Victory WC-8H User manual

Operator's Manual
WC-8H WOODCHIPPER
With Self-Propelled Hydraulic
Infeed Motor
VERSION 2.0 - EN 2022

Operator’s Manual Victory WC-8H - Page 2 of 64 - Version 2.0
COLOPHON
Addresses:
Visitor and Postal address:
65 Pine Ave #857, Long Beach, CA 90802, United States.
Business hours:
Monday-Friday 9:00 am - 5:00 pm
Internet address:
https://etractorimplements.com
E-mail address:
[email protected]om
Phone:
[phone]
Manual info:
These are the original instructions. The English language is binding.
No part of this documentation may be reproduced in any form without the written permission of
Victory Tractor Implements.
History of changes:
Operator’s Manual
Version:
Date:
Chapters:
Description:
V1.0
2021
-
First edition.
V2.0
July 2022
All
Editorial update. Layout update.

Operator’s Manual Victory WC-8H - Page 3 of 64 - Version 2.0
Table of contents
1 PREFACE ........................................................................................................................................6
1.1 Identification .........................................................................................................................6
1.2 CE Type Plate.........................................................................................................................6
1.3 Introduction...........................................................................................................................7
1.4 Warranty Provisions (See also Chapter 13)...........................................................................7
1.5 Liability ..................................................................................................................................7
2 INTRODUCTION .............................................................................................................................8
2.1 About This Manual ................................................................................................................8
2.2 Manual Update......................................................................................................................8
2.3 Explanation Documentation .................................................................................................8
2.4 List of Abbreviations..............................................................................................................8
2.5 Safety Warning Messages in this Manual .............................................................................9
2.6 Intended Users ......................................................................................................................9
2.7 Intended Use ...................................................................................................................... 10
2.8 Unintended Use.................................................................................................................. 10
2.9 Intended Operating Conditions.......................................................................................... 10
2.10 Tools, Parts, and Accessories for assembling and adjusting.............................................. 10
3 SAFETY INFORMATION............................................................................................................... 11
3.1 Introduction........................................................................................................................ 11
3.2 Generally Applicable Safety Rules...................................................................................... 11
3.3 Personal Protective Equipment.......................................................................................... 12
3.4 General Safety Rules for Machines .................................................................................... 12
3.5 ADDITIONAL SAFETY RULES FOR WOODCHIPPERS............................................................ 13
3.6 More Safety Tips for Safe Operation.................................................................................. 14
3.6.1 Use Safety Lights and Devices.................................................................................... 15
3.6.2 Transport Machinery Safely ....................................................................................... 15
3.6.3 Keep Riders Off Machinery ........................................................................................ 15
3.6.4 Practice Safe Maintenance......................................................................................... 15
3.6.5 Prepare For Emergencies ........................................................................................... 15
3.7 SAFETY AND HEALTH MEASURES WHEN USING HYDRAULIC FLUID.................................. 16
3.8 INFEED ROLLERS SAFETY .................................................................................................... 16
3.9 PTO DRIVELINE SAFETY ...................................................................................................... 16

