DèLonghi ECAM350.35.SB User manual

De’Longhi Appliances via Seitz, 47 31100 Treviso Italy www.delonghi.com 5713229861/09.16

ECAM35X.35
BEAN TO CUP ESPRESSO
AND CAPPUCCINO MACHINE
Instruction for Use
Instruction videos available at:
http://ecam35035.delonghi.com

2
EN
page 6
BB1
B2
B3
B4
B6
B7
B9
B11
B5
B8
B10
B12 B13
C
C2
C1 C3 C4

3
AA2 A1
A4
A3
A12
A17
A18
A11
A10
A14
A15
A13
A16
A8
A7 A9
A6
A22
A20
A21
A19
A5
B
A23
A24

4
3B
3A
2
678
10
21 23 24
25
22A
22B
PUSH
3A
20
PUSH
B
A
A B
26
4
1
5
911
16
17 19
15
1,8l
28
29
0,5 L
30 31 32
HOT MILK
OK
12
NO
13 14
18
27

5
3B
3A
2
678
10
21 23 24
25
22A
22B
PUSH
3A
20
PUSH
B
A
A B
26
4
1
5
911
16
17 19
15
1,8l
28
29
0,5 L
30 31 32
HOT MILK
OK
12
NO
13 14
18
27

6
CONTENTS
1. FUNDAMENTAL SAFETY WARNINGS.............7
2. SAFETY WARNINGS ...................................8
2.1 Symbols used in these instructions ...............8
2.2 Designated use..............................................8
2.3 Instruction for Use.........................................8
3. INTRODUCTION..........................................8
3.1 Letters in brackets.........................................8
3.2 Troubleshooting and repairs..........................8
4. DESCRIPTION.............................................9
4.1 Description of the appliance .........................9
4.2 Description of the accessories........................9
5. BEFORE USE...............................................9
5.1 Checking the appliance.................................9
5.2 Installing the appliance.................................9
5.3 Connecting the appliance..............................9
5.4 Setting up the appliance.............................10
6. TURNING THE APPLIANCE ON.................... 10
7. TURNING THE APPLIANCE OFF .................. 10
8. MENU SETTINGS ...................................... 10
8.1 Rinsing........................................................11
8.2 Language....................................................11
8.3 Maintenance...............................................11
8.4 Program beverages .....................................11
8.5 Program My beverages................................11
8.6 General .......................................................11
8.7 Statistics......................................................12
9. MAKING COFFEE....................................... 12
9.1 Adjusting the coee mill.............................12
9.2 Tips for a hotter coee.................................13
9.3 Making automatic recipes using coee beans.
13
9.4 Temporarily varying the coee aroma.........13
9.5 Making coee using pre-ground coee.......14
10. MAKING CAPPUCCINO AND HOT MILK NOT
FROTHED ............................................... 14
10.1 Making hot milk (not frothed).....................15
10.2 Cleaning the cappuccino maker after use....15
11. PROGRAMMING AND SELECTING............... 15
12. DELIVERING HOT WATER .......................... 15
13. CLEANING................................................ 16
13.1 Cleaning the machine .................................16
13.2 Cleaning the machine's internal circuit .......16
13.3 Cleaning the coee grounds container........16
13.4 Cleaning the drip tray and condensate tray.16
13.5 Cleaning the inside of the coee machine...16
13.6 Cleaning the water tank..............................16
13.7 Cleaning the coee spouts ..........................17
13.8 Cleaning the pre-ground coee funnel .......17
13.9 Cleaning the infuser....................................17
14. DESCALING.............................................. 17
15. SETTING WATER HARDNESS...................... 18
15.1 Measuring water hardness..........................18
15.2 Setting water hardness...............................18
16. WATER SOFTENER FILTER ......................... 18
16.1 Installing the lter ......................................18
16.2 Replacing the lter......................................19
16.3 Removing the lter .....................................19
17. TECHNICAL DATA...................................... 19
19. DISPLAYED MESSAGES.............................. 20
18. DISPOSING OF THE APPLIANCE ................. 20
20. TROUBLESHOOTING ................................. 22
21. ELECTRICAL REQUIREMENTS..................... 23

