Cyclops Lighting LEDE 100B User manual

USER MANUAL
LEDE 100B
100 watts Compact LED Beam Moving Head

Table of contents
Caution! ����������������������������������������������������������������������������������������������������������������������������������������������������� 3
Introduction����������������������������������������������������������������������������������������������������������������������������������������������� 3
Safety instructions ����������������������������������������������������������������������������������������������������������������������������������� 3
Fxiture overview ��������������������������������������������������������������������������������������������������������������������������������������� 4
Installation������������������������������������������������������������������������������������������������������������������������������������������������� 4
Read ‘Safety information’ before installing the fixture��������������������������������������������������������������������������� 4
Fastening the fixture to a flat surface ���������������������������������������������������������������������������������������������������� 4
Mounting the fixture on a truss�������������������������������������������������������������������������������������������������������������� 4
Securing with a safety cable������������������������������������������������������������������������������������������������������������������ 5
DMX-512 connection/connection between fixtures ������������������������������������������������������������������������������ 5
Operation �������������������������������������������������������������������������������������������������������������������������������������������������� 6
Addressing��������������������������������������������������������������������������������������������������������������������������������������������� 6
Universal DMX Control �������������������������������������������������������������������������������������������������������������������������� 6
Auto run mode��������������������������������������������������������������������������������������������������������������������������������������� 6
Sound Mode ������������������������������������������������������������������������������������������������������������������������������������������ 6
Master-Slave Operation������������������������������������������������������������������������������������������������������������������������� 6
Control Menu Map������������������������������������������������������������������������������������������������������������������������������������ 7
DMX Protocol�������������������������������������������������������������������������������������������������������������������������������������������� 8
Fixture Cleaning���������������������������������������������������������������������������������������������������������������������������������������� 9
Fuse Replacement���������������������������������������������������������������������������������������������������������������������������������� 10
Troubleshooting ������������������������������������������������������������������������������������������������������������������������������������� 10
The fixture does not work, no light ������������������������������������������������������������������������������������������������������ 10
No response to the sound ������������������������������������������������������������������������������������������������������������������� 10
Specifications ����������������������������������������������������������������������������������������������������������������������������������������� 11

3Version 1.0
Caution!
Be careful with your operations� With a dangerous voltage you can suffer a dangerous electric
shock when touching the wires!
Avoid looking directly into the light source!
Wear protective glasses and other PPE (personal protective equipment) when working on or near
the fixture�
For your own safety, please read this user manual carefully before you initial start-up�
Follow operating safety precautions and pay attention to warning signs methods and equipment
on the user manual�
Indoor use only! To prevent risk of fire or shock, do not expose this product to rain or moisture�
IP 20 rating�
The ambient temperature must always be between -5° C and +45° C�
Always make sure you are connecting this product to the proper voltage in accordance with the
specifications in this manual or on the product’s specification label�Make sure it is grounded
when using it!
Unplug mains lead before opening the housing!
Make sure that the power cord is never crimped or damaged by sharp edges� Check the fixture
and the powercord from time to time�
Make sure to replace the fuse with another of the same type and rating�
Warning! This symbol indicates a hot surface� Certain parts of the housing can become hot
during operation� After use, wait for a cool-down period of at least 10 minutes before handling or
transporting the device�
Every person involved with the installation, operation and maintenance of this device has to
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latest version of the user manual from the Internet
Introduction
Thank you for having chosen LEDE 100B� You will see you acquired a powerful and versatile device�
Unpack your item� Before you initial start-up, please make sure that there is no damage caused by
transportation� Should there be any, consult your dealer and do not use the device�
Safety instructions
This fixture is an extremely sophisticated piece of electronic equipment� To guarantee a smooth
operation, it is important to follow the guidelines in this manual� The manufacturer of this device will not
accept responsibility for damages resulting from the misuse of this fixture due to the disregard of the
information printed in this manual�
This device has left our premises in absolutely perfect condition� Always disconnect from the mains,
when the device is not in use or before cleaning it� Keep away children and amateurs from the device!
There are no serviceable parts inside the device� Maintenance and service operations are only to be
carried out by authorized dealers�

