Cyberdrive PA-101BT User manual

User Manual
PA-101BT
Up to 192K/24bit
Hi-Res Wireless Audio Amplifier
X Dual-Driver In-Ear Headphones
Portable BT Amplifier

PA-101BT Main Features
p1
CAEE Audio Enhancing Technology to 192K / 24bit Quality
Built-in 8GB MP3 Player
USB Audio
BT Wireless Audio
High / Low Gain Adjustments
High Gain for headphones with higher impedance level.
Low Gain for Earphones with lower impedance level.
Supports 2.5mm Balanced Audio Out
Up to 192K/24bit
Audio Quality

Contents in the Package
1. Portable Bluetooth Amplifier PA-101BT *1
2. Hi-Res Dual-Driver In-Ear Headphones*1
3. Ear caps in three sizes: Small, Medium, Large
4. USB Cable
5. User Manual
1 2
3 5
4
p2

PA-101BT Specifications
•Audio Output Balanced 192K / 24bit
•SNR (HP-AMP) 108dB
•THD + N (HP-AMP) 0.007 %
•Frequency Response 5Hz –48kHz
•Power Output 50mW / 16 Ω
•Audio Out Connector 2.5mm balanced
•Wireless Connection Bluetooth V4.2/BLE
•Bluetooth Protocol A2DP, AVRCP, HFP, SPP
•Bluetooth Power Class-2
•Communication Distance >10M
•USB Audio DSD128 / PCM352K Hi-Res Player
•PC Connection Micro USB 2.0
•Storage 8GB Internal Memory
•Microphone Built-in
•Battery Life 12 hrs
•Battery Charging via Micro USB Port
p3

PA-101BT Keys & Functions
p4
1
2 3 4 5
6 7
8
9
10
This end connects to headsets
Front View
Side View
Top View

PA-101BT Keys & Functions
Button Long press Short press
1 Power On / Off Audio Source Select
Bluetooth - Player
2 Disconnecting Bluetooth
(under BT connection)
Play / Pause Music
3 Language select
English –Voice Off - Japanese
Gain Select
Headphone –High Gain
Earphone –Low Gain
4 Select Previous Volume Down
5 Select Next Volume Up
6 Micro USB Port
Battery charging / USB Audio port
7 Reset
8 2.5mm Balanced Audio out port
9 LED Indicator
Solid Green LED - Under Player Mode
Solid Blue LED - Under BT Mode
Flashing Blue LED - Bluetooth pairing
Solid Red LED - Battery charging
p5

PA-101BT Basic Operations
Connecting to Bluetooth
Default start-up audio will be on Bluetooth wireless mode.
1 Turn on the unit by long press the power button. (button 1)
2 Connect your playing devices with the PA-101BT under ID name
“PA101_00a” shown on your playing devices.
3 To disconnect Bluetooth connection long press button 2 .
Bluetooth LED indications:
LED flashing in blue: Bluetooth Pairing
LED on solid blue: Bluetooth Connected.
Using the Built-in Player
1 Turn on the unit by long press the power button. (button1)
2 Switch to player mode by short press the audio source button.
(button 1)
3 Skip to the next track by long press the select next button.
(button 5), or return to the previous track by long press the select
previous button. (button 4)
p6

PA-101BT Basic Operations
USB Connection (USB Audio Streaming)
1 Turn on the unit by long press the power button. (button 1)
2 Connect to PC or Smartphones (via OTG) to use USB audio
streaming.
(under PC connection please activate USB memory for data transfer.)
3 Download the ZEUS Player for Windows Hi-Res use.
Download the SEIUN Player for Android Hi-Res use.
4 Run APP for Hi-Res music thru USB Audio Streaming.
Organizing Files via USB connection
1 Turn OFF the unit by long press the power button. (button1)
2 Use the USB cable included in the package to connect the
PA-101BT to the computer.
3 Select device under the name “Cyberdrive” and now you can
organize the music files.
p7

