Cydle M7 MultiPAD User manual

Introduction
Pre-caution
Safety and Handling Information
Important Safety Information
Before you start
M7 at a Glance
Battery
Detachable Stand
Getting Started
Turning the M7 MultiPAD On/Off
Home Screen and Applications Tab
How to Manage Icons
Status Indicator on Device
Music Playback
Gallery
Video Gallery
Photo Gallery
HDMI
How to Use HDMI
Web Browsing
Connecting to the Internet
To Start Internet Browser
Bookmark
Syncing
How to Use the Mini USB Port
How to Use Your Micro SD
Pairing a Wireless Device
App Square
To Start App Square
Manage Account
Application
Specification
Notice
Copyright
Warranty Card
2
3
4
5
6
7
8
8
9
10
12-13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Contents

Introduction
We hope you will find the instructions in this manual clear and easy to follow. Please take a few minutes to look
through the Quick Manual to learn how to use all the features of Cydle M7 MultiPAD.
Web site
Thank you for choosing Cydle
Please visit our website or contact a Cydle representative if you have any inquires while using the Cydle M7 MultiPAD.
Get the latest software update at the Cydle website at no cost.
Register as a Cydle Member for the latest updates, promotions and new product information.
Contact http://www.cydle.com
e-mail [email protected]
Cydle customer service Toll free number 1-877-810-5818
What’s in the Box
Box includes
Cydle M7 MultiPAD Manual
Earphone Mini USB Cable Wall Charger
2

Pr
Be sure to carefully read the operating instructions and adhere to the safety precautions before using your M7 MultiPAD to ensure
correct usage and user safety. Cydle Corporation will not be responsible for incidents that occur due to failing to follow instructions
presented. This information applies to all Cydle Corporation products.
Safety and Handling Information
This product should be used for personal use only and used as intended in accordance with the user’s manual. Do not
operate or adjust settings while driving , cycling, or walking near traffic.
Stop using the M7 MultiPAD if you find it disruptive or distracting while operating any type of vehicle, or performing
any other activity that requires your full attention. Check and obey the applicable laws and regulations on the use of
earphones and devices such as M7 MultiPAD in the areas where you drive or ride. Be careful and attentive while
driving.
Pre-caution
Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, paint, or insert foreign
objects into M7 MultiPAD.
Unit contains electronic components that can be permanently damaged when exposed to shock or vibration.
Please keep your unit in a stable place and avoid dropping the unit.
Do not operate unit in high–shock and high-vibration environments.
Do not attempt to take apart, open, service, or modify the product. Refer all servicing to qualified personnel.
Clean only with cloth dampened with water, gently wipe dry with dry cloth.
Do not apply liquid directly to the unit.
Never attempt to repair or modify the M7 MultiPAD yourself. If the M7 MultiPAD has been submerged in water,
punctured, or subjected to a severe fall, do not use it until you take it to an Cydle Authorized Service Provider. The M7
MultiPAD doesn’t contain any user-serviceable parts. Disassembling the M7 MultiPAD, including the removal of the back
cover, may cause damage that is not covered under warranty.
For service information, please visit our support center at www.cydle.com
The rechargeable battery in M7 MultiPAD should be replaced only by an Cydle Authorized Service Provider.
Operating in a safe place:
Proper handling:
Repair
Customer Service contact
3

