Service Manual – ThermoPro Single Head Brewer
FOR THE LATEST SPECIFICATIONS AND INFORMATION GO TO
W W W.WILBU RC U RTIS.COM
Important Safeguards/Conventions
This appliance is designed for commercial use. Any servicing other than cleaning and maintenance should be performed by an
authorized Wilbur Curtis service center.
• Do NOT immerse the unit in water or any other liquid
• To reduce the risk of fire or electric shock, do NOT open top or side panels. No user serviceable parts inside. Repair
should be done only by authorized service personnel.
• Keep hands and other items away from hot parts of unit during operation.
• Never clean with scouring powders, bleach or harsh implements.
Conventions
WARNINGS – To help avoid personal injury
Important Notes/Cautions – from the factory
Sanitation Requirements
This Curtis Generation 3 Unit is Factory Pre-Set and Ready to Go… Right from the Carton.
Following are the Factory Settings for your G3 Coffee Brewing Systems:
• Brew Temperature = 200°F • Water Bypass = On for LARGE (35%) MEDIUM (10%) SMALL (0%)
• Brew Volume = Set to Vessel Requirement. • Sleep Mode = Off
System Requirements:
• Water Source 20 – 90 PSI (Minimum Flow Rate of 1 GPM)
• Electrical: See attached schematic for standard model or visit www.wilburcurtis.com for your model.
SETUP STEPS
The unit should be level (left to right and front to back), located on a solid counter top. Connect a water line from the water filter
to the brewer. NOTE: Some type of water filtration device must be used to maintain a trouble-free operation. (In areas with
extremely hard water, we suggest that a sedimentary and taste & odor filter be installed.) This will prolong the life of your brewing
system and enhance coffee quality.
1. A 3/8” NPT x 3/8” Flare elbow has been supplied for water line connection. Use tubing sized sufficiently to provide a
minimum of 1.0 GPM.
2. To hookup the InterLock grinder, Locate the jack labeled “Class 2 Wiring Only” on brewer and grinder. Connect the two with
the cable plug.
3. Connect the unit to an appropriate electrical power circuit.
4. Turn on the toggle (STANDBY/ON) switch behind the unit. The heating tank will start to fill. When the water level in the
tank rises to the correct volume, the heating elements will energize automatically. With ADS Systems there is no danger
of element burnout caused by an empty tank.
5. The heating tank will require 20 to 30 minutes to reach operating temperature (200°F) as indicated by the READY-TO-
BREW indicator.
6. Prior to brewing, dispense 12 ounces of hot water through the hot water faucet.
7. Brew a cycle of at least 12 ounces, to purge the water lines of any air that may be trapped after filling.
The National Sanitation Foundation requires the following water connection:
1. A quick disconnect or additional coiled tubing (at least 2x the depth of the unit) so that the machine can be moved
for cleaning underneath.
2. In some areas an approved backflow prevention device may be required between the brewer and the water supply.
WILBUR CURTIS COMPANY, INC.
WILBUR CURTIS COMPANY
Montebello,CA 90640
Models Included
 TP2S
CAUTION:DONOT
connect this brewer to
hot water. The inlet valve
is not rated for hot water.
CAUTION:Pleaseuse
this setup procedure
before attempting to use
this brewer. Failure to follow the
instructions can result in injury or
the voiding of the warranty.
WARNING TO AVOID
SCALDING, Do not
remove brewcone while
brew light is flashing.
ISO9001REGISTERED
WARNING HOT LIQUID,
Scalding may occur.
Avoid splashing.
IMPORTANT:
Equipment to be
installed to comply with
applicable federal, state, or local
plumbing/electrical codes having
jurisdiction.
BREWING INSTRUCTIONS
1. Brewer should be ON (Confirm at rear toggle switch, then press the ON/OFF button). Ready-to-Brew should be ON. If
connected to an InterLock grinder, grinder should be on. If Interlocked, grind coffee at this time.
2. Place an empty ThermoPro server under the brewcone.
6. Press Brew button.
Brewing will begin
immediately.
5. Transfer filled
brewcone to
brewer.
3. Place a clean filter
into the brewcone. 4. Fill brewcone with ground coffee.

