setting.................................................................................................................................................19
7.10 Salt Test
7.11 Service Menu.................................................................................................................................................20
............................................................................................................................................................20
7.12 Spa Mode ........................................................................................................................................................20
8. WATER CHEMISTRY ...........................................................................................................................................................21
9.1 Inspecting and cleaning the cell Electrode..............................................................................23
9.2 Inspecting and cleaning the Power Pack ...................................................................................24
9. CHLORINATOR MAINTENANCE .................................................................................................................................23
10. CHLORINATOR TROUBLESHOOTING ....................................................................................................................25
11. SCHEMATICS AND PART NUMBERS ........................................................................................................................28
12. SPECIFICATION TABLE......................................................................................................................................................31
13. WARRANTY..............................................................................................................................................................................32
14. TECHNICAL SUPPORT
........................................................................................................................................................34
15. NOTES
..........................................................................................................................................................................................35
TABLE OF CONTENTS
............................................................................................................................................
16
19
19
7.13 Winter Mode ..................................................................................................................................................20
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea


The Power Supply internally contains live components. There is a danger of electric shock if opened.
If the power cord is damaged then it should be replaced by the manufacturer, their agent or similar
This manual contains important information about the installation, operation and
safe use of this product. This information should be given to the owner and/or
operator of this equipment. When installing and using this electrical equipment,
basic safety precautions should always be followed. Failure to follow safety warnings
and instructions in this manual can result in serious injury and/or damage to your
equipment. Read and follow all warning notices and instructions which are included
in this manual.
To reduce the risk of injury, do not permit young children to use this product unless they have been
trained by the person responsible for their safety and they acknowledge their ability to use such
equipment. To reduce the risk of accidents or incidents, service on the unit should only be
performed by your local pool Professional.

1.2 Important Safety Instructions
1.1 Important Warnings
1.3 General Warnings
1.IMPORTANT WARNINGS & SAFETY INSTRUCTIONS
www.crystalas.com
4

When mixing acid with water, ALWAYS ADD ACID TO WATER. NEVER ADD WATER TO ACID.
DO NOT PLUG UNIT IN IF CARTON HAS BEEN WET.
GAS BUILDUP CAN OCCUR WITH IMPROPER WIRING: To reduce the risk of personal injury the
Power Pack is designed so that the Electrolytic Cell will only receive power when the pool pump is
on. Otherwise, dangerous chlorine gas build-up can occur. If the pump is not installed to the AC
Socket (pump outlet) on the Power Pack then the installer must ensure that the Electrolytic Cell is
never ener owing through the unit.
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

While every e rt has been made to ensure that the information contained in this guide is
accurate and complete, no liability can be accepted for any errors or omissions. Crystal Aquatic
Systems reserves the right to change the speci cations of the hardware and software described
herein at any time without prior notice.
TM
Please remember that your VAPURE VP-Series Salt Chlorinator is not designed to chemically
maintain your pool water and keep it balanced, but rather to produce chlorine from a mild salt
solution within the water. We encourage regular water testing, balancing and correction if & when
required to maintain the recommended balanced levels of your pool water. This is a vital part of a
complete maintenance program and will ensure trouble free performance as well as a healthy and
sparkling clean pool.
Ther erent size models in our range:
The models available (VP15, 25, 35, 45 and 55) are all reverse polarity units designed to automatically
change direction every 4-16hrs (depending on your setting). See 7.3 CELL CLEANING to change
the reversing times. This change of polarity causes the calcium to dislodge and keep the cell plates
clean. Please note occasional cleaning of the electrode plates may still be necessary.
TM
Thank you again for choosing a VAPURE VP-Series Salt Chlorinator.
We wish you many happy years of swimming in your crystal clear pool.
TM
Congratulations on your recent purchase of your VAPURE VP-Series Salt Chlorinator.
Please take a moment to read through the entire manual before installing your new unit.
Your chlorinator must be installed and operated as speci ed.
5
www.crystalas.com
2.GENERAL OVERVIEW
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

