Cub Cadet CSV 070 User manual

CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
OperatOr’sManual
Safe Operation Practices • Set-Up • Operation • Service • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
Form No. 769-11754
(July 15, 2016)
Self Propelled Yard Vacuum/Chipper/Shredder
with Vacuum/Hose — Model CSV 070
NOTE: This Operator’s Manual covers several models. Features may vary by model. Not all features in this manual are applicable to all
models and the model depicted may differ from yours.

Customer Support
Please do NOT return the machine to the retailer or dealer without first contacting the Customer Support Department.
If you have difficulty assembling this product, have questions regarding the controls, operation, or maintenance of this machine, want
to order replacement parts/attachments/accessories, or want to view an online How-To video; you can seek help from the experts. Have
your full model number and serial number ready. Choose from the options below:
◊ Web: www.cubcadet.com/equipment/cubcadet/service-and-parts
◊ Phone: [phone]CUB
◊ Mail: Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019
Thank you for purchasing this product. It was carefully engineered
to provide excellent performance when properly operated and
maintained.
Please read this entire manual prior to operating the equipment. It
instructs you how to safely and easily set up, operate and maintain
your machine. Please be sure that you, and any other persons who will
operate the machine, carefully follow the recommended safety practices
at all times. Failure to do so could result in personal injury or property
damage.
All information in this manual is relative to the most recent product
information available at the time of printing. Review this manual
frequently to familiarize yourself with the machine, its features and
operation. Please be aware that this Operator’s Manual may cover a
range of product specifications for various models. Characteristics
and features discussed and/or illustrated in this manual may not be
applicable to all models. We reserve the right to change product
specifications, designs and equipment without notice and without
incurring obligation.
If applicable, the power testing information used to establish the power
rating of the engine equipped on this machine can be found at www.
opei.org or the engine manufacturer’s web site.
If you have any problems or questions concerning the machine, phone
an authorized service dealer or contact us directly. Customer support
telephone numbers, website address and mailing address can be found
on this page. We want to ensure your complete satisfaction at all times.
Throughout this manual, all references to right and left side of the
machine are observed from the operating position.
Thank You
Record Product Information
Before setting up and operating your new equipment, please locate
the model plate on the equipment and record the information in the
provided area to the right. You can locate the model plate by standing
at the operator’s position and looking down at the rear of the deck. This
information will be necessary, should you seek technical support via our
web site or with your local authorized service dealer.
Model NuMber
Serial NuMber
To The Owner 1
2
Safe Operation Practices ........................................ 3
Assembly & Set-Up .................................................. 5
Controls & Operation.............................................. 7
Product Care ............................................................ 9
Replacement Parts.................................................12
Warranty .................................................................16
Table of Contents

Important Safe Operation Practices 2
3
Training
1. Read, understand, and follow all instructions
on the machine and in the manual(s) before
attempting to assemble and operate. Keep this
manual in a safe place for future and regular
reference and for ordering replacement parts.
2. Be familiar with all controls and their proper
operation. Know how to stop the machine and
disengage them quickly.
3. Never allow children under 16 years of age to
operate this machine. Children 16 and over
should read and understand the instructions
and safe operation practices in this manual
and on the machine and be trained and
supervised by an adult.
4. Never allow adults to operate this machine
without proper instruction.
5. Keep bystanders, pets, and children at least 75
feet from the machine while it is in operation.
Stop machine if anyone enters the area.
6. Never run an engine indoors or in a poorly
ventilated area. Engine exhaust contains
carbon monoxide, an odorless and deadly gas.
7. Do not put hands and feet near rotating parts
or in the feeding chambers and discharge
opening. Contact with the rotating impeller
can amputate fingers, hands, and feet.
8. Never attempt to unclog either the feed intake
or discharge opening, remove or empty bag,
or inspect and repair the machine while the
engine is running. Shut the engine off and
wait until all moving parts have come to a
complete stop. Disconnect the spark plug wire
and ground it against the engine.
Preparation
1. Thoroughly inspect the area where the
equipment is to be used. Remove all rocks,
bottles, cans, or other foreign objects which
could be picked up or thrown and cause
personal injury or damage to the machine.
2. Always wear safety glasses or safety goggles
during operation and while performing an
adjustment or repair, to protect your eyes.
Thrown objects which ricochet can cause
serious injury to the eyes.
3. Wear sturdy, rough-soled work shoes and
close-fitting slacks and shirts. Loose fitting
clothes or jewelry can be caught in movable
parts. Never operate this machine in bare feet
or sandals. Wear leather work gloves when
feeding material in the chipper chute.
4. Before starting, check all bolts and screws for
proper tightness to be sure the machine is in
safe working condition. Also, visually inspect
machine for any damage at frequent intervals.
5. Maintain or replace safety and instructions
labels, as necessary.
Safe Handling of Gasoline:
To avoid personal injury or property damage use
extreme care in handling gasoline. Gasoline is
extremely flammable and the vapors are explosive.
Serious personal injury can occur when gasoline is
spilled on yourself or your clothes which can ignite.
Wash your skin and change clothes immediately.
1. Use only an approved gasoline container.
2. Never fill containers inside a vehicle or on a
truck or trailer bed with a plastic liner. Always
place containers on the ground away from
your vehicle before filling.
3. When practical, remove gas-powered
equipment from the truck or trailer and refuel
it on the ground. If this is not possible, then
refuel such equipment on a trailer with a
portable container, rather than from a gasoline
dispenser nozzle.
4. Keep the nozzle in contact with the rim of the
fuel tank or container opening at all times
until fueling is complete. Do not use a nozzle
lock-open device.
5. Extinguish all cigarettes, cigars, pipes and
other sources of ignition.
6. Never fuel machine indoors.
7. Never remove gas cap or add fuel while the
engine is hot or running. Allow engine to cool
at least two minutes before refueling.
8. Never over fill fuel tank. Fill tank to no more
than ½ inch below bottom of filler neck to
allow space for fuel expansion.
9. Replace gasoline cap and tighten securely.
10. If gasoline is spilled, wipe it off the engine and
equipment. Move unit to another area. Wait 5
minutes before starting the engine.
11. To reduce fire hazards, keep machine free of
grass, leaves, or other debris build-up. Clean
up oil or fuel spillage and remove any fuel
soaked debris.
12. Never store the machine or fuel container
inside where there is an open flame, spark or
pilot light as on a water heater, space heater,
furnace, clothes dryer or other gas appliances.
Operation
1. Do not put hands and feet near rotating parts
or in the feeding chambers and discharge
opening. Contact with the rotating impeller
can amputate fingers, hands, and feet.
2. Before starting the machine, make sure
the chipper chute, feed intake, and cutting
chamber are empty and free of all debris.
3. Thoroughly inspect all material to be shredded
and remove any metal, rocks, bottles, cans,
or other foreign objects which could cause
personal injury or damage to the machine.
WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself
and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result
in personal injury. When you see this symbol - HEED ITS WARNING!
DANGER: This machine was built to be operated according to the safe operation practices in this manual. As with any type of power equipment,
carelessness or error on the part of the operator can result in serious injury. This machine is capable of amputating fingers, hands, toes and feet and
throwing debris. Failure to observe the following safety instructions could result in serious injury or death.
CALIFORNIA PROPOSITION 65
WARNING: Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to State of California to cause
cancer and birth defects or other reproductive harm.
4. If the impeller strikes a foreign object or if your
machine should start making an unusual noise
or vibration, immediately shut the engine
off. Allow the impeller to come to a complete
stop. Disconnect the spark plug wire, ground it
against the engine and perform the following
steps:
a. Inspect for damage.
b. Repair or replace any damaged parts.
c. Check for any loose parts and tighten
to assure continued safe operation.
5. Do not allow an accumulation of processed
material to build up in the discharge area.
This can prevent proper discharge and result
in kickback of material through the feed
opening.
6. Do not attempt to shred or chip material
larger than specified on the machine or in this
manual. Personal injury or machine damage
could result.
7. Never attempt to unclog either the feed
intake or discharge opening while the engine
is running. Shut the engine off, wait until all
moving parts have stopped, disconnect the
spark plug wire and ground it against the
engine before clearing debris.
8. Never operate without vacuum bag and
discharge chute properly attached to the
machine. Never empty or change vacuum bag
while the engine is running. Vacuum bag must
be kept closed at all times during operation.
9. Never operate without either the inlet nozzle
or optional hose attachment (if applicable)
properly attached to the machine. Never
attempt to attach or change either attachment
while the engine is running.
10. Keep all guards, deflectors and safety devices
in place and operating properly.
11. Keep your face and body back and to the side
of the chipper chute while feeding material
into the machine to avoid accidental kickback
injuries.
12. Never operate this machine without good
visibility or light. Always be sure of your
footing and keep a firm hold on the handles.
13. Do not operate this machine on a paved,
gravel or non-level surface.
14. Do not operate this machine while under the
influence of alcohol or drugs.
15. Muffler and engine become hot and can cause
a burn. Do not touch.
16. Never pick up or carry machine while the
engine is running.
17. If situations occur which are not covered in
this manual, use care and good judgement.
Contact Customer Support for assistance and
the name of the nearest service dealer.

