Cypress CLUX-11CA User manual

CLUX-11CA
HDMI Repeater with
Audio In
Operation Manual
CLUX-11CA
DRAFT MANUAL

Disclaimers
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes
no commitment to update or to keep current the information
contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright Notice
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2009 by Cypress Technology.
All Rights Reserved.
Version 1.0 October 2009
Trademark Acknowledgments
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
 Always follow basic safety precautions to reduce the risk of
re, electrical shock and injury to persons.
 To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
 Never spill liquid of any kind on or into this product.
 Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
 Do not attach the power supply cabling to building surfaces.
 Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
 To protect the equipment from overheating, do not block the
slots and openings in the module housing that provide ventilation.
Revision History
Version No Date Summary of Change
V1 20100826 Preliminary Release

Table of Contents
1. Introduction..................................................................................1
2. Applications.................................................................................1
3. PackageContents......................................................................1
4. SystemRequirements..................................................................1
5. Features........................................................................................1
6. Specifications..............................................................................2
7. OperationControlsandFunctions............................................. 3
7.1 Top Panel ...................................................................... 3
7.1 Right Panel .................................................................... 3
7.3 Left Panel ...................................................................... 4
7.4 Upper Panel .................................................................. 4
7.5 Rear Panel .................................................................... 4
8. ConnectionandInstallation..................................................... 5

1
1. Introduction
The HDMI repeater with audio in is a device that guaranties your HDMI source
display with alternatives selection of audio combination display. The device
has optical and R/L audio input including the original HDMI audio signal for
user’s favorite selection. While displaying the HDMI image, users can now enjoy
the display with different type of music. The HDMI repeater with audio in is a
brilliant tool for your HDMI entertainment enjoyment.
2. Applications
• Game entertainment
• Product image display
• Demonstration display
• Showroom display
3. Package Contents
• HDMI Repeater with Audio In
• 5V / 1A Power Adaptor
• Operation Manual
4. System Requirements
Input source equipment such as PC or DVD player with connection cables and
output HD monitor or LCD TV with HDMI cable.
5. Features
• Compliant with HDMI 1.3, HDCP 1.2 and DVI 1.0
• Supports HDMI Sample Rates up to 192 kHz
• Supports Optical Sample Rate up to 48 kHz
• Supports TMDS clock frequency rate 225MHz
• Supports high-bit-rate (HBR) audio
• HDMI cable distance test with 1080p 8/12bit resolution, the input & output
can run up to 10 meters
• Low power consumption
• 24 bit resolution

2
6. Specications
Input Port 1 x HDMI, 1 x Optical, 1 x R/L
HDMI Sample Frequency Up to 192 kHz
Optical Sample Frequency Up to 48 kHz
Output Port 1 x HDMI
HDMI Audio Format PCM2/5.1/7.1, Dolby 5.1, DTS 5.1, DD+, D-TrueHD, DTS-HD
Optical Audio Format PCM2
Power Supply 5V / 1A DC ( US/EU standards, CE/FCC/UL certied)
ESD Protection Human body model: ± 8kV (air-gap discharge)
± 6kV (contact discharge)
Dimensions(mm) 100 (W) x 70 (D) x 20(H)
Weight(g) 90
Chassis Material Plastic
Silkscreen Color White
Operating Temperature 0ºC~40ºC / 32ºF~104ºF
Storage Temperature -20ºC~60ºC / -4ºF~140ºF
Power Consumption 1.5W
Relative Humidity 20 ~ 90% RH (non-condensing)

3
7. Operation Controls and Functions
7.1TopPanel
1
2
1. Power LED: The red LED will illuminate when the power is connected with
AC wall outlet.
2. LINK: The LED will illuminate in blue when both the source and the display
are sync together. This LED will also blink once while the power is turned on.
7.2RightPanel
1 2
1. Audio In Select: This switch allows user to select the audio input from HDMI,
Optical or L/R. By switching the dip switch according to the printing from
left to right HDMI, Optical and L/R.
2. Power Button: Press this button switch ON or set the device to standby
mode.
6. Specications
Input Port 1 x HDMI, 1 x Optical, 1 x R/L
HDMI Sample Frequency Up to 192 kHz
Optical Sample Frequency Up to 48 kHz
Output Port 1 x HDMI
HDMI Audio Format PCM2/5.1/7.1, Dolby 5.1, DTS 5.1, DD+, D-TrueHD, DTS-HD
Optical Audio Format PCM2
Power Supply 5V / 1A DC ( US/EU standards, CE/FCC/UL certied)
ESD Protection Human body model: ± 8kV (air-gap discharge)
± 6kV (contact discharge)
Dimensions(mm) 100 (W) x 70 (D) x 20(H)
Weight(g) 90
Chassis Material Plastic
Silkscreen Color White
Operating Temperature 0ºC~40ºC / 32ºF~104ºF
Storage Temperature -20ºC~60ºC / -4ºF~140ºF
Power Consumption 1.5W
Relative Humidity 20 ~ 90% RH (non-condensing)

4
7.3LeftPanel
1
1. DC 5V: This slot is where you plug the 5V DC power supply into the unit
and connect the adaptor to an AC wall outlet.
7.4UpperPanel
1 2 3
1. Input R/L: These slots are to connect with audio source equipment such
as CD player or Hi-Fi equipment with RCA jack for input audio signal.
2. Input Optical: This slot is to connect with audio source equipment such as
stereo system or Hi-Fi equipment with optical cable for input audio signal.
3. This slot is to connect with input source equipments such as DVD/Blu-Ray
player with HDMI cable for video and audio input signal.
7.5RearPanel
1
1. HDMI Out: This slot is to connect with LCD TV or HD monitor for both video
and audio display with HDMI cable.

5
8. Connection and Installation
Monitor
HDTV
or
Amplier
Stereo or
Blu-Ray DVD

6
Acronyms A
Acronym Complete Term
DVI Digital Visual Interface
HDCP High-bandwidth Digital content protection
HDMI High-Denition Multimedia Interface

7
A
Acronym Complete Term
DVI Digital Visual Interface
HDCP High-bandwidth Digital content protection
HDMI High-Denition Multimedia Interface

MPM-CLUX11CA
Home page: http://www.cypress.com.tw
CYPRESSTECHNOLOGYCO.,LTD.
