Cyberteam FiberTechnic Ftech G-01 User manual

User Manual
v. 3.0
FiberTechnic® Ftech G-01

DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
Contents
1 Note ...............................................................................................................................................1
1.1 Installation Precautions .........................................................................................................1
1.2 Precautions for Use ...............................................................................................................1
2 Introduce ....................................................................................................................................... 3
2.1 Product Feature ..................................................................................................................... 3
2.2 Environmental Requirements ............................................................................................... 4
2.3 Product Operation Introduction ............................................................................................ 4
2.4 Product Interface Definitions ............................................................................................... 5
2.5 Product LED Definitions ...................................................................................................... 5
2.6 Device Connection ................................................................................................................5
2.7 Network Application .............................................................................................................6
3 ONU Local WEB login ................................................................................................................ 6
3.1 ONU and PC physical Connection ....................................................................................... 6
3.2 Computer Access ONU Local WEB .................................................................................... 7
4 ONU Registration Information Configuration(When adaptive to GPON mode) ........................8
4.1 ONU Registration Status View .............................................................................................8
4.2 ONU Optical Power Information View ................................................................................8
4.3 ONU Registration LOID Configuration ...............................................................................9
4.4 ONU Registers SN Configuration ...................................................................................... 10
5 ONU Registration Information Configuration(When adaptive to EPON mode) ...................... 10
5.1 ONU Registration Status View ...........................................................................................10
5.2 ONU Optical Power Information View .............................................................................. 11
5.3 ONU Registration LOID Configuration .............................................................................11
6 Internet Basic Configuration ...................................................................................................... 12
6.1 Routing mode broadband Internet settings .........................................................................13
6.1.1 PPPoE broadband Internet access in routing mode ................................................ 13
6.1.2 DHCP broadband Internet access in routing mode ................................................. 15
6.1.3 Static IP Broadband Internet Access In Routing Mode .......................................... 18

DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
6.2 Broadband Internet Access In Bridge Mode ...................................................................... 21
6.3 View Broadband WAN Status ............................................................................................ 21
6.4 Delete Internet WAN Connection .......................................................................................22
7 ONU LAN configuration ............................................................................................................22
7.1 LAN IP Address Configuration .......................................................................................... 23
8 Multicast / IPTV Service Basic Settings ....................................................................................24
9 ONU Device Management ......................................................................................................... 24
9.1 Restore Default ................................................................................................................... 24
9.2 Software Upgrade ............................................................................................................... 25
9.3 Reboot Device .................................................................................................................... 25
Concluding Remarks ..................................................................................................................... 26

1
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
1 Note
1.1 Installation Precautions
Do not near flammable or conductive items, high temperature, direct sunlight or moist
environment, or on PC chassis, and check whether other home equipment placed around
stability
Check the cable line. Test and confirm the ac or dc input voltage in the range of allowable,
and direct current (dc) correct polarity.
Unless the manufacturer has given permission, please use the volume and the types of the
power supply with Ming products attached adapter
To prevent lightning damage to the product, make sure that the power outlet and the power
adapter ground are securely grounded. In the thunderstorm, be sure to unplug the power and
all the connections.
Equipment shall be less than 10% of the input voltage fluctuations, power plug with a
refrigerator, hair dryer, electric iron not use the same socket.
To avoid any damage to body by power socket overload, or damage to cause electric shock
or fire plug, please check the power cord, if found damaged, please change immediately.
Please place the equipment on the smooth plane and equipment cannot be placed on other
items.
Equipment is easy heat when working, should maintain the appropriate cooling space to
avoid damage caused by overheating products. The elongated holes on the housing are
designed for heat dissipation. Keep the ventilation clean and prevent the items from falling
into the inside of the equipment. Doing so may cause damage or fire to the equipment. Do
not spill liquid onto the surface of the equipment.
1.2 Precautions for Use
Please read the user manual carefully before using the equipment and follow all the
precautions on the user manual.
Do not look straight at fiber which may damage the eyes. Please wear safet
y glasses to effectively protect your eyes from damage. Wear the fiber cap wh
en fiber no in use.
Power off the device when it not in use.
Please make sure the power switch is closed before plug the power supply, to avoid
surge. Please be careful when remove the power supply, transformer temperature
may be higher.
For safety, please do not open the shell of equipment, especially equipment power
on.

