AN205336
F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
This application note describes how to use the watch-dog timer, the functions of the watchdog timer and gives some
examples.
Contents
1Introduction...............................................................1
2Watchdog Timer.......................................................1
2.1 Key Features ...................................................1
2.2 Block Diagram .................................................2
2.3 Registers..........................................................3
2.4 NVR (Non-Volatile Register) Function.............4
3Interval Time.............................................................5
4Usage and Examples ...............................................6
4.1 Functions and Operations of Watchdog Timer 6
4.2 Software Watchdog Timer...............................7
4.3 Hardware Watchdog Timer..............................8
5Note on Using Watchdog Timer ...............................9
6Additional Information...............................................9
6.1 Sample Code.................................................10
7Document History...................................................14
1 Introduction
This application note describes how to use the watch-dog timer.
The application note describes the functions of the watchdog timer and gives some examples.
2 Watchdog Timer
This chapter introduces the basic function of the watchdog timer.
2.1 Key Features
The watchdog timer functions as a counter used to prevent program from running out of control. Once the watchdog
timer is activated, its counter needs to be cleared at specified intervals regularly. A watchdog reset is generated if the
timer is not cleared within a preset interval time based on Chapter 3. The watchdog timer that is not cleared may be
due to problems in the program which has entered into an infinite loop or Stack over-run or other possible problems
that caused the CPU to hang.
The watchdog timer has the following features:
Count clock selector
Watchdog timer counter
Reset control circuit is used to generate the reset signal when the WDT counter overflows
Watchdog timer clear selector is used to selects the watchdog timer clear signal
Counter timer control circuit
Hardware and software watchdog timer

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 2
2.2 Block Diagram
Figure 1 shows the internal block diagram of watchdog timer.
Figure 1. Block Diagram of Watchdog Timer

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 3
2.3 Registers
Please refer to Chapter 11 and Chapter 22 of MB95200H/210H Series Hardware Manual for detailed register setting.
2.3.1 Watchdog Timer Control Register (WDTC)
This register is used to activate or clear the watchdog timer.
Figure 2. WDTC
Address
bit7
bit6
bit5
bit4
bit3
bit2
bit1
bit0
Initial value
000CH
CS1
CS0
CSP
HWWDT
WTE3
WTE2
WTE1
WTE0
software
R/W
R/W
R/W
R0,WX
R0/W
R0/W
R0/W
R0/W
00000000B
hardware
R0/WX
R0/WX
R1/WX
R1,WX
R0/W
R0/W
R0/W
R0/W
00110000B
2.3.2 Watchdog Timer Selection ID Register (WDTH, WDTL)
The two registers are used to select hardware or software watchdog timer.
Figure 3. Watchdog Timer Selection ID Register (WDTH, WDTL)
Address
bit7
bit6
bit5
bit4
bit3
bit2
bit1
bit0
Initial value
0FEBH
WDTH
WDTH7
WDTH6
WDTH5
WDTH4
WDTH 3
WDTH 2
WDTH 1
WDTH 0
xxxxxxxx
0FECH
WDTL
WDTL7
WDTL6
WDTL5
WDTL4
WDTL 3
WDTL 2
WDTL 1
WDTL 0
xxxxxxxx
R/WX
R/WX
R/WX
R/WX
R/WX
R/WX
R/WX
R/WX
R/W : Readable/writeable (Read value is the same as write value)
R/WX : Read only (Readable, writing has no effect on operation)
R0/WX : Undefined bit (Read value is “0”, writing has no effect on operation)
R1/WX : Undefined bit (Read value is “1”, writing has no effect on operation)
R0/W : Write only (Writable, “0” is read)