Stabliser
2X Green Wall
Plugs with Screws
The Installation
& Operating Manual
2X50/40
Redusing Bushes
23 Tools Needed
DRILL WITH 6MM
BASIC PVC FITTINGS
HACKSAW NO.2. PHILIPS HEAD SCREWDRIVER
PVC PRIMER
AND GLUE
2.1 Recommendations and Helpful Hints
22 Contents
GENERAL OVERVIEW
www.crystalas.com
WALL MOUNTING
BRACKET WITH LEVEL POWER PACK
CELL HOUSING
WITH UNIONS
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

Before operating your please read the following:VAPURE VP-Series Salt Chlorinator
Handy Tips
NEVER ADD SALT/MINERALS DIRECTLY TO THE SKIMMER BOX. This high concentration
of either salt or minerals will pass through your filtration, pump and other pool
For all new pool installations please seek advice from your pool builder or your local pool Professional
before adding salt, as some new surfaces request no salt to be added when initially completed.
Salt levels above 5000ppm may overload the unit and cause excessive heat and void
your warranty.
Salt levels should ideally be 3000-3500ppm and no more than 5000ppm and mineral levels should
Check your salt levels in your pool before starting your unit. See 6.6 to perform a SALT TEST.
be 20-30% higher. Contact your local pool Professional for further assistance.
The colder the water the lower your output but this does not mean you need more salt. There will
always be less chlorine demand in colder water.
We recommend 3.5kg per 1000 litre of pool water and a 50,000lt new pool needs approximately
175kg of salt. For the FRESHWATER LOW SALT SYSTEM Model: VP25LS, we recommend 1.5kg per
1000 litre of pool water.
The unit can operate on mineral/magnesium chloride salts and you should allow an extra 20-30% on
the ppm for these type of salts.
Salt should always be added to the shallow end of the pool and allowed to dissolve. Do not let the
y cause damage to the surface. Use your pool brush to
mix the salt into the water.
Running the pump will mix the water and help the salt to dissolve.
) to allow the salt to
dissolve.
By pressing [ TDS TEST ] a salt measurement is taken and a total TDS reading is displayed. The ideal
TDS reading should be 3000-3500 and this will be displayed. If >4500 is displayed the salt level is too
high and we suggest taking a sample to your local pool Professional for a more accurate result and
further assistance. For the FRESHWATER LOW SALT SYSTEM Model: VP25LS, the ideal TDS reading is
1500-2000ppm.
3. POOL PREPARATION
www.crystalas.com 7
7
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

Connect the Cell Housing horizontally in the return line to the pool (use reducing bushes supplied if
40mm PVC pipe) using high pressure PVC glue. The Cell Housing can be mounted vertically but
provision must be made for a gas trap.
Direction of wate ow through the Cell Housing is not critical although we do recommend entry from
the closed end of the Cell Housing and exit from the end closest to the Cell Locking Ring. The reason is
to cause less water hammer over time on the cell plates.
Check that the O-ring is clean, greased with silicone grease (DO NOT use petroleum based jelly) and
securely located in the Cell Housing.
Ensure Cell Locking Ring i rmly tightened by hand (DO NOT use a tool to tighten).
Connect the lead from the Cell Electrode to the Cell Plug under the Power Pack ensurin rm snap
lock connection.
Plug the Power Pack 3 pin plug into a suitable weatherproof RCD protected 10amp outlet and then
plug the pump into the 3 pin AC Socket located at the bottom of the Power Pack.
The VAPURE VP-Series Salt Chlorinator has a Ingress Protection Rating of IP23 enabling it to be installed
outdoors. Regulations require that the Power Pack shall be installed outside the pool zone. The Power
Pack shall be installed according to AS/NZS 3000 wiring rules.
The Power Pack should be installed in a well ventilated position ideally away from sunlight and rain to
prolong life and at least 1m above ground to prevent run o ater entry.
Ensure that the Power Pack is not stored near chemicals, fertilisers or in a closed unventilated shed with
similar products as the fumes will cause excessive corrosion and damage to the internals of the Power
Pack and may void warranty.
When mounting the Power Pack on a post it is recommended to instal at panel at least the same
size to act as a waterproof backing plate.
Mount the Power Pack with the Mounting Bracket, Green Plugs and Screws provided.
The Power Pack should be mounted no further than 1.5 metres from the Chlorinator Cell for ease of
operation.
8
4. POWER PACK AND CELL INSTALLATION
4.2 Cell Electrode Installation
4.1 Power Pack Installation
www.crystalas.com
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