Pr
Caution: Power Adapter Usage
Important safety Information
When using the Power Adapter to charge the M7 MultiPAD, make sure that the Power Adapter is plugged into the power outlet. Do not connect
or disconnect the Power Adapter while hands are wet. Do not use any other Power Adapter other than the AC/DC Power Adapter certificated by
Cydle to charge your M7 MultiPAD. (Make sure that the rated Voltage of the M7 MultiPAD is 5V)
The Power Adapter may become warm during normal use. Always allow adequate ventilation around the Power Adapter and use care when
handling.
Pre-caution
1. The power cord or plug has become frayed or damaged.
2. The adapter is exposed to rain, liquids, or excessive moisture.
3. The adapter case has become damaged.
4. You suspect the adapter needs service or repair.
5. You want to clean the adapter.
Unplug the Power Adapter if any of the following conditions exist:
Caution: Battery Care & Recycle regulation
THERE IS A RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECET TYPE.
This unit contains materials such as battery, circuit boards, cables, electromagnetic
compatibility gaskets and connectors which may contain lead and copper/beryllium alloys
that require special handling and disposal at end of life. Before this unit is disposed of,
these materials must be removed and recycled or discarded according to applicable
regulations.
4

M7 MultiPAD at a Glance
Microphone
Power Button
Volume Keys
Home Button
Menu Button
Before you start
e
f
ⓕⓖⓗⓘⓙ
ⓐⓑⓒⓓⓔ
Back Button
Microphone Jack
3.5mm Earphone Jack
Mini USB Port
HDMI Port
ⓚⓛⓜⓝ
Power Jack
External Speaker
Hook for Detachable Stand
Micro SD Slot
Stand body
Support & cover
Before you start
P
q
5

Battery
6
Before you start
f
Before you start
Charge the M7 MultiPAD with the original Power Adapter included in the box.
Use only the adapter(5V,2A) included in the box.
1. The Power Jack is located on the bottom right of the unit.
2. Plug in the Power Adapter to the Power Outlet.
3. Connect the Power Adapter to the M7 MultiPAD.
4. The M7 MultiPAD will begin charging. The Battery Icon will change to the
Charging Icon on the top right of the screen.
Charging the Battery
Understanding Battery Status
When the M7 MultiPAD is connected to a power source, the
battery icon changes to show that the battery is charging or
fully charged.
When the M7 MultiPAD isn’t connected to a power source,
a battery icon on the M7 MultiPAD screen shows approximately how much
battery life is left.
The charge time can vary but when the M7 MultiPAD battery has completely depleted, expect about 5 hours to charge
the M7 MultiPAD completely.
The charging time can be different when using the M7 MultiPAD while charging.
Use Battery

Introduction
How to detach the stand
Use the M7 MultiPAD Detachable Stand to set on top of the desk for a hands free operation or use as a Screen Cover when
collapsed, to protect the LCD screen when mobile.
How to attach the stand
Before you start
How to turn the stand
Push off the stand like above
Place a pen or
pencil between the
M7 and stand,
then close the M7
to easily detach.
The Detachable Stand can be easily disassembled using the following 2 options:
To attach the
Detachable Stand to
the M7, place the M7
as shown in the picture.
Insert the hook of the
Detachable Stand to
the specified
connecting point of
the M7 MultiPAD and
push up until a clicking
noise is heard.
Gently lift up the Screen to set the M7 MultiPAD for horizontal view,
turn the Screen to the left for vertical view.
WARNING: For user safety, users must follow the instructions outlined in the manual and proceed with caution when detaching the stand. All
damages resulting from failing to follow the outlined instructions will be the responsibility of the user.
Detachable Stand
7

Turning the M7 Multi PAD On/Off
Introduction
Home Screen and Applications Tab
To turn Power On/Off, press the Power Button for 3 seconds, located on top of the unit.
Unlock:
Slide the Green Lock Icon up to green spot to unlock the screen.
The Home Screen is what you see when turning on the M7 MultiPAD. It gives you access to shortcuts, widgets and more.
The Home Screen expands further by dragging the screen to the left or right.
Sleep Mode:
Press the power button to activate Sleep mode.
To activate the screen again, hold the power button for 3 seconds.
Getting Started
The M7’s LCD is a Resistive Touch Screen so utilizing a stylus pen might be more convenient to control the screen.
8

How to manage Icons
Introduction
Getting Started
4. To add Widgets, Folders and Wallpapers to the Home
Screen: Press and hold the Home Screen (place finger on
area with no Icons) for 3 seconds to open the Tools
Window.
Select the desired function.
<Choose Widgets> <Choose Wallpapers>
9

