BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
1
Sensitivity: Public
BLG15 BEST
LIGUİD DOSİNG VOLTRAN
WASHING MACHINE
SERVICE HANDBOOK
SERVICE HANDBOOK NO:00

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
2
Sensitivity: Public
1 COVER
2 CONTENTS
1 COVER ................................................................................................................................................. 2
2 CONTENTS .......................................................................................................................................... 2
3 COMPONENT OPERATİON PRİNCİPLES .................................................................................................. 4
3.1 ELECTRONİC BOARD ASSEMBLY.................................................................................................................................................................... 4
3.2 . WATER INLET VALVE (WİTH WATER METER).................................................................................................................. 5
3.3 STEAM INPUT VALVE.....................................................................................................................................................................................5
3.4 STEAM GENERATOR......................................................................................................................................................................................6
3.4.1 Operating Principle ..................................................................................................................................... 6
3.5 WATER LEVEL SENSOR..................................................................................................................................................................................9
3.6 PARASİTE FİLTER ........................................................................................................................................................................................ 10
3.7 DOOR SWİTCH ASSEMBLY ......................................................................................................................................................................... 10
3.8 . WASH MOTOR......................................................................................................................................................................................... 11
3.8.1 Atlas Motor .................................................................................................................................................... 11
3.9 SAFETY KEYS (DOOR LOCK) ....................................................................................................................................... 12
3.10 HEATER................................................................................................................................................................................................. 14
3.11 NTC ................................................................................................................................................................ 14
3.12 DRAİN PUMP ........................................................................................................................................................................................ 15
3.13 LİQUİD DOSİNG PUMP ......................................................................................................................................................................... 16
3.14 DETERGENT DOSİNG SYSTEM ............................................................................................................................................................... 17
3.15 WEMOD BOARD ................................................................................................................................................................................... 21
3.16 HOMEWHİZ FUNCTİON ....................................................................................................................................................................... 22
3.16.2 Initial setup .................................................................................................................................................. 22
3.16.3 Wi-Fi Setting To manage the WLAN settings; .............................................................................................. 22
3.16.6 Possible Error Scenarios and Solutions......................................................................................................... 24
4 SERVİCE FUNCTİON TEST .............................................................................................................. 25
4.1 STEP 1: SWİTCHİNG TO THE SERVİCE PROGRAMME.................................................................................................................................. 25
4.2 . STEP 2: SOFTWARE VERSİON CHECK ....................................................................................................................................................... 26
4.3 STEP 3: 7 SEGMENT AND LCD SEGMENT CHECK...................................................................................................................................... 26
4.4 STEP 4: MOTOR CLOCKWİSE WASH CHECK ............................................................................................................................................... 27
4.5 STEP 5: MOTOR COUNTER CLOCKWİSE WASH CHECK............................................................................................................................... 27
4.6 STEP 6: NTC CHECK / MAİNS VOLTAGE ADC İNPUT CHECK / ........................................................................................... 28
4.7 STEP 7: LİQUİD DETERGENT DOSİNG PUMP CHECK ............................................................................................................................. 30
4.8 STEP 8: SOFTENER DOSİNG PUMP CHECK............................................................................................................................................ 30
4.9 STEP 9: LİQUİD DETERGENT VALVE AND FLOWMETER CHECK............................................................................................................. 30
4.10 STEP 10: POWDER DETERGENT VALVE CHECK..................................................................................................................................... 31
4.11 STEP 11: HEATER CHECK-WATER LEVEL SENSOR CHECK-FLOWMETER CHECK-JET SYSTEM CHECK-MOTOR CLOCKWİSE WASH
CHECK DESCRİPTİON .............................................................................................................................................................................................. 31
4.12 STEP 12: PUMP CHECK ........................................................................................................................................................................ 33
4.13 STEP 13: JET PUMP CHECK .................................................................................................................................................................. 34
4.14 STEP 14: DİSPLAY OF THE ERRORS OCCURRED İN THE SERVİCE MODE ............................................................................................. 34
4.15 STEP 15: HOW MANY TİMES HAS THE SERVİCE MODE BEEN COMPLETED SUCCESSFULLY? ............................................... 36
5 EQUİPMENT / APARATUS LİST TO BE USED FOR COMPONENT ATTACHMENT -
DETACHMENT................................................................................................................................................ 38
5.1 . SCHOCK ABSORBER PİN NAİLİNG APPARATUS ....................................................................................................................................... 38
6 COMPONENT ATTACHMENT - DETACHMENT.............................................................................. 41
6.1 UPPER TABLE ATTACHMENT / DETACHMENT........................................................................................................................................... 41
6.1.1 Attachment............................................................................................................................................... 41
6.1.2 Disassembly .............................................................................................................................................. 43
6.2 PANEL ASSEMBLY / DİSASSEMBLY............................................................................................................................................................. 44
6.2.1 Assembly................................................................................................................................................... 44
6.2.2 Disassembly .............................................................................................................................................. 46
6.3 DİSPLAY BOARD İNSTALLATİON/REMOVAL ................................................................................................................................................ 48