4Version 1.0
Fxiture overview
Installation
Read ‘Safety information’ before installing the fixture
The fixture is designed for indoor use only and must be used in a dry location with adequate ventilation� Ensure that
none of the fixture’s ventilation slots are blocked�
Fasten the fixture to a secure structure or surface� Do not stand it on a surface or leave it where it can be moved
or fall over� If you install the fixture in a location where it may cause injury or damage if it falls, secure it as directed
in this user manual using a securely anchored safety cable that will hold the fixture if the primary fastening method
fails�
Fastening the fixture to a flat surface
The fixture can be fastened to a hard, fixed, flat surface that is oriented at any angle� Ensure that the
surface and all fasteners used can support at least 10 times the weight of all fixtures and equipment to
be installed on it�
Fasten the fixture securely� Do not stand it on a surface or leave it where it can be moved or fall over�
If you install the fixture in a location where it may cause injury or damage if it falls, secure it as directed
below with a securely anchored safety cable that will hold the fixture if the primary fastening method
fails�
Mounting the fixture on a truss
The fixture can be clamped to a truss or similar rigging structure in any orientation� When installing the
fixture hanging vertically down, you can use an open-type clamp such as a G-clamp� When installing in
any other orientation, you must use a half-coupler clamp that completely encircles the truss chord�
To clamp the fixture to a truss:
1� Check that the rigging structure can support at least 10 times the weight of all fixtures and
equipment to be installed on it�
2� Block access under the work area�
3� Fold the legs of the mounting bracket together and bolt a rigging clamp securely to the mounting
bracket� The bolt used must be M12� It must pass through both mounting bracket legs and be
fastened with a self-locking nut�
4� Working from a stable platform, hang the fixture with its clamp on the truss and fasten the clamp

5Version 1.0
securely�
5� Secure the fixture with a safety cable as directed below�
Securing with a safety cable
Secure the fixture with a safety cable (or other secondary attachment) that is approved for the weight of
the fixture so that the safety cable will hold the fixture if a primary attachment fails�
Loop the safety cable through the eyebolt in the back of the fixture and around a secure anchoring
point� Do not loop the safety cable around the fixture’s mounting bracket only, as this will leave the
fixture unsecured if it separates from the bracket�
DMX-512 connection/connection between fixtures
Occupation of the XLR-connection:
1. Group
2. Signal (-)
3. Signal (+)
DMX OUT
1. Group
2. Signal (-)
3. Signal (+)
DMX IN
If you are using controllers with this occupation, you can connect the DMX-output of the controller
directly with the DMX-input of the first fixture in the DMX-chain� If you wish to connect DMX-controllers
with other XLR-outputs, you need to use adapter-cables�
Building a serial DMX-chain:
Connect the DMX-output of the first fixture in the DMX-chain with the DMX-input of the next fixture�
Always connect one output with the input of the next fixture until all fixtures are connected�
DMX-512 connection with DMX terminator:
For installations where the DMX cable has to run a long distance or is in an electrically noisy
environment, such as in a discotheque, it is recommended to use a DMX terminator� This helps in
preventing corruption of the digital control signal by electrical noise� The DMX terminator is simply an
XLR plug with a 120 resistor connected between pins 2 and 3, which is then plugged into the output
XLR socket of the last fixture in the chain�
Caution: At the last fixture, the DMX-cable has to be terminated with a terminator� Solder a 120
resistor between Signal (–) and Signal (+) into a 3-pin XLR-plug and plug it in the DMX-output of the
last fixture�
Connection with the mains:
The LEDE 100B is equipped with auto-switching power supply that automatically adjusts to any 50-
60Hz AC power source from 100-240 Volts�
This fixture must be earthed� To use the fixture, a plug must be fixed�
The correct assembly of a sufficient plug may be done by professional persons only�
Connect the device to the mains with the enclosed power supply cable�
The occupation of the connection cables as below:
Cable color Connection International
Brown Live L
Blue Neutral N

6Version 1.0
Yellow/green Earth(Ground)
Operation
The LEDE 100B can operate in three different modes� In each mode you can run the fixture as a stand
alone fixture or in a master/slave confiugration� This next section will detail the dif-ferences in the
operating modes�
Addressing
All fixtures should be given a DMX starting address when using a DMX signal, so that the correct fixture
responds to the correct control signals� This digital starting address is the channel number from which
the fixture starts to listen to the digital control information sent out from the DMX controller� The
allocation of this starting address is achieved by setting the correct number on the display located on
the base of the device�
You can set the same starting address for all fixtures or a group of fixtures, or make different address
for
each fixture individually�
If you set the same address, all the units will start to listen to the same control signal from the same
channel number� In other words, changing the settings of one channel will affect all the fixtures
simultaneously�
If you set a different address, each unit will start to listen to the channel number you have set, based on
the quantity of control channels of the unit� That means changing the settings of one channel will affect
only the selected fixture�
In the case of the LEDE 100B, which is 16 channels fixture� If you set, for example, the address in the
16 channel mode to channel 17, the device will use the channel 17 to 32 for control�
Universal DMX Control
This function allows you to use a universal DMX-512 controller to control the chases and patterns,
dimmer and strobe� A DMX controller allows you to create unique programs tailored to your individual
needs�
Auto run mode
In this mode, you can run internal program without a controller�
1� Press the MENU button until “MODE” is displayed, and press ENTER�
2� Press the UP or DOWN button so that “Auto run” is displayed�
3� The unit will now run auto mode without a DMX controller�
Sound Mode
This mode allows either single unit or several units linked together, to run to the beat of the music�
1� Press the MENU button until “MODE” is displayed, and press ENTER�
2� Press the UP or DOWN button so that “Sound ctrl” is displayed�
3� The unit will now run to the beat of the music�
Master-Slave Operation
This function will allow you to link up to 16 units together and operate without a controller� In a Master-
Slave set up one unit will act as the controlling unit and the others will react to the controlling units
programs� Any unit can act as a Master or as a Slave�
1� Using approved DMX data cables, daisy chain your units together via the XLR connector on the rear

