Cupra Ateca 2018 User manual

ATECA
Owner’s manual
ATECA Inglés (09.18)
575012720BF
Inglés 575012720BF (09.18)

SEAT S.A. is permanently concerned about continuous development of its types and models. For this reason we ask you to understand,
that at any given time, changes regarding shape, equipment and technique may take place on the car delivered. For this reason no
right at all may derive based on the data, drawings and descriptions in this current handbook.
All texts, illustrations and standards in this handbook are based on the status of information at the time of printing. Except for error or
omission, the information included in the current handbook is valid as of the date of closing print.
Re-printing, copying or translating, whether total or partial is not allowed unless SEAT allows it in written form.
SEAT reserves all rights in accordance with the “Copyright” Act.
All rights on changes are reserved.
❀
This paper has been manufactured using bleached non-chlorine cellulose.
© SEAT S.A. - Reprint: 15.09.18
Vehicle identication data
Model:
Vehicle Registration:
Vehicle identification
number:
Date of vehicle registration
or vehicle delivery:
SEAT Official Service:
Service advisor:
Telephone:
Conrmation of receipt of
documentation and vehicle keys
The following items were delivered
with the vehicle: YES NO
On-board documentation
First key
Second key
Correct working order of all keys was
checked
Location:
Date:
Signature of owner:

Introduction
Thank you for your trust choosing a CUPRA
vehicle.
With your new CUPRA, you will be able to en-
joy a vehicle with state-of-the-art technolo-
gy and top quality features.
We recommend reading this Instruction
Manual carefully to learn more about your
vehicle so you can enjoy all its benefits in
your daily driving.
Information about handling is complemen-
ted with instructions regarding the operation
and maintenance of the vehicle in order to
ensure its safety and maintain its value.
Moreover, we want to give you valuable ad-
vice and tips to drive your vehicle efficiently
and respecting the environment.
We wish you safe and enjoyable motoring.
CUPRA
WARNING
Read and always observe safety infor-
mation concerning the passenger's
front airbag ›››page 74, Important in-
formation regarding the front passeng-
er's airbag.

About this manual
This manual describes the features of the
vehicle at the time of drafting this text. Some
of the features described below will be intro-
duced in the future or will only be available in
certain markets.
Some of the features described here are
not included in all the types or variations
of the model and they can be varied or
modified based on technical or marketing
requirements without it being considered
misleading advertising.
Some details on the drawings may vary from
its vehicle and must be interpreted as a
standard representation.
The direction indicators (left, right, for-
wards, backwards) in this manual refer to the
travel direction of the vehicle unless other-
wise stated.
The audiovisual material is only meant to
help the users better understand some fea-
tures of the car. It is not a replacement for
the instruction manual. Access the instruc-
tion manual to see the complete information
and warnings.
The features marked with an asterisk
are included by default only in certain
versions of the model, supplied as op-
tional only for certain versions or only
offered in certain countries.

Trademarks are marked with ®. The ab-
sence of this symbol does not guaran-
tee that the term is not a trademark.
It indicates that the section continues
on the next page.
Important warnings on the page.
More in-depth content on the page.
General information on page indicated.
Emergency information on the page.
You can access the information in this man-
ual using:
●Thematic table of contents that follows the
manual’s general chapter structure.
●Visual table of contents that uses graphics
to indicate the pages containing “essential”
information, which is detailed in the corre-
sponding chapters.
●Alphabetical index with many terms and
synonyms to help you find information.
WARNING
Texts after this symbol contain informa-
tion about safety and warn you about
possible accident or injury risks.
®





CAUTION
Texts after this symbol indicate possible
damage to the vehicle.
For the sake of the environment
Texts after this symbol contain informa-
tion about the protection of the envi-
ronment.
Note
Texts after this symbol contain addition-
al information.

Printed Instruction Manual
The printed instruction manual contains rel-
evant information about the use of the vehi-
cle and the Infotainment System.
The digital version of the manuals contains
more in-depth information.

Frequently Asked Ques-
tions
Before driving
How do you adjust the seat? ›››page 19
How do you adjust the steering wheel?
›››page 21
How do you adjust the exterior mirrors?
›››page 20
How do you turn on the exterior lights?
›››page 30
How does the automatic gearbox selector lever
work? ›››page 38
How do you refuel? ›››page 41
How do you activate the windscreen wipers and
windscreen washer system? ›››page 32
Emergency situations
A warning lamp lights up or flashes. What does
this mean? ›››page 36
How do you open the bonnet? ›››page 17
How do you perform a jump start? ›››page 52
Where is the vehicle tool kit located?
›››page 48
How do you repair a tyre with the anti-puncture
kit? ›››page 47
How do you change a wheel? ›››page 48
How do you change a fuse? ›››page 45
How do you change a light? ›››page 46
How do you tow a vehicle? ›››page 51
Useful tips
How do you set the time? ›››page 104
When should the vehicle inspection should be
performed? ›››page 106
What functions do the buttons/thumbwheels on
the steering wheel perform? ›››page 110
How do you remove the luggage compartment
cover? ›››page 155
How do you drive in an economical and environ-
mentally-friendly way? ›››page 233
How do you check and top up the engine oil?
›››page 41
How do you check and top up the engine cool-
ant? ›››page 42
How do you top up the windscreen washer fluid?
›››page 43
How do you check and top up the brake fluid?
›››page 43
How do you check and adjust tyre pressure val-
ues? ›››page 322
Vehicle washing tips ›››page 334
Functions of interest
Easy Connect, Car menu ›››page 33
How does the START-STOP system work?
›››page 238
What parking assistants are available?
›››page 281
How does the rear assist work? ›››page 294
How does the adaptive cruise control work?
›››page 251
How can the driving mode be adjusted?
›››page 271
How does the lane departure warning system
work? ›››page 260
How does tyre pressure monitoring work?
›››page 325
How do you open the vehicle without a key (Key-
less Access)? ›››page 116
Interior lighting and ambient light ›››page 138
