Original Curidor™ & Curidor™ XL
Owner’s Manual
Congratulations on your new Curidor™! Please follow the instructions to
ensure proper operation and set up. Keep this manual for future references.

Safety Precautions

Safety Precautions and Installation
To reduce the risk of fire, electrical shock, or injury when using your
Curidor™, please follow these basic instructions:
Danger or Warning: An empty Curidor™ can be a hazard for small children or small pets. If
disposing of the unit, remove gasket seals, latches, or entire door from your unused unit.
★Never allow children to operate, play with, or crawl inside the Curidor™.
★Never clean Curidor™ parts with flammable fluids or harsh chemicals. The fumes can
create a fire hazard or explosion.
★Do not store or use flammable chemicals or liquids in the vicinity of this or any other
appliance. The fumes can create a fire hazard or explosion.
★Do not store or install this unit outdoors.
★This unit is designed for curing and storing terpene rich material. Do not store perishable
food items.
Before using your Curidor™:
❏Remove the exterior and interior packaging, as well as plastic film coverings (including
the control panel)
Installation of your Curidor™:
❏Use two or more people to move and install the appliance. Failure to do so can result in
injury.
❏When positioning the Curidor™ in your ideal location, ensure there is at least a 6”
clearance on the sides and a 6” clearance on the back.
❏Please note that this is a freestanding unit, and should not be placed into a built in
space. Even with the recommended clearance, there may not be adequate airflow.
❏It is recommended that you position the Curidor™ in an interior space where the ambient
temperature is between 68˚F-78˚F. This unit must be installed in an area protected from the
elements, such as wind, rain, water spray/drips/or vapor, or direct sunlight.
❏This appliance should not be located next to ovens, grills or other sources of heat.
❏The appliance must be installed with all electrical connections in accordance with state
and local codes.
❏This unit requires a 15 amp circuit supplying 120V power.
❏It is important to level the appliance in order for it to work properly. For a stable installation,
make sure the appliance is place on a flat and solid surface.
❏Ensure that the surface on which the appliance is placed is strong enough to hold the
appliance and the items stored inside.
❏Do not use solvent-based cleaning agents or abrasives on the interior of the unit. These
cleaners may damage or discolor the interior.

Safety Precautions and Installation
❏Keep fingers out of the “pinch-point” areas. Clearance between the door and the body of
the unit is sealed airtight by weather stripping. Be careful closing doors if/when children
are in the area.
❏Close the Curidor™ immediately after adding or removing any items to ensure that the
internal temperature stays relatively constant. Fluctuations in temperature negatively
impact stored material.
❏Avoid placing any objects on top of the Curidor™.
❏This is an electrical appliance. To avoid injury from electrical shock, do not operate the unit
with wet hands, while standing on a wet surface or standing in water. Do not use outdoors
or in wet conditions.
❏Never pull the power cord to disconnect it from the outlet. Grasp the plug and pull it
directly out of the outlet.
❏Never lift, carry, or drag the appliance by the power cord.
❏This appliance is designed for household, non-commercial use only. Any other use will
void the warranty.
❏Do not plug into the power outlet before set up is complete.
❏Do not cut or remove the ground prong from the power cord.
❏Do not move this appliance without emptying it of the items inside, and securely locking
the door.
Electrical Connection: This unit require a standard 115/120 Volt AC ~/60Hz electrical grounded
three-prong outlet. If not sure, have a qualified electrician inspect the wall outlet and circuit
breaker that the outlet is properly grounded. The cord should be secured behind the unit and not
left exposed or dangling, to prevent injury. The Curidor™ should always be plugged into its own
individual electrical outlet, to prevent overloading the circuit. Repair or replace immediately if
power cord becomes frayed or otherwise damaged.
Extension Cords: Because of the potential safety hazards as well as mechanical hazards, it is
strongly advised that you do not use extension cords with this unit. If you must use an extension
cord, it is absolutely necessary that it be UL/CUL-Listed, three-pronged wire with a grounding type
plug. The rating of the extension cord must be 115V and at least 10 amperes.

Parts Diagram
1. Door Hinge/Cover
8. Control Panel and LED Display
2. Interior LED Light
9. Magnetic Door Seal
3. Fan Mask
10. Double Pane Tempered
Glass
With 99.9% UV Protection
4. Shelf (Curidor™ XL 2qty)
11. Door Handle
5. Adjustable Leveling Feet
12. Door Sealing Gasket
6. Condensate trap
13. Secure Barrel Lock and Latch
7. Light button
*Note: The exact Curidor™ model size may slightly vary, but all
parts are in corresponding locations.