7Version 1.0
of the units�
2� For the Master unit select "MODE" - "Auto Run"�
3� For the slave units selcet "MODE" - "M/S choose" - "Slave"�
4� The slave units will now follow the Master unit�
Control Menu Map
Default settings=bold print
Main Menu Level 1 Level 2 Function
Addr
001-497 DMX address setting
Prev Previous address, address -16
Next Next address, address +16
Chan Channel mode
MODE
DMX Ctrl √ Control mode, DMX mode
Auto Run Control mode, Auto mode
Sound Ctrl Control mode, Sound mode
Scene Mode
Auto
Scene mode, please refer to "SCENE" - "Scene select"
menu
01
���
10
M/S choose
Auto
Master-slave select
Slave
Master
Theater Mod off / on Fan mode, low fan speed
DISP
Screen saver
Off Display shut off time, always on
Mod 1 Display blackout
Mod 2 Show DMX address and control mode
Mod 3 Show brand icons
Screen Rot
Auto
Screen reverseReverse
Forward
DMX Indicate
Mode 1 LED indicator always on
Mode 2 LED indicator off
Mode 3 LED indicator flash
Screen light 01-10 Screen brightness
SCENE
Scene Select 1-10 Scene Select
Scene Time 000-255 Scene time, ms
01� Pan 000-255
Manual setting
02� Pan fine 000-255
03� Tilt 000-255
04� Tilt fine 000-255
��� ���
15� Focus 000-255
16� Reset 000-255
ADVA
Pan Invert off / on Pan reverse
Tilt Invert off / on Tilt reverse
P/T Rectify off / on Pan/Tilt opticalcoupler calibration
Pan offset 004-150 Pan offset
Tilt offset 004-048 Tilt offset
Data hold off / on Hold last value if no signal
Reset Sure / no Fixture reset
Factory setting Sure / no Reset setting to factory default

8Version 1.0
STAT
Stepper info
Status
Error logging
Fixture status
Version
Light time
Total time
DMX Protocol
16 CHANNEL DMX value Function
CH1 Pan
000-255 0-540°
CH2 Pan fine
000-255 Fine control of pan movement
CH3 Tilt
000-255 Tilt movement by 270°
CH4 Tilt fine
000-255 Fine control of tilt movement
CH5 Pan/Tilt speed
000-255 Pan/Tilt speed, decreasing
CH6
Strobe
000-003 Closed
004-127 Pulse strobe, slow - fast
128-191 Fade strobe, slow - fast
192-255 Random strobe, slow - fast
CH7 Dimmer
000-255 0-100% dimmer
CH8
Color wheel
000-005 Open/hole
Color
006-011 Color 1
012-017 Color 2
018-023 Color 3
024-028 Color 4
029-034 Color 5
035-040 Color 6
041-046 Color 7
047-051 Color 8
052-057 Color 9
058-063 Color 10
Half color
064-069 Color1+white
070-075 Color1+color2
076-080 Color2+color3
081-086 Color3+color4
087-092 Color4+color5
093-098 Color5+color6
099-103 Color6+color7
104-109 Color7+color8
110-115 Color8+color9
116-121 Color9+color10
122-127 Color10+open
128-191 Backwards rainbow effect slow to fast
192-255 Forwards rainbow effect slow to fast