2
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]

Unplug the power supply before cleaning equipment. Use a soft dry cloth cleaning
equipment, do not use the liquid or spray.
Do not use this product connected to any electronic products unless got our
engineer allow. because any wrong connection may cause electricity or fire danger.

3
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
2 Introduce
The double-mode series ONU is GPON/EPON adaptive terminal products to meet the
telecom, radio and television FTTH fiber to the home multi-service access. This series of
products based on mature and stable, cost-effective Gigabit GPON/EPON technology,
integration Gigabit and Fast Ethernet switching technology and powerful routing and
forwarding technology. With high bandwidth, high reliability, easy management and good
quality of service (QoS) guarantee, the technical performance of the equipment meets the
requirements of ITU G.984 equipment and other specifications.
It is easy to manage and can be flexibly upgraded, expanded, and networked. The
equipment has been implemented with GPON/EPON central office equipment (Huawei /
ZTE / FiberHome / Alcatel-Lucent) OLT) interoperability, composed of Gigabit systems, to
meet access needs of the two-in-one video, data services, FTTH / FTTO.
2.1 Product Feature
Support both GPON and EPON mode adaptation
Internet service access
Fully in line with GPON ITU-T G.984 standard, using GPON uplink 1.25G,
downlink 2.5G standard
Support G.984 standard, China Telecom CTC2.1&3.0
Support bidirectional FEC, supports the RS (255, 239) FEC decoding
Support PPPoE, DHCP, static IP broadband service access
Support NAT, static routing, port forwarding
Support data encryption, VLAN transparent, vlan tag, vlan trunk
Support up and down traffic limit function
Supports port loop detection / port link status detection / power dying gasp alarm
Support OLT remote upgrade / WEB local upgrade function
Supports broadcast storm suppression
Support port flow control

4
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
Support managed by different manufacturers OLT work as SNMP-agent. Easy to
install and maintain
Provide a variety of fault alarm function, easy to fault diagnosis
Support AES-128 decryption, support key generation and switching
Support DBA technology and priority Dual management model to ensure
minimum bandwidth requirements for users
2.2 Environmental Requirements
Operation temperature：-0°C～50°C
Operation humidity：10%—90%(Non-condensing)
Power adapter input: 12V / 0.5A
Transmitted optical power: 0.5~5dBm
Input optical power: -8 ~ -28dBm
2.3 Product Operation Introduction
The dual-mode ONU is a "combination" of GPON and EPON ONU. Compared with
the single-mode EPON/GPON ONU, the main difference lies in the registration process.
The dual-mode ONU adds a pre-judgment to the current application system
(EPON/GPON). That is, the dual-mode ONU first switches mode, and then starts and
completes registration process in the corresponding mode. When the ONU runs normally in
the current system, its configuration and processing of various messages are basically the
same as single-mode EPON/GPON ONU.
This product mode switch depends on the packet sent by the front-end OLT device to
the ONU. When ONU receives the packet sent by the EPON OLT, the ONU automatically
switches to the EPON mode after detecting it. In this case, the ONU can be regarded as the
EPON ONU. When the ONU receives the packet sent by the GPON OLT, the ONU
automatically switches to the GPON mode after detecting it. In this case, the ONU can be
used as the GPON ONU.