7
1. FUNDAMENTAL SAFETY WARNINGS
• The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Cleaning and user maintenance shall not be made by children without supervision.
• Never clean by immersing the appliance in water.
• This is an household appliance only. It is not intended to be used in: sta kitchen
areas in shops, oces and other working environments; farm houses; by clients in
hotels, motels and other residential type environments; bed and breakfast type
environments.
• If the plug or cord is damaged, it must be replaced by Customer Services only to avoid
all risk.
FOR EUROPEAN MARKETS ONLY:
• This appliance can be used by children aged from 8 years and above if they have been
given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. User cleaning and maintenance shall not be made
by children unless they are above 8 years old and supervised. Keep the appliance and
power cord away from children under 8 years of age.
• Appliances can be used by persons with reduced physical, sensory or mental capabil-
ities or lack of experience and knowledge if they are supervised or have been given
instruction concerning use of the appliance in a safe way and if they understand the
hazards involved.
• Children shall not play with the appliance.
• Always unplug the appliance when left unattended and before assembly, taking apart
or cleaning.
Surfaces marked with this symbol become hot during use (the symbol is present in
certain models only).

8
2. SAFETY WARNINGS
2.1 Symbols used in these instructions
Important warnings are identied by these symbols. It is vital to
respect these warnings.
Danger!
Failure to observe the warning may result in life threatening
injury by electric shock.
Important!
Failure to observe the warning could result in injury or damage
to the appliance.
Danger of burns!
Failure to observe the warning could result in scalds or burns.
Please note:
This symbol identies important advice or information for the
user.
Danger!
This is an electrical appliance and may cause electric shock.
You should therefore follow these safety warnings:
• Never touch the appliance with damp hands or feet.
• Never touch the plug with damp hands.
• Make sure the socket used is freely accessible at all times,
enabling the appliance to be unplugged when necessary.
• Unplug directly from the plug only. Never pull the cord as
you could damage it.
• To disconnect the appliance completely you must unplug it
from the mains socket.
• If the appliance is faulty, do not attempt to repair.
Turn it o, unplug from the mains socket and contact Cus-
tomer Services.
• Before cleaning the appliance, turn it o, unplug from the
mains socket and allow to cool.
Important:
Keep all packaging (plastic bags, polystyrene foam) away from
children.
Danger of burns!
This appliance produces hot water and steam may form while
it is in operation.
Avoid contact with splashes of water or hot steam.
When the appliance is in operation, the cup shelf could become
very hot.
2.2 Designated use
This appliance is designed and made to prepare coee and heat
beverages.
Any other use is considered improper and thus dangerous. The
manufacturer is not liable for damage deriving from improper
use of the appliance.
2.3 Instruction for Use
Read this Instruction for Use carefully before using the appli-
ance. Failure to follow this Instruction for Use may result in
burns or damage to the appliance.
The manufacturer is not liable for damage deriving from failure
to respect this Instruction for Use.
Please note:
Keep these instructions for future use. If the appliance is passed
to other persons, they must also be provided with this Instruc-
tion for Use.
3. INTRODUCTION
Thank you for choosing this bean to cup espresso and cappuc-
cino machine.
We hope you enjoy using your new appliance. Take a few min-
utes to read this Instruction for Use. This will avoid all risks and
damage to the appliance.
3.1 Letters in brackets
The letters in brackets refer to the legend in the description of
the appliance on pages 2-3.
3.2 Troubleshooting and repairs
In the event of problems, rst try and resolve them by reading
the information given in sections“19. Displayed messages”and
“20. Troubleshooting”.
If this does not resolve the problem or you require further in-
formation, you should consult Customer Services by calling the
number given on the annexed "Customer Service" sheet.
If your country is not among those listed on the sheet, call the
number given in the guarantee. If repairs are required, contact
De’Longhi Customer Services only. The addresses are given in
the guarantee certicate provided with the machine.