Operator’s Manual Victory WC-8H - Page 4 of 64 - Version 2.0
3.9.1 Driveline Safety Checklist............................................................................................17
3.10 Not Allowed Use .................................................................................................................19
3.11 Safety Decals and Markings on the WC-8H ........................................................................19
3.12 Calamities............................................................................................................................21
4 ASSEMBLY INSTRUCTIONS ..........................................................................................................22
4.1 Assembly Info:.....................................................................................................................23
4.1.1 Determine the PTO Shaft Length; shorten it if necessary ..........................................27
4.1.2 Install the PTO shaft....................................................................................................28
4.1.3 Checking the PTO Shaft’s Interference .......................................................................29
4.2 Instructions before starting the Woodchipper...................................................................29
4.3 Preparation before Operating ............................................................................................30
4.4 Pre-operation checklist.......................................................................................................31
4.4.1 Adjusting the Discharge Chute....................................................................................32
4.5 Running-in the woodchipper ..............................................................................................32
4.6 Instructions before starting the Woodchipper...................................................................33
5 OPERATION .................................................................................................................................36
5.1.1 Human.........................................................................................................................36
5.1.2 Operator......................................................................................................................36
5.1.3 Workplace ...................................................................................................................37
5.2 Preparation before operating.............................................................................................37
5.2.1 Using the Safety Handle..............................................................................................38
5.3 Operating the WC-8H..........................................................................................................38
6 Other activities............................................................................................................................40
7 MAINTENANCE AND REPAIR.......................................................................................................44
7.1 LUBRICATION ......................................................................................................................45
7.2 Bearing Lubrication Guide; Based on Environmental Conditions.......................................45
7.3 Hydraulic oil reservoir.........................................................................................................46
7.4 Preventive Maintenance.....................................................................................................46
7.5 General Troubleshooting ....................................................................................................47
7.6 SPARE PARTS AND WEARING PARTS...................................................................................48
7.7 Order Parts..........................................................................................................................48
7.8 Wearing Parts......................................................................................................................49
7.9 List of Consumables ............................................................................................................49
8 TRANSPORT, STORAGE, AND ENVIRONMENT ............................................................................50

Operator’s Manual Victory WC-8H - Page 5 of 64 - Version 2.0
8.1 Transport and Storage........................................................................................................ 50
8.2 Decommissioning and Environment .................................................................................. 50
8.2.1 Decommissioning Requirements ............................................................................... 50
8.2.2 Environment............................................................................................................... 51
9 EXPLODED VIEW DRAWINGS...................................................................................................... 52
9.1 Torque Specifications......................................................................................................... 60
10 FLYWHEEL KNIFE CARE........................................................................................................... 61
10.1 How long will my Woodchipper Knives last? ..................................................................... 61
11 VICTORY TRACTOR IMPLEMENTS WARRANTY....................................................................... 62
12 SPECIFICATIONS, FEATURES, PERFORMANCE........................................................................ 63

Operator’s Manual Victory WC-8H - Page 6 of 64 - Version 2.0
1PREFACE
1.1 Identification
The Victory WC-8H is a robust, compact PTO-driven wood chipper with a self-propelled hydraulic
auto-infeed system with an impressive 8 x 8” infeed opening.
The WC-8H is used on smaller sub-compact tractors with as little as 15 hp at the PTO, such as BX
series Kubotas, John Deere 1000 series, New Holland, Massy Ferguson GC series, Mahindra Max
series, and more.
The Victory WC-8H-series woodchipper is compact yet built to withstand commercial use. Using
two powerful hydraulic infeed motors, the PTO propelled hydraulically powered infeed rollers grab
and pull material into the chipper head. The hydraulic system is powered by a belt-driven hydraulic
pump in the woodchipper.
1.2 CE Type Plate
The type plate shows the following data:
◼Name of the Manufacturer.
◼Address of the Manufacturer.
◼Machine Model and Type.
◼Manufacturing date.
◼Serial Number.
◼Power.
◼CE Mark.

Operator’s Manual Victory WC-8H - Page 7 of 64 - Version 2.0
1.3 Introduction
CONGRATULATIONS! You have just purchased the Victory WC-8H Woodchipper, the strongest,
safest, and the most compact PTO Woodchipper with self-propelled hydraulic infeed in its
category.
We have compiled this Operator’s manual to help you understand and appreciate your
woodchipper. Taking a few minutes to read this manual and understand the maintenance
instructions will give you better performance and extend the life of your woodchipper. You must
read this manual before assembling and operating the device.
Using This Manual
This Operator’s Manual is created to help familiarize you with Safety, Assembly, Operation,
Adjustments, Troubleshooting and Maintenance.
The information contained within this manual was current at the time of printing. Some parts may
change slightly to assure you of the best performance. To check for updates, refer to our website
at www.etractorimplements.com or call [phone] to speak to one of our representatives.
Owner Assistance
If customer service or spare parts are required, please contact Victory Tractor Implements at
[phone]. Victory has trained technicians, spare parts, and equipment to service the device.
The parts on your machine are specially designed; replace these parts always with genuine Victory
parts. Please reference your order number or serial number when calling.
1.4 Warranty Provisions (See also Chapter 13)
Victory Tractor Implements guarantees the proper functioning of the provided equipment.
However, Victory is not responsible for unsafe situations, accidents, or damage, which are the
result of:
◼ignoring warnings and regulations as stated on the machine or in this Operator's manual;
◼the use of the device for other applications or under other circumstances than stated in this
documentation;
◼mutations to the machine; this also includes the application of different replacement parts as
specified;
◼insufficient or careless maintenance.
1.5 Liability
Victory Tractor Implements can't be held liable for consequential damage (business interruption,
product damage, etc.).

