CYP QU-14S User manual

QU-14S
1 to 4 HDMI Distribution Amplier (4K Resolution)
Operation Manual
Operation Manual

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 22/15/13 Preliminary release
RDV2 08/07/13 EDID behavior

CONTENTS
1. Introduction ............................................ 1
2. Applications ........................................... 1
3. Package Contents ................................ 1
4. System Requirements ............................ 1
5. Features .................................................. 1
6. Operation Controls and Functions ....... 2
6.1 Front Panel ........................................2
6.2 Rear Panel .........................................3
7. Specications ........................................ 4
8. Connection and Installation ................. 5
9. Acronyms ............................................... 6

1
1. INTRODUCTION
This range of high performance HDMI splitters provide one HDMI in to
four HDMI outputs and support 4Kx2K, 3D, 12-bit Deep Coloer as well
as High denition Lossless Audio. With its 3Gbps bandwidth and the
additional features of the latest HDMI standards you can be sure of
great HDMI distribution.
2. APPLICATIONS
• Simultaneously display one HDMI source on 4 TVs/projectors
• Showroom display
• University lecture hall display
• Retail sales display
• Commercial presentation switcher/scaler
3. PACKAGE CONTENTS
• 1 x 1 by 4 HDMI Splitter
• 1 x 5V DC Power Supply Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI equipped source devices such as a DVD/Blu-ray play with
HDMI cables or DVI to HDMI cables
• HDMI equipped displays (TV or monitors) with HDMI cables
5. FEATURES
• Supports HDTV resolutions up to 4Kx2K/30Hz
• HDMI and DVI compatible
• Supports 1080p@60Hz, Deep Color 12-bit
• Supports LPCM 7.1CH, Dolby TrueHD and DTS-HD Master Audio
• Supports 3D
• Supports System reset and EDID selection functions
Note: Displaying HDMI 4Kx2K resolution require the standard 4Kx2K
HDMI cable and display in order for proper image displaying.

2
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
2 3 4
1
SYNCPOWER
HDMI OUT
4Kx2K
1 2 3
1 POWER LED
Once the power supply is connected the LED will illuminate.
2 SYNC
This LED will illuminate when the HDMI input port is connected to an
active source.
3 HDMI OUT LEDs
These LEDs will illuminate when HDMI output are connected to TV
or display monitor.

3
6.2 Rear Panel
DC 5V
HDMI OUT
SYS
RESET
ON OFF
SERVICEEDID
STD TV
1 2 3 4
HDMI IN
4321 65
1 SYS RESET ON/OFF
This switch allows the user to perform a system reset. The default
setting is OFF, leave as it is when in normal use. By switching
ON, the unit will perform a reset every 8~10 minutes, in order to
perfrom this function the displays must have CEC supported.
When performed successfully, the system will automatically switch
the displays to HDMI input 1. They system reset will not perform on
those displays that do not have a CEC function.
2 EDID STD/TV
The default factory setting is on TV, leave as it is when the display
is properly. The unit will detect the 1st HDMI output’s EDID when
it obtain a 4Kx2K EDID and send out the signal accordingly to all
other output ports.
If the 1st HDMI output is without a 4Kx2K's EDID the unit will detect all
output's EDID and send out the signal that all outputs can accept.
This device obtain the last memory function therefore, the device
will use the last output port 1's EDID when output port 1 is not
connected to a display after every power cycling or switch in
between the EDID setting.
Switch to STD to use build-in EDID if the display has problem. STD
EDID’s video at 1080p@60Hz and audio at LPCM 2CH.
3 SERVICE
This slot is reserved for factory service only.
4 HDMI IN
Connect with source equipment such as DVD/Blu-ray or PS3
player.

4
5 HDMI OUT
Connect to HDMI display for instant image display or cascade with
another family type transmitter.
6 DC 5V
Plug the 5V DC power supply into the unit and connected the
adaptor to an AC outlet.
7. SPECIFICATIONS
Video Bandwidth 300Mbps/9Gbps
Input ports 1 x HDMI,
1 x USB (Service only)
Output ports 4 x HDMI
Resolution Up to 4kx2k (3840x2160@24/25/30Hz/4096x
2160@24Hz)
Power Supply 5V / 2.6 A DC (US/EU standards, CE/FCC/
UL certied)
Dimensions 215mm(W) x 140mm(D) x 48mm(H)
Weight 858 g
Chassis Material Metal
Silkscreen Color Black
ESD Protection Human Body Model: ±8kV (air-gap
discharge)
±4kV (contact
discharge)
Operating Temperature 0˚C ~ 40˚C / 32 ˚F ~ 104 ˚F
Storage Temperature -20˚C ~ 60˚C / -4 ˚F ~ 140 ˚F
Relative Humidity 20~90% RH (non-condensing)
Power Consumption 4W

5
8. CONNECTION AND INSTALLATION
TV/Monitors
Blu-ray Player
HDMI Input
Simultaneous
HDMI Outputs
Power
Supply
Example Shown:
1 to 4 HDMI Splitter

6
9. ACRONYMS
ACRONYM COMPLETE TERM
DTS Digital Theater System
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television

www.cypeurope.com
