Curtis 3301T User manual

Manual
Read Instructions Carefully!
Specications are subject to change without notice.
© 2021 Curtis Instruments, Inc. ® Curtis is a registered trademark of Curtis Instruments, Inc.
© The design and appearance of the products depicted herein are the copyright of Curtis Instruments, Inc. 53245 Rev A September 2021
Curtis Instruments, Inc.
200 Kisco Avenue
Mt. Kisco, NY 10549
www.curtisinstruments.com
» Software Device Profile: 103.0.0.0 «
Model 3301T
Digital Instrumentation

Curtis Model 3301T Digital Instrumentation – September 2021
pg. ii
CHAPTERS
1: OVERVIEW ...................................................................................................................................... 1
USING THIS MANUAL .................................................................................................................... 2
FEATURES .................................................................................................................................... 2
DISPLAY ELEMENTS ............................................................................................................... 2
FAULT CODES AND NAMES ..................................................................................................... 2
PROGRAMMING...................................................................................................................... 3
LCD HEATER........................................................................................................................... 3
MISCELLANEOUS FEATURES................................................................................................... 3
CONVENTIONS.............................................................................................................................. 4
NUMERAL SYSTEM NOTATION ................................................................................................ 4
MISCELLANEOUS CONVENTIONS............................................................................................ 4
2: USING THE 3301T........................................................................................................................... 5
BUTTONS ..................................................................................................................................... 5
POWER-ON 3301T PASSWORD OR ECS AUTHORIZATION .............................................................. 6
POWER-ON 3301T PASSWORD............................................................................................... 6
ECS AUTHORIZATION .............................................................................................................. 8
VIEW FAULT NAMES...................................................................................................................... 9
VIEW AND EDIT PARAMETERS....................................................................................................... 9
OPEN THE 3301T’S MAIN MENU............................................................................................ 10
OPEN THE 3301T’S PARAMETER MENUS ............................................................................... 10
OPEN READ-WRITE PARAMETER MENUS FOR OTHER CURTIS DEVICES.................................. 12
OPEN READ-ONLY PARAMETER MENUS OF DEVICES CONNECTED TO THE SERIAL PORT........ 13
USING THE PARAMETER MENU SCREENS .............................................................................. 13
ALARM BUZZER........................................................................................................................... 15
TABLE OF CONTENTS

Curtis Model 3301T Digital Instrumentation – September 2021 pg. iii
TABLE OF CONTENTS cont’d
PRESET USER INTERFACES — 3301T-7001 MODEL .................................................................... 15
SPEED MODE ........................................................................................................................ 17
SIGNAL ICONS....................................................................................................................... 17
DIRECTION ICONS ................................................................................................................. 18
BDI........................................................................................................................................ 18
SPEEDOMETER...................................................................................................................... 19
CARGO WEIGHT AND LIFT HEIGHT ......................................................................................... 19
CONTROLLER HOUR METERS ................................................................................................ 19
KEYSWITCH HOUR METER ..................................................................................................... 20
STEERING ANGLE .................................................................................................................. 20
FAULT CODES........................................................................................................................ 20
FORKLIFT STATUS ................................................................................................................. 21
3: INSTALLATION AND WIRING ........................................................................................................... 22
INSTALLING THE 3301T ............................................................................................................... 22
I/O CONNECTOR .......................................................................................................................... 23
I/O PINS....................................................................................................................................... 24
WIRING DIAGRAM ........................................................................................................................ 25
OPERATING VOLTAGE ................................................................................................................... 26
OPERATING CURRENT.................................................................................................................. 26
BATTERY CONNECTIONS.............................................................................................................. 27
KEYSWITCH ................................................................................................................................. 27
SWITCH 1–5 INPUTS.................................................................................................................... 27
SWITCH INPUTS .................................................................................................................... 27
FAULT CODE INPUTS.............................................................................................................. 28
SENDER INPUTS.................................................................................................................... 28
MOSFET DRIVER.................................................................................................................... 28
CAN CONNECTIONS..................................................................................................................... 28

