CY3210-PSoCEVAL1 EVALUATION KIT
QUICK START GUIDE
Remove CY3210-PSoCEval1 Kit from
package.
Plug the PSoC CY8C29466 chip into the
socket (U2).
Power the board; LED5 (red) lights up. Connect jumper at JP1 and JP2. Connect
jumper wire between P01 and VR.
Vary the potentiometer and see the out-
put hex values on the LCD module.
Insert the PSoC Kit CD in the CD drive of your
PC. Install the kit contents, PSoC Designer,
and PSoC Programmer.
1
2
3
4
5
6
Downloaded from Elcodis.com electronic components distributor

© 2011 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks
referenced herein are the properties of their respective owners. DOC#: 001-66719 REV **
www.cypress.com/go/CY3210-PSoCEVAL1
For the latest information about this kit visit
CY3210-PSoCEVAL1 EVALUATION KIT
QUICK START GUIDE
CY3210-PSoCEval1 Evaluation Kit Details
Character LCD
Prototyping Area
UART Rx Pin
RS232 Interface
Power LED
Voltage Regulator
DC Supply Jack
Push Button Switch Potentiometer
(Analog Input)
LCD Contrast
Control
GPIO Expansion Board
Reset Switch
Chip Socket for
PSoC Device
ISSP Programming Header
9-V Battery
Terminals
JP2 connects P27 to UART Tx Pin
JP1 connects P16 to UART Rx Pin
UART Tx Pin
RS232 Tranceiver
Jumper (JP3) to select
Power Option (3.3 V/5 V)
LEDs
