PR O CTM BLE REMOTE CONTROL REFERENCE DESIGN KIT
CY5672 QUICK START GUIDE
• Open the back cover, insert the AAA batteries and
move your nger on the trackpad of the PRoC BLE
remote control
• The blue LED, on dongle, glows to indicate successful
connection with the remote control
Note: The color of the actual product may differ from the color shown in images herein
Two AAA Batteries
The PRoC BLE remote control features:
Bluetooth®4.1- compliant Bluetooth Smart connectivity
Trackpad with two- and one-nger gestures
Microphone to capture and stream voice data
Six-axis motion sensing
3
• Start using the PRoC BLE remote control with your PC
4
12
1
2
3
4
8
6
5
7
Y
Z
X
• Unpack the kit which includes: 1. PRoCTM BLE remote
control, 2. CySmartTM USB dongle, 3. MiniProg3
programmer/debugger, 4. 10-pin ribbon cable,
5. Two M2 X 5 mm screws, 6. Two AAA batteries,
7. Phillips head screwdriver, 8. USB 2.0 standard-A to
mini-B cable
• This guide explains how to evaluate the PRoC BLE
remote control using any PC
• Connect the CySmart USB dongle to a USB port on a PC
• The red LED glows to indicate that the dongle is
powered, the green LED glows to indicate that the
enumeration has nished on the dongle side and the
blue LED breathes slowly to indicate that dongle is
scanning for the remote control
Note: Time taken to complete enumeration on the PC,
for the rst time, depends on the driver installation time

PR O CTM BLE REMOTE CONTROL REFERENCE DESIGN KIT
© 2014 - 2015 Cypress Semiconductor Corporation. All rights reserved.
All trademarks or registered trademarks referenced herein are the properties of their respective owners.
001-93658 Rev.*A
CY5672 QUICK START GUIDE
The PRoC BLE remote control supports:
• Plug-and-play microphone functionality with the CySmart USB dongle (can be tested with any application like
Sound Recorder on Windows)
• Trackpad with gestures (mapped to Windows functions for demonstration) like:
- Finger tracking for cursor movement, one-nger tap for left click and two-nger tap for right click
- Two-nger pinch in/out for zoom in/out
- One-nger swipe at right and bottom edges for vertical and horizontal scrolling* respectively
- One-nger swipe down on top edge to go to Start Screen (for Windows 8 and later)
• Six-axis motion sensing for cursor movement
• Buttons for left click, right click, volume control, power**, channel control**, return** and source** functions
• Bluetooth Smart and Infrared (IR) connectivity
• LED indications for low battery and connection status
• 10-pin header to enable programming and debugging using MiniProg3
The PRoC BLE remote control works with any Bluetooth Smart Ready HID-compatible device. For details, read the
user guide available at
www.cypress.com/CY5672
*Only for applications which support AC Pan usage
** These features can be evaluated using Cypress’s CySmart
TM
tool available at www.cypress.com/CySmart
For the latest information on PRoC BLE, visit www.cypress.com/PRoCBLE
For the latest information about this kit and to download the kit installer with software and hardware les, visit
www.cypress.com/CY5672
Microphone
Microphone Button -
Press and Hold to
Use Microphone
Volume Control
Buttons
Left Click Right Click
Trackpad
Channel
Control Buttons
Power Button
(for host device)
Status LED
Connect Button Infrared Diode
PRoC BLE
Provision to Measure
PRoC BLE Current
(Jumper J1)
10-pin Header for
Programming/
Debugging
PRoC BLE
Two AAA Battery
Holder
Grooves for M2 X 5 mm Screws
to attach Back Cover
Antenna
Source Button
Return Button
Button to switch between Motion Sensor and Trackpad
Note: There is no ON/OFF switch on the remote. Remove the jumper J1 to power off the remote if needed