4Section 2 — important Safe operation practiceS
Notice Regarding Emissions
Engines which are certified to comply with California
and federal EPA emission regulations for SORE
(Small Off Road Equipment) are certified to operate
on regular unleaded gasoline, and may include
the following emission control systems: Engine
Modification (EM), Oxidizing Catalyst (OC), Secondary
Air Injection (SAI) and Three Way Catalyst (TWC) if so
equipped.
Spark Arrestor
WARNING: This machine is equipped
with an internal combustion engine and
should not be used on or near any
unimproved forest-covered,
brushcovered or grass-covered land
unless the engine’s exhaust system is
equipped with a spark arrestor meeting
applicable local or state laws (if any).
If a spark arrestor is used, it should be maintained in
effective working order by the operator. In the State
of California the above is required by law (Section
4442 of the California Public Resources Code). Other
states may have similar laws. Federal laws apply on
federal lands.
A spark arrestor for the muffler is available through
your nearest engine authorized service dealer or
contact the service department, P.O. Box 361131
Cleveland, Ohio 44136-0019.
Safety Symbols
This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to
assemble and operate.
Symbol Description
READ THE OPERATOR’S MANUAL(S)
Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate.
WARNING— ROTATING BLADES
Keep hands out of inlet and discharge openings while machine is running. There are rotating blades inside.
BYSTANDERS
Keep bystanders, pets, and children at least 75 feet from the machine while it is in operation. Stop machine if anyone
enters the area.
WARNING— THROWN OBJECTS
This machine may pick up and throw and objects which can ricochet.
EYE PROTECTION
Always wear safety glasses or safety goggles when operating this machine.
WARNING— GASOLINE IS FLAMMABLE
Allow the engine to cool at least two minutes before refueling.
WARNING— CARBON MONOXIDE
Never run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon monoxide, an odorless and
deadly gas.
Maintenance & Storage
1. Never tamper with safety devices. Check their
proper operation regularly.
2. Check bolts and screws for proper tightness
at frequent intervals to keep the machine in
safe working condition. Also, visually inspect
machine for any damage and repair, if needed.
3. Before cleaning, repairing, or inspecting, stop
the engine and make certain the impeller and
all moving parts have stopped. Disconnect
the spark plug wire and ground it against the
engine to prevent unintended starting.
4. Do not change the engine governor settings
or overspeed the engine. The governor
controls the maximum safe operating speed of
the engine.
5. Maintain or replace safety and instruction
labels, as necessary.
6. Follow this manual for safe loading, unloading,
transporting, and storage of this machine.
7. Never store the machine or fuel container
inside where there is an open flame, spark
or pilot light such as a water heater, furnace,
clothes dryer, etc.
8. Allow machine to cool at least 5 minutes
before storing.
9. Always refer to the operator’s manual for
proper instructions on off-season storage.
10. If the fuel tank has to be drained, do this
outdoors.
11. Observe proper disposal laws and regulations
for gas, oil, etc. to protect the environment.
12. According to the Consumer Products
Safety Commission (CPSC) and the U.S.
Environmental Protection Agency (EPA), this
product has an Average Useful Life of seven
(7) years, or 60 hours of operation. At the end
of the Average Useful Life have the machine
inspected annually by an authorized service
dealer to ensure that all mechanical and
safety systems are working properly and not
worn excessively. Failure to do so can result in
accidents, injuries or death.
Do not modify engine
To avoid serious injury or death, do not modify
engine in any way. Tampering with the governor
setting can lead to a runaway engine and cause it to
operate at unsafe speeds. Never tamper with factory
setting of engine governor.
WARNING: Your Responsibility—Restrict the use of this power machine to persons who read, understand and follow the warnings and
instructions in this manual and on the machine.
SAVE THESE INSTRUCTIONS!