Operator’s Manual Victory WC-8H - Page 8 of 64 - Version 2.0
2INTRODUCTION
2.1 About This Manual
This Operator’s manual belongs to the owner of the Victory WC-8H woodchipper.
Read this Operator’s Manual before operating the WC-8H
•Pay special attention to safety precautions presented in this manual, as
they prevent accidents causing machine damage, human injury, or
death.
•This machine can be dangerous. Therefore, reading this manual
entirely before the operation is essential.
•This manual describes characteristics unique to woodchipper WC-8H.
•In this manual, safety is a priority. You will become aware of the
dangers and hazards of operating this machine by reading it.
2.2 Manual Update
Reason for raising the Operator’s manual to version 2.0:
◼Editorial update according to Standard IEC 82079.
◼Graphics and layout improved.
2.3 Explanation Documentation
Chapter 3; 'Introduction' and Chapter 4, 'Safety' is essential for anyone working on the machine.
◼For operators is essential:
- Chapter 5; Operation.
◼For Service and Maintenance personnel is essential:
- Chapter 5; Operation.
- Chapter 6; Other activities.
- Chapter 7; Maintenance.
◼For Product management is essential:
- Chapter 12; Specifications.
2.4 List of Abbreviations
◼PTO: Power Take Off.
◼ASME: American Society of Mechanical Engineers.
◼PPE: Personal Protective Equipment.

Operator’s Manual Victory WC-8H - Page 9 of 64 - Version 2.0
2.5 Safety Warning Messages in this Manual
Read this manual carefully before using the WC-8H to understand how to use it correctly.
◼After reading, store the manual in a safe place, easily accessible for everyone working with the
machine.
◼Incorrect handling of the equipment could result in personal injury or physical damage.
◼The manufacturer assumes no responsibility for any damage caused by mishandling beyond
normal usage defined in this Operating manual.
DANGER!
•This symbol indicates a potentially and imminently hazardous situation
that, if not avoided, will result in death or severe injury.
This RED symbol indicates All DANGER notifications.
WARNING!
•This symbol indicates a potentially hazardous situation that, if not
avoided, could result in death or severe injury, or machine damage.
This ORANGE symbol indicates All WARNING notifications.
CAUTION!
•This symbol indicates a potentially hazardous situation that, if not
avoided, may result in minor or moderate injury.
This YELLOW symbol indicates All CAUTION notifications.
NOTICE:
•This Notice symbol shows special procedures or points out essential
facts.
◼Always adhere to the recommendations and warnings in this manual. They are the
recommendations of Victory Tractor Implements and several essential components
manufacturers. If you ignore these recommendations, there will be no warranty.
◼Any warranty claim will be rejected if you exceed the maintenance intervals for the essential
machine components claim.
2.6 Intended Users
Intended users are well-trained, technically skilled operators.

