DISHWASHER
INSTALLATION / INSTRUCTION MANUAL
CID45B10
CID45B10_IB_110426.indd 1 4/26/11 8:14 PM

CID45B10_IB_110426.indd 2 4/26/11 8:14 PM

Contents
Unpacking.................................................................................................................................... 5
Installation ................................................................................................................................... 6
Location ..................................................................................................................................................................... 6
Product Overview...................................................................................................................... 12
Internal View...........................................................................................................................................................12
Rear View .................................................................................................................................................................12
Control Panel..........................................................................................................................................................13
Wash Cycle Table........................................................................................................................ 14
Before Operating....................................................................................................................... 15
To Open the Door.................................................................................................................................................15
To Close the Door .................................................................................................................................................15
Items Not Suitable for Use in the Dishwasher............................................................................................15
Adding Detergent or Detergent Tablet.................................................................................... 16
Adding Rinse Aid .......................................................................................................................17
Adjusting the Rinse Aid Reservoir..................................................................................................................17
Adding Salt .............................................................................................................................................................18
Adjusting Salt Consumption............................................................................................................................19
Loading the Dishwasher ........................................................................................................... 20
Before Loading the Dishwasher......................................................................................................................20
Upper Basket..........................................................................................................................................................21
- Adjusting the Upper Basket...................................................................................................................21
- Hinged Cup Rack .......................................................................................................................................21
- Loading the Upper Basket for 8 Place Settings...............................................................................22
Lower Basket ..........................................................................................................................................................22
- Hinged Spikes.............................................................................................................................................22
- Loading the Lower Basket for 8 Place Settings...............................................................................22
Cutlery Basket........................................................................................................................................................23
Starting a Wash Cycle ................................................................................................................24
Changing a Programme ............................................................................................................24
At the End of a Programme....................................................................................................... 24
Switching O the Unit............................................................................................................... 25
Unloading the Dishwasher .......................................................................................................25
Delay Start.................................................................................................................................. 25
Cleaning After Use..................................................................................................................... 26
External Care ..........................................................................................................................................................26
- The Door and the Door Seal ..................................................................................................................26
- The Control Panel ......................................................................................................................................26
Internal Care...........................................................................................................................................................26
- Filtering System..........................................................................................................................................26
- Spray Arms...................................................................................................................................................27
CID45B10_IB_110426.indd 3 4/26/11 8:14 PM

Frost Precaution ........................................................................................................................ 27
Moving the Dishwasher ............................................................................................................ 27
Maintenance After a Prolonged Period of Non-Operation ....................................................27
Hints and Tips ............................................................................................................................ 28
Fault Code ...............................................................................................................................................................28
Technical Problems..............................................................................................................................................28
Disposal of the Dishwasher ......................................................................................................30
Disposal of Packing Material .................................................................................................... 30
Specications............................................................................................................................. 31
Safety Warnings......................................................................................................................... 32
CID45B10_IB_110426.indd 4 4/26/11 8:14 PM

GB-5
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
Thank you for purchasing the new Curry Essentials Dishwasher.
We recommend that you spend some time reading this installation / instruction
manual in order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this installation /
instruction manual for future reference.
This product has been wet tested to ensure correct operation. As a result some water may remain
inside the unit. This is normal and safe. Remove any water droplets from the exterior if necessary.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
The Main Unit
Lower Hook X 2
P.N.: 672000200103
Detergent Measuring Spoon X 1
1 full spoon = 20g (approx.)
P.N.: 673002200079
Instruction Manual X 1
P.N.: CID45B10-002
Door Template X 1
P.N.: 675001800309
ST4 screws X 10
P.N.: 672000900040
ST3.9x13 screws (white) X 2
P.N.: 672000900078
Condensation Strip X 1
P.N.: 675001300715
ST3.9x13 screws (black) X 2
P.N.: 672000900079
3.5x25 screws X 2
P.N.: 672000900041
U-Shape Hose Holder X 1
P.N.: 673006200003
Salt Funnel X 1
P.N.: 673002200043
Hop Hook X 2
P.N.: 672000200023
Measuring Cup X 1
60ml (approx.)
P.N.: 673006200004
Water Supply Hose X 1
P.N.: 673005400045
Cutlery Basket
P.N.: 673002200049
4x18 screws X 2
P.N.: 672000900039
4x20 screws X 2
P.N.: 672000900036
CID45B10_IB_110426.indd 5 4/26/11 8:15 PM