2
Your Curtis ADS System is Factory Pre-Set for Optimum Performance.
After connection to water and power; the rear toggle switch must be on. You will hear a beep sound, indicating power is available to the controller.
The control displays . Press ON/OFF button and the screen will display . After three seconds, is displayed.
Water will fill the tank (approximately 2-3 minutes depending on water flow rate). When the proper level is reached will appear on the
screen. It takes approximately 20 minutes to reach setpoint temperature of 200°F.
Control will display when temperature reaches the setpoint (200°F). Unit is now ready to brew.
T-PRO1
CURTIS
CURTIS CURTIS
FILLING...
CURTIS
HEATING. . .
CURTIS
READYTOBREW
ThermoPro
All programming selections are performed with the three center buttons.
The symbols below the buttons are:
Scroll LEFT
SELECTIONorENTERtosavenewparameter
ScrollRIGHT
IMPORTANTNOTE:

Illustrated Parts List
3
1
2
2A
3
4
5
5A
5B
6
6A
7
8
9
10
11
12
13
14
14A
15
16
17
18
19
20
21
22
22A
23
24
24A
25
26
27
28
29
WC-61509
GEM-6-01
GEM-6
WC--3765L*
WC- 844-101*
WC-39444
WC-39417
WC-39416
WC-3354
WC-3357
WC-29050*
WC-58037-101
WC- 847*
WC-1501
WC-37122*
WC-37132*
WC-1825
WC-8559*
WC-8556-101
WC-8591*
WC-3526
WC-5350*
WC-5851
WC-5502*
WC-4382
WC-5310*
WC- 904-04
WC- 906-04*
WC- 522*
WC-61500
WC-61505
WC- 102*
WC-5231*
WC-1438-101*
WC-37176
WC-43055
COVER, TOP WRAP
FILTERS, 12½” X 4” 500/PKG (FOR WC-3354)
FILTERS, 500/PKG (USE WITH WC-3357)
KIT, VALVE REPAIR USE ON WC-825 & WC-826
VALVE, ADJ BY-PASS
LABEL, UCM OVERLAY TP2S 3-BATCH CURTIS
LABEL, UCM OVERLAY TP2S 1-BATCH CURTIS
LABEL, UCM OVERLAY TP2S 2-BATCH CURTIS
BREWCONEASSY, GOURMET LARGE CAP
BREWCONEASSYW/BASKET(NOTSHOWN)
SPRAYHEAD ASSY, ADVANCED FLOW
COVER, CENTER WRAP
VALVE, WATER INLET 2GPM 120V 10W
FUSE HOLDER W/5A FUSE
KIT, DUMP VALVE BREW RIGHT
KIT, DUMP VALVE WC-820WC-821,WC-844
FAUCET ASSY, HOT WATER TP2S/2T
RELAY, SOLID STATE 40A W/HEAT SINK
HEATSINK, ASSY W/OPTICAL BD (OLDER UNITS)
CAPACITOR, X2
LEG, ADJUSTABLE 4 IN ASSY
TUBE, ½ ID x 1/8W SILICONE
COVER, TANK W/KNOTCHES
PROBE, WATER LEVEL
GUARD, SHOCK HEATING ELEMENTS
TUBE, 5/16” I.D. X 1/8” SILICONE (NOT SHOWN)
ELEMENT, HEATING 1.6KW 120V W/JAM NUTS
ELEMENT, HEATING 2KW 220V W/JAM NUTS
THERMOSTAT,RESET
TANK ASSY, COMPLETE 120V 3.2KW
TANK ASSY, COMPLETE 220V 4.0KW
SWITCH, TOGGLE
COMPOUND, SILICONE
SENSOR, HEATING TANK
KIT, UCM & LABEL INSTRUCTIONS
GUARD, SHOCK RESET THERMOSTAT
NºPart NºDescription
26
27 C
D
3
E
12
11
C
2
6D
* Recommended Parts to Stock
EF
28

