CYP CPLUS-V2PE User manual

CPLUS-V2PE
4K UHD+ HDMI to Dual HDMI Scaler
with Audio De-Embedding & Test Patterns
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2017 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
VR0 07/04/16 Preliminary release
VR1 02/06/16 Remove HDR from OSD
VS2 20/06/17 Updated text/diagrams

CONTENTS
1. Introduction......................................................1
2. Applications.....................................................1
3. Package Contents ..........................................1
4. System Requirements......................................1
5. Features............................................................2
6. Operation Controls and Functions.................3
6.1 Front Panel ................................................. 3
6.2 Rear Panel.................................................. 4
6.3 OSD Menu.................................................. 5
6.3.1 Unit's OSD Menu............................... 5
6.3.2 Conversion Rules............................ 11
7. Connection Diagram ....................................13
8. Specications ................................................14
8.1 Technical Specications ........................ 14
8.2 Video Specications............................... 15
8.3 Audio Specications............................... 16
9. Acronyms .......................................................16

1
1. INTRODUCTION
This HDMI to Dual HDMI Scaler with Audio De-Embedding & Test
Patterns is designed to upscale 1080p signals into 4K UHD (18Gbps)
or downscale 4K UHD (18Gbps) signals into 1080p with synchronized
digital and analog audio output. A friendly and simple interface
design allows the user to control the unit while viewing the OSD
directly on the HDMI output. The input signal can be output to both
HDMI outputs simultaneously with a different resolution on each or the
unit can generate a test pattern at a preferred video resolution for
easy on-site display testing and validation. This UHD Scaler is the best
tool to use with your HD and UHD signals.
2. APPLICATIONS
• HDMI signal splitting
• On-site equipment testing
• Production testing
• R&D design and testing
3. PACKAGE CONTENTS
• 1×HDMI to Dual HDMI Scaler
• 1×5V/2.6A DC Power Adaptor
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI input source equipment such as media players, video game
consoles or set-top boxes
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• The use of “Premium High Speed HDMI” cables is highly
recommended.
Notes:
• When displaying 4K HDR or equivalent signals, appropriate output
displays and HDMI cables are required in order to obtain the best
image quality. The use of “Premium High Speed HDMI” cables is
highly recommended for 18Gbps HDMI signals.

2
• HDMI cable distance can be impacted by the materials and design
of the cable used. The use of “Premium High Speed HDMI” cables is
highly recommended for resolutions of 1080p or above.
5. FEATURES
• 1 HDMI input and 2 HDMI outputs with 4K UHD (18Gbps) support and
HDCP 2.2 compliance
• Supports HDCP 2.2 to HDCP1.4 conversion
• Compatible with DVI 1.0
• HDMI signal bypass on both outputs or upscales 1080p signals to 4K
on output B and downscales 4K signals to 1080p on output A
• 4K UHD (4:4:4) to 4K UHD (4:2:0) conversion
• HDMI signal bypass, upscale and downscale
• Integrated EDID management
• Test pattern generation at selected resolutions for on-site display
testing
• Supports High-Dynamic-Range (HDR) sources
• Supports HDR conversion from 4K@24/25/30Hz (4:4:4/4:2:2) 10 or 12-
bit to 4K@24/25/30Hz (8-bit)
• Supports UHD resolutions up to 3840×2160@50/60Hz (4:4:4) &
4096×2160@50/60Hz (4:4:4)
• Supports data rates up to 18Gbps (600MHz) and Deep Color up to
1080p/16-bit
• Supports pass-through of HD audio formats including LPCM
2.0/5.1/7.1, Bitstream, and HD Bitstream
• OSD with instant I/O resolution display
• Digital to Analog (DAC) audio conversion
• Supports the Apple source compatibility mode option

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER 4K2K SYNCMENU
–+
ENTER
TEST
PATTERN
–+
1 2 3 4 5 6
1POWER: This LED will illuminate when the unit is connected with a
power supply.
24K2K: This LED will illuminate when the input source contains a 4K
UHD signal.
3SYNC: This LED will illuminate when the input source is sending
signal.
4MENU: Press this button to enter into OSD menu. Once within the
OSD press this button a second time to exit. Press and hold this
button together with the “-” button for 3 seconds to reset the unit
back to factory defaults.
5DOWN & UP/TEST PATTERN: When the OSD menu is in use, press
these buttons to move within the menu. Outside of the OSD,
press these buttons together to instantly set the output timing to
1280×720@60Hz and display test patterns on both outputs.
6ENTER: Press to conrm a selection or to go deeper into a menu
item.

