ADTRAN 401 1 GE Micro ONT User manual

Q
uick Star
t
DESCRIPTION
The ADTRAN 401 1 GE Micro ONT is an Optical Network
Terminal (ONT). It is a member of the Micro ONT family
supporting auto-detection of Active Ethernet and GPON network
connections for use in point-to-point and point to-multipoint optical
distribution networks (ODNs).
Figure 1 illustrates the key features on the Micro ONT.
Figure 1. Micro ONT Key Features
The table opposite provides descriptions for each feature number
above.
LAN
FIBER
POWER
2
1
3
5
4
Fiber (FIBER)
GPON/Active Ethernet is supplied to the Micro ONT using an SC/
APC Fiber connection located on the rear of the unit.
Ethernet Interface (LAN)
The Micro ONT supports data service through one 10/100/
1000BASE-T Ethernet interface.
Power
The power feed is +12 VDC from the included AC to DC Adapter.
The adapter plugs into the PWR connector. The total power
consumption is approximately 5 watts.
ONT Reset (RESET)
Refer to Figure 1 for the location of the Reset button.
Reset the Micro ONT if you need to reboot the unit. The RESET
button is accessed through an opening on the bottom of the unit.
To reset the Micro ONT, insert a small pin (paper clip) into the
RESET opening and hold the button down for 10 seconds.
The Micro ONT will automatically download the latest provisioning
after the reset process has completed.
INSTALLATION
Before installing the Micro ONT, inspect it for damage. If damage
has occurred during shipping, file a claim with the carrier and then
contact ADTRAN. For more information, refer to the warranty.
Installation Guidelines
The following are guidelines for this installation.
■Read all warnings and cautions before installing or servicing
the Micro ONT.
■Do not locate the Micro ONT in direct sunlight or next to any
thermal obstructions.
■When the SC/APC fiber connection is not in use, replacing the
Protective Cover will help keep the optical connection clean.
■This product should not come in contact with water or other
liquids.
Number Feature
1 Single GPON and Active Ethernet fiber interface with
1.244 Gbps upstream and 2.488 Gbps downstream
2 10/100/1000BASE-T Ethernet Interface (LAN)
3 AC Power Adapter Input
4 Status LEDs
5 Reset Button
ADTRAN 401
Micro ONT
1 GE
September 2020
61287786F1-13A
P/N: 1287786F1

261287786F1-13A
The Micro ONT supports a 1 Gbps (10/100/1000BASE-T)
connection (LAN).
Refer to Figure 1 and insert a Category 5e or better Ethernet
cable in the LAN Port.
Step 3: Connect Fiber
Do not view directly with optical instruments.
This product contains a Class 1 Laser module that complies with
21 CFR 1040.10 and 1040.11 and IEC 60825-1.
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
Fiber is installed in an SC/APC connector (FIBER) located on the
rear of the Micro ONT (see Figure 1).
Complete the following steps to install fiber.
1. Refer to Figure 2 and remove the protective cover from the
SC/APC Connector.
Figure 2. SC/APC Protective Cover
2. Clean the ends of the incoming fiber patch cord.
3. Before installing the fiber, use an optical power meter to
measure the power level. The power level should not
exceed –8.0 dBm. Use an appropriate bi-directional optical
attenuator if the power levels are at or above –8.0 dBm. A
level between –8.0 dBm and –27.0 dBm is acceptable, but
levels between –12.0 dBm and –18.0 dBm are optimal.
4. Refer to Figure 3 and connect the incoming fiber patch cord.
Figure 3. Fiber Installed
gNOTE
When the SC/APC fiber connection is not in use, replace the
protective cover. This will help keep the optical connector clean.
SC/APC
Connector
Protective
Cover
3.625 x 3.625
Incoming Fiber
Patch Cord
Installation Overview
To install the Micro ONT, you will need to complete the following
steps:
■Step 1: Position the Micro ONT
■Step 2: Connect Ethernet
■Step 3: Connect Fiber
■Step 4: Connect 12 VDC Power
Required Tools
Standard technician tools and those listed below are required for
installing the Micro ONT.
■Optical power meter with wavelength filtering
■Fiberscope or videoscope
For fiber optic connections, the following is required:
■ODC Fiber cleaning tool
Installation Steps
To install the Micro ONT, complete the following steps.
Step 1: Position the Micro ONT
The Micro ONT can be mounted on a wall, or on a desk top.
Wall Mount Installation
To wall mount the Micro ONT complete the following steps:
gNOTE
Refer to Figure 1 when installing the Micro ONT on a wall.
1. Determine a location for the Micro ONT.
2. Use the key holes (2 inches apart) on the back of the Micro
ONT as a template and install two #6 drywall anchors.
3. Install two #6 pan head screws. Leave approximately 1/4
inch protruding from the mounting surface.
4. Slide the Micro ONT over the pan head screws and exert a
small amount of downward pressure to ensure that the top of
the slots are resting on the shafts of the pan head screws.
Desk Top Installation
The Micro ONT can be located on a desk top. Ensure the Micro
ONT is not located in direct sunlight, next to any thermal obstruc-
tions, sources of moisture, or liquids.
Step 2: Connect Ethernet
fCAUTION!
The product is intended for indoor use only. Ethernet cable and
attached equipment are intended for use within the same building
with equipotential bonding, and not intended to be placed in
separate buildings or structures. Failure to deploy as described
could result in permanent damage from lightning or other
electrical events and voids the warranty.

