Curtis PCGT3 User manual

HOT COLD
G3 PRIMO CAPPUCCINO SYSTEMS
MODELS: PCGT3; PCGT4; PCGT5
Rich in Design.
Rich in Features.
Rich in Profits.
ITEM NO
PROJECT
DATE

•G3 ADS™ Digital Control Module (G3/ADS™) –
Provides precise control over all critical blending
and dispensing functions.
•Pre-Dispense – Easy to use. Choose a size from
small, medium or large by the touch of a button.
•Factory Pre-Set – For out-of-the-box operation.
•Irradiant LCD Digital Display – Extra bright and
easy to see.
•Scroll-Through Precision Programming –
Adjust powder flow in 5% increments and water
temperature from 80°F to 200°F to create the
perfect hot or cold beverage for your operation.
•Uniform programming is ideal for large roll-
outs of equipment.
•Access Code – Prevents unauthorized access to
programming and control features.
•Touch Controls –
Smooth and easy-to-
clean.
•On-Board
Diagnostics –
Continually senses
proper operation. A
Service Number will
be displayed if tech-
nical assistance is
required.
•Fully Sealed – G3 chips and processors are
encapsulated in an impact-resistant polymer, vir-
tually eliminating the harmful effects of heat,
moisture and physical damage.
•Direct Drive Mixing Augers – Ensure smooth,
high-speed blending of powdered drinks.
•High Velocity Whipping Motors – Sloped whip-
ping motors ensure smooth, high-speed blending
of powdered drinks.
•Digital Temperature Control – Precisely senses
water temperature and level to maximize energy
efficiency and prevent heating element burnout.
•Fixed-Flow Water System – Ensures precise drink
blending regardless of irregularities in water pres-
sure/volume.
•Standard 120VAC Operation – Makes installation
quick and simple.
•Curtis Exclusive 3/2/1 Warranty – 3-years elec-
tronic components, 2-years non-electronic com-
ponents, 1-year labor.
FEATURES AT A GLANCE
Beautifully styled, digitally advanced and financially rewarding, there’s
never been anything like the all-new G3 Concept
Series Primo Cappuccino™ Machine from Curtis.
The first thing you’ll notice about the new
Primo Cappuccino is its
smooth Euro-Styled lines,
with an impressive, over-
sized backlit display. The PCGT captures attention from the moment your
customers walk in... stimulating more impulse sales.
But the real beauty is what lies behind its stunning surface. Curtis has
incorporated the industry’s most advanced digital technology – G3 ADS™ –
into the new Primo Cappuccino Machine. It’s this G3 technology that
dramatically
simplifies use,
minimizes
maintenance
costs and
increases your
profitability.
Curtis G3 Primo Cappuccino Machines are available in your choice of
models. Select from three, four, or five dispensing heads. Each provides
unmatched reliability, serviceability, sales AND more profits than ever
before!
PCGT3 PCGT4 PCGT5
INTRODUCING . . . THE CURTIS G3 CONCEPT
S E R I E S
C O N C E P T
S E R I E S
Careful liquid is hot • Release button when cup is 3/4 full
Model PCGT3/PCGT5
▲
▲