GB-6
INSTALLATION
1. Please ensure the dishwasher is installed by a
qualified technician. Refer to the tools required.
Location
When selecting a position for your dishwasher you
should make sure the installation surface is flat
and firm, and the room is well ventilated. Avoid
locating your dishwasher near a heat source, e.g.
cooker, boiler or radiator. Extreme cold ambient
temperatures may also cause the appliance not to
perform properly. This dishwasher is not designed
for use in a garage or outdoor installation.
Do not drape the dishwasher with any covering.
When installing, ensure that free space is left at the
sides.
2. Ensure there is clearance each side of the unit
to allow slight sideways movement for servicing
when required. Good levelling is essential for
correct closure and sealing of the door. When
the unit is correctly levelled, the door should
not catch the inner liner on either side of the
cabinet. The adjustable feet may be loosened
or tightened in order to obtain the optimum
levelling of the unit.
level
level
level level
screw
cone
gear
level
Installation
All parts removed must be saved to do
the reinstallation in the future. Ensure
the dishwasher is unplugged and empty.
We recommend that 2 people handle the
dishwasher during installation.
The supplied door template also contains
installation steps which will assist
installation.
CID45B10_IB_110426.indd 6 4/26/11 8:15 PM

GB-7
INSTALLATION
3. The height of the unit is 820 mm. The figure
outlines the minimum dimensions required
to accommodate the dishwasher within fitted
kitchen furniture units.
820
450
560
450
540
820
unit in mm
4. Do not connect the unit to the mains socket
before installation. Ensure you are not installing
the unit right in front of the mains socket. This
is to avoid potential damage to the back of the
unit.
5. The condensation strip must be fitted to
the underside of the worktop above your
dishwasher to protect it against any moisture. Its
purpose is to protect your worktop’s underside
from steam rising from the dishwasher.
Remove the backing paper from the
condensation strip.
Ensure the surface is clean prior to
sticking the condensation strip to
the underside of the worktop.
Leave some space
Stick the Condensation
Strip under the worktop,
where you want to
install the dishwasher.
6. Stick the condensation strip to the underside of
the worktop.
Failure to attach the condensation
strip could result in damage to the
underside of your worktop!
CID45B10_IB_110426.indd 7 4/26/11 8:15 PM

GB-8
INSTALLATION
7. Position the dishwasher next to a water tap and
a drain. Ensure the water inlet and drain hoses
are not kinked or squashed. The unit must not
stand on the mains cable.
8. To secure the dishwasher under the table top,
tighten the screws through the top sides of the
unit onto the table top.
<4.5kg
9. Tape the supplied Door Template to the
dishwasher door. Make sure the top of the
template is at the top of the door. Drill the
required holes following the depth and diametre
shown on the Door Template.
CID45B10_IB_110426.indd 8 4/26/11 8:15 PM

GB-9
INSTALLATION
10. Install the Aesthetic Panel onto the dishwasher door. Ensure the aesthetic panel weight is a
minimum of 3kg and a maximum of 6kg. After the aesthetic panel is installed, the tension of the
dishwasher door spring can be adjusted by rotating the adjusting bolt. If the tension is right, the
door will remain horizontal in the fully open position.
4 X 18 screw
Cover
Spacer for
aesthetic
panel
Hook for
aesthetic panel
Aesthetic panel
Outer door of
dishwasher
Lower hook
Hop hook
ST4 countersunk
head screw
11. Ensure to tighten the screws on both sides of
the dishwasher door and to secure the Aesthetic
Panel.
Rubber cover
Screw
4*14 screw
Loosen
12. Adjust the bolt to loosen or tighten the tension
of the dishwasher door.
CID45B10_IB_110426.indd 9 4/26/11 8:15 PM