5
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
2.4 Product Interface Definitions
2.5 Product LED Definitions
Indicator Description
1 LAN LAN port status
On: Ethernet connection is normal;
Blin
king: Data is being transmitted through the
Ethernet port;
Off: Ethernet connection is not set up;
2 LOS XPON optical signals
On: Optical power lower than receiver
sensitivity ;
Off: Optical in normal
3 PON ONT Register
On: Success to register to OLT;
Blinking: In process of registering to OLT;
Off: Failed to register to OLT or no normal
optical signal input;
4 PWR Power status
On: The ONT is power on;
Off: The ONT is Power off;
2.6 Device Connection
Connecting the fiber: Insert the SC fiber connector into the PON connector on
the rear panel of the ONU.
Connect the Ethernet cable: Connect the RJ-45 Ethernet cable to any LAN port
of the ONU and the home device, ie, the computer, IPTV set-top box.
Connect the AC adapter: Plug the AC / DC adapter into the AC wall jack and the
ONU 12V DC power jack.

6
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
2.7 Network Application
3 ONU Local WEB login
3.1 ONU and PC physical Connection
a) Connect your computer's local network card to the LAN port or ETH port of the ONU via a
network cable.
b) Set the IP address of the computer's local network card to 192.168.101.X (X: 2-254).
c) The computer opens the cmd window. To ensure that the computer can ping ONU
management ip address 192.168.101.1

7
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
3.2 Computer Access ONU Local WEB
In the case # 3.1 computer can communicate with the ONU, open the
computer's Web browser (IE, Firefox, google), copy and paste the ONU access
URL: http: //192.168.101.1, pop-up as follows ONU prompt landing page:
Enter the ONU super login user: adminisp password: adminisp Click
"Login" button, there will be the following ONU main login interface:

8
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
After entering the main interface of the ONU, the ONU can be set up further. For
details, see the following setup guide.
4 ONU Registration Information Configuration(When
adaptive to GPON mode)
4.1 ONU Registration Status View
web login ONU select the Status -> PON inform, you can check whether the
ONU registered successfully:
4.2 ONU Optical Power Information View
web login ONU select the Status ->PON inform, you can view the ONU input

9
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
and output optical power information:
4.3 ONU Registration LOID Configuration
The LOID of the ONU is mainly applicable to the authentication mode of LOID
and LOID + Password. General ONU authentication mose is SN, and rarely use the
LOID authentication mode, so normal circumstances do not need to configure the
LOID. The LOID of the ONU is configured as follows:
1.web login ONU select the WAN Configuration-> ONT Authentication, you
can set and view the ONU LOID and password:
2.After completing the LOID and password settings, you can click the "Apply" button
below to complete the setup.

10
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
4.4 ONU Registers SN Configuration
The SN of the ONU is mainly applicable to the OLT SN authentication mode
by default. Sometimes it may be related to the problem of compatibility, need to
modify the default SN of the ONU, you can refer to the following ways to modify, SN
by 4 characters prefix (letters) + 8 ASCII code. The standard specifies this length.
1.web login ONU and select the WAN Configuration-> ONT Authentication,
you can set and view the ONU SN and password (generally do not need to modify):
2.After completing the SN and password settings, you can click the "Apply"
button below to complete the setup.
5 ONU Registration Information Configuration(When
adaptive to EPON mode)
5.1 ONU Registration Status View
web login ONU select the Status ->PON inform, you can check whether the
ONU registered successfully:

11
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
5.2 ONU Optical Power Information View
web login ONU select the Status ->PON inform, you can view the ONU input
and output optical power information:
5.3 ONU Registration LOID Configuration
The LOID of the ONU is mainly applicable to the authentication mode of LOID
and LOID + Password. General EPON ONU authentication method is MAC address,
and rarely use the LOID authentication mode, so normal circumstances do not
need to configure the LOID. The LOID of the ONU is configured as follows:
1.web login ONU select the WAN Configuration-> ONT Authentication, you

12
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
can set and view the ONU LOID and password:
2.After completing the LOID and password settings, you can click the "Apply"
button below to complete the setup.
6 Internet Basic Configuration
ZTE ONU series of products support route function, Internet can work by route
mode or bridge mode, the difference between the two modes are as follows:
Routing mode Broadband Internet access: ONU as a home gateway
equipment, ONU on route mode can obtained IP address in three ways: DHCP,
static IP and PPPoE. The IP address of the user terminal device (PC, etc.)
obtained by the ONU own DHCP address pool or manually set the static IP
address the same as DHCP address pool.
Bridging mode broadband Internet access: ONU itself will not get the IP
address assigned by the upper device, or can not manually set the static IP address,
then ONU as a relay device. The IP address of the user device (PC) connecting the
ONU LAN port obtained by the OLT upper layer server. The PC is connected to the
Internet through DHCP, PPPoE, and static ip address.