Assembly & Set-Up 3
5
Contents of Carton
• Chipper/Shredder Vacuum (1) • Operator’s Manual (1) • Engine Operator’s Manual (1)
• Upper and Lower Handle (1) • Hose Assembly (1) • Safety Glasses (1)
• Bag (1) • Bottle of Oil (1) • Hose Extension (1)
Assembly
NOTE: This unit is shipped without gasoline or oil in
the engine. Fill up gasoline and oil as instructed in
the accompanying engine manual BEFORE operating
your chipper shredder vacuum.
Handle
1. Remove the hairpin clips from the handle
brackets and the carriage screws and wing
nuts from the lower handle.
a. Place the bottom holes in lower handle
over the pins on the handle brackets
and secure with hairpin clips. See
Figure 3-1.
a
b
b
Figure 3-1
b. Insert carriage screws through upper
hole in lower handle from the inside
and secure with wing nuts. See Figure
3-1.
3. Unfold the upper handle until it aligns with
thelower handle. Make sure the rope guide is
on the right side of upper handle. See Figure
3-2a.
ab
Figure 3-2
IMPORTANT: Make sure the cables are routed
outside the lower handle. Also, do not crimp
the cables while lifting up the handles.
4. Secure the two handles by tightening the star
knobs (carriage bolts must be seated properly
into the handle). See Figure 3-2b.
5. Pull the two cable ties attached to the cables
tight approximately 8 inches from each cable
end and place the cables into the cable guide.
6. Loosen the wing nut that secures the rope
guide to the right side of upper handle.
a. Slowly pull starter rope out of engine.
b. Slip the starter rope into the rope
guide. See Figure 3-3.
a
b
c
Figure 3-3
c. Tighten the wing nut.
Hose Assembly
1. Slide hose adapter of hose assembly into the
base adapter located on the left front of the
chipper shredder vacuum. See Figure 3-4a.
a
b
Align pin
with this
hole.
Figure 3-4
2. Pull spring loaded pin out on the base and
align pin with the first hole (closest to the end
of the tube) in the hose adapter. See Figure
3-4b.
3. Release the pin to lock the hose in place.
4. Lay hose tubing in curved end of hose handle
next to chipper chute and into hose cradle.
See Figure 3-5a & b.
b
a
c
Figure 3-5
5. Snap the hose handle first into the upper hose
handle bracket and then into the lower hose
handle bracket. See Figure 3-5c.

6Section 3 — ASSembly & Set-Up
Adjustments
Nozzle Height
The nozzle can be adjusted to any six positions,
ranging from 5/8” to 4 1/8” ground clearance. The
nozzle height has to be adjusted according to
chipper shredder conditions.
1. Depress nozzle height adjustment lever
towards wheel. See Figure 3-7.
3
2
1
Figure 3-7
2. Move the height adjustment lever forward
or backward to adjust the nozzle upwards or
downwards. Make sure both levers are in the
same position.
3. Release lever towards deck. See Figure 3-7.
NOTE: In general, raise the nozzle height
to vacuum a thick layer of leaves. Lower the
nozzle height for smoother surfaces.
Set-Up
Gas and Oil Fill-Up
Refer to the separate engine owner’s manual for
additional engine information.
1. Add oil provided before starting unit for the
first time out of the box.
2. Service the engine with gasoline as instructed
in the separate engine owner’s manual.
WARNING: Use extreme care when
handling gasoline. Gasoline is extremely
flammable and the vapors are explosive.
Never fuel the machine indoors or while
the engine is hot or running. Extinguish
cigarettes, cigars, pipes and other sources
of ignition.
WARNING: Never fill fuel tank indoors
with engine running or until the engine
has been allowed to cool for at least two
minutes after running.
Bag
1. Grasp bag handle with one hand and slide
locking rod on mounting bracket with other
hand toward engine. Use the end of mounting
bracket as leverage when sliding the locking
rod. See Figure 3-6.
4
3
1
2
Figure 3-6
1. Slip bag over the rim of the discharge opening
and release locking rod to secure bag in place.
2. Snap bag clip to the top of the lower handle.
3. Place the lower straps on the bag over the top
of lower handle, hooking them on the studs.
See Figure 3-6.
NOTE: The bag/chute switch button attached
to the mounting bracket must be fully
depressed by the tip of front tab on bag
handle when securing the bag or engine will
not start.

Controls and Operation 4
7
Nozzle Height
Adjustment Lever
Chipper Chute
Hose Handle
Recoil Starter
Bag
Nozzle
Hose Extension
Speed Control
Drive Control
Hose Assembly
Nozzle/Hose
Vac Lever
Figure 4-1
Controls
WARNING: The operation of any chipper
shredder can result in foreign objects
being thrown into the eyes, which can
damage your eyes severely. Always wear
the safety glasses provided with this unit
or eye shields while operating or while
performing any adjustments or repairs.
Drive Control
Located on the underside of the upper handle, the
drive control is used to engage/disengage wheels.
Fully squeeze the drive control against the upper
handle to engage the wheels; release to disengage.
(DO NOT slip clutch).
Speed Control
Located on the left side of the upper handle, the
speed control is used to select the forward speed of
the yard vacuum.
Chipper Chute
Allows twigs and small branches up to 1-1/2” in
diameter to be fed into the impeller for chipping.
Nozzle Height Adjustment Lever
Used to adjust the nozzle ground clearance ranging
approximately 5/8” to 4 1/8”.
Nozzle
Yard waste such as leaves or pine needles can be
vacuumed up through the nozzle for shredding.
Hose Assembly
Used as an alternative to the nozzle to vacuum yard
waste such as leaves or pine needles.
Hose Extension
Used to vacuum yard waste in hard to reach places
of yard.
Nozzle/ Hose Vac Lever
The nozzle/hose vac handle is located on top of the
nozzle. Use it to switch vacuum suction between the
nozzle and the hose assembly.
Hose Handle
Used to guide hose assembly when vacuuming.
Recoil Starter
The recoil starter is attached to the right upper
handle. Stand behind unit and pull the recoil starter
to start engine.
Operation
Starting & Stopping Engine
Refer to the Engine Operator’s manual packed with
your chipper/shredder vacuum for instructions on
starting and stopping the engine.
To Empty Bag
1. Unhook bag straps from the lower handle.
2. Unsnap bag clip from the top of lower handle.
See Figure 4-2.
1
2
3
4
Figure 4-2
3. Grasp bag handle with one hand and pull lock
rod on mounting bracket with other hand
toward engine to release.
4. Lift bag off back of unit.
5. Twist the two buttons on the back of the bag
to unlock and empty contents. See Figure 4-3.
Hold bag handle and bag clip while emptying
the contents.
Outer Flap
Buttons
Inner
Flap
Figure 4-3
6. Compress bag opening and fold inner flap
over opening.
7. Fold outer flap over inner flap and insert
buttons on the bag through metal outlets. See
Figure 4-3.
8. Twist the buttons to lock bag. Place bag back
onto unit as instructed in the Assembly & Set-
Up section of this manual.
WARNING: Do not at any time make any
adjustments without first stopping
engine and disconnecting spark plug
wire.
Using The Nozzle Vacuum
Yard waste such as leaves and pine needles can be
vacuumed up through the nozzle for shredding.
After material has been shredded by the flail blades
on the impeller assembly, it will be discharged into
catcher bag. Do not attempt to shred or chip any
material other than vegetation found in a normal
yard (i.e. branches, leaves, twigs, etc.) Avoid fibrous
plants such as tomato vines until they are thoroughly
dried out. Materials such as stalks or heavy branches
up to 1 1/2” in diameter may be fed into the chipper
chute.