POWER PACK
(Ensure good ven
CELL HOUSING
RETURN
TO POOL
PUMP
FROM
SKIMMER BOX
FILTER
POWER
WARNING: DO NOT plug in if carton has been wet.
4. POWER PACK AND CELL INSTALLATION
9
4.3 Installation Diagram
A LWAYS ensure that pipe work and equipment do not allow gases generated from the cell to collect and
build up in any part of the installation.
It is RECOMMENDED that the Cell Housing be installed horizontally to create a natural gas trap that acts as
a safety device. Installation in any other way may cause explosion, injury or death if the installer does not
allow for gas removal. A venturi pipe is installed/moulded within the Cell Housing design to eliminate any
possible gas build up, although it is always recommended to ensure proper installation to eliminate this
from happening.
The Cell Housing must be installed in the RETURN pipework to the pool. It must always be installed after
, gas heater, solar heating or heat pump.
DO NOT ell Housing, it is not needed and may react with the plastic.
Saltwater may damage electrical components in the Power Pack.
WARNING:
Important Notes:
The pump rating must not exceed 8amps.
We DO NOT recommend the use of valves on the inlet or outlet of the cell housing. If you do use a valve
then it is important to ensure that the valve cannot deadhead (lock closed) while the pump is running. It is
the installers responsibility to ensure some f w control is installed in this instance and it disables
the pump.
www.crystalas.com
WITH UNIONS
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

5. INITIAL START UP OF YOUR UNIT
10
5.2 Start Up Clock Set
essing [+] will increase the time and pressing [-] will decrease
the time.
[-] will decrease the time.
essing [+] will increase the time and pressing
Pressing [OK] saves the selected hour HH and MM.
Pressing [<] skips this menu however you will need to set this later.
Pressing [OK] saves the selected hour HH and MM.
Pressing [<] returns you to the previous menu screen.
START UP CLOCK SET allows you to program the exact time of the day.
5.1 Initial Start Up
On initial start up of your VAPURE VP-Series Salt Chlorinator the screen
to the right will be displayed.
5.3 Start Up Run Period
1: 2 CYCLES/DAY - unit runs from 6am-10am and 4pm-8pm
Pressing [<] returns you to the previous menu screen.
START UP RUN PERIOD allows you to program your daily run times.
2: 1 CYCLE AM - unit runs from 8am - 4pm
3: 1 CYCLE PM - unit runs from 8pm-4am
Pressing [OK] saves the selected PERIOD
2 CYLCLES/DA essing [+] or [-] will change the selection.
PERIODS of running.
5.4 Start Up Information
START UP INFORMATION allows you to customise the unit to your pool size.
Holding the [+] or [-] in will change it in 5,000lt increments.
[OK] and set this later or contact your local pool Professional for further assistance.
Pressing [+] or [-] will change it in 1,000lt increments.
A r w it can be changed.
Pressing [OK our selection. If you do not know your pool size you can press
Pressing [<] returns you to the previous menu screen.
www.crystalas.com
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

