CSI MW-50H User manual

SINGLE CHANNEL WIRELESS MICROPHONE SYSTEM
With Lapel and Headset (MW-50L
With Handheld Microphone (MW-50H
• VHF HIGH BAND DUAL-CHANNEL WIRELESS
RECEIVER SYSTEM
• FREQUENCY QUARTZ LOCKED CONTROLLED
• COMPACT, LIGHTWEIGHT SINGLE-CHANNEL
RECEIVER
• LED POWER INDICATOR AND TELESCOPIC
ANTENNA
• SPECIAL CIRCUIT FOR EXTENDING
DYNAMIC RANGE
• SPECIAL CIRCUIT DESIGN TO ELIMINATE
MICROPHONE SWITCH ON/OFF NOISE
• AUDIO OUTPUT CABLE WITH
XLR BALANCED AND MONO
1/4” PHONE PLUG UNBALANCED
RECEPTION MODE Non-diversity model
FREQUENCY BAND VHF high-band 160-245MHz
FREQUENCY STABILITY +/- 0.005% at/25°C
MODULATION MODE FM (F3E
MAX DEVIATION +/- 40KHz w/limiting compressor
T.H.D. <0.8%
DYNAMIC RANGE >100dB
S/N RATIO >80dB
FREQUENCY RESPONSE 50Hz-15KHz
RECEIVING MODE Quartz controlled fixed frequency
SQUELCH External noise control
OUTPUT CONNECTORS 1. XLR Balanced (CH-1 & CH-2
Independent
2. 6.3mm (1/4” mono phone
jack unbalanced (Mixed
POWER SUPPLY 12V DC~300 mA with AC/DC
Power supply included
DIMENSIONS 1-1/2”H x 4-1/2”W x 11-1/2”D
WEIGHT 1 lb. 5oz.
Specifications subject to change without notice.
MW-50H/MW-50L
CSI/SPECO
200 NEW HIGHWAY • P.O. BOX 726 • AMITYVILLE, NEW YORK 11701-0726
TOLL FREE (800 645-5516 • IN METRO NY (631 957-8700 • FAX [phone] OR (631 957-3880
VISIT OUR WEBSITE AT WWW.CSI-SPECO.COM
VHF Frequencies:
Channel A: 171.90 MHz
Channel B: 184.54 MHz
Channel D: 209.82 MHz
Channel F: 203.30 MHz
THE CSI PRODUCT
LINE INCLUDES:
• Professional Series PA Amplifiers
• In-Wall Speakers
• Weatherproof Outdoor Speakers
• Video Door Phone Systems
• Volume Controls
• FM/AM Tuners
SPECIFICATIONS
FEATURES