8Section 4 — controlS and operation
1. Place nozzle/hose vac lever in the top position
on the nozzle to vacuum through nozzle. See
Figure 4-4.
Figure 4-4
2. The spring loaded pin must be in the first hole
(closest to the end of the tube) of the hose
adapter to operate the nozzle vac. See Figure
4-4.
3. Place both hands on top of upper handle and
fully lift the drive control against upper handle
to propel unit over yard waste.
4. Use the speed control to choose either the
high or low speed. The speed control may be
moved either while the unit is propelling or
before engaging the wheels.
IMPORTANT: Move the speed control only
when the engine is running. Changing the
speed control setting with the engine off can
damage the chipper/shredder vacuum.
WARNING: Do not attempt to shred,
chip, or vacuum any material larger than
specified on the machine or in this
manual. Personal injury or damage to the
machine could result.
IMPORTANT: The flail screen is located inside
the housing in the discharge area. If the
flail screen becomes clogged, remove and
clean as instructed in Product Care. For best
performance, it is also important to keep the
chipper blade sharp.
Using The Hose Assembly
1. Place nozzle/hose vac lever in the bottom
position on the nozzle to redirect vacuum to
the hose assembly. See Figure 4-5.
Figure 4-5
2. The spring loaded pin must be in the second
hole of the hose adapter to operate the hose
assembly. See Figure 4-5.
3. Unhook the hose from upper and lower hose
handle brackets and grasp the hose handle to
guide the hose while vacuuming yard waste
such as leaves or pine needles.
4. If necessary, attach the hose extension to
vacuum in hard to reach places as follows:
a. Insert round end of hose extension into
end of hose assembly.
b. Secure strap on hose extension to pin
on hose assembly. See Figure 4-6.
AB
Figure 4-6

Product Care 5
9
Equipment Care
• Clean the chipper/shredder vacuum
thoroughly after each use.
• Wash bag periodically with water. Allow to dry
thoroughly in shade.
• If the flail screen becomes clogged, remove
and clean as instructed below.
NOTE: Cleaning with a forceful spray of water
is not recommended as it could contaminate
the fuel system.
Engine Care
Refer to the Maintenance section of the Engine
Operator’s manual packed with your unit. Read and
follow instructions carefully.
WARNING: Before performing any type
of maintenance on the machine, wait for
all parts to stop moving and disconnect
the spark plug wire. Failure to follow this
instruction could result in personal injury
or property damage.
• Check engine oil level before each use as
instructed in the separate Engine Operator’s
manual.
• Clean or replace air cleaner every 25 hours
under normal conditions. Clean every few
hours under extremely dusty conditions. To
service the air cleaner, refer to the engine
manual.
• The spark plug should be cleaned and the gap
reset once a season. Check engine manual for
correct plug type and gap specifications.
• Clean engine regularly with a cloth or brush.
Keep the top of the engine clean to permit
proper air circulation. Remove all grass, dirt,
and combustible debris from muffler area.
Removing the Flail Screen
If the discharge area becomes clogged, remove the
flail screen and clean area as follows:
1. Stop the engine. Make certain the chipper/
shredder vacuum has come to a complete
stop.
2. Before unclogging the discharge chute,
disconnect and ground the spark plug wire to
retaining post.
3. Remove the vacuum bag from the unit as
instructed in the Controls and Operation
section to obtain access to flail screen.
Maintenance
General Recommendations
• Always observe safety rules when performing
any maintenance.
• The warranty on this chipper/shredder
vacuum does not cover items that have been
subjected to operator abuse or negligence.
To receive full value from warranty, operator
must maintain the equipment as instructed
here.
• Changing of engine-governed speed will void
engine warranty.
• All adjustments should be checked at least
once each season.
• Periodically check all fasteners and make sure
these are tight.
WARNING: Always stop engine,
disconnect spark plug, and ground
against engine before performing any
type of maintenance on your machine.
Lubrication
1. Lubricate each wheel shoulder screw (rear
wheel) and pivot arm axle (front wheel) once a
season with light oil.
2. Lubricate the pivot points of the nozzle height
adjustment levers once a season with light oil.
3. Lubricate the locking rod with light oil to ease
the application of attaching on or removing
bag.
4. Lubricate the nozzle/hose vac lever on top of
the nozzle once a season with light oil. See
Figure 7-1.
Figure 7-1
5. Follow the separate engine manual packed
with your unit for lubrication instructions.
4. Remove the three self tapping screws securing
the belt cover, and remove belt cover. See
Figure 7-2.
Figure 7-2
5. Remove self tapping screw on right side of
unit that attaches to the flail screen. It may be
necessary to remove the hose bracket hanger
to get access to the screw. See Figure 7-3.
Figure 7-3
6. Remove hex screw on top of rear housing near
mounting bracket and the flange lock nut that
secures flail screen. See Figure 7-3.
7. Remove and clean the screen by scraping or
washing with water. See Figure 7-4.
Figure 7-4
8. Reinstall the screen.

10 Section 5 — Product care
Adjustments
Drive Control Cable
Adjust the drive control cable if the yard vacuum
does not self propel with the drive control engaged,
or if the unit hesitates while the engine maintains the
same speed after approximately 20 hours of use.
To move the z-fitting of the drive control cable from
its factory set position in the front hole of the drive
control to the rear hole, proceed as follows:
1. Push the right side of the control out of the
right hole in the upper handle. See Figure 7-5.
123
Figure 7-5
2. Pivot control down towards the lower handle.
3. Pivot straight up to remove it from the left
hole in the upper handle. See Figure 7-5.
4. There is now sufficient slack in the drive
control cable to grasp the z-fitting with your
hand and move it from the front hole to the
rear hole of the drive control. See Figure 7-6.
Figure 7-6
IMPORTANT: Make sure to insert the z-fitting
into the rear hole as it was inserted in the
front hole, that is from the outside of the drive
control.
5. You may now carefully reinstall the drive
control by performing the previous steps in
the opposite order and manner of removal.
IMPORTANT: Once assembled and prior to
restarting, make sure that the cable is properly
adjusted. With the drive control disengaged,
the unit should freely pull in reverse.
Service
Blade Care
WARNING: Before performing any type
of maintenance on the machine, wait for
all parts to stop moving and disconnect
the spark plug wire. Failure to follow this
instruction could result in personal injury
or property damage.
NOTE: When tipping the unit, empty the oil and fuel
tank and keep engine spark plug side up.
6. Disconnect and ground the spark plug wire to
retaining post.
7. Remove bag assembly or blower chute.
8. Remove the three hex cap screws holding the
hose hanger bracket and chipper chute to the
upper housing. See Figure 7-7.
Figure 7-7
9. Remove the flange lock nuts, front wheels,
and wave washers that attach to the pivot arm
assemblies. See Figure 7-8.
Wave
Washer
Wheel
Lock Nut
Shoulder
Screw
Thrust
Washer
Bell
Washer
Pivot Arm
Assembly
Front Support Brace/
Lock Nut
Figure 7-8
10. Remove the shoulder screws, thrust washers,
and bell washers that go through the pivot
arms to the front support brace. The front
support brace and lock nut can be removed at
this time as well.
11. Remove the four screws on the upper housing
that secure the nozzle cover. See Figure 7-9.
Figure 7-9
12. Carefully tilt and support the unit up to
provide access underneath to the nozzle
mounting hardware and impeller. Remove the
three shoulder bolts securing the black plastic
lower flail housing to the lower housing. Refer
to Figure 7-10.
Figure 7-10
13. Tilt top of black plastic lower flail housing
toward the engine to remove.
14. Using a 3/16” allen wrench, remove the flat
head cap screws that hold the chipper blade
to the impeller. These screws are accessible
through the opening created when the chipper
chute was removed earlier. See Figure 7-11.
Chipper
Blade
Flat Head
Cap Screws
Figure 7-11