Large Capacity Drip
Tray/Cup Guide
Integral guide, positions cups
directly below dispensing spout.
Dual overow via-ducts indicate
when drip tray should be drained
and serviced.
Angled Whipping
Chamber and “Brake-Type”
Auger Motors
To ensure perfect drinks, powder
augers feature a brake-type motor
that accurately stops the dispensing
process at your set ratio every time.
Angled chamber drain liquids far
better to signicantly reduce cleaning
requirements.
Multi-Volume Powder Hoppers
Both 5 lb. and 10 lb. sizes allow operators to double the
volume of top selling avors... reducing ll times.
Hoppers must be removed for relling, virtually eliminat-
ing the wear and operating downtime caused by spilled
powder. Positioning guides make it impossible to insert
the hoppers incorrectly.
Pre-Dispense Control Label
Each adjustable station is factory preset to:
12 oz. small cup; 16 oz. medium cup; 20 oz. large cup.
Easy Access Front
Open Door with Inside
Hinged Panel
Simplies powder rells and
maintenance. Provides easy
access to change lighted
graphic or replace the units
standard orescent tube.
Touch-Button Hot Water Cleaning System
Simple, one button operation sends a powerful blast of
hot water into the whipper chamber, rinsing it for easy
clean-up and reducing powder build up.
Easy-Serv Dispensing Tubes.
Bright yellow color directs customers to proper cup
placement. Extended, taper design prevents splashes.
Oversized Backlighted Graphic
Attracts customers. Increases impulse sales. Choose
Hot or Iced Cappuccino graphic on PCGT3 model.
PCGT3 PCGT4
SERIES PRIMO CAPPUCCINO MACHINE.

Hoppers 543
.bl5-3dna.bl01-2.bl5-2dna.bl01-2.bl5-1dna.bl01-2yticapaCreppoH
snollag52.5snollag52.5snollag52.5knaTretaW
”39.71x”5.31”39.71x”5.31”28.11x”57.31)WxH(aerAyalpsiDdethgiL
”5.32x”12x”5.43”5.32x”12x”5.43”5.32x”5.41x”5.43)DxWxH(snoisnemiD
”52.7”52.7”52.7*ecnaraelCpuC
zH06/CAV021zH06/CAV021zH06/CAV021egatloV
A51/W0081A51/W0081A51/W0081stnemeriuqeRrewoP
P51-5AMEN/tf6P51-5AMEN/tf6P51-5AMEN/tf6gulP&droC
eralF”4/1eralF”4/1eralF”4/1telnIretaW
.sbl541.sbl931.sbl08thgieWgnippihS
Cube 01017
34.5
[90.2 cm]
7.25
[18.4 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
14.5
[36.8 cm]
4.7
[11.9 cm]
1.6
[4.1 cm]
34.5
[90.2 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
21.0
[53.3 cm]
7.2
[18.3 cm]
1.6
[4.1 cm]
7.25
[18.4 cm]
34.5
[90.2 cm]
7.25
[18.4 cm]
21.0
[53.3 cm]
7.2
[18.3 cm]
1.6
[4.1 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
34.5
[90.2 cm]
7.25
[18.4 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
14.5
[36.8 cm]
4.7
[11.9 cm]
1.6
[4.1 cm]
34.5
[90.2 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
21.0
[53.3 cm]
7.2
[18.3 cm]
1.6
[4.1 cm]
7.25
[18.4 cm]
34.5
[90.2 cm]
7.25
[18.4 cm]
21.0
[53.3 cm]
7.2
[18.3 cm]
1.6
[4.1 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
WILBUR CURTIS COMPANY, INC.
6913 Acco Street, Montebello, CA 90640-5403
Telephone: [phone] · 323-837-2300
Fax: [phone]
www.wilburcurtis.com
© 2007 Wilbur Curtis Company, Inc. Printed In U.S.A · OCT/07 – 11421 F-3226 rev. D
PCGT3
(Hot and Cold
Cappuccino)
Optional:
Pre-Dispense
PCGT4
5TGCP4TGCP3TGCPsnoitacificepS
34.5
[90.2 cm]
7.25
[18.4 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
14.5
[36.8 cm]
4.7
[11.9 cm]
1.6
[4.1 cm]
34.5
[90.2 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
21.0
[53.3 cm]
7.2
[18.3 cm]
1.6
[4.1 cm]
7.25
[18.4 cm]
34.5
[90.2 cm]
7.25
[18.4 cm]
21.0
[53.3 cm]
7.2
[18.3 cm]
1.6
[4.1 cm]
24.3
[61.7 cm]
23.5
[59.7 cm]
PCGT5
*Shorter extension tubes are available for greater cup clearance.