Status Indicator on Device
Introduction
Getting Started
Current Status Indicators are shown on the Top Bar in the upper screen. Icons will appear to show SD Card in use, USB connection,
Wi-Fi connection, Wireless Device connection, and more. Please see the corresponding icons for more details.
WiFi Connection
Alarm Set
Micro SD Card is removed
Uploading Content
Downloading Content
Insufficient Internal Memory Capacity
USB Connection
Wireless Audio System Mode ON
Pairing Wireless Device
Music Playing
Caution Message from the Operating System
Preparing for Recognition of Micro SD card
Battery Low
10

Music Playback
11
Music
1. Tap on ‘Music’ icon.
2. Choose a song or browse through categories located on the top of the Music Screen
3. Select desired Music from the list.
Music

Music Playback
4. Playback options to Shuffle or Repeat music will be
located on the screen.
5. Change, pause or play a song with the Music Controls.
1) Move Back to
Play List 2) Shuffle Play
3) Repeat
4. Additional menu options will appear on the Play Screen
when the “Menu” button is selected. To add the current
song to a new playlist, tap on “Add to playlist” icon.
5. To create new playlist, select “New”
6. Name your new playlist, then tap on “Save”
Music
12

Video Gallery
Gallery
<Video Play Screen>
<Gallery Setting Screen>
<File Managing Screen>
Gallery
13

Photo Gallery
14
Gallery
1) To set Main screen image
2) To share image with the other device
3) To delete the image
1) To rotate the image
2) To crop the image
Gallery

How to use HDMI
15
HDMI
The M7 MultiPAD fully supports 1080p HDMI. Connect to your television or monitor to enjoy your favorite movies on a bigger
screen.
1. Tap on the ‘Settings’ icon from the Home Screen.
2. Go to Sound & Display > Output Select.
3. Select “HDMI” option
Specification of HDMI Port : Mini HDMI: C-19 Pin
HDMI

5. Choose the network you wish to connect with.
6. Once connection is completed, the Wi-Fi icon will
be seen on the top right of the Top Bar.
7. Wifi Access Point can be lost due to status of the
router. In the event this happens, restart your
router or reconnect the Wifi on the M7 MultiPAD.
1. Tap on ‘Settings’.
2. Go to ‘Wireless & Networks’.
3. Turn on the ‘Wi-Fi’ by placing a check in box.
4. Tap on ‘Wifi Settings’
Connecting to the Internet
16
Wi-Fi Set Up
Click on “Wi-Fi > Wi-Fi On/Off” to reconnect and
reinstate connection to the Wi-Fi

1. Tap on the ‘Internet’ icon.
To Start Internet Browser
Internet Browsing
2. The Internet Browser will open. To browse other
websites, touch the Address Bar
3. When the keyboard pops up, input the URL of desired
website and tap on the “Go” or Enter button.
4. Enjoy mobile web surfing.
To zoom in and out web screen, Use the Zoom In/Out
icon located on the bottom right or double touch the
screen.
17

Tap on the “Bookmark” icon located on the top right of the address bar to display the web browsing History and Favorites.
Bookmark
18
Internet Browsing
<Most Viewed>
<History>
1. Select Bookmark
2. Tap on “Add” icon located on the top left.
3. Input the name you would like displayed in the
Bookmark List. Then tap on “Done” to complete
To Create Bookmark

How to use the Mini USB Port
You can use the M7 MultiPAD as a ‘Mass Storage’ by connecting to the PC with the Mini USB Cable. The Micro USB Port supports USB
2.0.
Syncing
3.A separate window will pop up and ask if you wish to
“Mount” or “Don’t Mount”. Select “Mount” to
complete connection.
4.To disconnect drag down the Top Bar and tap on “Turn
Off USB”. Select “Turn off” to complete.
19