11Section 5 — Product care
15. The nuts on the flat head cap screws can be
reached from underneath using a 1/2-inch
socket, universal, and extension. See Figure
7-12.
Nuts
Impeller
Figure 7-12
16. Replace or sharpen chipper blade. The blade can
be sharpened with a file or on a grinding wheel.
WARNING: The chipper blade is sharp.
When sharpening blade, wear leather
work gloves to protect your hands and
follow the original angle of grind.
17. Reassemble by performing the previous steps
in the opposite order and manner of removal.
NOTE: Tighten blade screws to 210 - 250 in-lbs.
Make certain chipper blade is reassembled
with the sharp edge facing upward.
Off-Season Storage
• When storing the chipper/shredder vacuum
in an unventilated or metal storage shed, care
should be taken to rustproof the non-painted
surfaces. Using a light oil or silicone, coat the
equipment, especially any springs, bearings,
and cables.
• Remove all dirt from exterior of engine and
equipment.
• Follow lubrication recommendations.
• Refer to engine manual for correct engine
storage instructions.
• Store equipment in a clean, dry area. Do not
store in an area where equipment is present
that may use a pilot light or has a component
that can create a spark.
Troubleshooting
Problem Cause Remedy
Engine Fails to start 1. Throttle lever (if equipped) not in correct starting position.
2. Engine switch (if equipped) in OFF position.
3. Spark plug wire disconnected.
4. Choke not in CHOKE position (if equipped).
5. Fuel tank empty or stale fuel.
6. Fuel shut-off valve closed (if equipped).
7. Faulty spark plug.
8. Bag/chute switch button is not fully depressed.
1. Move throttle lever to FAST or START position.
2. Move engine switch to ON position.
3. Connect wire to spark plug.
4. Move choke lever to CHOKE position.
5. Fill tank with clean, fresh gasoline.
6. Turn on fuel shut-off valve.
7. Clean, adjust gap, or replace.
8. Make certain the bag is correctly secured, and the bag/chute switch button
is fully depressed.
Engine runs erratic 1. Spark plug boot loose.
2. Unit running on CHOKE (if equipped).
3. Blocked fuel line or stale fuel.
4. Low engine RPM.
5. Water or dirt in fuel system.
6. Dirty air cleaner.
7. Carburetor out of adjustment.
1. Connect and tighten spark plug boot.
2. Move choke lever to OFF position.
3. Clean fuel line; fill tank with clean, fresh
gasoline.
4. Always run engine at full throttle.
5. Drain fuel tank. Refill with fresh fuel.
6. Refer to engine manual.
7. See authorized service dealer.
Engine overheats 1. Engine oil level low.
2. Dirty air cleaner.
1. Fill crankcase with proper oil.
2. Refer to engine manual.
Occasional skips (hesitates) at high speed 1. Spark plug gap too close.
2. Carburetor idle mixture adjustment improperly set.
1. Remove spark plug and adjust gap to .030”.
2. See authorized service dealer.
Excessive Vibration 1. Loose parts or damaged impeller. 2. See authorized service dealer.
Unit does not discharge 1. Discharge area clogged.
2. Foreign object lodged in impeller.
3. Low engine RPM.
4. Vacuum bag is full.
1. Stop engine immediately and disconnect spark plug wire. Clean flail screen
and inside of discharge opening.
2. Stop engine and disconnect spark plug wire. Remove lodged object.
3. Always run engine at full throttle.
4. Empty bag.
Rate of discharge slows considerably or
composition of discharged material changes
1. Low engine RPM.
2. Chipper blade dull.
1. Always run engine at full throttle.
2. Replace chipper blade or see your authorized service dealer.
Unit fails to propel itself or slips when drive
control is engaged
1. Drive control cable out of adjustment.
2. Drive belt worn or damaged.
1. Follow adjustment procedure in Maintenance & Adjustments section of
manual.
2. See authorized service dealer.

Replacement Parts 6
12
Component Part Number and Description
951-14437 Spark Plug
951-14632 Air Cleaner Kit
951-14407 Fuel Cap Assembly
951-10358A Fuel Filter
664-04040 Bag
981-0490 Chipper Blade
719-0329 Flail Blade (2 total)
634-04665 Wheel (Front)
634-05040 Wheel (Rear)
954-0369 Belt
Cub Cadet Genuine Parts can be ordered through your local authorized Cub Cadet dealer, online at cubcadet.com or by phone at 1-800-965-4Cub.
To locate your nearest authorized Cub Cadet dealer, visit cubcadet.com or call 1-877-282-8684.