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
3
Sensitivity: Public
6.3.1 Wemod board installation/removal ......................................................................................................... 50
6.3.2 Main board installation/removal ............................................................................................................. 52
6.4 DOOR GROUP ASSEMBLY/DİSASSEMBLY.................................................................................................................................................. 56
6.4.1 Attachment............................................................................................................................................... 56
6.4.2 Exterior Decorative Handle Cover............................................................................................................. 56
6.4.3 Exterior Door............................................................................................................................................. 57
6.4.4 Handle ...................................................................................................................................................... 58
6.4.5 Decorative Door........................................................................................................................................ 58
6.4.6 Lock Hook ................................................................................................................................................. 60
6.4.7 Glass ......................................................................................................................................................... 61
6.4.8 Exterior Door Assembly............................................................................................................................. 61
6.5 PUMP COVER ASSEMBLY/DİSASSEMBLY .................................................................................................................................................... 63
6.6 FRONT WALL ASSEMBLY/DİSASSEMBLY ................................................................................................................................................... 63
6.6.1 Disassembly .............................................................................................................................................. 63
6.6.2 Assembly................................................................................................................................................... 67
6.7 DETERGENT BOX ASSEMBLY/DİSASSEMBLY ............................................................................................................................................. 68
6.7.1 Disassembly .............................................................................................................................................. 68
6.7.2 Assembly................................................................................................................................................... 71
6.8 LIQUID DETERGENT DOSING SYSTEM................................................................................................................. 73
6.8.1 Liquid dosing system assembly/disassembly............................................................................................ 73
6.9 TRİPLE VALVE ASSEMBLY/DİSASSEMBLY .................................................................................................................................................. 75
6.10 WATER LEVEL SENSOR ASSEMBLY / DİSASSEMBLY ............................................................................................................................ 75
6.11 PARASİTE FİLTER ASSEMBLY/DİSASSEMBLY........................................................................................................................................ 76
6.12 POWER CABLE ASSEMBLY/DİSASSEMBLY ........................................................................................................................................... 76
6.13 WASHİNG MOTOR............................................................................................................................................................................... 77
6.13.1 ATLAS motor ........................................................................................................................................ 77
6.14 INTEGRATED CONTROL BOARD (VOLTRON BOARD) INSTALLATİON/REMOVAL................................................................................ 77
6.15 POLY V BELT ASSEMBLY ...................................................................................................................................................................... 81
6.16 SHOCK ABSORBER AND SHOCK ABSORBER PİN ASSEMBLY/DİSASSEMBLY........................................................................................ 83
6.16.1 Shock Absorber Assembly/Disassembly............................................................................................... 83
6.17 UPPER COUNTERWEİGHT ASSEMBLY / DİSASSEMBLY ........................................................................................................................ 84
6.18 LOWER COUNTERWEİGHT ASSEMBLY/DİSASSEMBLY......................................................................................................................... 84
6.19 DRAİN PUMP ATTACHMENT / DETACHMENT..................................................................................................................................... 85
6.20 STEAM GENERATOR AND PARTS' ATTACHMENT / DETACHMENT ..................................................................................................... 86
6.20.1 Steam Generator Detachment..................................................................................................................... 86
6.20.3. Steam Generator Bracket Attachment / Detachment ................................................................................ 94
6.20.5 Steam Hose Attachment / Detachment ....................................................................................................... 97
6.20.7.Steam Generator Water Hose Attachment / Detachment........................................................................... 99
6.20.10 Attachment .............................................................................................................................................. 100
6.21 WATER INLET HOSE ASSEMBLY/DİSASSEMBLY ................................................................................................................................101
6.22 DRAİN HOSE ASSEMBLY/DİSASSEMBLY ............................................................................................................................................101
7 PART LİST..................................................................................................................................................... 102
8 FİGURE AND PİCTURE LİST ....................................................................................................................102
9 TABLE LİST ..................................................................................................................................................105

