CTC Union IMC-100-PD User manual

Installation
IMC-100-PD(-E) comes with both wall mount and DIN rail
hardware brackets. When installing the DIN rail bracket, be sure
to correctly align the orientation pin.
Figure 6. DIN Rail Figure 7. Wall Mount
IMC-100-PD(-E) with DIN Rail bracket has a steel spring in the
upper rail of the bracket. This spring is compressed for mounting
and un-mounting by applying downward force.
Figure 8. Mounting Figure 9.Un-mounting
Introduction
IMC-100-PD(-E) are Fast Ethernet PoE PD (Powered Device)
media converters that not only support conversion between
electrical 10/100Base-TX and optical 100Base-FX Ethernet but
also support IEEE 802.3af standard for PoE, enabling PD to obtain
its power over a designated powered device port. Housed in
rugged DIN rail or wall mountable enclosures, these converters
are designed for harsh environments, such as industrial
networking and intelligent transportation systems (ITS) and are
also suitable for many military and utility market applications
where environmental conditions exceed commercial product
specifications. Standard operating temperature range models
(-10°C to 60°C) and wide operating temperature range models
(-40°C to 75°C) fulfill the special needs of industrial automation
applications.
Features
Redundant dual DC inputs 12/24/48VDC
IP30 rugged metal housing
Wide temperature range -40°C ~75°C (IMC-100-PD-E)
Switch/converter mode setting
Industrial grade EMS, EMI, UL60950-1, EN50121-4,
EN61000-6-2, EN61000-6-4
Specifications
Ethernet Interface
Standards: IEEE802.3, 802.3u, 802.3x, 802.3af
Connector: RJ-45 (shielded)
Speed: 10/100Base-TX (Auto/Forced by DIP)
Duplex: Full/Half (Auto/Forced by DIP)
Flow Control: 802.3x (by DIP)
Store & Forward Switch/Pass through converter (by DIP)
1024 MAC table (in switch mode)
MTU: 2046 bytes (switch mode)/9600 bytes (converter mode)
Link Fault Pass Through (LFP) (enable/disable by DIP)
Optical Interface
100Base-FX
Options for SC or ST connectors
Multimode (2km) 50/125um, 62.5/125um
Single mode (30km or 50km) 9/125um
Wavelength: 1310nm (S/M or M/M)
BiDi option (20km) for Single mode single fiber
Quick Installation Guide
IMC-100-PD
IMC-100-PD (Hardened)
Industrial Grade Fast Ethernet PoE PD Media Converters
Specifications (cont.)
Power
Absolute Range: 9.6VDC~58VDC
Reverse Polarity Protection: Yes
Dual Power Inputs: Yes
Connector: Removable terminal block
Consumption: 2.9W
Mechanical
Water & Dust Proof: IP30 Protection
Dimensions: 106 mm (D) x 39 mm (W) x 142 mm (H)
Mounting: DIN-Rail, Wall Mount (Kits included)
Weight: 720 g (1.5 lb)
Environmental
Operating Temperature: -10°C~60°C (IMC-100-PD)
-40°C~75°C (IMC-100-PD-E)
Storage Temperature: -40°C~85°C
Humidity: 5%~95% (Non-condensing)
Certifications
EMC: CE
EMI (Electromagnetic Interference): FCC, FCC Part 15 Subpart
B Class A, CE EN55022 Class A
Railway Traffic: EN50121-4
Immunity for Heavy Industrial Environment: EN61000-6-2
Emission for Heavy Industrial Environment: EN61000-6-4
EMS (Electromagnetic Susceptibility) Protection Level:
EN61000-4-2 (ESD) Level 3, Criteria B
EN61000-4-3 (RS) Level 3, Criteria A
EN61000-4-4 (Burst) Level 3, Criteria A
EN61000-4-5 (Surge) Level 3, Criteria B
EN61000-4-6 (CS) Level 3, Criteria A
EN61000-4-8 (PFMF, Magnetic Field) Field Strength:
300A/m, Criteria A
Safety: UL60950-1
Shock: EN60068-2-27
Freefall: EN60068-2-32
Vibration: EN60068-2-6
MTBF: 852,727 hours (MIL-HDBK-217)
V1.0
- 2 -
[email protected]
- 7 -
- 1 -
To download this QIG or a more complete user manual, please visit
http://www.ctcu.com/Industrial/
T+886-2-26591021
F+886-2-26590237
E[email protected]
CTC Union Technologies Co., Ltd.
Far Eastern Vienna Technology Center
(Neihu Technology Park)
8F, No. 60 Zhouzi St., Neihu District, Taipei 114
Taiwan
© 2014 CTC Union Technologies Co., Ltd.
All trademarks are the property of their respective owners.