GB-10
INSTALLATION
• Do not bend your drain hose.
14. Make sure your plumbing is suitable for use with
the dishwasher. If in doubt contact a qualified
plumber. This unit MUST BE connected to COLD
WATER MAINS using the new water inlet hose.
OLD HOSE SETS MUST NOT BE RE-USED. The
water pressure from the water mains needs to
be at a minimum of 0.04 MPa and a maximum of
1.00MPa.
• Connect one end of the safety water supply
hose to your dishwasher, and then connect
the other end of the hose to your water
mains. Please ensure the black rubber seal is
in place.
• After connecting the hose, turn on your water
mains and check for leaks.
• Connect the dishwasher to the mains socket.
water mains
water supply hose
Y-Adaptor
(not included)
Connect to
another
appliance
if required.
You may use a Y-Adaptor (not included)
for an additional water feed for another
appliance, for example a washing
machine. This is only applicable for cold
water mains. A Y-Adaptor is available
from most DIY stores.
screw
cone
gear
level
13. Adjust the adjustable feet again to obtain the
optimum levelling of the unit.
CID45B10_IB_110426.indd 10 4/26/11 8:15 PM

GB-11
INSTALLATION
water drain
hose
U-shaped drain
hose holder
• You may use the U-shaped drain hose holder
to secure your drain hose and to avoid
bending it.
• The waste pipe must only be connected
to the foul drains and not the surface
water drainage system.
• The water drain hose should be placed
between 40 cm and 100 cm from the
floor level and must not be extended,
otherwise the unit may not be able to
expel the waste water properly.
• Secure the water drain hose to the waste pipe
to avoid it coming off during the washing
process.
CID45B10_IB_110426.indd 11 4/26/11 8:15 PM

GB-12
Product Overview
Internal View
Rear View
Upper
Basket
Rinse Aid
Reservoir
Detergent
Dispenser
Cup Rack
Lower
Basket
Spray Arm
Filtering System
Salt Reservoir
Water Inlet
Mains Cable
Drain Outlet
Drain Hose
CID45B10_IB_110426.indd 12 4/26/11 8:15 PM

GB-13
Control Panel
3h 9h
6h 12h
1h
1 2 3 4 4
1. On/Off Button
• To turn the dishwasher on and off.
Power On light
• Illuminates when On/Off button is pressed.
2. Rinse Aid Refill Warning Light
• Illuminates when the rinse aid dispenser needs refilling.
Salt Refill Warning Light
• Illuminates when the salt reservoir needs refilling.
3 Delay Start Button and Indicator Lights
• Press to preset the wash timer and delay the starting time by up to 12 hours.
• Illuminates when different delay start time is selected, for examples 3 hours, 6 hours, 9 hours or 12
hours only.
4. Function Button
• Press to select the 3 in 1 function in washing cycle.
Indicator Light
• Illuminates when the 3 in 1 function is selected.
5. Programme Control Buttons
• Press to select your required washing programme.
CID45B10_IB_110426.indd 13 4/26/11 8:15 PM

GB-14
Wash Cycle Table
Programme Cycle
Cycle
Selection
Information
Process
Detergent
Amount
(Pre-wash/
Main wash)
Running
Time
(min.)
Energy
Consumption
(Kwh)
Water
Consumption
(I)
Rinse
Aid
Intensive • Pots, utensils
and cutlery.
• Highly
soiled.
• Pre-wash
(50°C)
• Pre-wash
• Wash (65°C)
• Rinse (55°C)
• Drying
• Pre-wash
(4g)
• Main wash
(20g)
OR
• All in 1
120 1.2 18.5
Normal • Pots, utensils
and cutlery.
• Normally
soiled.
• Pre-wash
(50°C)
• Wash (50°C)
• Rinse (65°C)
• Drying
• Pre-wash
(4g)
• Main wash
(20g)
OR
• All in 1
150 0.95 13
Economy*
(EN50242)
• Plates,
glasses,
bowls.
• Lightly
soiled.
• Pre-wash
• Wash (55°C)
• Rinse (65°C)
• Drying
• Pre-wash
(4g)
• Main wash
(20g)
OR
• All in 1
160 0.74 12
1 hour
1h
• 1 hour wash
for lightly
to normal
soiled loads.
• Wash (65°C)
• Rinse (50°C)
• Drying
• Pre-wash
(4g)
• Main wash
(20g)
OR
• All in 1
60 0.72 10
Rapid • A shorter
wash for
lightly soiled
loads that
do not need
drying.
• Wash (40°C)
• Rinse (45°C)
• Main wash
(15g)
30 0.4 10
* To comply with Standards of Performance, i.e. EN50242, please ensure to use economy washing cycle for
the test.
3 in 1 function is available only for intensive, normal, or economy washing cycle.
If you choose to use detergent tablet in these washing cycles, please do not add rinse aid.
Condensing dry technology
• Energy is saved by drying the dishes using the remaining heat after the last rinse cycle.
• Wash cycle times are extended due to this drying method.
• Some wash programmes do not have a drying function, please refer to the Wash Cycle Table for
more details.
CID45B10_IB_110426.indd 14 4/26/11 8:15 PM