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
4
Sensitivity: Public
Sensitivity: Public
3 COMPONENT OPERATION PRINCIPLES
3.1 Electronic Board Assembly
Picture 3.1 Integrated board
Picture 3.2 Display board
Electronic board assembly comprises
the following:
• Integrated board (main board-
motor board)
• Display board
• Wemod board
• Wemod board holder and
the extension cable.
The integrated board is designed to
ensure that the main board control and
motor board functions, which are
designed for the product, run on the
same board. This designed is intended
to increase the control functionality of
the board.
The display board allows the user to
select the programme and other
auxiliary functions and sends this
information to the processor on the main
board.
Wash programs which are written onto
the microprocessor on the main board,
washing and spinning motor profiles,
protection algorithms and components
(motor, heater, pump, valves, door
safety lock, ntc, water level sensor,
spinning/temperature selection, water
meter) are controlled. On the main
board, along with the LCD display, there
are also buttons used for function
selection.
Picture 3.3 Display and Wemod board

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
5
Sensitivity: Public
Sensitivity: Public
3.2 . Water Inlet Valve (with water meter)
It is used to take water inside the machine at required amounts when needed.
Operating Voltage : 220 / 240VAC 50-60 Hz
Nominal Power : 5 – 8 W
Flow : 10 l/min
Operating Temperatures : T85ºC
Coil resistance : 3400 – 4850 Ω
Picture 3.4 Water inlet valve
•Dual valve is used in the models with one water inlet and without steam
generator;
•Triple valve is used in the models with one water inlet and steam generator (it has
been described in the section concerning steam valve feature);
•Dual valve and an additional single valve are used in the models with double
water inlet and without steam generator,
•Triple valve is used in the models with dual water inlet and steam generator (it
has been described in the section concerning steam valve feature) and additional
single valve is used.
Valves are released by the triacs on the electronic board.
Both valves are released in the softener step by use of crashed water directing
system and the water is directed to the medium compartment (softener compartment)
of the detergent dispenser.
3.3 Steam Input Valve
Steam generator is supplied with water for steam application.
Operating Voltage : 220 / 240V
Flow : 1 l/min
Operating Temperatures : T85ºC
Resistance : 4,1 kΩ
Picture 3.5 Steam input valve
Coil resistances are measured. If it is between 3,5 /
4,85 kΩ, it means that the component is sound.

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
6
Sensitivity: Public
Sensitivity: Public
3.4 Steam Generator
It prepares water steam for the steam applications of the machine.
Operating Voltage : 220 / 240V
Flow : 1 l/min
Resistance : 42 / 47 Ω
Picture 3.6 Steam generator
3.4.1 Operating Principle
Coil resistances are measured. If it is between 42 /
47 Ω, it means that the component is sound.
•Water inside the drum is drained.
•Water is taken from the steam
valve.
•Generator is filled with water.
•Level of the overflowing water
inside the drum is measured.
•Steam valve is released and it is
decided that the generator is full and
valve is shut when there is a 10.0 Hz
increase inside the drum and heating
phase is started.
•Water taken inside the drum is
drained again.
Figure 3.1 Steam generator's operating principle - 1

