G3 DIGITAL COMBO BREW SYSTEMS
ITEM NO
PROJECT
DATE
MODELS: CBS, CBP
• G3 Digital Control Module (G3/Technology) –
 Offersfullbrewingprogrammabilitywith
 unsurpassedreliability.Allowsforgourmetne-tuning
 withPulse-Brewing,Pre-Infusion,Fast-Brew,
 Dual-BatchandotherG3standardfeatures.
• Two Preset Buttons for Coffee and Tea –
Allowsyoutoselectbetweensmallandlargebrews
 atthetouchofabutton.
• Curtis’ Exclusive G3 3-Year Warranty – Protectsyour
 digitalinvestment.
• Intuitive Scroll-Through Prescision Programming–
 Largedisplaycommunicatesfunctionsataglance.
 Easilyadjusttime,volume,temperature,brew
 functionsandmore.
• Saves Operating Costs –Savemodeautomatically
 activateswhenbrewerisidle.
• On-Board Diagnostics Reduce Downtime –
 Continualsensingofproperoperation.AService
 PhoneNumberanderrorcodewillbedisplayedin
 therareeventassistanceisrequired.
• Standard (CBS) and Low-Profile (CBP) Models –
 Selecttheidealmodeltosuiteoperationalspaceand
 volumerequirements.
ICED TEA BREAWING FEATURES
• Factory Set Iced Tea Recipes . . . Regular
and Tropical –Forout-of-the-boxoperation.
• G3 Enhanced Tea Flavor & Clarity –Twoseparate
 precisionvalvesandG3technologyprovide
 unsurpassedcontroloverconcentratebrewingand
 dilutioncycles.
• “Tuneability” –Digitallypreciseadjustmentsallow
 fornetuningoftea’savor.
• Automatic Brew Lock-Out Switch for
Enhanced Safety –Teabrewingisonlyallowed
 whenTCODispenserisdetectedinplace.
COFFEE BREWING FEATURES
• Gourmet Fine Tuning Brewing Modes –
 Pre-infusionorpulsebrewenhancesextractionof
 gourmetcoffeeavor.
• Adjustable Shelf –Accommodatesbrewing
 intosmallerairpotsandother
 servingvessels.
FEATURES AT A GLANCE
The Curtis GT ComboBrew.
Your SINGLE, simple brewing solution for
avorful iced tea and gourmet coffee!
 NowyoucanbrewcrystalclearicedteaANDrich,robustcoffeefromthe
sameprecisionsystem.Withasimplechangeofbrewingvesselandbrewcone
thenewCurtisG3ComboBrewprovideyouthatandawholelotmore.
AtthecenteroftheComboBrewisCurtis’exclusiveG3UniversalControl
Module.Thissophisticateddigital“brain”providesprecisioncontroloverthe
entirebrewingandoperatingprocess.Itspre-programmedfactorysettings
deliveridealresultsrightoutofthecarton.Simplyaddbulktealeaves,
owthrulterpacksorgroundcoffee,thenpresstheclearlymarkedbrew
buttonforgallonsofcool,avorfulicedteaorrichcoffeeinjustminutes.
 WiththeCurtisComboBrew,qualitycoffeebrewingisnotanafterthought...
thesystemhasbeenengineeredtoprovidethesamegourmetbrewingfeatures
asourG3Airpotsystem.
Revolutionary Design
TWO Ultra-Precision Inlet Valves
and Water Level Sensor System provide
unsurpased tea flavor
CBS10000-
ComboBrewSystem
ShownwithTCO421OvalTeaDispenser(L)
andTLXA-22AirpotCoffeeDispenser(R).
Safetyswitch
ensuresteabrewing
onlywhenproper
vesselisinplace
CBP10000-
LowProleComboBrewSystem
ShownwithstandardTCO308OvalTeaDispenser
(L)andThermoProTLXP-19PourPotwithshort
brewcone(R).

CBP
3Gallons
29”x9”20.875”
9”
120AVAC/60Hz
1700W/14.2A
6ft/NEMA5-15P
1/4”Flare
46lbs.
7.5
WILBUR CURTIS COMPANY, INC.
6913 Acco Street, Montebello, CA 90640-5403
Telephone: [phone] · 323-837-2300
Fax: [phone]
www.wilburcurtis.com
© 2008 Wilbur Curtis Company, Inc. Printed In U.S.A · JUN/08 – 12626 F-3359 revD
CBS
(Dispenser Not Included)
CBP
Low Profile
(TCO 308 Dispenser Included)
Specifications
FinishedBrewCapacity
Dimensions(HxWxD)
FaucetClearance
Voltage
PowerRequirements
Cord&Plug
WaterInlet
ShippingWeight
Cube(cu.ft)
CBS
3to5Gallons
34”x10.125”x20.875”
N/A
120AVAC/60Hz
1675W/14A
6ft/NEMA5-15P
1/4”Flare
38lbs.
9.14
Accessories for Tea
Description
Capacity
Dimensions(H”)
TC-3H TCO421
RoundTeaDispenser
3.5gal.
22.75”
OvalTeaDispenserOvalTeaDispenser
withEZVU-BrewThru/SolidLidCombination
3gal.4gal.
9.875”21.75”
TC-5H-S TCO308
RoundTeaDispenser
5gal.
23”
Accessories for Coffee
Description
Capacity
Dimensions(H”)
CLXP64 TLXP19 TLXA25 TLXA22 TLXA30 CAP-T1
ThermalPourPot
64oz./1.9L
7.25”
ThermalPourPot*
64oz./1.9L
11.5”
AirpotLever*
2.5L
11”
AirpotLever
(CBSonly)
2.2L
13”
AirpotLever
(CBSonly)
3.0L
12”
GravityThermalServer
w/base(CBSonly)
2.5L
16.75”
34"
(864cm)
23.125"
(586.1cm)
9"
(230.2cm)
11.375"
(289.4cm)
16.5"
(420.7cm)
1.125”
(27.3cm)
30"
(762.4cm)
20.875"
(529.4cm)
5.25"
(134.2cm)
8.25"
(209.6cm)
14"
(355.6cm)
3 1/4"
(82.7cm)
3.625"
(92.1cm)
1.125"
(27.3cm)
10.125"
(255.8cm)
9.3125”
14.125”
16.5”
13.5”
22.5”
20.875”
8.25”
11.125”
10.3125”
11.4375”
9.375”
3.6875”
*RequiresoptionalWC-37242shortbrewconeonCBP.