9
4. DESCRIPTION
4.1 Description of the appliance
(page 3 - A)
A1. Beans container lid
A2. Pre-ground coee funnel lid
A3. Beans container
A4. Pre-ground coee funnel
A5. Grinding adjustment dial
A6. Main switch
A7. Infuser door
A8. Infuser
A9. Power cord
A10. Condensate tray
A11. Coee grounds container
A12. Cup tray
A13. Drip tray water level indicator
A14. Drip tray grille
A15. Drip tray
A16. Water tank lid
A17. Water tank
A18. Water softener lter housing
A19. Coee spouts (adjustable height)
A20. Cappuccino maker
A21. Cappuccino maker selection ring
A22. Hot water and steam connection nozzle
A23. button: turns the appliance on and o (standby)
A24. Cup shelf
Description of the touch screen
(page 2 - B )
A number of icons on the touch screen have a double function. This
is indicated in brackets in the description.
B1. Display: guides the user in using the appliance.The current
selection is at the centre between two dotted lines.
B2. ▼Selection arrow (“ESC”: when programming beverages,
press to exit without saving the change)
B3. OK: to conrm the selection(During the rst few seconds of
"espresso", "ristretto" or "espresso lungo" delivery, press for 2
cups)
B4. ▲Selection arrow (“STOP” - When delivering/program-
ming beverages, press to interrupt/programme)
B5. /ESC: appliance settings menu
(When in the settings menu, it acts as the "ESC" to exit from
the selected function and go back to the main menu)
B6. : hot water
B7. : aroma selection
Directly selected beverages:
B8. : Espresso
B9. : Coee
B10. : Long
B11. : Doppio+
B12. : Beverage selection menu (other than direct-
ly selected beverages): Espresso Lungo, Ristretto, Steam, 2
Espresso, 2 Espresso Lungo, 2 Ristretto.
B13. : My beverages selection menu. Unless previous-
ly programmed from the settings menu (“8.5 Program My
beverages”), the beverage is programmed directly the rst
time you use the appliance.
4.2 Description of the accessories
(page 2 - C )
C1. Indicator paper
C2. Pre-ground coee measure
C3. Descaler
C4. Water softener lter (certain models only)
5. BEFORE USE
5.1 Checking the appliance
After removing the packaging, make sure the product is com-
plete and undamaged and that all accessories (C) are pres-
ent. Do not use the appliance if it is visibly damaged. Contact
De’Longhi Customer Services.
5.2 Installing the appliance
Important!
When you install the appliance, you should respect the follow-
ing safety warnings:
• The appliance gives o heat. After positioning the appli-
ance on the worktop, leave a space of at least 3 cm be-
tween the surfaces of the appliance and the side and rear
walls and at least 15 cm above the coee maker.
• Water penetrating the coee machine could cause
damage.
Do not place the appliance near taps or sinks.
• The appliance could be damaged if the water it contains
freezes.
Do not install the appliance in a room where the tempera-
ture could drop below freezing point.
• Arrange the cord (A9) in such a way that it cannot be dam-
aged by sharp edges or contact with hot surfaces (e.g. elec-
tric hot plates).
5.3 Connecting the appliance
Important!
Check that the mains power supply voltage corresponds to that
indicated on the rating plate on the bottom of the appliance.
Connect the appliance to an eciently earthed and correctly
installed socket with a minimum current rating of 10A only.

