CYP CPLUS-11HB User manual

CPLUS-11HB
4K2K HDMI 6G Pattern Generator
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
All Rights Reserved.
Version 1.0 September 2015
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 27/08/15 Preliminary Release
RDV2 21/09/15 Timing LED add 25/50
RDV3 08/10/15 Optical LED

CONTENTS
1. Introduction...............................................1
2. Applications..............................................1
3. Package Contents ...................................1
4. System Requirements...............................1
5. Features.....................................................1
6. Operation Controls and Functions..........2
6.1 Front Panel ...........................................2
6.2 Rear Panel............................................3
7. Connection Diagram ...............................5
8. Specications ...........................................6

1
1. INTRODUCTION
The 4K2K HDMI 6G Pattern Generator is the most advance and handy
tool for verify HDMI devices and produce 6G HDMI signal. With built-in
resolution timing and test patters of 4 each, HDCP and audio type of 3
each that provide over hundred types of test patterns. Allowing both
digital and analogue audio inputs for output HDMI selection. Colorful
LED design allows fast selection on various patterns and quick viewing
on the status.
2. APPLICATIONS
• Production testing
• R&D design and testing
3. PACKAGE CONTENTS
• 1 x 4K2K HDMI 6G Pattern Generator
• 1 x Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Input audio source signals with output HDMI display/monitor and
connection cables.
5. FEATURES
• HDMI with 4K2K 6G supported and HDCP 2.2 compliant
• Generate HDMI timings up to 6Gbps 4K2K@60
• Generate HDCP v1.4/v2.2 and non-HDCP signal
• Supports external stereo and optical audio input

2
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
RL
AUDIO IN
OPTICAL
DC 5V
POWER
O.V.P
21 3 4 5
1AUDIO IN L/R: Connect from audio source equipment with L/R
cables.
2AUDIO IN OPTICAL: Connect from audio source equipment with
optical cable.
3POWER: Plug the 5V DC power supply into the unit and connect
the adaptor to an AC outlet.
4POWER: This LED will illuminate when the device is connected with
power supply.
5O.V.P.(Over Voltage Protection): This LED will illuminate when the
input power supply exceed 5V and the device will be terminated.

3
6.2 Rear Panel
HDCP PATTERNTIMING
SERVICE
HDMI OUTEXITENTERSELECT
SELECT
TIMINGPATTERN
AUDIO25/50
1 3 4 5 62
1SERVICE: This slot is reserved for factory use only.
2SELECT LED: These LEDs will illuminate according to the selection.
Each selection with 2 LEDs of 3 colors, left LED is blue and right LED
are red or green. Each LED color represent a pattern/timing as
below:
Blue Red Green None 25/50
HDCP LED HDCP2.2 HDCP1.4* OFF
PATTERN LED Blue Scale Red Scale Green Scale Gray Scale *
TIMING LED 4K2K60 4K2K30 1080P60 720P60*
4K2K50 4K2K25 1080P50 720P50 ˅
AUDIO LED Optical* LR
*are default setting.
3SELECT Button: Press this button to enter into selection mode and
both LEDs will be ashing in blue and green. Press again to enter
into another selection.
4ENTER/PATTERN Button: Press this button to enter into the selection
then press the SELECT button to select and the LED will illuminate
in sequence from the default setting, press ENTER again to conrm
the selection. When exit selection mode press this button to select
pattern directly.
For example, to select HDCP 2.2 with blue scale and 4K2K60 timing
from the default setting, press SELECT (to enter into selection)→

4
press ENTER (to select HDCP) → press SELECT 3 times (to select
HDCP2.2) → press ENTER (to conrm HDCP selection) →
press SELECT again (to enter into PATTERN selection)→ press ENTER
(to select Patter) → press SELECT 3 times (to select Blue Scale) →
press ENTER (to conrm Pattern selection) →
press SELECT again(to enter into Timing selection) → press ENTER(to
select Timing) → press SELECT twice(to select 4K2k60) → and press
ENTER (to conrm Timing selection).
Note: If the ENTER button is not pressed after the selection is made
the setting will not be established and will remain under the
selection mode.
5EXIT/TIMING Button: Press this button to exit/cancel the selection.
When exit selection mode press this button to select timing directly.
6HDMI OUT: Connect with display/monitor with HDMI cable.

5
7. CONNECTION DIAGRAM
Amplier or HD TV
DVD or Blu-ray Player
RL
AUDIO IN
OPTICAL
DC 5V
POWER
O.V.P
HDCP PATTERN TIMING
SERVICE
HDMI OUTEXITENTERSELECT
SELECT
TIMINGPATTERN
AUDIO25/50

6
8. SPECIFICATIONS
Video Bandwidth 600MHz/6Gbps
Input Port 1 x L/R
1 x Optical
1 x USB(Service)
Output Ports 1 x HDMI
Supported Resolutions 720p@50/60, 1080p@50/60,
4K2K@25/30/50/60
Power Supply 5V/2.6A DC (US/EU standards,
CE/FCC/UL certied)
Chassis Material Aluminum
Chassis color Black
Weight 202g
Dimensions 78.5mm(W) x 87.1mm(D) x 30mm(H)/Jacks
Excluded
78.5mm(W) x 95.25mm(D) x 30mm(H)/Jacks
Included
Power Consumption W
