Cube Design RAW gable ends User manual

RAW gable ends
Phone no:
Email:
Website:
Version:
[phone]
[email protected]
www.cube-design.dk/en
02-01-2024
Cube Design A/S
Vadstedvej 212 | DK-8450 Hammel | Phone no.: [phone] | www.cube-design.dk/en | [e-mail]
Parts list:
1. 2 x gable ends
2. 1 x metal frame in 2 or
3 pieces
3. 4,5 x 16 mm screws for
brackets and magnets
4. 4 mm magnets
5. 4 mm washers
Assembly manual for RAW gable ends
A product by Cube Design
CUBE
DESIGN

Cube Design A/S
Vadstedvej 212 | DK-8450 Hammel | Phone no.: [phone] | www.cube-design.dk/en | [email protected]
Step 1: Position the inner side of the RAW gable end as shown.
Step 2: Mount each of the metal frames with the supplied screws and washers in the pre-drilled holes:
Place a washer between bracket and gable, and then mount a screw through the washer.
For easier assembling use a universal joint or exible bit holder.
Step 3: Place the outer gable on a soft non-scratching surface. Take care not to scratch the surface.
Mount the supplied magnets with screws in the pre-drilled holes.
Assembly manual for RAW gable ends
CUBE
DESIGN

Cube Design A/S
Vadstedvej 212 | DK-8450 Hammel | Phone no.: [phone] | www.cube-design.dk/en | [email protected]
Do not over-tighten the screws as the magnets may break.
Step 4: Place the outer gable in the metal frame, and gently push it in place, until the magnets snap.
The RAW gable end is assembled and nished.
You can now mount other accessories, like cable tray or acoustic screen for Bench.
Enjoy your new RAW gable ends!
Assembly manual for RAW gable ends
CUBE
DESIGN