5. INITIAL START UP OF YOUR UNIT
11
5.5 Mineral or Salt Mix
The reason for this is because a higher salt reading is required for MINERALS to be as
conductive as SALT.
Pressing [+] or [-] will change it from SALT to MINERAL MIX.
MINERAL OR SALT MIX allows you to enter the type of mineral used in the pool.
Pressing [<] returns you to the previous menu screen.
Pressing [OK our selection.
5.6 Default Display Screen
This should always remain at 100% unless SPA MODE has been selected.
reverse dir
The (●) symbol indicat
The cell status shows as FWD when the cell is in the forward dir
The pump AC socket status is displayed, either ON or OFF.
Any power failures return you to the DDS screen and the last sav e.
ed.
s with HH:MM in 24hr clock format.
ON or OFF).
DEFAULT DISPLAY SCREEN (DDS) displays the screen to the right. This is the actual
Pressing [+] or [-] will incr een will change as seen on the right.
The Mode shows AUTO and this can be changed by pressing Power/Mode (either AUTO,
The Water Temperature is diplayed.
T2 is the def ying "Dual Timer Cycle" and T1 displays "Single Timer Cycle"
output % of the unit.
www.crystalas.com
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

6. CONTROL PANEL OPERATION
12
6.1 OK BUTTON
11 Service Menu
9 Pump Setting
10 Salt Test
8 Power/Mode
12 Spa Mode
Menus are entered by either pressing the menus shortcut button on the control panel
or by entering MAIN MENU,which is done by pressing the [OK] button.
Any inactivity in any display for longer than 60 seconds results in the display returning
to the DDS screen.
MAIN MENU allows you to enter all MENU's including those available with
shortcut buttons on the control panel.
Pressing [+] takes you to the last menu and using the [-] or [OK] enters the
firt  menu
Pressing [<] returns you to the previous menu screen.
reing  or  roll up or don and  enter the ahing menu
See 7.0 for the workings of any menu's not explained here.
2 Brightness
4 Chlor Boost
1 Backwash
Below are the available menus in the VAPURE VP-Series Salt Chlorinator.
 ell leaning
www.crystalas.com
POWER/MODE
CHLOR BOOST
WINTER MODE
CLOCK/TIMER
SALT TEST
FILTER CLEAN
 inter ode
5 Chlor Setting
6 Clock/Timer
7 Contrast
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

6. CONTROL PANEL OPERATION
13
6.2POWER/MODE
Pressing [<] returns you to the DDS screen.
[POWER] button changes the operating modes of your
wered on the factory setting is in AUTO as shown to the right.
Pressing [<] returns you to the DDS screen.
Press [OK] to enter POWER/MODE.
Pressing [OK] enters the display shown to the right and pressing the [+] or
Pressing [OK] saves the required mode and returns to the previous screen.
Pressing [POWER] to ON will display the screen as seen to the right.
Pressing [OK] from the DDS screen enters the MAIN MENU.
VAPURE VP-Series Salt Chlorinator.
When pressed the Mode will change AUTO to OFF then ON.
Pressing [POWER] to OFF will display the screen as seen to the right
Pressing [+] takes you to the last menu and using the [-] or [OK .
Pressing [+] 5 times above displays the display shown to the right.
Pressing [+] takes you to last menus.
[-] allows you to adjust the POWER/MODE setting from AUTO to OFF to ON.
6.3 CHLOR BOOST
to operate for 8hrs and automatically sets the chlorine setting to 100%.
Super-Chlorinate. The bottom line will alternate between "[CHLOR BOOST] to END"
This allows for an injection of extra sanitising time, also know as Chlorine Boost or
and the fault message if there is any fault during CHLOR BOOST.
Two digits 08 wn to the right.
Pressing [+] or [-] increases or decreases in increments of 01:00 hrs whilst running.
When completed the unit will return to the DDS screen in the last selected POWER/MODE state
and the CHLOR BOOST LED goes OFF.
Pressing [BOOST ] again allows you to exit the CHLOR BOOST screen and return to the DDS screen.
CHLOR BOOST can also be entered by pressing the [OK] button in MAIN MENU and scrolling to
CHLOR BOOST.
BEFORE ENTERING CHLOR BOOST YOU MUST BE IN THE DDS SCREEN.
[ BOOST ] button sets your VAPURE VP-Series Salt Chlorinator and pump
When in operation the LED will be on. After the set time it reverts back to last selected
POWER/MODE unless ON then it reverts to AUTO.
The unit automatically defaults to 08:00 hours of ON time and the timer starts counting down
immediately.
www.crystalas.com
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