61287786F1-13A 3
Step 4: Connect 12 VDC Power
Refer to Figure 1 and the following steps when connecting power.
The Micro ONT is powered by a 12 VDC connection.
12 VDC Connection
To power the Micro ONT, complete the following steps:
1. Plug the supplied 12 V AC/DC power converter into the PWR
connection.
2. Connect the power plug to a standard AC outlet. This
immediately turns the unit ON.
LED STATUS
The LEDs are located beneath the plastic housing and are only
visible after power has been applied. The following table provides
the LED status during normal operations.
Label Status Indication
LAN 

2
Off
Green
Green Flashing
Fast
LAN Port is not connected
LAN Port is connected, but
data is not being transmitted
LAN Port is connected, and
data is being transmitted
FIBER 

2
Off
Green
Green Flashing
Fast
ONT is not active (not Ranged)
ONT is active (Ranged)
ONT Is Activating (Ranging is
progress)
POWER 

Off
Green
ONT power is Off
ONT power On
TROUBLESHOOTING
The following table provides troubleshooting tips.
Problem Possible Solution
The FIBER LED contin-
ues flashing Green
■Use an optical power meter to check
the receiving power to see if it between
–27 dbm and –8 dbm.
■Reset the ONT using the Reset button.
If the ONT fails again, replace the ONT
with another unit.
The Power LED is Off ■Make sure the power cable connector
is properly seated in the ONT power
input.
■Verify that the power adapter is
plugged into a live AC outlet.
■Check the power cable for shorts or
breaks.
■Disconnect the power input connector
at the ONT; use a voltmeter to verify
that the proper voltage level is present
on the 12 V pin (power and power
return) from the power adapter.
The LAN LED is green ■During boot-up, the LED will flash
green. This is normal. Once boot-up is
complete, the LED will illuminate solid
green. When data is transmitted, the
LED will flash green. If the LED
remains solid green, contact the
Central Office to verify that the ONT
serial number, password, and vendor
ID match those provisioned in the
database.
■If provisioning is correct, have the
Central Office determine if there are
alarms on the PON feeding the ONT. If
no alarms exist, use an optical power
meter to troubleshoot the fiber
network.

CAUTION!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY
HANDLING PRECAUTIONS REQUIRED
Warranty: ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can be
found online at www.adtran.com/warranty.
Trademarks: Brand names and product names included in this document are trademarks,
registered trademarks, or trade names of their respective holders.
Copyright © 2020 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.888.423.8726
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61287786F1-13A*
SPECIFICATIONS
Specifications for the Micro ONT are as follows:
■Electrical
♦Nominal Input Voltage: 12.0 VDC
♦Minimum Voltage: 10.0 VDC
♦Maximum Voltage: 13.9 VDC
♦Maximum Power Consumption: 5 W
■Optical
♦TX min power: +0.5 dBm
♦TX max power: +5.0 dBm
♦RSSI max sensitivity: –27.0 dBm
♦RX overload: –8.0 dBm
♦TX wavelength: 1310 nm typical
♦RX wavelength: 1490 nm typical
■Physical
♦Width: 2.5 in (6.4 cm)
♦Depth: 2.5 in (6.4 cm)
♦Height: 0.75 in (2.0 cm)
♦Weight: 8 oz (0.23 kg)
■Environmental
♦Operational Temperature: 32°F to +104°F (0°C to +40°C)
♦Storage Temperature: –40°F to 70°F (–40°C to +21°C)
♦Relative Humidity: 5%, noncondensing
MAINTENANCE
The Micro ONT does not require routine hardware maintenance
for normal operation. We do not recommend that you attempt
repairs in the field. Obtain repair services by returning the
defective unit to ADTRAN. Refer to the warranty for further infor-
mation. Field support for software is provided through upgrade
facilities.
SAFETY AND REGULATORY
Refer to the Safety and Regulatory Notice for this product
(P/N 61287786F1-17) for detailed safety and regulatory infor-
mation.
Consultez l'avis sur la sécurité et la conformité à la réglementation
pour ce produit (61287786F1-17) pour obtenir des renseigne-
ments détaillés sur la sécurité et la réglementation.
Ausführliche Sicherheits- und regulatorische Informationen sind in
der Konformitätserklärung zur Sicherheit und Einhaltung von
Normen zu diesem Produkt (61287786F1-17) aufgeführt.
Documentation for ADTRAN Network Solutions products is available for
viewing and download directly from the ADTRAN Support Community
website.
Go to: https://supportforums.adtran.com/welcome
Registration is required.
ADTRAN offers training courses on our products, including customized
training and courses taught at our facilities or at customer sites.
For inquiries, go to: http://adtran.com/training
The following online documents and resources provide additional information for this product:
Total Access 5000 GPON OLT User Interface Guide
Total Access 5000 Series Fiber to the Premises Deployment Guide