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 4
2.4 NVR (Non-Volatile Register) Function
The NVR interface enables users to select hardware or software watchdog timer by modifying the 16-bit watchdog
timer selection ID. Please note that the watchdog timer selection ID cannot be modified while the CPU is running,
therefore please modify NVR in Flash Area first, then the MCU will copy these values to NVR interface (IO Area)
automatically after a reset.
Figure 4 shows the basic configuration of serial programming connection for flash memory products.
Figure 4. Retrieval of NVR during Reset
Please note that either the SWWDT or HWWDT can work at the same time. NVR is used to decide which one is
working.
These 16 bits of WDTH and WDTL are loaded from the flash address FFBEH, FFBFHafter a reset. The initial values
are determined by the pre-loaded values in the NVR flash area.
Write certain values to the address FFBEHand FFBFHto select watchdog timer’s mode.
Table 1 shows watchdog timer selection ID.
Table 1. Watchdog Timer Selection ID
WDTH[7:0], WDTL[7:0]
Function
A596H
The HWWDT is disabled and the SWWDT is enabled.
A597H
The HWWDT is selected and the SWWDT is disabled. [It can be stopped in one of
the standby modes (stop/sleep/timebase timer/watch mode).]
Other than the above values
The WHWDT is selected and the SWWDT is disabled. [It keeps running in one of the
standby modes (stop/sleep/timebase timer/watch mode).]

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 5
3 Interval Time
This chapter describes the interval time of the watchdog timer
The interval times of the watchdog timer are shown in Table 2. If the counter of watchdog timer is not cleared, a
watchdog reset is generated between the minimum time and the maximum time.
Table 2. Interval Times of Watchdog Timer
Count clock type
Count clock switch bit
CS[1:0], CSP
Interval time
Minimum time
Maximum time
Timebase timer output
(main clock = 4MHz)
000B(SWWDT)
221/FCH
524 ms
1.05 s
010B(SWWDT)
220/FCH
262 ms
524 ms
Watch prescaler output
( sub-clock = 32.768KHz)
100B(SWWDT)
214/FCL
500 ms
1.00 s
110B(SWWDT)
213/FCL
250 ms
500 ms
Sub-CR timer
(sub-CR clock = 50-200KHz)
XX1B(SWWDT) or HWWDT*1
216/FCRL
328 ms
2.62 s
*1: CS [1:0] = 00B, CSP = 1B(read only)
The interval time varies depending on the timing of clearing the watchdog timer. Figure 5 shows the correlation
between the timing of clearing the watchdog timer and the interval time when the timebase timer output 221/FCH (FCH:
main clock) is selected as the count clock (main clock = 4MHz).
Figure 5. Clearing Timing and Interval Time of Watchdog Timer
Please note that program must clear the counter of the watchdog timer within the minimum time.

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 6
4 Usage and Examples
Functions and examples for watchdog timer
This chapter describes the usage of watchdog timer and gives some examples.
4.1 Functions and Operations of Watchdog Timer
Please write certain values to NVR flash area address FFBEHand FFBFHto choose the watchdog timer operation
mode. See Table 1 for detailed settings of mode choose.
The Watchdog Timer has two operate modes as below:
Software watchdog
1. Write “A596H”(enable software watchdog timer) to the address FFBEHand FFBFHon the flash memory, which
are copied to the watchdog timer selection ID register WDTH/WDTL (0FEBH/0FECH) after a reset.
2. The watchdog timer is activated when “0101B”is written to the watchdog control bits of the watchdog timer
control register (WDTC: WTE3 to WTE0) for the first time after a reset. The count clock switch bits of the
watchdog timer register (WDTC: CS1, CS0, CSP) should also be set at the same time.
3. Once the watchdog timer is activated, a reset is the only way to stop its operation. Please clear watchdog
counter in a specified intervals regularly depend on the setting of WDTC: CS1, CS0, CSP. Refer to Table 3-1 for
detailed interval time.
Hardware watchdog
1. Write “A597H”(WDT can be stopped in a standby mode) or any other value (WDT is enabled in every mode)
except than “A596H”or “A597H” to the address FFBEHand FFBFHon the flash memory, which are copied to the
watchdog timer selection ID register WDTH/WDTL (0FEBH/0FECH) after a reset.
2. The hardware watchdog timer starts automatically after a reset and cannot be stopped. Please clear its counter
at specified intervals regularly to avoid generates a watchdog timer reset.
3. This timer is cleared by reset and resumes operation after the reset.
Please note that the watchdog timer is cleared at the same time as the timer selected as the count clock (timebase
timer or watch prescaler) is cleared. For this reason, the watchdog timer cannot function as such, if the software is set
to clear the selected timer repeatedly during the interval time of the watchdog timer

