CZH FMUSER DP-100 User manual

DP-100 half wave Dipole Antenna
Manual
1. Introduction:
Adipole antenna is a radio antenna that can be made of aluminum, copper, and bronze
tube with a center-fed driven element. It consists of two metal conductors of rod,
oriented parallel and collinear with each other (in line with each other), with a small
space between them. The radio frequency voltage is applied to the antenna at the
center, between the two conductors. These antennas are the simplest practical
antennas from a theoretical point of view. They are used alone as antennas, notably in
traditional "rabbit ears" television antennas, and as the driven element in many other
types of antennas, such as the Yagi. Dipole antennas were invented by German
physicist Heinrich Hertz around 1886 in his pioneering experiments with radio waves.

Radiation pattern of a half-wave dipole antenna, scale is linear

The Gain of a half-wave dipole (same as above).
The scale is in dBi (decibels over isotropic).
Many people have had success in feeding a dipole directly with a coaxial cable feed
rather than a ladder-line. However, coax is not symmetrical and thus not a balanced
feeder. It is unbalanced, because the outer shield is connected to earth potential at the
other end. When a balanced antenna such as a dipole is fed with an unbalanced feeder,
common mode currents can cause the coax line to radiate in addition to the antenna
itself, and the radiation pattern may be asymmetrically distorted. This can be remedied
with the use of a balun.
2. Antenna Gain Information:
This antenna gain chart shows the maximum theoretical (minus a small allowance for
system losses) gain achievable from arrays of closely spaced co-linear dipole elements.
Dimensions shown are for elements almost touching; the actual heights may be slightly
more due to phasing networks used between the dipole elements.

Table 1.1
3. Assemble & Install
1).How to assemble the antenna elements:
Figure 1.1

A.Insert the elements into the T tube with corresponding polarity positive( + ) to
positive ( + ) and negative (–) to negative (- )
B .When inserted screw it with the metal screw as you see in figure 1.1
C .As you finish assembling the antenna it look like at the figure 1.2 in the picture
Figure 1.2
2).Tuning/calibrating the Dipole Antenna:
A. Select the Frequency you would like to use as you can see frequency with
corresponding scale of elements.

figure 1.3
B. When you have selected the frequency we are ready to tune/calibrate the element.
a) First we loosen the bolt and nut of the element as we can see in figure 1.3
b) Then adjust the adjustable element to its corresponding frequency scale
c) We can tighten the bolt and nuts in every elements. Now we can mount it to your
tower.
3).Install the dipole antenna it to your tower or post:
A. Insert the rod opposite T-tube end to the metal fixture, check the picture below:

B. Unscrew the U clips and insert the two U clips through the holes of metal fixture, fix
the whole antenna to the post/tower:

Attention: the post should be at least 2 meters high, this is to ensure the antenna will
maximize its advantage.
C. Fix the post to one place, make sure the “Anode” end is up and “Negative Electrode”
end is down.

D. Finished Installation (We didn’t connect the cable in this manual, in real operation,
please connect the cable to the antenna after installation)