Operator’s Manual Victory WC-8H - Page 10 of 64 - Version 2.0
2.7 Intended Use
The WC-8H is a woodchipper for tree branches max 5” thick and other pruning waste.
2.8 Unintended Use
Unintentional use is any other use than described under 'Intended use.'
2.9 Intended Operating Conditions
◼Ambient temperature: 0° to + 40°C.
◼Temp. transport/Storage: –10° up to + 40°C.
◼Lighting: Normal ambient lighting.
2.10 Tools, Parts, and Accessories for assembling and
adjusting
◼Adjustable wrench 1”max.
◼18 mm socket; ½”.
◼17 mm socket; ½”.
◼6 mm Allen key bit socket; ½”.
◼Torque wrench ½”.
◼Awl, Pick.
◼New knife nuts, M10 with Nylon lock.
◼PTO Shear bolts.
◼Tape measure.
◼Feeler gauge; 1.5 mm.
Accessories
◼Heavy leather gloves.
◼This manual.

Operator’s Manual Victory WC-8H - Page 11 of 64 - Version 2.0
3SAFETY INFORMATION
WARNING!
•Read and understand all Safety measures and Warnings before carrying
out any operation or adjustments.
•Untrained persons who have not thoroughly read and understood this
manual might never approach the machine.
•Refer to all safety decals in this manual. Read all instructions noted on
them.
3.1 Introduction
The machine design is such that safe use and maintenance are possible. Anyone who works with it
must know the instructions and regulations stated in this manual.
The owner ensures that users know the instructions, operating regulations, and observations.
In this Operator's Manual, there is a distinction between:
◼Normal / Intended use (see operating instructions).
◼Other activities such as service and maintenance.
This distinction is because operators must meet other (safety) requirements than the technical
service staff.
◼The operator performs the daily cleaning and maintenance work described in the operating
instructions.
3.2 Generally Applicable Safety Rules
This list contains general safety measures which must be complied with for personal safety
reasons.
◼Make sure children and animals cannot come into the machine's vicinity.
◼Only persons who have read and understood the operating instructions might be in the
machine's vicinity.
◼Unauthorized persons may not perform acts if the machine is in use.
◼Never work alone; always ensure that at least one person is nearby.
◼Do not remove the brought warning stickers or markings.
◼Always clean the machine properly and keep the workplace free of dirt and obstacles.
◼Always use the equipment in daylight or ensure sufficient artificial lighting.

Operator’s Manual Victory WC-8H - Page 12 of 64 - Version 2.0
3.3 Personal Protective Equipment
While handling, assembling and maintaining the woodchipper, adhering to all recommended safety
instructions and ensuring that the correct Personal Protective Equipment (PPE) is used.
Always wear:
◼Safety helmet for head protection and prevention from falling objects.
◼Safety gloves for hand protection and prevention of cuts from sharp edges.
◼Steel-tipped safety boots for foot protection from falling objects.
◼Wrap-around safety glasses for eye protection and prevent damage caused by shooting
particles.
◼Safety vest for recognizable presence, visibility and safety.
◼Any other Personal Protection Equipment that might be required, specified, or dictated by the
working environment.
◼Your Company can prescribe additional (safety) instructions. This Manual does not describe
how to comply with this.
3.4 General Safety Rules for Machines
◼Incorrect practice or lack of care can cause burns, wounds, mutilation, suffocation, bodily
injuries, or death.
◼Ensure the work area around the equipment is smooth, clean and free from any obstacles.
Keep in mind that a dangerous situation can always arise.
◼Always wear safety glasses and protective shoes when carrying out the operation.
◼Long hair is not allowed.
◼Never wear loose or torn clothing. Permanently remove jewelry.
◼When lifting heavy parts, use a hoist or ask for help, to prevent personal injury.
◼Ensure that all hoisting equipment such as lifting straps, hooks, or ropes are in a good state of
repair and that they can safely bear the equipment's weight.
◼Never bypass door interlocks or safety sensors and switches.
◼Leaking chemicals, oil, or water on electrical equipment can result in severe damage or fire.
◼Watch for hot parts on switched-off components and hot liquids in lines, pipes, and
compartments to prevent burns.
◼Never open any vent or drain valve or remove any plugs while the system is under pressure.
◼Ensure that oil pumps are isolated from the system and relieve the pressure before
disassembling a pump, removing plugs, or disconnecting piping.
◼Always use tools that are in a good state of repair. Ensure you know how to use the tools
before doing any work.
◼ONLY use replacement parts from the same brand as the relevant part.