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 7
4.2 Software Watchdog Timer
Setting Procedure Example
The software watchdog timer is set up through the following procedure:
1. Ensure that the address FFBEH, FFBFHvalues are “A596H”(NVR flash area)
2. Select the count clock.(WDTC:CS1,CS0,CSP)
3. Activate the watchdog timer. (WDTC:WTE3 to WTE0 = 0101B)
4. Clear the watchdog timer within the minimum interval time.(WDTC:WTE3 to WTE0 = 0101B)
Refer Table 2.
The following example shows how to set up watchdog Timer for operation with software mode.
main.c
startup.asm
Refer to Appendix Sample Code for project “SWWDT”.
Please note that once the watchdog timer is activated, it cannot be stopped until a reset is generated.
/* initial watchdog timer */
void InitWDT (void)
{
WDTC = 0x05; // set count clock is 221/FCH
// start WDT counter
}
/* main routine */
void main (void)
{
InitWDT();
...
WDTC |= 0x05; // clear WDT counter
}
#define HWD_DISABLE
;------------------------------------------------------------------------
; Hard Watchdog
;------------------------------------------------------------------------
#ifdef HWD_DISABLE
.SECTION WDT, CONST, LOCATE=H'FFBE
.DATA.W 0xA596
#endif

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 8
4.3 Hardware Watchdog Timer
The hardware watchdog timer is set up through the following procedure:
1. Activate the watchdog timer by writing “A597H” (WDT is enabled except in standby mode) or any other value
(WDT is enabled in every mode) except other than “A596H”and ”A597H” to the address FFBEHand FFBFHon the
flash memory, which are copied to the watchdog timer selection ID register WDTH/WDTL (0FEBH/0FECH)
2. The HWWDT starts automatically after a reset.
3. Clear the watchdog timer with minimum interval time. (WDTC:WTE3 to WTE0 = 0101B)
Cause of while using the HWWDT, the count clock switch bits: CS1, CS0, CSP are fixed at “001”, the interval time is
fixed at 216/FCRL too.
The following example shows how to set watchdog timer for operating in hardware mode.
main.c
startup.asm
Refer to Appendix Sample Code for project “HWWDT”.
Please note that the hardware watchdog timer starts automatically after a reset and cannot stop its operation.
/* Hardware watchdog timer starts automatically after a reset and */
/* cannot be stopped. The internal time is fixed to 216/FCRL */
/* main routine */
void main (void)
{
...
WDTC |= 0x05; // clear WDT counter
...
}
;------------------------------------------------------------------------
; Hard Watchdog
;------------------------------------------------------------------------
; #define HWD_DISABLE
#ifdef HWD_DISABLE
.SECTION WDT, CONST, LOCATE=H'FFBE
.DATA.W 0xA596
#endif

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 9
5 Note on Using Watchdog Timer
Take account of the following points when using the watchdog timer.
Stopping the watchdog timer
Once activated, the watchdog timer cannot be stopped until a reset is generated.
If a HWWDT is select, it will resume operation after a reset.
Selecting the count clock
Software watchdog timer
The count clock switch bits (WDTC: CS1, CS0, CSP) can be rewritten only when the watchdog control bits (WDTC:
WTE3 to WTE0) are set to "0101B" upon the activation of the watchdog timer. The count clock switch bits cannot be
written by a bit operation instruction. Moreover, the bit settings should not be changed once the timer is activated.
In sub-clock mode, the timebase timer does not operate because the main clock stops oscillating.
In order to operate the watchdog timer in sub-clock mode, it is necessary to select the watch prescaler as the count
clock beforehand and set "WDTC: CS1, CS0, CSP" to "100B" or "110B" or "XX1B".
Hardware watchdog timer
The count clock is fixed at 216/FCRL.
Clearing the watchdog timer
Clearing the counter used for the count clock of the watchdog timer (timebase timer or watch prescaler or sub-CR
timer) also clears the counter of the watchdog timer.
The counter of the watchdog timer is cleared when entering the sleep mode, stop mode or watch mode except in the
case of selecting the hardware activation with the hardware watchdog timer running in a standby mode.
Programming precaution
When creating a program in which the watchdog timer is cleared repeatedly in the main loop, set the processing time
of the main loop including the interrupt processing time to the minimum watchdog timer interval time or shorter.
Hardware watchdog (with timer running in a standby mode)
The watchdog timer does not stop in stop mode, sleep mode, timebase timer mode or watch mode. Therefore, the
watchdog timer is not to be cleared by the CPU even if the internal clock stops. (in stop mode, sleep mode, timebase
timer mode or watch mode).
Regularly release a standby mode and clear the watchdog timer. However, a watchdog reset may be generated
depending on the setting of the oscillation stabilization wait time setting register after the CPU returns from stop mode
in sub-clock mode or sub-CR mode.
Take account of the setting of the sub-clock stabilization wait time when selecting the sub-clock.
6 Additional Information
For more Information on MB95200 products, visit the following website:
http://www.cypress.com/8fx-mb95200