14
6. CONTROL PANEL OPERATION
6.4 WINTER MODE
Chlorinator set point (Chlor Setting) down by 50% when the unit is either in AUTO
[WINTER MODE] button automatically turns your VAPURE VP-Series Salt
or ON mode. The unit defaults to a 50% set point and will stay on this until [WINTER MODE] is pressed again.
When in operation the LED will be on.
Pressing [+] or [-] increases or decreases this 50% set point by increments of 10% from 0% to 90%.
Once your desired set point is entered, pressing [OK] will return to the DDS screen and the output will display at the
lower erent if you set it to that).
Pressing [ eturns to a set point of 100%.
Pressing [TIMER] will allow you to adjust operating times of the unit if necessary. See 6.5 CLOCK/TIMER for more
detail or contact your local pool Professional for further assistance.
WINTER MODE can also be entered by pressing the [OK] button in MAIN MENU and scrolling to WINTER MODE.
BEFORE ENTERING WINTER MODE YOU MUST BE IN THE DDS SCREEN.
BEFORE ENTERING CLOCK/TIMER YOU MUST BE IN THE DDS SCREEN.
Your VAPURE VP-Series unit comes with a built in digital timer.
CLOCK /TIMER displays are all shown in 24 hour format.
[TIMER] button allows you to set the CLOCK and run TIMER times of the chlorinator .
It is important to understand the difference between CLOCK and TIMER CLOCK means the physical time
of the day (e.g. 08:00) and TIMER means the settings progammed to turn the unit ON and OFF
To run the chlorinator in MANUAL ON (i.e. always ON):
Mode set to: ON
T1 & T2 ON & OFF set to 00:00
6.51 Clock Settings
CLOCK SETTING allows you to program the exact time of the day.
 digit ah and preing  inreae the time and  dereae the time
reing  aept the eleted hour 
reing  return you to the preiou diplay
 digit ah and preing  inreae the time and  dereae the time
reing  aept the eleted minute 
reing  exits you to the  reen
Obviously sunlight and higher bather loads in summer dissipate more chlorine than in winter . That is why you need
to check your chlorine reading regularly and adjust your settings when required .
6.5 CLOCK/TIMER
www.crystalas.com
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

Pressing [+] then it changes to Single Timer Cycle (T1).
Pressing [TIMER] displays the screen to the right.
To program the actual time of the day press [TIMER] again.
Pressing [+] changes back to Dual Timer Cycle (T2).
To program the actual time of the day press [TIMER] again.
Pressing [OK] accepts the selected cycle and enters the Timer Program.
 digit ah and preing  inreae the time and  dereae the
time.
Pressing [OK] accepts the selected hour HH.
TIMER 1: ON TIME (HH)
Pressing [<] returns you to the previous display.
Pressing [OK] accepts the selected cycle and enters the Timer Program.
TIMER 1: ON TIME (MM)
Pressing [OK] accepts the selected minute MM.
Pressing [<] returns you to the previous display.
TIMER 1: OFF TIME (HH)
 digit ah and preing  inreae the time and  dereae the
time.
Pressing [OK] accepts the selected hour HH.
MM digit ah and preing  inreae the time and  dereae the
time.
Pressing [<] returns you to the previous display.
TIMER 1: OFF TIME (MM)
MM digit ah and preing  inreae the time and  dereae the
time.
TIMER 2: ON TIME (HH)
 digit ah and preing  inreae the time and  dereae the
time.
Pressing [OK] accepts the selected hour HH.
Pressing [<] returns you to the previous display.
Pressing [OK] accepts the selected minute MM.
Pressing [<] returns you to the previous display.
you can run less hours. In extreme weather it may be necessary to run longer hours. Contact your local pool
Professional for further assistance.
Winter Settings See 6.4 WINTER MODE for more detail
Summer Settings
Ideally, run for 4 hours in the morning (6am-10am) and 4 hours in the evening (4pm-8pm). For a smaller pool
www.pentair.com 15
15
www.crystalas.com
6.52 Timer Settings
6. CONTROL PANEL OPERATION
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