Operator’s Manual Victory WC-8H - Page 13 of 64 - Version 2.0
◼Always use replacement fittings having the same part number (or equivalent). Do not use
fitting of inferior quality.
◼Do not make any repairs if you are tired or consume alcohol or drugs, affecting your ability to
work perfectly.
◼PROTECT THE ENVIRONMENT: The handling and cleaning of spent oil or chemicals may be
subject to national or local laws and regulations. Use authorized waste processing services,
including Municipal facilities and garages, which provide official facilities for collecting oil and
chemicals.
◼Contact the provincial or Municipal authorities or the Environmental Protection Service for
guidelines about handling correctly and cleaning up spent oil and chemicals if in doubt.
◼Parts that rotate can cause cuts, mutilations or strangulation.
◼Always switch OFF the main power before performing service and maintenance.
◼Do not allow water or any other fluid to contact electrical components.
◼Switch the power ON only after closing all machine protection guards and covers.
◼Never use a high-pressure water beam for cleaning electrical components and cabinets.
◼Do not aim a high-pressure water beam directly at wiring, breathers, or hydraulic components'
sealings of drive components.
◼Always protect venting spots from the inlet of large amounts of water.
3.5 ADDITIONAL SAFETY RULES FOR WOODCHIPPERS
◼Keep the implement clear of debris and other accumulations.
◼The operator should be familiar with all functions of the device.
◼Start the implement from the driver’s seat only.
◼Persons under 16 should NEVER operate or be near the woodchipper during operation.
◼Set up your work site, so you are not endangering traffic and the public. Take great care to
provide adequate warnings.
◼Do not operate the Woodchipper under the influence of drugs or alcohol, as severe injury or
death could result.
◼Bystanders must keep a safe distance from an operating woodchopper (15 m.)
◼Ensure all guards and shields are secured before operating the equipment.
◼Check the cutting chamber to verify it is empty before starting the machine.
◼Do not operate the device for any purpose other than what it is meant for. (See Chapter
Warranty for details.)
◼Never open safety guards when the machine is working.
◼Never bypass safety sensors or switches.
◼Immediately push the emergency stop and cut off the power if system parts emit smoke,
unusual odor, or unusual sounds. Otherwise, fire may start.
◼Never leave the woodchipper unattended while it is running.
◼Dismounting from a moving tractor could cause severe injury or death.
◼Do not stand between the tractor and the implement during hitching.
◼When raising and moving implements, watch for wires, trees, etc. Make sure all persons are
clear of the working area.
◼Turning the tractor too tight may cause the implement to ride upon wheels. It can result in
injury or equipment damage.