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 10
6.1 Sample Code
6.1.1 Project Name: SWWDT
Software watchdog timer
main.c
#include "mb95200.h"
/*---------------------------------------------------------------------------
name: Delay();
function: delay function
-----------------------------------------------------------------------------*/
void Delay (unsigned int i)
{
while(i--)
{
asm("\tNOP");
}
}
/*---------------------------------------------------------------------------
name: InitWDT();
function: initial watchdog timer
-----------------------------------------------------------------------------*/
void InitCompTimer (void)
{
WDTC = 0x05; // set count clock is 221/FCH
// start WDT counter
}
/*---------------------------------------------------------------------------
name: main();
function: main loop
-----------------------------------------------------------------------------*/
void main(void)
{
PDR0_P05 = 0; // initial value
DDR0_P05 = 1; // set P05 as output
InitWDT ();

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 11
while(1)
{
PDR0_P05 = ~PDR0_P05; // show program is normal run
Delay (500);
WDTC |= 0x05; // clear WDT timer within a certain amount of time
}
}
startup.asm
;--------------------------------------------------------------------------
; variable define declaration
;--------------------------------------------------------------------------
#define HWD_DISABLE ; if define this, Hard Watchdog will disable.
;--------------------------------------------------------------------------
; Hard Watchdog
;--------------------------------------------------------------------------
#ifdef HWD_DISABLE
.SECTION WDT, CONST, LOCATE=H'FFBE
.DATA.W 0xA596
#endif

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 12
6.1.2 Project Name: HWWDT
Hardware watchdog
main.c
#include "mb95200.h"
/* Hardware watchdog timer starts automatically after a reset and cannot be stopped */
/* The internal time is fixed to 216/FCRL */
/*---------------------------------------------------------------------------
name: Delay();
function: delay function
-----------------------------------------------------------------------------*/
void Delay (unsigned int i)
{
while(i--)
{
asm("\tNOP");
}
}
/*---------------------------------------------------------------------------
name: main();
function: main loop
-----------------------------------------------------------------------------*/
void main(void)
{
PDR0_P05 = 0; // initial value
DDR0_P05 = 1; // set P05 as output
while(1)
{
PDR0_P05 = ~PDR0_P05; // show program is normal run
Delay (500);
WDTC |= 0x05; // clear WDT timer within a certain amount of time
}
}

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 13
startup.asm
;--------------------------------------------------------------------------
; variable define declaration
;--------------------------------------------------------------------------
;#define HWD_DISABLE ; if define this, Hard Watchdog will disable.
;--------------------------------------------------------------------------
; Hard Watchdog
;--------------------------------------------------------------------------
#ifdef HWD_DISABLE
.SECTION WDT, CONST, LOCATE=H'FFBE
.DATA.W 0xA596
#endif

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 14
7 Document History
Document Title: AN205336 - F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
Document Number: 002-05336
Revision
ECN
Orig. of
Change
Submission
Date
Description of Change
**
-
HUAL
03/20/2008
Initial release
07/18/2008
Added URL in Chapter 6 Additional Information; modified
figure number and some sample code.
*A
5267132
HUAL
05/11/2016
Migrated Spansion Application Note MCU-AN-500013-E-11 to Cypress
format