Cub Cadet LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019; Phone: [phone]
MTD Products Limited - KITCHENER, ON N2G 4J1; Phone [phone]
GDOC-100160 REV. D
CUB CADET LLC
MANUFACTURER’S LIMITED WARRANTY FOR SNOW THROWERS, LOG SPLITTERS
CHIPPERSHREDDERS, CHIPPERSHREDDER VACUUMS AND JET SWEEPS
The limited warranty set forth below is given by Cub Cadet LLC
with respect to new merchandise purchased and used in the United
States, its possessions and territories, and by MTD Products Limited
with respect to new merchandise purchased and used in Canada
and/or its territories and possessions.
This warranty is in addition to any applicable emissions warranty
provided with your product.
For non-commercial use: Cub Cadet warrants this product
(excluding Normal Wear Parts and the Auger Gearbox, as described
below) against defects in material and workmanship for a period of
three (3) years from the date of original retail purchase or lease.
For commercial uses and applications: Cub Cadet warrants this
product (excluding Normal Wear Parts and the Auger Gearbox, as
described below) against defects in material and workmanship for
a period of one (1) year from the date of original retail purchase or
lease.
“Cub Cadet” will, at its option, repair or replace, free of charge, any
part found to be defective in materials or workmanship. This limited
warranty shall only apply if this product has been operated and
maintained in accordance with the Operator’s Manual furnished
with the product, and has not been subject to misuse, abuse,
neglect, accident, improper maintenance, alteration, vandalism,
theft, fire, water, or damage because of other peril or natural
disaster. Damage resulting from the installation or use of any part,
accessory or attachment not approved by Cub Cadet for use with
the product(s) covered by this manual will void your warranty as to
any resulting damage.
Normal Wear Parts are warranted to be free from defects in material
and workmanship for a period of thirty (30) days from the date of
purchase. Normal wear parts include, but are not limited to items
such as: belts, skid shoes, shave plates, blades, debris collection
bags, wheels and tires.
Auger Gearbox — Cub Cadet warrants the auger gearbox (on three-
stage snow thrower models only) against defects in material and
workmanship for a period of five (5) years, commencing on the date
of the snow thrower’s original purchase.
HOW TO OBTAIN SERVICE: Warranty service is available, WITH
PROOF OF PURCHASE, through your local authorized service dealer.
To locate the dealer in your area:
In the U.S.A.
To locate the dealer in your area, check your Yellow Pages, or
contact Cub Cadet LLC at P.O. Box 361131, Cleveland, Ohio 44136-
0019, or call 1-877-282-8684, or log on to our Web site at www.
cubcadet.com.
In Canada
Contact MTD Products Limited, Kitchener, ON N2G 4J1, or call
1-800-668-1238 or log on to our Web site at www.mtdcanada.com.
This limited warranty does not provide coverage in the following
cases:
a. Routine maintenance items such as lubricants, filters, blade
sharpening, tune-ups, brake adjustments, clutch adjustments,
deck adjustments, and normal deterioration of the exterior
finish due to use or exposure.
b. Log splitter pumps, valves, and cylinders have a separate one
year warranty.
c. Cub Cadet does not extend any warranty for products sold
or exported outside of the United States and/or Canada, and
their respective possessions and territories, except those
sold through Cub Cadet’s authorized channels of export
distribution.
d. Replacement parts that are not genuine Cub Cadet parts.
e. Service completed by someone other than an authorized
service dealer.
f. Transportation charges and service calls.
No implied warranty, including any implied warranty of
merchantability of fitness for a particular purpose, applies
after the applicable period of express written warranty above
as to the parts as identified. No other express warranty,
whether written or oral, except as mentioned above, given by
any person or entity, including a dealer or retailer, with respect
to any product, shall bind Cub Cadet. During the period of the
warranty, the exclusive remedy is repair or replacement of the
product as set forth above.
The provisions as set forth in this warranty provide the sole
and exclusive remedy arising from the sale. Cub Cadet shall
not be liable for incidental or consequential loss or damage
including, without limitation, expenses incurred for substitute
or replacement lawn care services or for rental expenses to
temporarily replace a warranted product.
Some states do not allow the exclusion or limitation of incidental
or consequential damages, or limitations on how long an implied
warranty lasts, so the above exclusions or limitations may not apply
to you.
In no event shall recovery of any kind be greater than the amount
of the purchase price of the product sold. Alteration of safety
features of the product shall void this warranty. You assume the
risk and liability for loss, damage, or injury to you and your property
and/or to others and their property arising out of the misuse or
inability to use the product.
This limited warranty shall not extend to anyone other than the
original purchaser or to the person for whom it was purchased as a
gift.
HOW STATE LAW RELATES TO THIS WARRANTY: This limited
warranty gives you specific legal rights, and you may also have
other rights that vary in different jurisdictions.
IMPORTANT: Owner must present Original Proof of Purchase to
obtain warranty coverage.

MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Safe Operation Practices • Set-Up • Operation • Maintenance • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
OperatOr’sManual
159 cc & 196 cc OHV Vertical Shaft Engine
Form No. 769-15770
(May 24, 2018)

Thank You
This Operator’s Manual is an important part of your new engine. It will help you prepare and maintain the engine for the best
performance. Please read and understand the contents before operating the engine.
Customer Support
Please do NOT return the machine to the retailer or dealer without first contacting the Customer Support Department.
If you have difficulty assembling this product, have questions regarding the controls, operation, or maintenance of this machine, want to order
replacement parts/attachments/accessories, or want to view an online How-To video; you can seek help from the experts. Have your full model number
and serial number ready. Choose from the options below:
• Web: www.mtdproducts.com/equipment/mtdproducts
• Phone: [phone]
• Mail: MTD LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019
To The Owner 1
2
Table of Contents
Important Safe Operation Practices.......................................3
Safety Labels .............................................................................4
Set-Up.........................................................................................5
Controls & Features ..................................................................6
Operation ..................................................................................7
Maintenance & Adjustments ...................................................9
Troubleshooting......................................................................12
Replacement Parts..................................................................13
Spanish ....................................................................................15
Record Product Information
Before operating your new engine, please locate the model plate on the engine (shaded area in Figure below) and record the information in the
provided area below. This information will be necessary, should you seek technical support via our web site or with your local dealer.
Model NuMber
Serial NuMber