Curtis Model 3301T Digital Instrumentation – September 2021
pg. iv
TABLE OF CONTENTS cont’d
4: PROGRAMMABLE PARAMETERS .................................................................................................... 29
MAIN MENU PARAMETERS........................................................................................................... 31
SET HOURMETERS MENU ............................................................................................................ 32
SET HOURMETERS SUBMENU ............................................................................................... 32
CAN MENU .................................................................................................................................. 33
RPDO AND TPDO BYTE MAP MENUS...................................................................................... 34
BDI MENU.................................................................................................................................... 37
PASSWORD MENU ....................................................................................................................... 38
MAINTENANCE MENU .................................................................................................................. 38
ODOMETERS MENU..................................................................................................................... 39
SENDERS MENU .......................................................................................................................... 39
OUTPUT MENU ............................................................................................................................ 40
RAMP MENU ......................................................................................................................... 40
INITIAL MENU........................................................................................................................ 41
CURRENT LIMIT MENU .......................................................................................................... 41
DITHER MENU ....................................................................................................................... 41
PI MENU................................................................................................................................ 42
MISC MENU................................................................................................................................. 42
5: MONITOR PARAMETERS ................................................................................................................ 43
HOURMETERS MENU ................................................................................................................... 43
MAINTENANCE MENU .................................................................................................................. 44
ODOMETERS MENU..................................................................................................................... 44
SENDERS MENU .......................................................................................................................... 44
OUTPUT MENU ............................................................................................................................ 45
TEMPERATURE MENU.................................................................................................................. 45

Curtis Model 3301T Digital Instrumentation – September 2021 pg. v
TABLE OF CONTENTS cont’d
6: CANOPEN COMMUNICATIONS........................................................................................................ 46
BYTE AND BIT SEQUENCE ORDER ................................................................................................ 46
NODE IDS .................................................................................................................................... 47
BAUD RATE.................................................................................................................................. 47
MESSAGE CAN-IDS...................................................................................................................... 47
EXPEDITED SDOS ........................................................................................................................ 47
PDOS........................................................................................................................................... 48
PDO COB-IDS ........................................................................................................................ 48
PDO TIMING .......................................................................................................................... 48
PRECONFIGURED PDOS......................................................................................................... 49
STANDARD CANOPEN OBJECTS................................................................................................... 53
DISPLAY HOUR METERS OBJECT ................................................................................................. 54
APPENDIX A: CURTIS PROGRAMMING DEVICES .................................................................................. 55
APPENDIX B: SPECIFICATIONS ........................................................................................................... 57

Curtis Model 3301T Digital Instrumentation – September 2021
pg. vi
TABLES
TABLE 1 3301T AND CURTIS PROGRAMMING DEVICE ACCESS LEVELS ............................................... 9
TABLE 2 3301T-7001 HOME SCREEN AREAS ..................................................................................... 16
TABLE 3 MATING CONNECTOR PARTS — IP40 PROTECTION.............................................................. 23
TABLE 4 MATING CONNECTOR PARTS — IP54 PROTECTION.............................................................. 23
TABLE 5 I/O PINS............................................................................................................................... 24
TABLE 6 OPERATING CURRENT — LCD HEATER OFF ......................................................................... 26
TABLE 7 OPERATING CURRENT — LCD HEATER ON........................................................................... 26
TABLE 8 PDO BYTE MAP MENUS — CAN INDEXES AND DEFAULT VALUES ......................................... 35
TABLE OF CONTENTS cont’d
FIGURES
FIGURE 1 CURTIS 3301T HMI.............................................................................................................. 1
FIGURE 2 COUNTERBALANCED FORKLIFTS APPLICATION — 3301T-7001.......................................... 15
FIGURE 3 REACH TRUCKS AND ORDER PICKERS APPLICATION — 3301T-7001.................................. 16
FIGURE 4 SPEEDOMETER — COUNTERBALANCED FORKLIFTS .......................................................... 19
FIGURE 5 SPEEDOMETER — REACH TRUCKS AND ORDERS PICKERS ................................................ 19
FIGURE 6 MOUNTING DIMENSIONS.................................................................................................... 22
FIGURE 7 WIRING DIAGRAM ............................................................................................................... 25