F²MC-8FX Family, MB95200H/210H Series Watchdog Timer
www.cypress.com Document No. 002-05336 Rev.*A 15
Worldwide Sales and Design Support
Cypress maintains a worldwide network of offices, solution centers, manufacturer’s representatives, and distributors. To find
the office closest to you, visit us at Cypress Locations.
Products
ARM®Cortex®Microcontrollers
cypress.com/arm
Automotive
cypress.com/automotive
Clocks & Buffers
cypress.com/clocks
Interface
cypress.com/interface
Lighting & Power Control
cypress.com/powerpsoc
Memory
cypress.com/memory
PSoC
cypress.com/psoc
Touch Sensing
cypress.com/touch
USB Controllers
cypress.com/usb
Wireless/RF
cypress.com/wireless
PSoC®Solutions
cypress.com/psoc
PSoC 1 | PSoC 3 | PSoC 4 | PSoC 5LP
Cypress Developer Community
Community | Forums |Blogs | Video |Training
Technical Support
cypress.com/support
PSoC is a registered trademark and PSoC Creator is a trademark of Cypress Semiconductor Corp. All other trademarks or registered trademarks
referenced herein are the property of their respective owners.
Cypress Semiconductor
198 Champion Court
San Jose, CA 95134-1709
Phone : [phone]
Fax : [phone]
Website : www.cypress.com
© Cypress Semiconductor Corporation, 2008-2016. This document is the property of Cypress Semiconductor Corporation and its subsidiaries, including
Spansion LLC (“Cypress”). This document, including any software or firmware included or referenced in this document (“Software”), is owned by
Cypress under the intellectual property laws and treaties of the United States and other countries worldwide. Cypress reserves all rights under such
laws and treaties and does not, except as specifically stated in this paragraph, grant any license under its patents, copyrights, trademarks, or other
intellectual property rights. If the Software is not accompanied by a license agreement and you do not otherwise have a written agreement with
Cypress governing the use of the Software, then Cypress hereby grants you a personal, non-exclusive, nontransferable license (without the right to
sublicense) (1) under its copyright rights in the Software (a) for Software provided in source code form, to modify and reproduce the Software solely for
use with Cypress hardware products, only internally within your organization, and (b) to distribute the Software in binary code form externally to end
users (either directly or indirectly through resellers and distributors), solely for use on Cypress hardware product units, and (2) under those claims of
Cypress’s patents that are infringed by the Software (as provided by Cypress, unmodified) to make, use, distribute, and import the Software solely for
use with Cypress hardware products. Any other use, reproduction, modification, translation, or compilation of the Software is prohibited.
TO THE EXTENT PERMITTED BY APPLICABLE LAW, CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD
TO THIS DOCUMENT OR ANY SOFTWARE OR ACCOMPANYING HARDWARE, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. To the extent permitted by applicable law, Cypress reserves the right to
make changes to this document without further notice. Cypress does not assume any liability arising out of the application or use of any product or
circuit described in this document. Any information provided in this document, including any sample design information or programming code, is
provided only for reference purposes. It is the responsibility of the user of this document to properly design, program, and test the functionality and
safety of any application made of this information and any resulting product. Cypress products are not designed, intended, or authorized for use as
critical components in systems designed or intended for the operation of weapons, weapons systems, nuclear installations, life-support devices or
systems, other medical devices or systems (including resuscitation equipment and surgical implants), pollution control or hazardous substances
management, or other uses where the failure of the device or system could cause personal injury, death, or property damage (“Unintended Uses”). A
critical component is any component of a device or system whose failure to perform can be reasonably expected to cause the failure of the device or
system, or to affect its safety or effectiveness. Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim,
damage, or other liability arising from or related to all Unintended Uses of Cypress products. You shall indemnify and hold Cypress harmless from and
against all claims, costs, damages, and other liabilities, including claims for personal injury or death, arising from or related to any Unintended Uses of
Cypress products.
Cypress, the Cypress logo, Spansion, the Spansion logo, and combinations thereof, PSoC, CapSense, EZ-USB, F-RAM, and Traveo are trademarks or
registered trademarks of Cypress in the United States and other countries. For a more complete list of Cypress trademarks, visit cypress.com. Other
names and brands may be claimed as property of their respective owners.