Operator’s Manual Victory WC-8H - Page 14 of 64 - Version 2.0
◼Visually inspect the infeed bin and the flywheel before starting. Ensure that the chipper head is
clear, all the bolts are tightened, and the knives do not touch the case and the counter knife.
◼Ensure the PTO shaft does not come apart or bottom out during the normal lifting range.
◼Check the chip pile to see if the knives need to be serviced. Long slivers in the chip pile are one
of the best indicators of dull knives.
◼It is NOT recommended to operate the woodchipper in temperatures below freezing. Hardened
steel (used on knives) can become brittle in temperatures below freezing and may result in
breakage. Ensure debris does not blow into traffic, parked cars, or pedestrians.
◼Always stand clear of the discharge area when operating this machine. Keep face and body
away from feed and discharge openings.
◼Keep hands and feet out of feed and discharge openings while the machine is operating to
avoid serious personal injury. Stop and allow the woodchipper to come to a complete stop
before clearing obstructions.
◼Do not climb on the machine when operating. Keep proper balance and footing at all times.
◼The disk will continue to rotate when the clutch is disengaged or reversing valves in the
median. Shut off the tractor, remove the ignition key, and ensure all moving parts have come
to a complete stop.
◼Do not insert logs more prominent than 5 inches in diameter into the woodchipper or machine;
damage may occur.
◼When feeding wood into the machine, do not allow metal, bottles, cans, or other foreign
material.
◼Do not allow processed material to build up in the discharge area. It may prevent proper
discharge and kick-off material through the feed opening.
◼Shut off the woodchipper immediately if it becomes clogged, the cutting mechanism strikes any
foreign object, or the machine starts vibrating or making an unusual noise. Shut off the engine,
remove the tractor’s ignition key and make sure all moving parts have come to a complete
stop. After the woodchipper stops: Inspect for damage.
◼Check blade bolts for proper torque after every 8 hours of operation. Keep blades sharp.
Failure to do so may cause poor performance, damage, or personal injury and void the machine
warranty.
3.6 More Safety Tips for Safe Operation
◼Always keep the guards and chip deflector installed properly while operating the chipper.
◼Never leave the chipper running unattended.
◼Do not attempt alterations, repairs, or adjustments while the flywheel turns.
◼Always disconnect the PTO, stop the tractor’s motor, and put the key in your pocket before
attempting any alterations, repairs, or adjustments.
◼Keep hands, feet, clothing, and other extremities away from the hopper (infeed bin) and any
power-driven parts. Wear snug-fitting clothing to avoid entanglement with moving parts.
◼Do not wear loose clothing when working around the woodchipper. Personal injury can occur if
someone or something turns the flywheel over while checking the knives or adjusting the
cutter bar. The flywheel has enough residual energy to remove fingers easily.

Operator’s Manual Victory WC-8H - Page 15 of 64 - Version 2.0
◼Point the discharge chute away from persons, doorways, sidewalks, or areas obstructing your
view. Point the chute downwind when possible. This will keep the chips from blowing back in
the operator’s direction.
3.6.1 Use Safety Lights and Devices
◼Driving on public roads, slow-moving tractors, self-propelled equipment, and towed
implements can create a hazard. They are challenging to see, especially at night.
◼Use flashing warning lights and turn signals whenever driving on public roads. Use lights and
devices provided with the implement.
3.6.2 Transport Machinery Safely
◼Comply with state and local laws.
◼The maximum transport speed for any Victory implement is twenty mph on paved surfaces and
ten mph maximum on an unpaved surface. Do not exceed. Never travel at a speed that does
not allow adequate control of steering and stopping. Rough terrain requires a slower speed.
Traveling excessively on uneven terrain that causes violent shaking or bouncing will damage
the attachment point on the implement and/or the tractor. This type of damage is not covered
under warranty.
◼Use the following maximum speed - for paved surfaces only:
-20 mph when weight is less than or equal to the weight of the tractor.
-10 mph when weight is more than the weight of the tractor.
3.6.3 Keep Riders Off Machinery
◼Riders obstruct the operator’s view; they could be struck by foreign objects or thrown from the
machine.
◼Never allow children below 16 to operate the equipment.
3.6.4 Practice Safe Maintenance
◼Always work in a clean and dry environment.
◼Lower the implement to the ground, put the tractor in parking mode, turn off the engine and
remove the ignition key before performing maintenance.
3.6.5 Prepare For Emergencies
◼Be prepared if a fire starts.
◼Keep a first aid kit and fire extinguisher handy.
◼Ensure you have telephone numbers for the doctor, ambulance, hospital, and fire department.