7
Sensitivity: Public
Sensitivity: Public
During the steam generation process, temperature keeps constant at
120C.
When the water inside the generator starts to decrease, temperature will
increase and thermostat interrupts power at 140C and it steps in again
when
the temperature drops to 125C.
Total
duration of step is 10 minutes.
Normal Operation
In case of thermostat failure,
thermofuse
interrupts power at 260C.
In case of thermostat and
thermofuse failure, relay
interrupts power after 10
minutes.
BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
•Generator is activated for 10
minutes with the relay on the card.
•First steam generation is seen
within approx. 1-2 minutes.
•Generated steam enters into the
drum from behind the drum.
•If the water inside the generator
finished within 10 minutes, thermostat
temperature reaches 140C and it
stops the current of the generator,
later if the temperature decreases to
125C, it steps in again.
•Next step is taken after 10 minutes.
Wash movement is applied for 5
minutes with the steam inside the
drum at this step.
Figure 3.2 Steam generator's operating principle - 2
Figure 3.3 Steam generator's operating principle - 3

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
8
Sensitivity: Public
Sensitivity: Public
Steam generator is used in 2 different ways in the product. Operating logic is the
same in both cases.
•Steam auxiliary function
ois selected after the program is selected like other auxiliary functions.
oSteam generator steps in at the beginning of the program in order to soften the
stains.
•Ventilation program:
oIt is one of the programs.
oIt ensures that the dry - creased shirts are moistened a little and their crease is
eliminated and they are made ready for ironing.
Result of the ventilation program is as follows:
Dry and creased shirt before
the ventilation program
Picture 3.7 Before the ventilation program
Picture 3.8 After the ventilation program
Shirt which is slightly moist and
creased after ventilation
program
Result of max. 4 or 5 shirts is
as seen at the side.
Crease level of the shirts may
be more if more shirts or more
laundry are processed with this
program.

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
9
Sensitivity: Public
Sensitivity: Public
3.5 Water Level Sensor
An analog water level sensor supplied by 5 V is used. This sensor ensures instant
determination of water level by means of frequency values it generates corresponding to the
built up pressure. There are frequency values corresponding to all pressure values. Infinite
number of levels can be determined by an analog water level sensor. Subject to the selected
program, temperature and auxilliary function, water levels vary according to the wash criteria
of designed programme.
Analog water level sensors, in general sense, are elements to turn pressure-displacement.
Analog water level sensors generate frequency modulation as an output.
It basically consists of 2 capacitors, 1 coil and a rotator on itself or on the control system it is
connected to.
Pressure increase pushes a ferrite part in the sensor, into the coil. Thus, coil winding's
L(inductance) value changes and the value of the sensor-rotator system changes. In this
way, analog value of pressure can be measured.
Quantity of hot water to be taken in the machine in the programmes is controlled by water
counters. The task of water level sensor is to perform basic controls such as deciding to take
in water again, check the heater safety level, door opening level or foam level.
If there is an error in water counters or connections thereof, water is taken in by water level
sensor.
Cable inputs
is in the form of 5VDC / Data / GND.
Operation Voltage : 5 VDC
When empty, 625 ± 2 Hz should be read as
Frequency value from the Data and GND tips.
Picture 3.9 Water level sensor

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
10
Sensitivity: Public
Sensitivity: Public
3.6 Parasite Filter
Picture 3.10 Parasite filter
3.7 Door Switch Assembly
Operation Voltage : 220 / 250VAC
Operation Temperatures : T100
Can be checked by measuring input and output
voltages.
Also, control can be made between inputs and
outputs by short circuit control.
It is used to detect if door is open or closed while operating.
Operating Voltage : 5 V dc
Operating Temperatures : T85
Picture 3.11 Door switch assembly
Check short circuit using multimeter on contact
ends.
Open and closed positions must be observed
when contact is moved.
If the relevant value is obtained from the concerned terminals during resistance
measurement, this indicates a problem with the load sensor board. In this case, the
load sensor board needs to be replaced.