10
If the power socket does not match the plug on the appliance,
have the socket replaced with a suitable type by a qualied
professional.
5.4 Setting up the appliance
Please note:
• Coee has been used to factory test the appliance and it is
therefore completely normal for there to be traces of cof-
fee in the mill. The machine is, however, guaranteed to be
new.
You should customise water hardness as soon as possible follow-
ing the instructions in section“15. Setting water hardness”.
1. Connect the appliance to the mains electricity supply (g.
1) and make sure the main switch (A6) at the back of the
appliance is pressed down (g. 1) ;
2. "Language": press the selection arrow (B2) until the re-
quired language is displayed between the two dotted
lines, then press OK (B3) to conrm.
Then follow the instructions indicated on the appliance display
(B1):
3. “Fill tank”: remove the water tank (A17 - g. 2), ll to the
MAX line with fresh water (g. 3A), then replace in the ap-
pliance (g. 3B);
4. Place a container with a minimum capacity of 100 ml (g.
4) under the cappuccino maker (A20);
5. "Water circuit empty, Fill water circuit, Hot water,
Conrm?";
6. Press OK to conrm. The appliance delivers water from the
cappuccino maker then goes o automatically.
The coee machine is now ready for normal use.
Please note:
• The rst time you use the appliance, you need to make 4-5
cups of coee before it starts to give satisfactory results.
• To enjoy your coee even more and improve the perfor-
mance of your appliance, we recommend installing a
water softener lter (C4) as described in section“16. Water
softener lter”. If your model is not provided with a lter,
you can request one from De'Longhi Customer Services.
6. TURNING THE APPLIANCE ON
Please note:
Before turning the appliance on, make sure the main switch
(A6) on the back of the appliance is pressed (g. 1).
Each time the appliance is turned on, it performs an automatic
preheat and rinse cycle which cannot be interrupted.The appli-
ance is ready for use only after completion of this cycle.
Danger of burns!
During rinsing, a little hot water comes out of the coee spouts
(A19) and is collected in the drip tray (A15) underneath. Avoid
contact with splashes of water.
• To turn the appliance on, press the button (A23) (g.
5). The message "Heating Please wait" appears on the dis-
play (B1).
After heating, the message "Rinsing" is displayed, together with
a progress bar which gradually lls as preparation proceeds. As
well as heating the boiler, the appliance also heats the internal
circuits by circulating hot water.
The appliance is at temperature when the message "Select your
beverage" is displayed.
7. TURNING THE APPLIANCE OFF
Whenever the coee machine is turned o after being used to
make coee, it performs an automatic rinse cycle.
Danger of burns!
During rinsing, a little hot water ows from the coee spouts
(A19). Avoid contact with splashes of water.
• To turn the appliance o, press the button (A23 - g.
5);
• The message "Turning o underway Please wait" appears
on the display (B1), then (if provided for) the appliance
performs a rinse cycle and goes o (standby).
Please note!
If you will not be using the appliance for some time, unplug
from the mains socket:
• rst turn the appliance o by pressing the button
(g. 5);
• release the main switch (A6) (g. 1).
Important!
Never press the main switch while the appliance is on.
8. MENU SETTINGS
The menu has 6 items, some divided into subgroups:
• Rinsing;
• Language;
• Maintenance:
- Descale,
- Install lter,
- (if a lter has been installed): Replace lter,
- (if a lter has been installed): Remove lter;
• Prg. beverages;
• Prg. My beverages;
• General:
- Set temperature,
- Water hardness,
- Auto-o,

11
- Energy saving,
- Beep,
- Default beverages,
- Default values;
• Statistics.
8.1 Rinsing
Use this function to deliver hot water from the coee spouts
(A19) to clean and heat the appliance’s internal circuit.
Place a container with a minimum capacity of 100ml under the
coee spouts.
Important! Danger of burns.
Do not leave the appliance unattended while hot water is being
delivered.
To perform a rinse, proceed as follows:
1. Press (B5) to enter the "Settings" menu;
2. Press OK B3 to conrm "Rinsing";
3. After a few seconds, hot water is delivered from the coee
spouts to clean and heat the appliance’s internal circuit. A
progress bar is displayed and lls gradually as preparation
proceeds;
4. To interrupt, press the arrow corresponding to "STOP" (B4).
Please note!
• If the appliance is not used for more than 3-4 days, when
switched on again, we strongly recommend performing
2/3 rinses before use;
• After cleaning, it is normal for the coee grounds container
(A11) to contain water.
8.2 Language
To modify the language of the display (B1), proceed as follows:
1. Press (B5) to enter the "Settings" menu;
2. Press the selection arrows (B2 and B4) until "Language" is
displayed between the two dotted lines;
3. Press OK (B3).The available languages are displayed;
4. Press the selection arrows until the required language is
displayed between the two dotted lines;
5. Press OK to conrm;
6. The appliance goes back to the "Settings" menu;
7. Press /ESC to exit the menu.
8.3 Maintenance
Here you can nd all the maintenance operations required by
the appliance over time:
• Descale: For instructions on descaling, see section “14.
Descaling”.
• Install lter: For instructions on how to install the lter
(C4), see section“16.1 Installing the lter”.
To select the operation you require, proceed as follows:
1. Press (B5) to enter the "Settings" menu;
2. Press the selection arrows (B2 and B4) until "Maintenance"
is displayed between the two dotted lines;
3. Press OK B3 to conrm;
4. Press the selection arrows to display the operation to be
performed;
5. Press OK to conrm and perform the operations as de-
scribed in the corresponding sections.
8.4 Program beverages
The appliance is set by default to automatically deliver stand-
ard quantities. To change these quantities and customise the
directly selected beverages and (B12), proceed as
follows:
1. Press (B5) to enter the "Settings" menu;
2. Press the selection arrows (B2 and B4) until "Prg. beverag-
es" is displayed between the two dotted lines;
3. Press OK (B3) to conrm: the appliance lists the beverages
you can customise;
4. Press the selection arrows until the beverage you want to
customise is displayed, then press OK to conrm;
5. Beverages with coee: "Program aroma" appears on
the display: press the selection arrows (B2 and B4) or
(B7) until the required aroma is selected (see section “9.4
Temporarily varying the coee aroma”), then press OK.
"Program coee" appears on the display together with a
bar which gradually lls as delivery progresses. When the
required quantity is reached, press OK;
Hot water: press OK. Delivery begins: press OK when the
required quantity is reached.
6. "Save parameters?": to save the settings, press OK (other-
wise press /ESC - B2 or B5).
7. "Parameters saved" (or "Parameters not saved"). The ap-
pliance is ready for use again.
8.5 Program My beverages
Follow the procedures described in the previous section“8.4 Pro-
gram beverages”to customise the beverages in the "
" (B13) or proceed with direct programming, as described in
section“11. Programming and selecting”.
8.6 General
Here you can nd the settings to customise the basic functions
of the appliance:
1. Press (B5) to enter the "Settings" menu;
2. Press the selection arrows (B2 and B4) until "General" is
displayed between the two dotted lines;