pg. 1
Return to TOC Curtis Model 3301T Digital Instrumentation – September 2021
1 — OVERVIEW
1 — OVERVIEW
e Curtis model 3301T is a highly congurable HMI that is suitable for demanding and cost-
sensitive applications. A color 3.5", 320 ×240 pixel high-brightness LCD allows vehicle operators to
view data in any lighting condition. An LCD heater is optional for operation in cold temperatures.
Vehicle operators use buttons to work with the user interface. e buttons make the 3301T ideal for
gloved operators and for applications that require precise tactile feedback.
e 3301T’s congurability allows various screen elements to be displayed. ese elements include
gauges, bar graphs, hour meters, warning icons, speedometers, and so on.
For example, the 3301T-7001 model provides two preset user interfaces: one for counterbalanced
forklis and the other for reach trucks and order pickers. For applications that require a tailor-made
user interface, the 3301T is easily customizable by Curtis engineers.
e 3301T provides four inputs that can be used as switch, analog resistive, analog voltage, and
frequency inputs. It also provides a pin that can be used for either a switch input or an output driver.
e 3301T also transmits and receives data over the CANbus.
Figure 1
Curtis 3301T
HMI

1 — OVERVIEW
Curtis Model 3301T Digital Instrumentation – September 2021 Return to TOC
pg. 2
USING THIS MANUAL
e next section describes the 3301T’s features. e following list describes the topics that apply to
various types of tasks:
• Vehicle operators should read the Using the 3301T chapter.
• Technicians who work on installation and wiring, or who need information on specications,
should read the Installation and Wiring chapter and the Specications appendix.
• Application developers should be familiar with the following chapters:
– Programmable Parameters
– Monitor Parameters
– CANopen Communications
FEATURES
e following sections describe the 3301T’s major features.
Display Elements
e following list describes the 3301T’s major display elements:
• Gauges: Gauges represent various types of data. For example, an application can include
gauges that indicate the vehicle speed, BDI percentage, forkli status, and steering angle.
• Icons: Icons indicate states such as on/o. For example, icons can indicate whether the seat
belt is on or whether li lockout is active.
• Hour meter: Hour meters provide a resolution of 0.1 hours and a maximum of 99999.9
hours. ere are four hour meters: one is for the 3301T and three are for Curtis devices on
the CANbus.
• Speed mode: e 3301T provides buttons for four speed modes. e selected mode is
transmitted over the CANbus.
Fault Codes and Names
e 3301T displays fault codes and names for Curtis devices. ere are a few ways in which the
3301T can receive fault codes:
• e CANbus.
• A switch input for Curtis DC pump controllers such as the 1253 and 1253C models.
• A switch input for Curtis DC traction controllers such as the 1243 and 1244 models.
e corresponding fault names of the fault codes are stored by the 3301T and are displayed on the
Fault Name screen.

1 — OVERVIEW pg. 3
Return to TOC Curtis Model 3301T Digital Instrumentation – September 2021
Programming
e 3301T provides the basic functions of the Curtis 1313 Handheld Programmer. Users can read and
write parameters for the 3301T and for other Curtis devices that are on the CANbus or connected
through the serial port. For more information, see View and Edit Parameters.
LCD Heater
Some models include an LCD heater for vehicles that operate in cold temperatures. e heater
extends the minimum operating temperature from −20°C to −40°C. e 3301T turns the heater on
when the LCD temperature is below −15°C and o when the LCD is heated to 5°C.
e model number indicates whether a 3301T model has an LCD heater. See the Model Encodement
section in the Specications appendix.
Miscellaneous Features
e following list describes other major features:
• Designed to meet regulatory requirements. For details, see the Specications appendix.
• Multi-language support.
• A buzzer alarm that indicates faults.
• CANopen, J1939, and an adjustable baud rate allow for seamless communication with any
node on the CANbus.
• Password protection for the following functions:
– Power on. A power-on password can optionally be specied. e power-on password is
entered with either the 3301T’s buttons or the Curtis Electronic Code Switch (ECS).
– Programming parameters for the 3301T and for other Curtis devices that are on the
CANbus or connected to the serial port. ere are dierent passwords for the OEM and
User access levels.
– Resetting the hour meters.
Note: For additional information on the 3301T’s features, see the data sheet on the Curtis Instruments
CAN & Serial Instrumentation page at https://www.curtisinstruments.com/products/can-serial-
instrumentation-programmable.