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
11
Sensitivity: Public
Sensitivity: Public
3.8 . Wash Motor
3.8.1 Atlas Motor
Picture 3.12 Motor (Atlas motor)
Picture 3.13 Integrated control board
Brushless motor is used. Motor stator consists of 3-phase coil and magnets are on the rotor.
Rotor position is detected from askoll-type hall sensor, stator windings are enegized with the
help of an inverter. In Atlas version,
Rotor position is detected without using hall sensor and stator windings are enegized with the
help of an inverter.
Along with the main board, there is an askoll-type motor driver card integrated on the motor.
However, motor card is discrete in Atlas type. While the motor and the motor card can give
service separately in Atlas type, service can be given in groups in the Askoll type as the
motor and the motor card are integrated. Motor speed is provided through communication of
the motor card and the main board with each other. Main board is the prevailing unit; what
the motor reference speed will be is determined by the main board.
However, all other control algorithms required for motor drive are realized by the motor driver
card. While the motor speed measurement is performed with the help of hall sensor in askoll
type, speed is detected thanks to software in atlas type without using an additional sensor.
Under abbnormal conditions (such as permanently locked rotor), thermic element is used to
protect the motor from overheating. Also, locked rotor condition is detected by the software to
ensure protection

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
12
Sensitivity: Public
Sensitivity: Public
3.9 Safety Keys (Door Lock)
Picture 3.14 Safety key Normal Operation Voltage : 230V 50-60Hz
Working Current : 16 A
Working Environment Humidity: Rh 10- 95%Rh
Work Environment Temperature: 5°C / 75°C
SOLENOID door safety lock is used. When any washing program is initiated after the door is
closed, the SOLENOID door lock is locked by sending a pulse once through the motherboard
and the opening is prevented while the program is running.
Once the program is finished, the door lock can be sent to the master card once it is opened
to open the door.
All components pass through the safety lock. To make defective production machine does
not work.
Locking slide
Fixing pin
Safety pin
Fixing hole
Door detection slider
Electrical
switching box

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
13
Sensitivity: Public
Sensitivity: Public
Picture 3.15 Cover unlocking arm

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
14
Sensitivity: Public
Sensitivity: Public
3.10 Heater
It is used to heat up the water in the drum.
Since it is an electronically controlled machine, there are two thermic protectors
(thermofuses) at heater inputs.
When the heater operates dry, thermic element that is overheated open circuits the heater.
Open circuited heater cannot be reused. To prevent waterless operation of heater "during
heating", heater safety water level (Psafety) is defined in the microprocessor. When the
water level measured by the water level sensor falls below defined Psafety level, heater is
deactivated.
When the water temperature read by NTC reaches "selected temperature", heater is
deactivated by the microprocessor.
Operation Voltage : 230VAC 50-60 Hz
Power : 1950W
Resistance : 26W ± 3Ω
Picture 3.16 Heater
3.11 NTC
When the resistance is read at both tips by
Multimeter, approx. 26Ωshould be read.
It is a component used to measure the temperature of the water in the drum, whose
resistance decreases against temperature increments.
When the water temperature reaches the set temperature, it is deactivated by the heater
relay on the card.
Picture 3.17 NTC
Resistance (25 °C) : 4773 ohm (±4.2%,siemens)-
4837 ohm (±3.2%,elth)
Operation Temperature : -10°C...+100°C
Thermal time constant : 16 ±2 sec
Resistance values read from the NTC ends by multimeter
will be matched with the following table. These values
should approximately be read.

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
15
Sensitivity: Public
Sensitivity: Public
Table 3.1 NTC values
3.12 Drain Pump
It is a synchronous motor equipped with a monophase bipolar magnet rotor. At the
draining step, electronic control card is driven by the triac on it. It is protected by
impedance for continuous operation and blocking situation of the rotor.
Drain pump drains the water inside the drum.
Rated Voltage 220-240 V 50Hz
Resistance 145 ohm
Current <0.2A
Flowrate >14 l/min
Starting performance <=4s (160V)
Picture 3.18 Drain pump
When the resistance is read at pump ends with multimeter, a value between 155 and
180W should be read.