PA-101BT Basic Operations
Battery Charging
1 Connect the PA-101BT to external power supply using the Micro
USB cable.
2 RED LED will come on indicating that the battery is charging.
3 LED will flash GREEN when the battery is fully charged.
4 Remove the USB cable when charging is completed.
Organizing Files via USB connection
1 Turn OFF the unit by long press the power button. (button1)
2 Use the USB cable included in the package to connect the
PA-101BT to the computer.
3 Select device under the name “Cyberdrive” and now you can
organize the music files.
p8

The Hi-Res In-Ear Dual-driver Headphones
p9
Hi-Res Dual-Driver In-Ear Headphones
2 Hi-Res Speaker-Driver units per Ear
Hybrid –Dual Driver Speaker
The EP-150 Series
•Audio Out: 2.5mm balanced
•Speaker Driver/ear 10mm Dynamic driver x 1unit
Balanced Armature driver x 1unit
•Frequency Response: 5Hz –40kHz
•Sensitivity 97 ±3 dB/mW@1KHz
•Impedance 16±15%ohm@1KHz
•Rated Power 1mW
•Power Capacity 10mW

2.5mm to 2.5mm Balanced cable
By using the balanced signal audio the sound noise generated when
audio signal passes thru the wires is greatly reduced very similar to
noise cancellation system. The PA-101BT portable Amplifier
supports balanced signal audio for maximum music listening
enjoyments.
The Hi-Res In-Ear Dual-driver Headphones

Legal Disclaimers
p10
LEGAL DISCALIMERS
SAFETY INSTRUCTIONS:
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus
that produce heat. Only use attachments / accessories specified by the manufacture.
Unplug this apparatus during lighting storms or when unused for long periods of time.
Refer all services to qualified service personal.
Servicing is required when the apparatus has been damaged in any way, such as plug damage,
Liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
Do not dismantle or attempt to repair your product.
Do not expose your product to temperatures outside the range of 0°C to 40°C (32°F to 104°F).
Do not pierce, rush or set fire to your product.
SAFETY WARNINGS:
To REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE.
Do not expose the unit to dripping or splashing.
Do not place any object filled with liquid, such as a vase, on the unit.
Do not place naked flame sources, such as lighted candles, on the unit.
To avoid overheating leave at least 10cm around the equipment for sufficient ventilation.
Do not position the unit in direct sunlight, near heat sources or directly on top of heat producing
Equipment.
To avoid interference do not position the unit near strong electrical or magnetic radiation, such
As near a power amplifier.

Warranty
p11
WARRANTY:
CYBERDRIVE Product is covered by warranty to be free from defects in material and
Workmanship for one year from the date of purchase; subject to the limitations and conditions
outlined below.
This warranty covers the cost of labor and materials for any repair deemed necessary by the
CYBERDRIVE Service Team. Proof of purchase or a copy of the sales receipt will be required for
any claim made against the warranty.
LIMITATIONS AND CONDITIONS:
The PA-101BT portable amplifier and the EP-150 In-Ear Headphones are covered under the warranty
only if the following conditions have been met:
It has been used in accordance with the instructions given in the section Safety.
Instructions and Safety warnings elsewhere in this document.
It has not been altered or modified in any way.
It has not been purchased from an unauthorized dealer.
It has not been subjected to an unauthorized repair or service.
In order to make a claim against the warranty, the approved process for returning a faulty unit
for repair or replacement must be followed.
To learn about this process please contact Support at: [e-mail]
RADIO INTEFERENCE:
FCC Warning: This equipment generates and can radiate radio frequency energy and if not
installed and used correctly in accordance with our instructions may cause interference to radio
Communications or radio and television reception. It has been type-tested and complies with the
Limits set out in Subpart J, Part 15 of FCC rules for a Class B computing device.
EEC: This product has been designed and type-tested to comply with the limits set out in
USE with USB 1.1, 2, 3, 3.1 only.

© 2017 CYBERDRIVE, All rights reserved. CYBERDRIVE, the CYBERDRIVE logo, and all other CYBERDRIVE trademarks are
Owned by CYBERDRIVE and may be registered. The Hi-Res work mark and logos are registered trademarks owned by
Japan Audio Society and any use of such marks by CYBERDRIVE is under license. All other trademarks are property of
their respective owners. CYBERDRIVE assumes no responsibility for any errors that may appear in this manual.
Information contained herein is subject to change without notice.