Installation and Operation Guide
Installation:
1. Remove all packaging, including any interior packaging.
2. Set the Curidor™ on a designated surface strong enough to support the Curidor™ and
the expected weight of the contents being stored inside.
3. Clean the interior surface using a damp cloth if any residues or dust.
4. To install the Towel Bar style handle please follow these instructions:
a. First, you will need a Phillips screwdriver (+)
b. Gather the screws, handle, and caps to prepare for installation.
c. Along the left side of the door (facing onwards) you will find two pre-drilled holes.
d. Hold up the handle to align its holes with the holes on the side of the door frame
(handle protruding outwards as shown in “Parts Diagram”)
e. First, insert the top screw through the handle’s top hole and into the top hole on
the door frame. Tighten slightly, but not all the way.
f. Similarly, insert the bottom screw, securing the bottom on the handle to the door.
g. Tighten both the top and bottom screw firmly (hand tight)
h. Insert the “caps” into the holes in the handle to visibly cover the screw heads.
5. Fill your Curidor™ with the products you wish to cure and store in the appropriately sized
impermeable containers.
6. Arrange your items inside to allow for a quick means of retrieving certain items.
Minimizing frequent openings or openings with long durations will increase the efficiency
of the Curidor™ as well as eliminate the possibility of temperature or humidity
fluctuations inside the machine.
7. Close the Curidor™ door and lock it using one of the two keys.
8. Finally, insert the power cord plug into a grounded power socket with 110V~AC/60Hz.
9. Set your desired temperature.
*Note: Upon initial set up, or repowering, of your Curidor™ it will take up to 48 hours to
reach the set temperature. The unit works using slow-cycle cooling to pull the thermal
masses stored inside to spec temperature, ensuring the optimization of humidity inside
the Curidor™ hits our target spec of 58-60% RH.
Setting Temperature:
Drier Flowers and Herbs
52˚F - 60˚F
Use the temperature adjustment buttons on the control panel to change the temperature.
Press the “Down” button to lower the set temperature.
Press the “Up” button to raise the set temperature.

Installation and Operation Guide
Interior light:
Your Curidor™ has an interior LED light on the ceiling panel inside the unit.
❖To turn the light “ON” or “OFF”, simply press the button on the Control Panel.
Door Lock:
Your Curidor™ comes with a factory installed secure barrel lock to prevent children or
unwanted persons from accessing products stored inside.
❖To lock your Curidor™, insert the key into the keyhole and turn the key counter
clockwise until the metal cam is fully extended (pointing downwards) and engaged.
❖To unlock your Curidor™ insert the key into the keyhole and turn the key clockwise
to disengage the cam from from its locked position.
Caution: Be sure to keep the keys in a safe location and out of reach of children.
Adjustable Leveling Feet:
Your Curidor™ has four adjustable leveling feet on the underside of the unit’s base. These
feet are adjustable as to level your Curidor™ ensuring proper operation. Using a
carpenter’s level, please follow these steps to properly level your Curidor™.
❖To adjust these legs, be sure that the Curidor™ is empty of any contents inside,
and the door is secured in its locked position.
❖Carefully lean the Curidor™ to one side to access the adjustable feet.
❖To raise the Curidor™: rotate the leg counter clockwise, extending the length of the
leg from the base of the unit.
❖To lower the Curidor™: rotate the leg clockwise, shortening the length of the leg
from the base of the unit.
Shelving:
Your Curidor™ comes with removable shelves. The Original Curidor™ comes standard
with one shelf, while the Curidor™ XL comes standard with two shelves.
❖To adjust the shelves, please simply remove any items on top of them, and pull
directly out of the Curidor™.
❖Place the shelf back in by sliding it into one of the designated shelf groves inlaid in
the interior walls of the Curidor™.
*Please follow the same instructions for the L+W Rolling Trays (item sold separately).