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
16
Sensitivity: Public
Sensitivity: Public
3.13 Liquid Dosing Pump
A liquid dosing pump supplied with 220 VAC is used for dosing liquid detergent and
softener. This is a piston pump. The pump motor makes a rotation movement to
make the piston, which is connected to a crank, move in a linear direction. The liquid
taken from the liquid detergent or softener container fills the empty section between
the pump cylinder and the piston. Every time the piston moves up and down, the
liquid taken will have been dosed and moved to the chamber in the door body. Then
the pump will stop and in the water intake step, through the showering holes on the
door body, the liquid detergent or the softener with water in the door body will be
transferred to the central powder detergent compartment in the drawer, and then to
the detergent box.
Picture 3.19 Liquid Dosing Pump
The festoon socket that is connected to cable terminals transmits energy to the
+/- terminals of the motor.
Operating Voltage: 220 VAC
Operating Current: 15±3 mA at 50 Hz.
Locked rotor current: max. 25 mA
Rotation speed: 20 rpm
Rated dosing amount: 60 ±6 ml/min.

BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
17
Sensitivity: Public
Sensitivity: Public
3.14 Detergent dosing system
Thanks to this liquid dosing system, the desired amount of liquid detergent and
softener can be transferred to the washing environment in line with the user's needs.
The dosing pump is located at the rear left side of the detergent box.
Figure 3.4. Automatic detergent dosing system
Figure 3.5. Detergent dosing system - Detergent drawer and lid
A piston pump is used as the dosing pump. Thanks to these pumps with a high
degree of volumetric accuracy, the desired amount can be dosed with a very small
error margin.
Softener
compartment
Liquid detergent
compartment
Powder
detergent
compartment

18
Sensitivity: Public
Sensitivity: Public
Main wash water inlet
Liquid dosing compartment
Top closure and rinse water inlet
Showering holes
to transfer the
water, liquid
detergent and
softener to the
drawer
Figure 3.6 Detailed illustration for dosing
Figure 3.7 Detailed illustration for dosing
User fills the relevant liquid in the softener and liquid detergent compartments. In
the drawer, there are floats in each compartment. These float if the compartment
BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
Dosing
Pump
Pump
piston
Pump
shaft
Liquid
Detergent inlet
Softener
inlet
Dosing
compartment
Pump liquid
outlet
Detergent
on/off
valve
Pump
liquid inlet

19
Sensitivity: Public
Sensitivity: Public
Softener Float
assembly
Liquid detergent
Float assembly
BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
is full, and if the liquid level in the compartment is low, they go down to let the user
know that liquid detergent or softener must be filled. The floats are detected by the
sensors located under the detergent box. The check valves found at the rear end
of the softener and liquid detergent compartments prevent the spillage of the liquid
in the compartments when the drawer is open. Once the drawer is seated and
pushed back, there will be a flow line from the area shown as the softener and
liquid detergent inlet to the compartment at the backside of the detergent box. If
liquid detergent will be filled, the valve of the system at the back of the box will
open to let the detergent flow in, while softener entry is allowed when the valve is
closed. Before dosing, the pump will start to operate and move the piston to
transfer the liquid coming from the pump liquid entry to the temporary liquid dosing
section, which is located on the door body. When dosing is complete, the pump
will stop and main wash water will be taken in. The water taken will extract the
detergent in the temporary compartment to transfer it to the drawer from the
showering area. The washing liquids will be transferred from the drawer to the
detergent box, and then to the drum through the drum inlet hose. With the water
taken, all liquid residues on the flow line will be transferred to the drum as well.
This way, the channels where water and liquids will flow through in the next
washing and rinsing steps will be cleaned. Moreover, the liquid detergent and
softener will be prevented from mixing with each other, delivering unwanted
results. The dosing principle is the same for softener. Only when the washing will
be performed with powder detergent, the liquid detergent must be unselected on
the interface. Or, when liquid detergent will be dosed, there should be no powder
detergent in the main wash compartment. Otherwise, liquid detergent and powder
detergent will be taken in together.
Figure 3.8. Detailed illustration for dosing softener/liquid detergent float

20
Sensitivity: Public
Sensitivity: Public
Float assembly
Detergent Dosing
Outlet Hole
Detergent Dosing
Outlet Hole
Cleaning (drain) rod
BLG15 BEST VOLTRAN WASHING MACHINE SERVICE HANDBOOK
Sensor
Figure 3.9. Float and sensor positions; liquid fullness detection
Figure 3.10. Detergent Box Rear Section Detail, Dosing Outlet Holes