Technical information in this document is subject to change without notice.
www.ctcu.com

Connectors
Figure 1. Front Panel
FIBER and LAN Connection
IMC-100-PD(-E) unit has fixed optical transceiver options for
connector types of ST or SC. The LAN connection uses a shielded
RJ-45 which supports Auto MDI/MDI-X. Configuration settings are
accomplished via a 6-pole DIP (dual inline package) switch. Please
see the page 5 for the settings of the operation mode switch.
RJ-45 Ethernet Port Pinouts
Figure 2. RJ-45 Ethernet Port Pinouts
RJ-45 PoE Pin Assignments
Pin No.
RJ-45 Ethernet
100Base-TX
PoE Input
1
RX+
2
RX-
3
TX+
4
-
V+
5
-
V+
6
TX-
7
-
V-
8
-
V-
Operation Mode Switch
IMC-100-PD(-E) uses a 6-pole DIP switch for configuration.
DIP
No.
Status
Function
Description
1
OFF *
Auto
Nway auto-negotiation of the TP port.
ON
Force
Manual forced mode. Before
configuring the speed and duplex
settings, this DIP switch must be ON.
2
OFF *
100
Force TP port speed to 100M (DIP No.
1 must be ON).
ON
10
Force TP port speed to 10M (DIP No. 1
must be ON).
3
OFF *
Full
Force TP port to Full Duplex (DIP No. 1
must be ON).
ON
Half
Force TP port to Half Duplex (DIP No. 1
must be ON).
4
OFF *
Disable LFP
Disable LFP (Link Fault Pass through).
ON
Enable LFP
LFP (Link Fault Pass through) allows a
link condition to be passed from fiber
to TP or from TP to fiber. LFP is only
available when the converter is set to
'Switch' mode (DIP No. 6 is OFF) and
'Auto' negotiation (DIP No. 1 is OFF).
5
OFF *
Disable Flow
Control
Disable flow control.
ON
Enable Flow
Control
Enable flow control.
6
OFF *
Switch Mode
In Switch mode, the device acts as a
store & forward device supporting
MAC learning and filtering with MTU
of 2046 bytes.
ON
Pass
Through
Mode
The device acts as pure 'converter'
that the internal switch is bypassed,
enabling low latency and jumbo frame
support. Do not enable LFP in this
mode or fiber may not link.
NOTE 1: By default, all DIP switches are set to OFF (marked with *).
NOTE 2: After changing the DIP switch setting, you must restart the device to
activate the setting.
Power & Alarm
IMC-100-PD(-E) can be either powered by PWR1 or PWR2 on
the terminal block or an active PSE (Power Source Equipment).
For RJ-45 PoE Pin Assignments, please refer to the page 3.
PWR1 & PWR2 Power Inputs
On the terminal block, there are input connectors for two
power sources (PWR1 & PWR2). Only one power source is
required for normal operation. The second power source input
may be provided for redundancy.
PoE Powered
When IMC-100-PD(-E) unit is being powered from PoE source,
the unit will be entirely powered by PoE and no power taken from
the PWR1 or PWR2 inputs. If PoE source should fail, the unit will
automatically switch to using power from the PWR1 and PWR2
DC source connections, if available.
Alarm Relay Contact
The Alarm is one electrical relay that can be wired into an alarm
circuit and is triggered in the event of either link loss for optical or
electrical or both. From the common pin (COM), the relay can be
connected as Normally Open (NO) or Normally Closed (NC). When
an alarm occurs NO-to-COM circuit closes and the COM-to-NC
circuit opens. See Figure 4 and 5 for normal and fault illustration
in each alarm relay type. Please note that the alarm relay contact
can only support 1A current at 24VDC. Do not apply voltage and
current that exceed these specifications.
LED Indicators
LED
Color
Definition
PWR1/
PWR2
Green
Power is connected and active at the
PWR1/PWR2 input terminal connection.
Off
Power is not connected.
Fault
Red
Lit if the fiber or TP have any fault
condition.
Off
No fiber or TP faults.
Fiber
Green
Fiber port has optical link.
Blinking
Blinking when there is data traffic.
Off
No optical link.
100
Amber
LAN connected speed is 100M.
Off
LAN connected speed is 10M.
LAN
Green
LAN port has a link.
Blinking
Blinking when there is Ethernet traffic.
Off
No Ethernet link.
PoE
Green
LAN is connected to an active PSE
(power source equipment) such as PoE
capable switch.
Off
LAN is not connected to an active PSE.
Application
- 4 -
- 3 -
1 2 3 4 5 6
- 6 -
Figure 7. IMC-100-PD Application Diagram
Figure 6. DIP Switch
Figure 3. Terminal block
Figure 5. Alarm Relay for NC (Normally Closed) Type
Normal
Fault
COM
NC
COM
NC
Figure 4. Alarm Relay for NO (Normally Open) Type
Fault
Normal
COM
NO
COM
NO
- 5 -