4
6.2 Rear Panel
AB LRSERVICE
DC 5V
AUDIO OUT
HDMI IN HDMI OUT
1 2 3 4 5
1HDMI IN: Connect to HDMI source equipment such as a media
player, game console or set-top box.
2HDMI OUT A~B: Connect to HDMI TVs, monitors or ampliers
for digital video and audio output. Each output can display a
different resolution with a choice between the HDMI source or a
test pattern.
3AUDIO OUT: Connect to powered speakers or an amplier for
stereo analog audio output extracted from an HDMI source with
LPCM 2.0 audio.
4SERVICE: This slot is reserved for rmware update use only.
5DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.

5
6.3 OSD Menu
6.3.1 Unit's OSD Menu
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
OUTPUT OUTPUT A INPUT 4K2K PASS THROUGH
DOWN 1080P
FIX 4K2K (420)
FIX 8 BITS
OUTPUT B INPUT 1080P PASS THROUGH
UP 4K2K
UP 4K2K (420)
INPUT 4K2K PASS THROUGH
FIX 4K2K (420)
FIX 8 BITS
EDID INT 4K (6G-2CH)
INT 4K (3G-2CH)
INT 4K (420-2CH)
INT 1080P (2CH)
EXT OUT A
EXT OUT B
EXT OUT A (2CH)
EXT OUT B (2CH)
HDCP HDCP SUPPORT
OFF
REFER TO SOURCE
REFER TO DISPLAY
OSD DISPLAY INFO. ON
OFF
OSD TIME OUT OFF
5 SEC.
10 SEC.
15 SEC.

6
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
OSD (cont.) OSD TIME OUT 20 SEC.
25 SEC.
30 SEC.
35 SEC.
40 SEC.
TEST PATTERN A MODE OFF
ON
AUTO PATTERN
AUTO TIMING
PATTERN WHITE COLOR
RED COLOR
GREEN COLOR
BLUE COLOR
MAGENTA
COLOR
YELLOW COLOR
CYAN COLOR
COLOR BAR
RAMP
TOGGLE
RESOLUTION 720×480P@60
720×576P@50
1280×720P@50
1280×720P@60
1920×1080P@50
1920×1080P@60
3840×2160P@24
3840×2160P@25
3840×2160P@30
4096×2160P@24

7
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
TEST PATTERN A
(cont.)
RESOLUTION 4096×2160P@25
4096×2160P@30
HDCP DISABLE
ENABLE
SWITCH TIME 10 SEC.
20 SEC.
30 SEC.
40 SEC.
50 SEC.
1 MIN.
2 MIN.
3 MIN.
5 MIN.
AUTO TIMING
SELECT
720×480P@60
720×576P@50
1280×720P@50
1280×720P@60
1920×1080P@50
1920×1080P@60
3840×2160P@24
3840×2160P@25
3840×2160P@30
4096×2160P@24
4096×2160P@25
4096×2160P@30
TEST PATTERN B MODE OFF
ON
AUTO PATTERN
AUTO TIMING
PATTERN WHITE COLOR

8
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
TEST PATTERN B
(cont.)
PATTERN RED COLOR
GREEN COLOR
BLUE COLOR
MAGENTA
COLOR
YELLOW COLOR
CYAN COLOR
COLOR BAR
RAMP
TOGGLE
RESOLUTION 720×480P@60
720×576P@50
1280×720P@50
1280×720P@60
1920×1080P@50
1920×1080P@60
3840×2160P@24
3840×2160P@25
3840×2160P@30
4096×2160P@24
4096×2160P@25
4096×2160P@30
3840×2160P@50
3840×2160P@60
4096×2160P@50
4096×2160P@60
HDCP DISABLE
ENABLE
SWITCH TIME 10 SEC.
20 SEC.

9
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
TEST PATTERN B
(cont.)
SWITCH TIME 30 SEC.
40 SEC.
50 SEC.
1 MIN.
2 MIN.
3 MIN.
5 MIN.
AUTO TIMING
SELECT
720×480P@60
720×576P@50
1280×720P@50
1280×720P@60
1920×1080P@50
1920×1080P@60
3840×2160P@24
3840×2160P@25
3840×2160P@30
4096×2160P@24
4096×2160P@25
4096×2160P@30
3840×2160P@50
3840×2160P@60
4096×2160P@50
4096×2160P@60
INFORMATION RESOLUTION INPUT
OUTPUT A
OUTPUT B
HDCP OUTPUT A
OUTPUT B
FIRMWARE VERSION

10
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
FIRMWARE
UPDATE
FACTORY SETTING
Note:
• Values in Bold are factory default settings.
• When input timing is non-VESA compliant the OSD may be
disabled. To get into the OSD menu in this case, press the hot key
combination to enter into test pattern mode and operate the OSD
menu while the test pattern is displaying.

