CSG270M2-35/1956×992 series
Pleasereadthismanualcompletelybeforeinstallingorusingthesolarmodule

INSTALLATION MANUAL
Southern Glass Green Energy Industrial Park,
Xinji Village, Machong Town, Dongguan, China.
Tel: [phone] Fax: [phone]
www.csgpvtech.com
I. INTRODUCTION
This manual contains information of electrical and mechanical installation and safety information which you should
know before using CSG270M2-35/1956х992 series，CSG230M2-30/1640×992 series，CSG205M2-26/1482×992 series，
CSG180M2-24/1324×992 series and CSG135M2-17/1482×674 series photovoltaic modules. This manual will show you how
to install the Photovoltaic Module.
Please read carefully this manual thoroughly before starting the installation.
The information in this manual is described on the basis of CSG PVTech’s knowledge and experience. But such
information and suggestions do not constitute a warranty. CSG PVTech reserves the right to make changes to the
product, specifications, or to the manual without prior notice.
II. APPEARANCE
The appearances and dimensions of the modules are as follows:
Series Power of each module Dimensions Fig. NO.
CSG270M2-35/1956х992 280W，275W，270W，265W，260W，255W，250W 1956mm(L) x 992mm(W)x 50mm(H) Fig. 1-a
CSG230M2-30/1640×992 230W，225W，220W，215W，210W 1640mm(L) x 992mm(W)x 45mm(H)
CSG205M2-26/1482×992 205W，200W，195W，190W，185W 1482mm(L) x 992mm(W)x 45mm(H)
CSG180M2-24/1324×992 180W，175W，170W，165W，160W 1324mm(L) x 992mm(W)x 45mm(H)
CSG135M2-17/1482×674 135W，130W，125W，120W，115W 1482mm(L) x 674mm(W)x 45mm(H)
Each module has eight 8mm diameter mounting holes at the aluminum frames using for fixed the modules to the
supporting structure. There is one terminal box installed on the back of module, two cables were lead out from the
box and with a connector at the end of each cable.
Fig. 1-a CSG270M2-35/1956*992 series solar module