16
6. CONTROL PANEL OPERATION
6.6SALT TEST
The LCD display then automatically returns to the DDS.
BEFORE ENTERING SALT TEST YOU MUST BE IN THE DDS SCREEN.
[ TDS TEST] button measures the salt level in your swimming pool. A reading will appear on the screen, allow at least
30 seconds for an accurate reading.
BEFORE PERFORMING A SALT TEST, ENSURE THE CELL IS CLEAR OF ANY CALCIUM DEPOSITS, AS THIS WILL
INSULATE THE ELECTRODES AND IMPACT YOUR READINGS. See 9.1 Inspecting and Cleaning the Cell Electrode
if manual cleaning is required.
The Salt level is tested and displayed as shown to the right.
Pressing [ TDS TEST] brings up the screen to the right for 6 seconds. This allows for the
The screen automatically then brings up the FWD direction TDS range for you to
record, as per the screen to the right for 5 seconds.
The screen automatically then brings up the CELL DISCHARGING which allows
testing of the TDS range.
the cell to loose its charge in the FWD direction, as per the screen to the right.
The screen to the right displays allowing for the testing of the TDS range.
The screen automatically then brings up the REV direction TDS range for you to record,
as per the screen to the right for 5 seconds.
Low salt levels (below 1000ppm) and high salt levels (above 8000ppm) ar e and results may
become inaccurate. It may be that your cell needs replacing, contact your local pool Professional for a more accurate
result and further assistance.
The SALT TEST measurement is meant to be a guide only as many factors can impact the result. We recommend
you take your pool water sample to your local pool Professional before adding salt/minerals or replacing your Cell.
NEVER add more salt if not required. NEVER add salt directly in the skimmer box.
SALT TEST can also be entered by pressing the [OK] button in MAIN MENU and scrolling to SALT TEST.
www.crystalas.com
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

17
6. CONTROL PANEL OPERATION
BEFORE ENTERING BACKWASH MODE YOU MUST BE IN THE DDS SCREEN.
ALWAYS FOLLOW MANUFACTURERS INSTRUCTIONS.
[FILTER CLEAN] can also be entered by pressing the [OK] button in the MAIN MENU and scrolling to
BACKWASH MODE.
IF UNSURE PERFORM MANUALLY BY PRESSING [POWER] ON&OFF TO
DO THE FILTER CLEAN.
During BACKWASH the [POWER] button displays the ON LED when the pump is
running and the OFF LED displays when the pump is stopped.
Pressing [OK] starts the pump for 2minutesand TIME LEFT will be displayed
Pressing [<] or [FILTER CLEAN] allows you to exit and this takes you to
BACKWASH COMPLETE.
Pressing the [OK] button starts the pump for 2minutes.
automatically counting down in 1 sec increments.
Pressing [OK] stops the pump and RINSE MODE is displayed.
TIME LEFT automatically starts counting down in 1 sec increments.
RINSE MODE will then be displayed.
otate the filter multiport ale to the aah poition, enure the
handle locks in place and once ready press [OK] to enter the RINSE MODE
cycle.
Once dirty water in the waste pipe or sight glass is clear then press [OK] to
finih   and enter   
ne dirty ater in the ate pipe or ight gla i lear pre  to finih
plae and one ready pre  to enter the final  
cycle.
Pressing [OK] stops the pump and BACKWASH COMPLETED is displa yed.
otate the filter multiport ale to the filter poition, enure the handle
locks in
6.7 BACKWASH
NEVER OPERATE THE FILTER LEVER WHILE THE PUMP IS RUNNING YOU MAY
DAMAGE THE SEAL AND LEAKS MAY OCCUR.
THE PUMP WILL START AND STOP AS YOU REQUIRE.
   ,  , , ,    
IMPORTANT INFORMATION BEFORE PERFORMING A BACKWASH.
[ utton ait you in the operation o your pump and filter during the aah proe
www.crystalas.com
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