11
6.3.2 Conversion Rules
• DOWN 1080P
Input Resolution (Hz) Output Resolution (Hz)
3840×2160p@24 →1920×1080p@24
3840×2160p@25 →1920×1080p@25
3840×2160p@30 →1920×1080p@30
3840×2160p@50 →1920×1080p@50
3840×2160p@60 →1920×1080p@60
4096×2160p@24 →1920×1080p@24
4096×2160p@25 →1920×1080p@25
4096×2160p@30 →1920×1080p@30
4096×2160p@50 →1920×1080p@50
4096×2160p@60 →1920×1080p@60
• UP 4K2K
Input Resolution (Hz) Output Resolution (Hz)
1920×1080p@24 →3840×2160p@24
1920×1080p@25 →3840×2160p@25
1920×1080p@30 →3840×2160p@30
1920×1080p@50 →3840×2160p@50
1920×1080p@60 →3840×2160p@60
• UP 4K2K (YUV420)
Input Resolution (Hz) Output Resolution (Hz)
RGB 4:4:4 & YCbCr 4:4:4/4:2:2 YCbCr 4:2:0
1920×1080p@50 →3840×2160p@50
1920×1080p@60 →3840×2160p@60

12
• FIX 4K2K (YUV420)
Input Resolution (Hz) Output Resolution (Hz)
RGB 4:4:4 & YCbCr 4:4:4/4:2:2 YCbCr 4:2:0
3840×2160p@50 →3840×2160p@50
3840×2160p@60 →3840×2160p@60
4096×2160p@50 →4096×2160p@50
4096×2160p@60 →4096×2160p@60
• FIX 8 BITS
Input Resolution (Hz) Output Resolution (Hz)
RGB 4:4:4 & YCbCr 4:4:4/4:2:2,
10/12/16-bit
RGB 4:4:4 & YCbCr 4:4:4/4:2:2,
8-bit
3840×2160p@24 →3840×2160p@24
3840×2160p@25 →3840×2160p@25
3840×2160p@30 →3840×2160p@30
4096×2160p@24 →4096×2160p@24
4096×2160p@25 →4096×2160p@25
4096×2160p@30 →4096×2160p@30
YCbCr 4:2:0, 10/12/16-bit YCbCr 4:2:0, 8-bit
3840×2160p@50 →3840×2160p@50
3840×2160p@60 →3840×2160p@60
4096×2160p@50 →4096×2160p@50
4096×2160p@60 →4096×2160p@60

13
7. CONNECTION DIAGRAM
AB LRSERVICE
DC 5V
AUDIO OUT
HDMI IN HDMI OUT
AB
DVD or Blu-ray Player
HDMI
Input
Power
Supply
UHDTV
(1080p→4K)
Upscaled or
Bypassed
HDMI Output
Powered
Speakers
Analog
Stereo
Output
HDTV
(4K→1080p)
Downscaled
or Bypassed
HDMI Output

14
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 600MHz/18Gbps
Input Ports 1×HDMI
Output Ports 2×HDMI
2×RCA (Stereo Audio)
Supported Resolutions 480i@60Hz - 4K@60Hz (4:4:4, 8-bit)
VGA@60Hz - WUXGA@60Hz (RB)
HDMI Cable Length 10m (1080p@60Hz, 12-bit)
5m (4K@60Hz, 4:4:4, 8-bit)
Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human Body Model:
±12kV (Air Discharge)
±8kV (Contact Discharge)
Dimensions 231.5mm×25mm×108mm (W×H×D)
[Case Only]
231.5mm×25mm×117mm (W×H×D)
[All Inclusive]
Weight 616g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0˚C - 40˚C/32˚F - 104˚F
Storage Temperature −20˚C - 60˚C/−4˚F - 140˚F
Relative Humidity 20 - 90% RH (Non-condensing)
Power Consumption 5.8W

15
8.2 Video Specications
Supported Resolutions (Hz) HDMI Input HDMI Output
800×600@56/60/72/75/85  
1024×768@60/70/75/85  
1280×768@60/75  
1280×800@60/75  
1280×1024@60/75  
1366×768@60  
1400×1050@60/75  
1440×900@60/75  
1600×900@60  
1600×1200@60  
1680×1050@60  
1920×1200@60  
640×480i@60  
640×480p@60  
720×480p@60  
720×576i@50  
720×576p@50  
1280×720p@50/60  
1920×1080i@50/60  
1920×1080p@24/25/30/50/60  
3840×2160p@24/25/30/50/60  
4096×2160p@24/25/30/50/60  