GB-15
●●
Small plastic items
(Milk bottle nipple)
Plastic items that
are not dishwasher safe
Crystal glasses
Silverware
Valuable vases
Copper pots and pans
Cast iron pans
Cracked / Chipped china
Scratched non-stick cookware
Towels and sponges
The Following Items Are Not Suitable
Before Operating
To Open the Door
• Pull the door handle.
• If the door is opened during operation all functions are automatically interrupted.
To Close the Door
• After loading the dishes, push the baskets fully into the dishwasher.
• Lift the door upwards and push until it clicks into position.
• Do not slam the dishwasher door.
Items Not Suitable for Use in the Dishwasher
When purchasing new crockery and cutlery, please make sure they are dishwasher-proof. Some items are
not suitable for dishwashers.
• Wooden cutlery and crockery or items with wooden parts may discolour and fade. The glue used in
these items is not dishwasher-proof and wooden handles may come loose after being washed in a
dishwasher.
• Craft items, antiques, valuable vases and decorative glassware are also not suitable for dishwashers.
• Plastic items (e.g. tupperware) which are not heat resistant may melt or loose shape due to the high
temperature in the dishwasher.
• Copper, brass, tin and aluminium items may discolour or become matt.
• Clouding may occur on glasses and delicate glassware after frequent washing. Do not wash delicate
glassware, or glassware containing lead crystal in a dishwasher. Wash delicate glassware by hand
instead.
• Silver and aluminium parts have a tendency to discolour during washing. Residues like egg white, egg
yolk and mustard often cause discolouring and staining on silver. Therefore, please clean the residues
from silver immediately after use.
CID45B10_IB_110426.indd 15 4/26/11 8:15 PM

GB-16
• Keep out of the reach of children.
• Irritating to eyes.
• Avoid contact with eyes. In case of contact with eyes, rinse immediately
with plenty of water and seek medical advice.
• If swallowed, seek medical advice immediately.
Adding Detergent or Detergent Tablet
Only use detergents specifically designed for use in dishwashers. To be more environmentally friendly,
please use no more than the correct amount of detergent. Fill the detergent dispenser with detergent
powder or tablet.
Please follow the steps below to fill the detergent dispenser.
1. Push the button on the lid of the detergent
dispenser in the direction of the arrow until the
flap springs open.
2. Fill the detergent dispenser with detergent
powder or insert the detergent tablet. The
marking indicates the filling level.
Bleach and
Countertop detergent Irritant
pre-wash detergent chamber
main wash detergent chamber
or
3. All programmes with pre-wash need an additional
detergent dosage that must be placed in the pre-
wash detergent chamber (please refer to the wash
cycle table). This detergent will take effect during
the pre-wash phase.
4. Close the lid firmly so that it clicks into place.
You can choose to add a detergent tablet
alone or to add detergent powder to both
the main wash detergent chamber and the
pre-wash detergent chamber for your selected
wash cycle.
push up from the right side
CID45B10_IB_110426.indd 16 4/26/11 8:15 PM

GB-17
Adding Rinse Aid
Rinse aid helps to ensure water does not cling and leave marks on crockery during the drying phase and
helps crockery dry faster after it has been washed. Only pour rinse aid that is for domestic dishwashers into
the reservoir. This model is designed to use liquid rinse aids only.
Please follow the steps below to pour the rinse aid into the storage reservoir, and the amount will dispense
automatically.
1. Turn the cap and open as indicated.
2. When the cap open marking is aligned, you
may lift the cap up.
3. Pour the rinse aid in until the level indicator
turns completely black in colour and close the
cap.
4. Be careful not to overfill the reservoir. Wipe up
any spills.
open
rinse aid indicator
Adjusting the Rinse Aid Reservoir
The rinse aid reservoir has six settings. Both the recommended
setting and the factory setting is “4”. If the dishes are not drying
properly or are spotted, adjust the dial to the next higher number
until your dishes are spot-free.
• If the water hardness in your area is soft, you may not need rinse aid as it may cause white film to
develop on your dishes.
• If there are some rinse aid residue left in the washing compartment of your dishes, please turn
the rinse aid dispenser dial to 1.
• If you select to use detergent tablet, you do not need to add rinse aid into the rinse aid reservoir.
• Rinse aid warning light will illuminate when the reservoir is running out of rinse aid and
requires refilling.
• Alternatively, you can judge the amount of rinse aid by checking the rinse aid indicator right
next to the reservoir’s cap. When the indicator is black, it means it is full. When it is clear, it
means it is almost empty.
CID45B10_IB_110426.indd 17 4/26/11 8:15 PM