Installation and Operation Guide
Cleaning the Curidor™:
1. Turn the Curidor™ off by unplugging the cord from the outlet.
2. Remove all items from the Curidor™.
3. Using a damp rag or cloth wipe the interior, exterior, and shelves. A mild cleaner may be
used but please be sure not to use any caustic or abrasive cleaning agents or scrubbers.
4. Dry using a dry cloth. Allow to air dry with the door ajar until absolutely sure any excess
moisture has evaporated.
5. Refill your Curidor™ with your items, close the door, lock it, plug it in, and choose your
setting (follow standard operating instructions included in this manual).
Transporting the Curidor™:
The ideal packaging for the Curidor™ is its original packaging. Please keep all
packaging in the case you need to repack the unit for transport to a new location.
The Original Curidor™ and Curidor™ XL can be tilted, and powered on immediately after
transport, whereas the Curidor™ Pro must rest in final resting position for a minimum of
6 hours.
Technical Data:
Model:
Original Curidor™
Curidor™ XL
Storage Capacity:
Roughly 2 lbs dried material
Roughly 5 lbs dried material
Cooling system:
Electrical Control
Electrical Control
Required Power Supply:
120 Volts / 60 Hertz
120 Volts / 60 Hertz
Power Consumption:
70 Watts / 1.0 Amps
70 Watts / 1.0 Amps
Net Weight of Unit:
35 lbs
50 lbs
Dimensions:
17”W x 19”D x 20”H
*add 1.25” in depth with handle installed
18”W x 20.5”D x 29”H
*add 1.25” in depth with handle installed

Installation and Operation Guide
How to use your Curidor™:
Preserving organic material is an Art.
Terpene Volatility is Science.
Combining Science with the Art of preservation is “Curing”.
● The Primary Drying Phase is the initial post-harvest process of removing the majority of
moisture from the organic material. The duration of this process can differ depending on
the material’s density, volume, and influence of ambient conditions, but most often takes
between 0 and 10 days. Using dehumidifiers, fans, or ideally a CurePro™ system, to dry
the material in a controlled space, this phase removes the majority of the material’s
moisture content.
● The Secondary Drying Phase, is the phase when the moisture which remains deep inside
the material is removed slowly, and the material’s exposure to ambient air is diminished.
Using large containers or vessels a technique commonly referred to as “burping”, is used
to expel the residual moisture by frequently opening the container to allow a brief
exchange of air. This “burping” process is best accomplished by storing the container
inside your Curidor™ to protect the volatile terpenes and precious characteristics (color,
flavor, and potency of the medicinal constituents) of the material from degradation.
This process will vary greatly depending on the varietal, density, and volume of the
material, but typically takes between 10-20 days. *This is where you become the artist: by
controlling the burping frequency and duration.
● Storage: Upon completion of the drying process to your preferred moisture content
(most often between 9-12%), the material is finally ready to be stored:
1. Consolidate your dried material into varietals and quantities that correlate with your
preferred consumption.
2. Using impermeable containers (water and air tight), fill the containers with the
material which you are wishing to store.
3. Be sure to fill in a way that the material is not crushed, but is filling/occupying the
space of the container as best as possible.
Note: We recommend filling many smaller jars of the same product versus
fewer larger jars. This allows you to have a smaller quantity that you open
and consume at one time, ensuring the remainder of that batch of material
stays in optimal conditions and is not oxidized prematurely.
4. Seal the containers tightly, label, and place inside your Curidor™. Be sure to
organize your collection in a way that you easily understand. This will allow for
quick removal of product and avoiding frequent or long door openings, which can
offset humidity and temperature levels.
5. Enjoy your collection responsibly!

Troubleshooting
Problem
Possible Causes
Solutions
The Curidor™ does not
operate.
● There is a power failure
● The Curidor™ is not
plugged in.
● A house fuse has blown or
the circuit breaker tripped.
● Ensure the Curidor™ is
plugged in and the outlet
has power.
● Replace the broken fuse or
reset the breaker.
The Curidor™ is not reaching
the desired set temperature.
● The Curidor™ is placed
too close to a heat source.
● Too frequent of openings.
● The door is not closed
completely.
● The door gasket does not
seal properly.
● Adjust the Temperature
● Keep the Curidor™ away
from direct sunlight or heat
sources.
● Close the door tightly, and
refrain from frequent
openings.
● Ensure gasket is not
compromised.
Frost forming inside the
Curidor™.
● The environment is too
humid.
● The ambient temperature
is too low.
● The door is opened too
frequently or for too long of
a period of time.
● Items inside are blocking
the internal fan.
● Although this Curidor™
uses an auto-defrost
system, under certain
conditions, manual defrost-
ing may be required. If
Frost builds up, try running
the unit on a warmer
temperature setting.
● Close the door tightly and
do not open the door too
frequently or for long
periods of time.
● Move items if blocking fans
Condensation build up on the
glass door or too high of
humidity within the Curidor™
● Ambient temperature or
humidity is too high
● Lower the room’s humidity
by using a dehumidifier
● Lower the room’s
temperature by using
appropriate appliances.
The Curidor™ turns itself on
and off frequently.
● The ambient (room)
temperature is too low or
too high.
● A large amount of contents
have been added inside
the Curidor™.
● Decrease or increase the
ambient room
temperature.
● To minimize internal temp
fluctuations do not add
large amounts of contents
at once.