7. UNIT MENU GUIDE
18
7.2 Brightness
7.1 Backwash
BRIGHTNESS (Menu 2).
Pressing [+] or [-] allows you to adjust the BRIGHTNESS. Pressing [OK] saves the
BRIGHTNESS is entered by pressing the [OK] button in the MAIN MENU and
scrolling to
The factory setting is 60%.
7.4 Chlor Boost
7.3 Cell Cleaning
(for high calcium areas) and as high as 16 hours.
The factory setting is every 10 hours and this can be adjusted from as low as 4 hours
In areas where the calcium hardness of the water is low (less than 200ppm) cleaning of the cell may
not be
acid solution may be necessary.
necessary. Where calcium levels exceed 200ppm, regular inspection of the cell is necessary.
Cleaning in an
CELL CLEANING is entered by pressing the [OK] button in the MAIN MENU and scrolling to CELL
See 6.7BACKWASH (CONTROL PANEL OPERATION)
See 6.3 CHLOR BOOST (CONTROL PANEL OPERATION)
www.crystalas.com
Smart self-cleaning technology allows the polarity of the OXI Cell plates to
change direction every 4-16hrs (depending on your setting). The change
of polarity causes the calcium to dislodge and keep the OXI plates clean.
Please note occasional cleaning of the plates may be necessary.
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

7. UNIT MENU GUIDE
19
7.6 Clock/Timer
See 6.5 CLOCK/TIMER (CONTROL PANEL OPERATION)
7.7 Contrast
Pressing [+] or [-] allows you to adjust the CONTRAST adjustment and
pressing [OK] saves the required CONTRAST and returns to the DDS screen.
The factory setting is 50%.
CONTRAST is entered by pressing the [OK] button in the MAIN MENU and
scrolling to CONTRAST (Menu 7).
7.8 Power/Mode
See 6.2 POWER/MODE (CONTROL PANEL OPERATION)
7.9 Pump Setting
PUMP SETTING (Menu 9).
You can also select OFF and it will be disabled and will not stop the pump outlet.
PUMP SETTING is entered by pressing the [OK] button in the MAIN MENU and scrolling to
The default setting is 3 minutes and pressing [+] or [-] allows you to adjust the time the pump is
turned off for. Pressing [OK] saves the required protection time.
7.5 Chlor Setting
CHLOR SETTING automatically controls the Chlorine output for your VAPURE VP-Series Salt Chlorinator.
This feature is particularly handy when you want to run the pump for longer hours (i.e. maybe with a variable speed
pump or y f this is the case the levels would be decreased.
The factory setting is set to 100%.
Pressing [+] or [-] anytime whilst in the DDS screen increases or decreases in 1% increments.
CHLOR SETTING is entered by pressing the [OK] button in the MAIN MENU and scrolling to CHLOR SETTING (Menu 5).
www.crystalas.com
enor on the ell detet there i no o o ater he pump ill e
PUMP SETTING is designed to protect your pump i there i no o o
water. This means the time the pump is allowed to run after the water
turned off from 3 to 1 minute, ater deteting no ater o
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea

7. UNIT MENU GUIDE
7.11 Service Menu
7.10 Salt Test
Please contact your distributor or your local pool Professional for further
See 6.6 SALT TEST (CONTROL PANEL OPERATION)
7.13 Winter Mode
See 6.4 WINTER MODE (CONTROL PANEL OPERATION)
7.12 Spa Mode
SPA MODE (Menu 12).
Pressing [+] or [-] allows you to adjust the SPA MODE settings from OFF to ON
SPA MODE allows your unit to be adjusted to suit your spa.
SPA MODE is entered by pressing the [OK] button in the MAIN MENU and scrolling to
and ON to OFF.
Selecting OFF setting leaves the OUTPUT SETTING at 100% and ON changes
the OUTPUT SETTING to 10%.
When SPA MODE is selected on the DDS screen will change as shown to the right.
Pressing [OK] saves the required settings and returns to the DDS screen.
20 www.crystalas.com
65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea65a010a5-6d71e2d3-6b3148b4-770d42ea