9Version 1.0
CH9
6 colors color wheel
000-127 No function
128-255 6 colors color effect
CH10
Gobo Wheel
000-009 Open/hole
010-018 Gobo 1
019-027 Gobo 2
028-036 Gobo 3
037-045 Gobo 4
046-054 Gobo 5
055-063 Gobo 6
064-072 Gobo 7
073-081 Gobo 8
082-090 Gobo 9
091-099 Gobo 10
100-108 Gobo 11
109-117 Gobo 12
118-127 Gobo 13
128-191 Backwards rainbow effect slow to fast
192-255 Forwards rainbow effect slow to fast
CH11
Gobo shake
000-191 Shaking gobos from slow to fast
192-255 No function
CH12
Prism
000-127 Open position (hole)
0128-255 Prism effect
CH13
Prism rotation and indexing
000-127 Prism indexing
128-190 Backwards rotation from slow to fast
191-192 Stop
193-255 Forwards rotation from fast to slow
CH14
Frost
000-127 No function
128-255 Frost effect
CH15 Focus
000-255 Focus
CH16
Reset
000-127 No function
128-255 Reset(in 3sec)
Fixture Cleaning
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses and mirror should
be carried out periodically to optimize light output� Cleaning frequency depends on the environment
in which the fixture operates (I�e� smoke, fog residue, dust, dew)� In heavy club use we recommend
cleaning on a monthly basis� Periodic cleaning will ensure longevity, and crisp output�
To clean the fixture:
1� Disconnect the fixture from power and allow it to cool for at least 10 minutes�
2� Vacuum or gently blow away dust and loose particles from the outside of the fixture with
3� low-pressure compressed air�
4� Clean the surfaces by wiping gently with a soft, clean lint-free cloth moistened with a weak
detergent solution� Do not rub glass surfaces hard: lift particles off with a soft repeated press� Dry
with a soft, clean, lint-free cloth or low-pressure compressed air� Remove stuck particles with an

10 Version 1.0
unscented tissue or cotton swab moistened with glass cleaner or distilled water�
5� Check that the fixture is dry before reapplying power�
Fuse Replacement
This fuse is located in a fuseholder next to the MAINS OUT socket on the connections panel�
To replace a fuse:
1� Disconnect the fixture from power and allow it to cool for at least 10 minutes�
2� Unscrew the cap of the fuseholder and remove the fuse� Replace with a fuse of the same size and
rating only�
3� Reinstall the fuseholder cap before reapplying power�
Troubleshooting
Listed below are a few common problems that you may encounter, with solutions�
The fixture does not work, no light
• Check the connection of power and main fuse� Be sure the external fuse has not blown�
• Measure the mains voltage on the main connector�
No response to the sound
• Make sure the fixture does not receive DMX signal�
• Low frequencies (bass) should cause the unit to react to sound�Tapping on the microphone, quiet or
high pitched sounds may not activate the unit�
• Check the sound sensitivity level� Make sure it is not set to a low sensitivity level�

11 Version 1.0
Specifications
Model LEDE 100B
Light source: 100 watts white LED
LED life expectancy: 50,000 Hrs�
Color temperature: 6600K
CRI 73
Beam angle: 3°
Light output: 70,000 Lux @ 4m @ 3°
Electronic focus
Dimmer: linear adjustment
Color wheel: 10 colors + open
Effect color wheel: 6 colors
Electronic variable strobe
Static gobo: 13 gobos +open
Rotating gobo: 7 gobos + open
Gobo shake function
Prism: 16-facet circular prism
Frost
Control protocols: DMX , Sound, Master-Slave, Auto Run
Control channels: 16 CHs
Pan: 540°
Tilt: 270°
Resolution: 16 bit
Input voltage: 100-240V/50-60Hz
Power consumption: 100 watts
DMX connections: 3 pin XLR In/Out male and female
Power connections: PowerCon In
Dimensions: 333 x 270 x 424mm
Net weight: 12�7 Kg
Color: Black
IP rating: 20
www�cyclopslighting�com
Table of contents
Other Cyclops Lighting Light Fixture manuals
Popular Light Fixture manuals by other brands

Lightolier
Lightolier Lytespan 6320 specification

Foxfury Lighting Solutions
Foxfury Lighting Solutions NOMAD 360 product manual

Rush
Rush MH 5 Profile user manual

MaxLite
MaxLite PhotonMax Series operating instructions

Kanlux
Kanlux TURRO LED manual

Utilitech
Utilitech Twin Halogen Light UT-5592-BZ owner's manual

IKEA
IKEA VIKT manual

Modulex
Modulex MSP-080F installation guide

Paradise Datacom
Paradise Datacom GL38682 quick start guide

Saxby Lighting
Saxby Lighting Cody track 79219 Instruction leaflet

Lightolier
Lightolier CTS3_FLNG Assembly and installation

Eliminator Lighting
Eliminator Lighting TRI DISC 9 IR instruction manual