GB-18
Adding Salt
If the water in your area is hard, deposits will form on your dishes and
utensils. This appliance contains a salt reservoir for you to reduce the
hardness of the water.
Please follow the steps below to pour the salt into the salt reservoir and
it must be set to correspond to the water hardness level in your area.
1. Remove the lower basket and unscrew the reservoir cap.
2. Fill the reservoir with approximately 500ml of water (first use only).
3. Place the funnel provided over the salt reservoir.
4. Pour in approximately 1.2kg of dishwasher salt depending on the
brand used.
5. Clean any excess salt from around the reservoir opening and then
screw the cap on again firmly.
6. Run the “Rapid” wash programme immediately (without any
crockery in the dishwasher) to remove any traces of salt from the
compartment.
OPEN
open
open
open
• The salt warning light will illuminate when the reservoir
is running out of salt and requires re-filling.
• The salt warning light will cease to illuminate within a
few days depending on how quickly the salt dissolves.
• If you select to use detergent tablet, you do not need to
add rinse aid into the rinse aid reservoir.
CID45B10_IB_110426.indd 18 4/26/11 8:15 PM

GB-19
Adjusting Salt Consumption
Salt consumption must be adjusted to correspond to the water hardness level in your area. If you don’t
know how hard the water in your home is, please ask the company that supplies water in your area.
It is recommended that adjustments should be made in accordance with the following chart.
WATER HARDNESS Selector
Position
Salt Consumption
(gram/cycle)
Number of cycle
/ 1.2 kgs
˚dh ˚fh ˚Clark mmol/l
0-8 0-14 0-10 0-1.4 / 0 /
8-22 14-39 10-28 1.4-3.9 - 20 60
22-45 39-80 28-56 3.9-8 Mid 40 30
>45 >80 >56 >8 + 60 20
turn
To optimise and customise the level of salt consumption, please follow the steps below.
1. Remove the lower basket and unscrew the reservoir cap.
2. There is an arrow-shaped indicator in the reservoir, which you can turn. You may turn it to the “-” or “+”
settings based on the water hardness in your area.
1 ˚dh (German degree) = 1.25mmol/l
1 ˚fh (French degree) = 0.178mmol/l
1 ˚Clark (British degree) = 1.78mmol/l
• Do not use everyday table salt or cooking salt
as they contain insoluble substances which
could damage the dishwasher.
• Do not pour detergent into the salt container.
This will damage the dishwasher.
CID45B10_IB_110426.indd 19 4/26/11 8:15 PM

GB-20
Loading the Dishwasher
Before Loading the Dishwasher
Please observe the following notes before loading your cutlery and crockery into the basket.
• Remove lipstick stains and any food residues from crockery and dishes. Rinse if necessary.
• Dishes and cutlery must not lay inside one another, or cover each other.
• Load your cutlery and crockery so that water can access all surfaces.
• Ensure all items are securely positioned.
• Hollow items such as cups, glasses, pans, etc. must be placed upside down in the basket.
• Wide based items should be placed at an angle so that water can run off them freely.
• The spray arms must not be blocked by items which are too tall or hang through the baskets. If in
doubt, test for free movement by manually rotating the spray arms.
• Ensure that small items cannot fall through the holders in the baskets.
Do not wash items soiled with ash, sand, wax, lubricating grease or paint in the dishwasher. Ash
does not dissolve and can distribute in the dishwasher. Wax, sand, lubricating grease and paint can
cause damage to the dishwasher.
CID45B10_IB_110426.indd 20 4/26/11 8:15 PM
