AOR DA5000 User manual

DA5000 - discone aerial for professional applications 700MHz ~ 3GHz
®
AOR Ltd
2-6-4 Misuji, Taito-ku, Tokyo 111-0055, Japan.
Tel: [phone] Fax: [phone]
[email protected] www.aorja.com
®
The DA5000 is a professionally constructed 'compact'
discone aerial for the upper UHF frequency range of
700MHz to 3GHz (3,000MHz). The top section comprises
of 16 horizontal elements and the lower section has eight
radials mounted on a solid stub terminated in a N-type
socket.
The construction is largely of brass (BsBM) accounting for its weight of
700g, it is finished in a military grey colour. The overall length from the top
elements to the N-socket is about 240mm with the overall top diameter being
82mm and each radial 100mm long.
Termination is via a N-socket which is housed within the stub-mast to keep
adverse weather out. Use of quality 50 OHM coaxial cable is essential, at
least URM67 / RG213 for short lengths and even better quality for longer
cable runs.
Avoid touching the horizontal elements, improper handling of the
horizontal elements will degrade the aerial's performance. Due to the
exacting method of construction, it is not possible to replace components
which are mishandled and accidentally damaged by the customer.
The DA5000 is supplied with an aluminium stub-mast of 32mm diameter and
400mm in length, clamps to secure the aerial / stub-mast / support pole
(support pole not included), 'V' brackets are also included which accept a
support pole of 25mm - 50mm diameter.
Specification
Frequency coverage 700MHz - 3GHz (3,000MHz)
Aerial gain (max) 2.5dB (see plot) vertical omni-directional
Impedance 50 OHM
Termination N-socket, female
Horizontal elements 16, overall top diameter 82mm
Radials 8, 100mm long, overall outer diameter 145mm
Overall height 240mm
Wind resistance up to 40m/S (theoretical)
Stub-mast 32mm diameter, 400mm long
Support pole size 25mm - 50mm (not included)
Coaxial cable Use low loss (not supplied)
Supplied items
1 x DA5000 aerial
1 x stub-mast with large securing bolt and split washer
2 x support clamp with two small bolts
2 x 'V' brackets with four washers & nuts
1 x instruction manual
Note: measurements approx, not intended for transmit
INRADIO
ABEL &PRO-FIT
tel.
e-mail:
internet:
ul. Puszkina 80 92-516 £ódŸ
([phone]
[email protected]
www.inRADIO.pl
Autoryzowany Przedstawiciel AOR w Polsce:

IMPORTANT !!!! READ unpacking instructions before proceeding !!! Do NOT touch the horizontal elements! Improper handling of the horizontal elements will degrade the aerial's performance.
Do NOT touch the horizontal elements! Improper handling of the horizontal elements will
degrade the aerial's performance.
Assembly instructions
1. Connect the N connector
2. Insert the screw with washer (as shown)
3. Secure to stub-mast (included) and to mounting pole (not supplied)