Operator’s Manual Victory WC-8H - Page 16 of 64 - Version 2.0
3.7 SAFETY AND HEALTH MEASURES WHEN USING
HYDRAULIC FLUID
Anyone working on installations where hydraulic fluid, lubricating oil, grease, or preservatives are
used must observe the following rules:
◼Do not remove the protection sleeves from the hydraulic hoses.
◼Avoid prolonged contact of the liquid with the skin. In the event of contact, carefully cleanse
the skin. Wear clothing that is free of this liquid. Also, be careful when eating and drinking
during the operation.
◼Avoid skin contact with liquids over 60°C or hot machine parts.
◼Avoid eye contact; if this happens, cleanse with plenty of water and contact a doctor.
◼Liquid storage must follow official guidelines; pay attention to fire extinguishers and emergency
exits.
◼Permanently remove spilled liquids immediately to prevent them from slipping.
◼Hydraulic liquids should not get into the ground or in surface water.
◼Avoid high-pressure fluids hazards. Escaping fluid under pressure can penetrate the skin
causing severe injury.
◼Avoid the hazard by relieving pressure before disconnecting hydraulic lines.
◼Never try to stop leaks from the system by hand.
◼Have used liquids removed and recycled by specialized companies.
◼Use a piece of paper or cardboard, not body parts, to check for suspected leaks. Wear
protective gloves and safety glasses or goggles when working with hydraulic systems.
◼If an accident occurs, see a doctor immediately. Always treat any fluid injected into the skin
within a few hours.
3.8 INFEED ROLLERS SAFETY
◼The infeed rollers can cause severe injury or death. Keep hands, feet, and clothing away from
the feed rollers and flywheel chipper knife blades.
◼Never climb onto the feed chute when the unit is operating or running.
◼Do not reach inside. Keep proper balance and footing.
◼Never allow passengers to ride on the feed chute.
◼When feeding material into the feed roller, wear eye, face, and hearing protection.
◼Release material and stand to the side of the feed chute.
3.9 PTO DRIVELINE SAFETY
Agriculture and forestry are very hazardous occupations. Today’s farmer spends long hours close
to increasingly complex and powerful machinery.
Everyone from the component supplier and the company that manufacturers and assembles the
machinery to the dealers and ultimately the actual user must keep safety in mind to avoid
accidents.
The safety rules below relate to the driveline of agricultural implements, general safety literature,
and the standards published by the American Society of Agricultural Engineers.
◼Read and follow instructions on PTO safety decals.

Operator’s Manual Victory WC-8H - Page 17 of 64 - Version 2.0
◼Stay alert and pay attention when PTO is operating.
◼Keep bystanders, especially children, away from the PTO driveline.
◼Check the driveline to ensure it is attached securely to the tractor.
◼Keep guards and shields in place at all times while operating. Disengage PTO, shut off the
power source, and ensure all moving parts have come to a complete stop before removing
guards or shields.
◼Clothing worn by the operator must be pretty tight. Never wear loose-fitted jackets, shirts, or
pants when working around the PTO. Tie long hair back or put it under a cap.
◼Keep hydraulic hoses, chains, and other items from contacting the driveline.
◼Do not exceed the recommended 540 rpm PTO operating speed.
◼Before inspecting or servicing the PTO drive area, disengage the driveline, shut off the power
source, and ensure all moving parts have come to a complete stop.
◼Keep hands, feet, and clothing away from all PTO drive parts.
◼Do not clean or touch the PTO shaft when it is running.
3.9.1 Driveline Safety Checklist
Driveline Specifications
The first step toward safe applications is to specify and test the driveline to operate appropriately
under expected field conditions.
◼Specify and test the proper size joints and telescoping members based on the power required
by the implement, rotation speed, joint angles, shock loads, and expected lifetime.
◼Test the hitch geometry to prevent the driveline from:
•Extending beyond the recommended maximum length.
•Bottoming out.
•Reaching a position that allows universal joints to lock.
•Exceeding the maximum allowable angle for the constant velocity of the universal joints.
You can find information concerning these parameters in all driveline manufacturer’s catalogs.
◼Specify and test telescoping members to allow the lowest possible thrust loads, considering the
expected working conditions.
◼Specify and test torque limiters to control excessive shock loads.
◼Specify and test overrunning clutches to prevent inertial loads from overpowering the tractor.
Hazard Reduction
The second step in specifying a safe driveline application is to strive to eliminate as many hazards
as possible
◼On a driveline with torque limiting or overrunning devices, specify that this device is positioned
at the end of the driveline near the implement.
◼To implement connections that require bolts or set screws, select and/or supply hardware that
minimizes protrusions. You can find Information concerning these parameters in all driveline
manufacturer’s catalogs.
◼For the tractor's PTO shaft connections, specify a safety type yoke (twist or slide collar) to
minimize protrusions.