1 — OVERVIEW
Curtis Model 3301T Digital Instrumentation – September 2021 Return to TOC
pg. 4
CONVENTIONS
e following topics describe terms and notations used in this manual.
Numeral System Notation
e following table describes how this manual denotes decimal, binary, and hexadecimal numbers.
Note: e letter nin the format column represents a digit.
Numeral System Format Example
Decimal
Either of the following:
• nnn
• nnnd
• 127
• 127d
Hexadecimal
Either of the following:
• nnnh
• 0xnnn
• 62Ah
• 0x62A
Binary nnnb 1011b
In addition, some CANopen examples have hexadecimal values without notation. ose examples
are formatted with a monospace font and with the bytes delimited by spaces, as shown in the
following example:
21 FF 01 11 22 01 00 00
Miscellaneous Conventions
• All voltages listed in this manual are DC voltages.
• RO means read-only.
• RW means read-write.
• N/A means not applicable.

2 — USING THE 3301T pg. 5
Return to TOC Curtis Model 3301T Digital Instrumentation – September 2021
2 — USING THE 3301T
is chapter describes how to use the 3301T’s buttons and screens.
BUTTONS
e following table describes the 3301T’s buttons. e buttons’ functions depend upon which screen
is active.
Button Home Screen Parameter Menu Screens Password Screens
HSpecies the high speed mode. Scrolls up to the previous menu item
on the screen.
Species whether the password is
for the User or OEM access level.
Species the turtle speed mode. Scrolls down to the next menu item on
the screen.
Species whether the password is
for the User or OEM access level.
SSpecies the standard speed mode. Returns to the previous menu.
If the menu is the device’s top menu,
pressing this button returns to the
home screen.
Species whether the password is
for the User or OEM access level.
ESpecies the economy speed mode. If a menu is selected, opens the menu. Species whether the password is
for the User or OEM access level.
F1 Opens the 3301T’s main parameter
menu, which does not require
a password.
Returns to the home screen from the
3301T’s main parameter menu.
Species the number 1.
F2 Opens the 3301T’s password-
protected parameter menus.
Returns to the home screen from
the 3301T’s password-protected
parameter menus.
Species the number 2.
F3 Opens the parameter menus of
other Curtis devices connected
through the CANbus or the
serial port.
Returns to the home screen from the
parameter menus of other
Curtis devices.
Species the number 3.
F4 Opens the parameter menus of Curtis
devices that support the ESP/SP
protocol and are connected through
the serial port. The menus have read-
only access.
Depends upon how the parameter
menu screens were accessed:
• If accessed with the F4 button,
returns to the home screen.
• If accessed with the F2 or F3
button, rapidly increases the
selected parameter’s value by
step sizes of 10, 100, and 1000.
Species the number 4.
C
-
-
No function. • When a writable parameter
is selected, decreases the
parameter value.
• When a menu is selected,
navigates to the previous menu.
• If password characters have
been entered, clears the
last number.
• If password characters either
have not been entered or have
been cleared, returns to the
home screen.
+
+
Opens the Fault Name screen.
Note: This button also exits the Fault
Name screen.
• When a writable parameter is
selected, increases the
parameter value.
• If a menu is selected, opens
the menu.
Submits the password.

2 — USING THE 3301T
Curtis Model 3301T Digital Instrumentation – September 2021 Return to TOC
pg. 6
POWER-ON 3301T PASSWORD OR ECS AUTHORIZATION
e 3301T can be congured so that only authorized users can access the device. ere are two
methods for authorizing access:
• Enter a password on the 3301T keypad.
• Log onto the Curtis Electronic Code Switch (ECS).
Note: e ECS ensures that only authorized users can operate a vehicle. Users log on by entering a
user ID and PIN code or by swiping an RFID tag. For more information, see the Input Devices page
on the Curtis Instruments website.
e following topics describe the two methods.
Power-On 3301T Password
If the 3301T is congured to require a password aer the device is powered on, the following screen
is displayed:

2 — USING THE 3301T pg. 7
Return to TOC Curtis Model 3301T Digital Instrumentation – September 2021
If this screen is visible, take the following steps to access the 3301T:
1. Use the F1–F4 buttons to enter the four-digit password, which consists of the numbers 1–4.
Pressing an F1–F4 button enters the number that follows the letter “F” in the button name: for
example, the F2 button enters 2.
2. To indicate how many of the password characters have been entered, the corresponding circle
in the middle of the screen turns blue when a button is pushed. In the following example, three
numbers have been entered:
Tip: To clear the most recently entered number, press the
C
-
-
button; the corresponding circle
turns white.
3. Press the +
+
button to submit the password. If the password is correct, the home screen
is displayed.
If the password screen indicates that the wrong password was entered, press the
C
-
-
button to
clear the password, then repeat this procedure.
Note: e default power-on password is 1234. Curtis recommends that you change the default
password. e power-on password is specied with the PIN Code parameter.