13
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
6.1 Routing mode broadband Internet settings
6.1.1 PPPoE broadband Internet access in routing mode
1. web login ONU and select WAN Configuration->WAN->NEW, and then set
the following parameters:
【Connection Name】Enter a qualified name.
【Enable】Check this option,It makes the WAN you configured take effect
【WAN Mode】Select “Route”.
【Mode】Select “PPPOE”.
【IP Protocol】Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’.
【Service Type】Check “INTERNET”.
【Enable Vlan】Configure this option according to our network plan.If the network plans
the vlan of broadband Internet, this item needs to choose ;If the network has no
vlan planning for broadband Internet access, this option is not to choose.
【Vlan ID】This will appear after the selection "tag", and the vlan id of the network plan
should be filled in.
【802.1p】Set the priority of vlan, The same as "enable Vlan", depending on the network
vlan planning to configure. The default priority is 0.
【PPP TransType】Select "PPPoE".
【Username 】Enter the PPPoE Internet PPPoE account provided by the network
operator.
【Password】Enter the PPPoE password provided by the network operator.
【Authentication Type】Select "Auto".
【Connection Trigger】The default is “Always On”.
【Enable NAT 】Check the "Enable NAT" function; NAT function is mainly used for
internal network and external network communication address translation function,
the default is checked enabled state, if not check the network ONU not get the
network.
【MTU】The default is 1492 does not need to modify; if you meet can ping DNS but the
web browser can not access the site. Modify MTU smaller, such as: 1400.

14
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
【As default gateway】Choose to tick according to your needs
Note: ZTE solution ONU series of products is no port binding function, because
the ONU is SFU (pure data)+ Routing, the ONU either works in SFU mode, or is
working in routing mode.

15
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
2. After the above configuration, click "Apply" button to complete the PPPoE
broadband Internet access settings:
6.1.2 DHCP broadband Internet access in routing mode
1. web login ONU and select WAN Configuration->WAN->NEW, and then set the
following parameters:
【Connection Name】Enter a qualified name.
【Enable】Check this option,It makes the WAN you configured take effect
【WAN Mode】Select “Route”.
【Mode】Select “IPOE”.
【IP Protocol】Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’.
【Service Type】Check “INTERNET”.
【Enable Vlan】Configure this option according to our network plan.If the network plans
the vlan of broadband Internet, this item needs to choose ;If the network has no

16
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
vlan planning for broadband Internet access, this option is not to choose.
【Vlan ID】This will appear after the selection "tag", and the vlan id of the network plan
should be filled in.
【802.1p】Set the priority of vlan, The same as "enable Vlan", depending on the network
vlan planning to configure. The default priority is 0.
【IP Acquisition Mode】Select“DHCP”.
【Enable NAT】Check ‘NAT’ feature;NAT is mainly used for address translation function
of local network and external network. The default is checked enable status. If you
do not check this option, maybe you can’t surf the internet.
【MTU】The default is 1500; if we can ping the DNS but not access to the website
via WEB broswer,we need to lower the value of MTU, such as 1400.
【As default gateway】Choose to tick according to your needs
Note: the default port is unbound, and all the LAN ports go through this WAN.
When the device has a route WAN at the same time,it needs to
bind the port for each WAN (a LAN can only be bound to a WAN, can not bind to
multiple WAN connections at the same time.)

17
DATASHEET V3.0
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
[e-mail] [phone]
2..After configuring the parameters of DHCP WAN connection as below, click ‘Apply’
to finish the setting：