Important Safe Operation Practices 2
3
WARNING!
This symbol points out important safety
instructions which, if not followed, could endanger
the personal safety and/or property of yourself
and others. Read and follow all instructions
in this manual before attempting to operate
the equipment. Failure to comply with these
instructions may result in personal injury. When
you see this symbol. HEED ITS WARNING!
WARNING!
CALIFORNIA PROPOSITION 65
Engine Exhaust, some of its constituents, and
certain vehicle components contain or emit
chemicals known to State of California to cause
cancer and birth defects or other reproductive
harm.
DANGER!
This engine was built to be operated according to
the safe operation practices in this manual. As with
any type of power equipment, carelessness or error
on the part of the operator can result in serious
injury. Failure to observe the following safety
instructions could result in serious injury or death.
Training
1. Read, understand and follow all
instructions on the engine and in the
manual(s) before attempting to assemble
and operate. Keep this manual in a safe
place for future and regular reference and
for ordering replacement parts.
2. Be familiar with all controls and their
proper operation. Know how to stop the
engine and disengage them quickly.
3. Never allow children under 14 years of
age to operate the engine. Children 14
and over should read and understand the
instructions and safe operation practices
in this manual and be trained and
supervised by an adult.
4. Never allow adults to operate the machine
without proper instruction.
5. Keep the area of operation clear of all
persons, particularly small children and
pets. Stop machine if anyone enters the
area.
Preparation
1. Wear sturdy, rough-soled work shoes and
close fitting slacks and shirts. Loose fitting
clothes or jewelry can be caught in the
moving parts. Never operate the machine
in bare feet or sandals.
2. Disengage clutch levers and shift (if
equipped) into neutral (“N”) before
starting the engine.
3. Never leave the engine running while
unattended.
4. Never attempt to make any adjustments
while the engine is running, except
where specifically recommended in the
operator’s manual.
Safe Handling of Gasoline:
To avoid personal injury or property damage,
use extreme care in handling gasoline. Gasoline
is extremely flammable and the vapors are
explosive. Serious personal injury can occur
when gasoline is spilled on yourself and/or your
clothes which can ignite. Wash your skin and
change clothes immediately.
1. When adding fuel, turn engine OFF and
let engine cool at least 2 minutes before
removing the gas cap.
2. Fill fuel tank outdoors or in well ventilated
area.
3. Use only an approved gasoline container.
4. Never fill containers inside a vehicle or on
a truck or trailer bed with a plastic liner.
Always place containers on the ground
away from your vehicle before filling.
5. If possible, remove gas-powered
equipment from the truck or trailer and
refuel it on the ground. If this is not
possible, then refuel such equipment on
a trailer with a portable container, rather
than from a gasoline dispenser nozzle.
6. Keep the nozzle in contact with the rim of
the fuel tank or container opening at all
times until fueling is complete. Do not use
a nozzle lock-open device.
7. Do not overfill fuel tank. Fill tank to full
as indicated by the fuel level indicator
installed inside of the fuel tank or marked
on the tank. Do not over-fill to allow space
for fuel expansion. On some models, a fuel
level indicator may NOT be present, in this
instance, fill the tank no more than 1/2
inch below the bottom of the filler neck to
allow space for fuel expansion.
8. Replace fuel cap and tighten until the cap
ratchets.
9. If gasoline is spilled, wipe it off the engine
and the equipment. Move the machine
to another area. Wait five minutes before
starting the engine.
10. To reduce fire hazards, keep the machine
free of grass , leaves or other debris
build up. Clean up oil or fuel spillage and
remove any fuel-soaked debris.
11. Keep gasoline away from sparks, open
flames, pilot lights, heat, and other
ignition sources.
12. Never fuel equipment indoors because
flammable vapors will accumulate in the
area.
13. Extinguish all cigarettes, cigars, pipes, and
other sources of ignition.
14. Check fuel line, tank, cap, and fittings
frequently for cracks or leaks. Replace if
necessary.
Operation
1. When starting the engine, make sure spark
plug, muffler, and fuel cap are in place.
2. Do not crank engine with spark plug
removed.
3. If fuel spills, wait until it evaporates before
starting engine.
4. Allow muffler, engine cylinder, and fins to
cool before touching.
5. Keep children away from hot or running
engines. They can suffer burns from a hot
muffler.
6. Remove accumulated combustibles from
muffler and cylinder area.
7. Operate equipment with all guards in
place.
8. Keep hands and feet away from rotating
parts.
9. Tie up long hair and remove jewelry.
10. Do not wear loose-fitting clothing,
dangling drawstrings or items that could
become caught.
11. When starting the engine, pull cord slowly
until resistance is felt, then pull rapidly (if
not electric start).
12. Remove all external equipment/engine
loads before starting engine.
13. Direct coupled equipment components
such as, but not limited to blades,
impellers, pulleys, sprockets, etc., must be
securely attached.

4Section 2 — important Safe operation practiceS
Maintenance & Storage
1. Keep the engine in safe working order
2. Allow the engine to cool at least five
minutes before storing. Never tamper
with safety devices. Check their proper
operation regularly.
3. Check bolts and screws for proper
tightness at frequent intervals to keep the
engine in safe working condition. Visually
inspect the engine for any damage.
4. Before cleaning, repairing or inspecting;
stop the engine and make certain all
moving parts have stopped. Disconnect
the spark plug wire and ground it against
the engine to prevent unintended
starting.
5. Do not change the engine governor
settings or over-speed the engine. The
governor controls the maximum safe
operating speed of the engine.
6. Maintain and replace safety and
instruction labels as necessary.
7. Always refer to the operator’s manual for
important details if the machine is to be
stored for an extended period of time.
8. If the fuel tank has to be drained, do this
outdoors.
9. Observe proper disposal laws and
regulations for gas, oil, etc. to protect the
environment.
Do not modify engine
To avoid serious injury or death, do not modify
engine in any way. Tampering with the governor
setting can lead to a runaway engine and cause
it to operate at unsafe speeds. Never tamper
with factory setting of engine governor.
Notice Regarding Emissions
Engines which are certified to comply with
California and federal EPA emission regulations
for SORE (Small Off Road Equipment) are
certified to operate on regular unleaded
gasoline, and may include the following
emission control systems: Engine Modification
(EM), Oxidizing Catalyst (OC), Secondary Air
Injection (SAI) and Three Way Catalyst (TWC) if
so equipped.
Safety Symbols
This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before
attempting to assemble and operate.
Symbol Description
READ THE OPERATOR’S MANUAL(S)
Read, understand, and follow all instructions in the manual(s) before attempting to assemble and
operate.
WARNING—GASOLINE IS FLAMMABLE
Allow the engine to cool at least two minutes before refueling.
WARNING— CARBON MONOXIDE
Never run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon monoxide, an
odorless and deadly gas.
WARNING— ELECTRICAL SHOCK
Do not use the engine’s electric starter in the rain.
WARNING— HOT SURFACE
Engine parts, especially the muffler, become extremely hot during operation. Allow engine and muffler
to cool before touching.
Spark Arrestor
WARNING!
This machine is equipped with an internal
combustion engine and should not be used on
or near any unimproved forest-covered, brush
covered or grass-covered land unless the engine’s
exhaust system is equipped with a spark arrestor
meeting applicable local or state laws (if any).
If a spark arrestor is used, it should be
maintained in effective working order by the
operator. In the State of California the above is
required by law (Section 4442 of the California
Public Resources Code). Other states may have
similar laws. Federal laws apply on federal lands.
A spark arrestor for the muffler is available
through your nearest engine authorized service
dealer or contact the service department, P.O.
Box 361131 Cleveland, Ohio 44136-0019.
WARNING! - SAVE THESE INSTRUCTIONS!
Your Responsibility — Restrict the use of this power machine to persons who read, understand and follow the warnings and instructions in this manual and on the
machine.