2 — USING THE 3301T
Curtis Model 3301T Digital Instrumentation – September 2021 Return to TOC
pg. 8
ECS Authorization
If the 3301T is congured to allow only authorized ECS users to access the device, the following
screen is displayed when a user is not logged onto the ECS:
If this screen is visible, log onto the ECS by swiping an RFID tag or by entering an ECS user ID and
PIN code on the ECS keypad. If the RFID tag or user ID and PIN code are valid, the home screen
is displayed.
Note: e CANbus must be in the Operational NMT state in order to log on with the ECS. If you
successfully log onto the ECS but the screen shown in the previous image is still visible, the CANbus
is probably in a dierent NMT state.
Aer you log o of the ECS, the 3301T displays the screen shown in the previous image.

2 — USING THE 3301T pg. 9
Return to TOC Curtis Model 3301T Digital Instrumentation – September 2021
VIEW FAULT NAMES
e Fault Name screen displays the names and fault codes of active faults. In the following example,
faults are active for traction and pump controllers:
Take the following steps to access the Fault Name screen:
1. Go to the home screen.
2. Press the +
+
button.
3. If there are too many faults to display on one screen, the bottom of the Fault Name screen will
display upward-facing and downward-facing triangles. Use the Hand buttons to scroll
through the screens.
To exit the home screen, press the
+
+
button.
VIEW AND EDIT PARAMETERS
You can use the 3301T to view and edit parameters for the 3301T and for other Curtis devices
connected through the CANbus or the serial port. e 3301T parameters are contained by the menus
described in the Programmable Parameters and Monitor Parameters chapters. e parameter menus
can be accessed when the home screen is visible.
Parameters have two access levels: User and OEM. e OEM level provides access to more parameters
than the User level. e following table describes how the 3301T access levels correspond to the
access levels for Curtis programming devices:
Table 1 3301T and Curtis Programming Device Access Levels
3301T Curtis Programming Device
User Field Intermediate
OEM OEM Dealer
A password is required to access the 3301T’s parameter menus and the read-write parameter menus
of other Curtis devices. e access levels have dierent passwords. When you enter a password, the
password is not cleared when the device returns to the home screen; this is for convenience when
testing and debugging parameter changes. Aer you have nished working with parameters, cycle
the keyswitch to clear the password.

2 — USING THE 3301T
Curtis Model 3301T Digital Instrumentation – September 2021 Return to TOC
pg. 10
e following list describes the default passwords for accessing parameter menus:
• User access level: 1111
• OEM access level: 2222
Curtis recommends that you change the default passwords. Passwords are changed with the OEM
Menu Password and USER Menu Password parameters on the Password menu.
e following topics describe how to open and use the screens.
Open the 3301T’s Main Menu
e 3301T’s main menu is not password-protected. Take the following steps to open the main menu.
Note: e parameters contained by the Monitor and Program menus are password-protected. To
open them, perform the steps in the next section.
1. Go to the home screen.
2. Press the F1 button. e main menu displays and you can now view and edit parameters.
To exit the menu, press the F1 button.
Open the 3301T’s Parameter Menus
You must enter a password to open all of the 3301T’s menus, which include the main menu, Program
menu, and Monitor menu. Take the following steps to open these menus.
1. Go to the home screen.
2. Press the F2 button. e Password screen displays:
You can enter a password for either the User or OEM access level. e screen’s active access level
is highlighted in blue; in the example above, the User access level is active.

