Close–up/Macro Adapter for
FujiFilm FinePix Real3D W3
Enhance the close up capabili"es
of your Fuji W3!
Cyclopital3D
Close up 3D photography produces some of the most stunning images
possible in the art.
However, the 75mm fixed lens spacing of Fuji W3 limits how close you
can get to your subject and still achieve a high quality 3D photo. As
you get closer to your subject, parallax increases and too much
parallax makes 3D images uncomfortable or difficult to view.
The Cyclopital3D Close-up adapter uses perfectly aligned high quality
mirrors to effectively reduce the stereo base of your Fuji W3 to 25mm.
This shortening of the stereo base allows you to get 3X closer to your
subject while still maintaining an acceptable level of parallax. It also
increases the common image seen by both lenses, reducing the
amount of image loss commonly experienced in 3D macro
photography. And you can take amazing action shots too!
Benefits and Features:
• Reduces stereo base to 25mm
• Reduces image loss
• Hot shoe mount & trigger for external flash
• Tripod mount
• Convenient hand grip is easy to hold
• Built in 72mm lens ring allows for attaching optional close up lens
(for subject closer than 12”), ring flash filters or lens hood
• Sealed mirror chamber protects against dust and fingers
• Precision laser alignment
There are a few situations that this close-up adapter is particularly per-
fect for:
1. To capture detail of a subject that is closer than about 4ft from the
camera
2. When you have infinity in the background but your subject is close
3. Close-ups of moving subjects

Instructions for use:
1. Slide lens cover open.
2. Insert camera into adapter.
3. Attach to camera by inserting thumb screw into the tripod mount.
4. Turning your camera on (and off). If the camera is off, press and
hold the “play” button in the middle of the control panel. The
camera will power up in playback mode, switch to camera mode
by half pressing the shutter button. To turn the camera off, press
the play button once which will return it to playback mode, then
press and hold the play button until camera turns off.
5. Adjust the zoom. When the camera is first turned on, the lens
will be at minimum zoom. To use the adapter you will need to
zoom in until there are no obstructions seen on the display- you
will see the black sides of the adapter until it is appropriately
zoomed in.
6. Put your camera into macro mode to improve its ability to set
auto-parallax on the close-up scene, by pressing the left selector
button (flower symbol) twice."
When using a flash:
• The flash hot shoe will accommodate almost any kind of flash unit
that has a hot shoe adapter.
• The camera must be set to “forced flash”.
• Set the camera to manual mode, use menu to set(recommended)
ISO 100 and aperture of f9, with shutter speed between 1/60 and
1/1000 sec. Using the faster shutter speeds is often useful to
minimize illumination of distracting backgrounds."
• It is recommended to use the flash in auto mode, with the same
aperture setting as your camera, or similar, e.g. f8 on the flash if
you are using f9 on the camera. Auto mode will allow your flash
unit to automatically produce the correct amount of light for the
situation.
• Note: because an additional battery is not needed to power the
flash control unit, it does not work with some flash models. A list
of known compatible flash models is being updated continuously
and is posted at www.cyclopital3d.com.
Expand the Poten"al of your Fuji W3!
Auxiliary Lens Adapter
Use with 37mm wide angle and fish eye lenses
Base Extender
Increases stereo base to 225mm!
Perfect for wildlife, landscapes and band or wedding photos.
All rights reserved, Cyclopital3D, Inc. 2010