Electrical Diagram
ThermoPro Single – 220 Volt
4

ThermoPro Single – 220 Volt
ASEE ECN-7023 FOR RESIVIONS
7023 SJ
5

WILBURCURTISCO., INC.
6913 Acco St., Montebello, CA 90640-5403 USA
Phone: [phone] Fax: [phone]
Technical Support Phone: [phone] (M-F 5:30A - 4:00P PST) E-Mail: [email protected]
Web Site: www.wilburcurtis.com
6Printed in U.S.A. 9/06 F-3316-S Rev C
ProductWarrantyInformation
TheWilburCurtisCompanycertifiesthatitsproductsarefreefromdefectsinmaterialandworkmanshipundernormaluse. Thefollowinglimitedwarranties
andconditionsapply:
3Years,PartsandLabor,fromOriginalDateofPurchaseondigitalcontrolboards.
2Years,Parts,fromOriginalDateofPurchaseonallotherelectricalcomponents,fittingsandtubing.
1Year,Labor,fromOriginalDateofPurchaseonallelectricalcomponents,fittingsandtubing.
Additionally,theWilburCurtisCompanywarrantsitsGrindingBurrsforForty(40)monthsfromdateofpurchaseor40,000poundsofcoffee,whichever
comesfirst. StainlessSteelcomponentsarewarrantedfortwo(2)yearsfromdateofpurchaseagainstleakingorpittingandreplacementpartsare
warrantedforninety(90)daysfromdateofpurchaseorfortheremainderofthelimitedwarrantyperiodoftheequipmentinwhichthecomponentis
installed.
Allin-warrantyservicecallsmusthavepriorauthorization. ForAuthorization,calltheTechnicalSupportDepartmentat1-800-995-0417. Effectivedate
ofthispolicyisApril1,2003.
Additionalconditionsmayapply. Gotowww.wilburcurtis.comtoviewthefullproductwarrantyinformation.
CONDITIONS&EXCEPTIONS
Thewarrantycoversoriginalequipmentattimeofpurchaseonly.TheWilburCurtisCompany,Inc.,assumesnoresponsibilityforsubstitutereplacement
partsinstalledonCurtisequipmentthathavenotbeenpurchasedfromthe
WilburCurtisCompany,Inc. TheWilburCurtisCompanywillnotacceptanyresponsibilityifthefollowingconditionsarenotmet.Thewarrantydoesnot
coverandisvoidunderthefollowingcircumstances:
1) Improper operation of equipment: Theequipmentmustbeusedfor its designed and intended purpose and function.
2) Improperinstallationofequipment: Thisequipmentmustbeinstalledbyaprofessionaltechnicianandmustcomplywithalllocalelectrical,
mechanicalandplumbingcodes.
3) Impropervoltage: Equipmentmustbeinstalledatthevoltagestatedontheserialplatesuppliedwiththisequipment.
4) Improperwatersupply: Thisincludes,butisnotlimitedto,excessiveorlowwaterpressure,andinadequateorfluctuatingwaterflowrate.
5) Adjustments and cleaning: The resetting of safety thermostats and circuit breakers, programming and temperature adjustments are the
responsibilityoftheequipmentowner. Theownerisresponsibleforpropercleaningandregularmaintenanceofthisequipment.
6) Damagedintransit: Equipmentdamagedintransitistheresponsibilityofthefreightcompanyandaclaimshouldbemadewiththecarrier.
7) Abuseorneglect(includingfailuretoperiodicallycleanorremovelimeaccumulations): Manufacturerisnotresponsibleforvariationin
equipment operation due to excessive lime or local water conditions. The equipment must be maintained according to the manufacturer’s
recommendations.
8) Replacement of items subject to normal use and wear: Thisshall include, butisnotlimitedto, light bulbs, shear disks, “0” rings,gaskets,
siliconetube,canisterassemblies,whipperchambersandplates,mixingbowls,agitationassembliesandwhipperpropellers.
9) Repairsand/orReplacementsaresubjecttoourdecisionthattheworkmanshiporpartswerefaultyandthedefectsshowedupundernormal
use. Alllaborshallbeperformedduringregularworkinghours.Overtimechargesaretheresponsibilityoftheowner. Chargesincurredbydelays,
waiting time, or operating restrictions that hinder the service technician’s ability to perform service is the responsibility of the owner of the
equipment. Thisincludesinstitutionalandcorrectionalfacilities. TheWilburCurtisCompanywillallowupto100miles,roundtrip,perin-warranty
servicecall.
RETURNMERCHANDISEAUTHORIZATION: AllclaimsunderthiswarrantymustbesubmittedtotheWilburCurtisCompanyTechnicalSupport
Departmentpriortoperforminganyrepair work orreturn ofthisequipmenttothefactory. Allreturned equipmentmustberepackagedproperlyin
theoriginalcarton.No unitswill beacceptedif theyare damagedintransitdueto improperpackaging. NOUNITS ORPARTS WILLBEAC-
CEPTEDWITHOUTARETURNMERCHANDISEAUTHORIZATION(RMA). RMANUMBERMUST BEMARKED ONTHE CARTONOR
SHIPPINGLABEL. Allin-warrantyservicecallsmustbeperformedbyanauthorizedserviceagent. CalltheWilburCurtisTechnicalSupport
Departmenttofindanagentnearyou.