2 — USING THE 3301T pg. 11
Return to TOC Curtis Model 3301T Digital Instrumentation – September 2021
3. To change the active access level, press the S, E, H, or button.
4. Use the F1–F4 buttons to enter the four-digit password, which consists of the numbers 1–4. Pressing
an F1–F4 button enters the number that follows the letter “F” in the button name: for example, the F2
button enters 2.
To indicate how many of the password characters have been entered, the corresponding circle in the
middle of the screen turns blue when a button is pushed. In the following example, four numbers have
been entered:
Tip: To clear the most recently entered number, press the
C
-
-
button; the corresponding circle turns
white. To exit the password screen, press the
C
--
button until the password is cleared, then press the
button again.
5. Press the
+
+
button to submit the password. If the password is correct, the main menu displays and you
can now view and edit parameters.
If the password screen indicates that the wrong password was entered, press the
C
--
button to clear the
password, then repeat steps 3–5.
To exit the menu, press the F2 button.
IMPORTANT: Aer you have nished working with parameters, cycle the keyswitch to clear the password.

2 — USING THE 3301T
Curtis Model 3301T Digital Instrumentation – September 2021 Return to TOC
pg. 12
Open Read-Write Parameter Menus for Other Curtis Devices
e 3301T allows you to view and edit parameters of Curtis devices that are connected through the
CANbus or that support the ESP/SP protocol and are connected through the serial port. Take the
following steps to open other Curtis devices’ menus.
1. Go to the home screen.
2. Press the F3 button. e Password screen displays:
You can enter a password for either the User or OEM access level. e screen’s active access level
is highlighted in blue; in the example above, the User access level is active.
3. To change the active access level, press the S, E, H, or button.
4. Use the F1–F4 buttons to enter the four-digit password, which consists of the numbers 1–4.
Pressing an F1–F4 button enters the number that follows the letter “F” in the button name: for
example, the F2 button enters 2.
To indicate how many of the password characters have been entered, the corresponding circle
in the middle of the screen turns blue when a button is pushed. In the following example, four
numbers have been entered:
Tip: To clear the most recently entered number, press the
C
-
-
button; the corresponding circle
turns white. To exit the password screen, press the
C
--
button until the password is cleared, then
press the button again.

2 — USING THE 3301T pg. 13
Return to TOC Curtis Model 3301T Digital Instrumentation – September 2021
5. Press the
+
+
button to submit the password. If the password is correct, the 3301T will list the
Curtis devices on the CANbus.
If the password screen indicates that the wrong password was entered, press the
C
--
button to
clear the password, then repeat steps 3–5.
6. If multiple devices are listed, use the and Hbuttons to select the device you want to
work with.
7. Press the +
+
button. e 3301T downloads the device’s menu and then displays the main menu.
You can now view and edit parameters.
To exit the menu, press the F3 button.
IMPORTANT: After you have finished working with parameters, cycle the keyswitch to clear
the password.
Open Read-Only Parameter Menus of Devices Connected to the Serial Port
e 3301T provides read-only access to the main and Monitor menus of Curtis devices that support
the ESP/SP protocol and are connected through the serial port. Take the following steps to open
these menus:
1. Go to the home screen.
2. Press the F4 button. e main menu displays and you can now view parameters.
To exit the menus, press the F4 button.
Using the Parameter Menu Screens
e following table describes how to use the 3301T’s buttons to navigate the menus and change
parameter values:
Action Button
Scroll up to the previous menu item on the screen. H
Scroll down to the next menu item on the screen.
Open the selected menu. Eor +
+
Return to the previous menu.
Note: If the device’s main menu is displayed, pressing this button returns to
the home screen.
Sor
C
--
Increment a parameter value. +
+
Decrement a parameter value.
C
-
-

2 — USING THE 3301T
Curtis Model 3301T Digital Instrumentation – September 2021 Return to TOC
pg. 14
In addition, you can rapidly change parameter values by factors of 10, 100, or 1000 times the
parameter’s step size. For example, suppose that you need to increase a parameter’s value by 1000
step sizes. Instead of incrementing the value 1000 times, you can increase the value by pressing a
few buttons.
Take the following steps to rapidly change the selected parameter’s value:
1. Press the F4 button until the screen’s upper right corner indicates the factor by which to change
the value. e following table lists the indicators:
Indicator Factor
1
Note: x1 is the default, and indicates that the parameter value
will be incremented or decremented by one step size.
10
100
1000
2. Perform one of the following steps:
• To increase the value by the specied factor, press the +
+
button.
• To decrease the value by the specied factor, press the
C
-
-
button.
3. If the value needs further adjustment but by a dierent factor, repeat this procedure.