5
Set-Up 3
Gas & Oil
NOTE: The engine is shipped without gasoline
or oil in the engine. Running the engine with
insufficient oil can cause serious engine damage
and void the engine warranty.
WARNING!
Always keep hands and feet clear of equipment
moving parts. Do not use a pressurized starting
fluid. Vapors are flammable.
Oil Recommendations
Before starting engine, fill with motor oil,
capacity is 600 ml/20 oz. Refer to viscosity
chart in Figure 3-1 for oil recommendations. Do
not over-fill. Use a 4-stroke, or an equivalent
high detergent, premium quality motor oil
certified to meet or exceed U.S. automobile
manufacturer’s requirements for service
classification of a minimum level SJ (higher
letter ratings are acceptable such as SL and SM
grades). Motor oil will display this designation
on the container.
SAE 10W-30 is recommended for general, all
temperature use. If single viscosity oil is used,
select the appropriate viscosity for the average
temperature in your area from the chart below.
-30º -20º
10w
20w
20
30
40
20w40, 20w50
15w40, 15w50
10w40
10w30
-10º 0º
0º 20º 40º 60º 80º 100º
10º 20º 30º 40º
-20º
(ºC)
(ºF)
1
2
Figure 3-1
1. Single Viscosity
2. Multi Viscosity
CAUTION
Do not use non-detergent oil or 2-stroke engine
oil. It could shorten the engine’s service life.
NOTE: A 5w30 synthetic oil may be used
to improve start ability for cold weather
(temperatures below 40 F).
Checking Oil Level
NOTE: Be sure to check the oil while on a level
surface with the engine stopped.
3. Remove the oil filler cap/dipstick and
wipe the dipstick clean.
4. Insert the dipstick into the oil filler neck.
Turn the dipstick a 1/4 turn into the
locked position to fully seat.
5. Remove dipstick. If the level is low, slowly
add oil to the upper limit on the dipstick.
See Figure 3-2 inset.
Oil Filler
Cap/Dipstick
Upper
Limit
H
Figure 3-2
6. Reinsert the dipstick into the locked
position before starting the engine.
NOTE: Do not overfill. Overfilling with
oil may cause smoking, hard starting,
spark plug fouling, or oil saturation of air
cleaner.
Fuel Requirements
CAUTION
Operating the engine with E15 or E85 fuel, an oil/
gasoline mixture, dirty gasoline, or gasoline
over 30 days old without fuel stabilizing
additive may result in damage to your engine’s
carburetor. Subsequent damage would not be
covered under the manufacturer’s warranty.
Use automotive gasoline (unleaded or low
leaded to minimize combustion chamber
deposits) with a minimum of 87 octane.
Gasoline with up to 10% ethanol (E10) or 15%
MTBE (Methyl Tertiary Butyl Ether) can be used.
Never use an oil/gasoline mixture or dirty
gasoline. Avoid getting dirt, dust, or water in the
fuel tank. DO NOT use E15 or E85 gasoline.
WARNING!
Gasoline is extremely flammable and is explosive
under certain conditions.
• Refuel in a well-ventilated area with the
engine stopped. Do not smoke or allow
flames or sparks in the area where the
engine is refueled or where gasoline is
stored.
• Do not overfill the fuel tank. After
refueling, make sure the tank cap is
closed properly and securely.
• Be careful not to spill fuel when refueling.
Spilled fuel or fuel vapor may ignite. If
any fuel is spilled, make sure the area is
dry before starting the engine.
• Avoid repeated or prolonged contact
with skin or breathing of vapor.
Adding Fuel
WARNING!
An adult should fuel this engine. NEVER allow
children to refuel the engine. Gasoline (fuel)
vapors are highly flammable and can explode.
Fuel vapors can spread and be ignited by a spark
or flame many feet away from engine. To prevent
injury or death from fuel fires, follow these
instructions:
NOTE: Some engines may not have the fuel
cap installed for shipping purposes. To install,
remove and discard the fuel tank dust cap
labeled “Discard”. Remove the bubble wrap
packaging from around the fuel cap and tighten
securely.
• DO NOT use leaded fuel.
• Fuel must be fresh and clean.
NEVER use fuel left over from last
season or stored for long periods.
• NEVER mix oil with fuel.
• DO NOT use fuel containing
Methanol (Wood Alcohol)
NOTE: Before refueling, allow engine to cool
two minutes.
7. Clean around fuel fill before removing
cap to fuel.
8. Fill tank until fuel reaches 1⁄2 inch below
the bottom of the filler neck to allow
space for fuel expansion. Be careful not
to overfill.
9. Replace the gasoline cap and tighten
securely. Wipe up spilled fuel before
starting engine. If fuel is spilled DO NOT
start engine. Move machine away from
area of spillage. Avoid creating any source
of ignition until fuel vapors are gone.

Controls and Features 4
6
Engine Switch (If Equipped)
The engine switch is located on rear of the
engine. Turn the switch ON when starting the
engine and turn it to OFF when you want to
shut it down.
Choke (If Equipped)
The choke control is located on the rear of
the engine below the engine switch and
when activated, closes the choke plate on the
carburetor and aids in starting the engine. Pull
the choke control to activate the choke on the
engine. Use of the choke may not be necessary
if the engine is warm or the air temperature is
high.
Fuel Shut-Off Valve (If Equipped)
The fuel shut off valve is located on the engine
below the fuel tank. Be sure the valve is ON
before starting the engine. Turn the valve OFF
when towing or transporting equipment.
Primer (If Equipped)
The primer is located on
the front of the air cleaner.
Pressing the primer forces
fuel directly into the
engine’s carburetor to aid
in starting the engine.
†If Equipped
Oil Drain
Muffler
Air Cleaner
Starter Handle
Oil Fill Cap
Fuel Cap
Spark Plug
Primer †
Engine
Switch†
Choke†
Fuel Shut-Off
Valve†
Figure 4-1
Oil Drain
Removing the oil drain plug will drain the oil
from the engine. The engine is equipped with a
side drain.
NOTE: Select engines are equipped with an oil
drain located on the rear of the engine.
Oil Fill Cap
Remove the oil fill cap to check the oil level and
add oil.
Fuel Cap
Remove the fuel cap to add fuel.
Oil Drain †
(Rear of Engine)

7
Operation 5
Pre-Operation Check
The engine is shipped without gasoline or oil in
the engine. See page 5 in the Set-Up Section of
this manual for instructions on adding oil and
gasoline.
Determine The Starting System
Before starting the engine, you must determine
the type of starting system that is on your
engine. Your engine will have one of the
following types:
• Auto-Choke System: This features an
automatic choke that does not have a
manual choke or primer.
• Primer System: This features a primer on
the engine.
• Manual Choke System: This features
a choke on the engine and no primer.
Choke systems located on the engine will
feature an engine switch and may also
feature a fuel shut-off valve.
• Auto-Choke/Electric Start System:
This features an automatic choke and an
electric start switch on the handle.
To start your engine, follow the instructions for
your type of starting system.
NOTE: Equipment may have remote controls.
See the equipment manual for location and
operation of remote controls.
Starting the Engine
WARNING!
Always keep hands and feet clear of equipment
moving parts. Do not use a pressurized starting
fluid. Vapors are flammable.
Auto-Choke System
1. Standing behind the mower, depress
the blade control and hold it against the
upper handle. See Figure 5-1.
2. Pull the starter grip lightly until resistance
is felt, then pull rapidly to overcome
compression, prevent kickback and start
engine. Repeat if necessary.
IMPORTANT: Do not allow the starter grip to
snap back against the engine. Return it gently to
prevent damage to the starter.
1
2
Figure 5-1
Primer System
1. Push primer three times. Wait about two
seconds between each push. See Figure
5-2. In temperature below 50°F, prime
five times. After the engine is warmed
up, one prime may be needed for all
temperatures.
2. Standing behind the mower, squeeze
and hold the blade control against upper
handle.
3. Pull the recoil starter lightly until
resistance is felt, then pull rapidly
to overcome compression, prevent
kickback, and start the engine. Repeat if
necessary. See Figure 5-2.
IMPORTANT: Do not allow the recoil
starter to snap back against the rope
guide.
If engine does not start, it may be necessary to
re-prime the engine.
3
1
3
2
Figure 5-2