Operator’s Manual Victory WC-8H - Page 18 of 64 - Version 2.0
◼Provide a proper clearance zone for the driveline operation to avoid damaging the shielding
components.
Some common areas of interference are:
◼Three-point linkage.
◼Extended or eye loop hitch pins.
◼Hydraulic hoses.
Guarding
To not effectively eliminated hazards, provide guarding whenever feasible.
The PTO master, critical driveline, and input connection shield should offer an interactive guarding
system.
◼Provide instructions by labels or manuals. Use the implement only with the tractor’s PTO
master shield.
◼Specify and test an integral driveline shield with end cones that overlap but do not interfere
with the PTO master shield or implement an input connection shield.
◼Provide an input connection shield to interact with the integral driveline shield to guard the
shaft coupling and any torque limiting devices installed on the driveline.
◼Check that all routine driveline maintenance can be done without removing the shields.
Warnings and Instructions
Provide warnings and instructions for hazards associated with the machine. Provide instructions
for proper maintenance and repair.
◼Provide labels on the unit to advise the user of proper hitch dimensions and maximum safe
operating speed.
◼Check that proper danger labels are supplied with the driveline concerning these parameters
may be found in all driveline manufacturer’s catalogs.
◼The operator's manual provides instructions for proper driveline operation, maintenance, and
repair.
◼Advise against using PTO adapters, which may defeat the purpose of the tractor’s master shield
and adversely affect the driveline's performance.
◼Advise the user of locations of genuine original equipment spare parts.
You can obtain further information about driveline specifications and safety from your driveline
supplier and the following ASME standards and engineering practices:
◼S203 Rear power take-off for agricultural tractors.
◼S205 Power take-off definitions and terminology of farming tractors.
◼S207 Operating requirements for tractors and power take-off driven equipment implements.
◼S318 Safety for agricultural equipment.
◼S331 Implement power take-off driveline specifications.
◼S333 Agricultural tractor auxiliary power take-off drives.
◼S350 Safety alert symbol for agricultural equipment.
◼S441 Safety signs.
◼S493 Guarding for agricultural equipment.

Operator’s Manual Victory WC-8H - Page 19 of 64 - Version 2.0
◼EP363 Technical publications for agricultural equipment.
Other standards may apply to particular types of implements. All driveline manufacturers strive to
produce a safe product.
Like most other components, drivelines must be appropriately used, including proper tractor
master shields and implement input connection shields. Please contact us if you have any
questions about your driveline applications.
3.10 Not Allowed Use
It is not allowed to use the WC-8H other than for woodchipper activities.
3.11 Safety Decals and Markings on the WC-8H
Your woodchipper comes equipped with all safety decals in place. The decals are designed to help
you safely operate your implement. Read and follow their directions.
◼Read and follow instructions on all safety decals.
◼Keep all safety decals clean and legible.
◼Replace all damaged or missing decals or labels. To order new ones, call Victory Tractor
Implements.
◼New equipment installed during repair requires safety labels to be affixed to the replaced
component as specified. When ordering new components, ensure the correct safety labels are
included in the request.
DANGER decal
READ THE OPERATOR’S MANUAL BEFORE OPERATING
MAINTENANCE AND REPAIR.
DANGER decal
THROWN OBJECT HAZARD.

Operator’s Manual Victory WC-8H - Page 20 of 64 - Version 2.0
DANGER decal
DO NOT STAND BEHIND THE TRACTOR OR IMPLEMENT.
DANGER decal
TURNING COMPONENTS.
•Danger of being caught by rotating parts.
WARNING decal
WARNING FOR HIGH-PRESSURE HYDRAULIC FLUID.
WARNING decal
MAX. OPERATING PTO SHAFT SPEED 540 rpm.