12
3. Press OK (B3) to conrm and select the required item with
the selection arrows. Then follow the instructions for each
setting.
• Set temperature:
To modify the temperature of the water used to make the coee,
proceed as follows:
4. Press OK (B3). The current value appears on the display
(B1) and the "New" value ashes;
5. Select the new value you want to set using the selection
arrows (B2 or B4);
6. When the required value (low, medium, high, maximum)
has been selected, press OK.
The display goes back to the previous screen.
• Water hardness:
For instructions on identifying and setting water hardness, see
section“15. Setting water hardness”.
• Auto-o (standby):
Auto-o can be set so that the appliance goes o after 15 or 30
minutes, or 1, 2 or 3 hours
4. Press OK.The current value appears on the display (B1) and
the "New" value ashes;
5. Select the new value you want to set using the selection
arrows (B2 or B4);
6. When the required time has been selected, press OK.
The display goes back to the previous screen.
• Energy saving:
Use this function to enable or disable energy saving. When en-
abled, the function reduces energy consumption in compliance
with European regulations.
To disable or enable "Energy Saving", proceed as follows:
4. Press OK. The current state ("Enabled" or "Disabled") and
the operation to be performed ("Disable?" or "Enable?") is
displayed. Press OK to conrm;
5. Press OK to disable or enable the function.
The display goes back to the previous screen.
Please note!
• when the function is enabled, the "ECO" symbol appears
on the display.
• When in energy saving mode, a few seconds elapse before
the rst coee, cappuccino or milk-based coee is deliv-
ered as the appliance must heat up again.
• Beep:
Use this function to enable or disable the beep. Proceed as
follows:
4. Press OK. The current state ("Enabled" or "Disabled") and
the operation to be performed ("Disable?" or "Enable?") is
displayed. Press OK to conrm;
5. Press OK to disable or enable the function.
The display goes back to the previous screen.
• Default beverages:
Use this function to reset the default values for all the beverag-
es, or the individual beverages programmed previously. Select
the beverage, then proceed as follows:
4. Select "All" to reset the aroma and quantity settings to the
default values, or select the required beverage, then press
OK;
5. "Reset?": to reset the default values, press OK.
6. "Reset complete": the appliance conrms the reset and
goes back to the previous screen.
To reset another beverage, repeat from point 4 or to exit, press
/ESC (B5).
• Default values:
Use this function to reset all the appliance and beverage set-
tings (apart from the language which remains as selected the
rst time the appliance was used). Select the item, then proceed
as follows:
4. "Reset?"; press OK;
5. "Reset complete": the appliance conrms the reset and
goes back to the previous screen.
To exit, press /ESC (B5).
8.7 Statistics
This displays statistics relating to the machine. To display the
statistics, proceed as follows:
1. Press (B5) to enter the "Settings" menu;
2. Press the selection arrows (B2 and B4) until "Statistics" is
displayed between the two dotted lines;
3. Press OK (B3): statistics on the appliance are displayed, use
the selection arrows to scroll through the items;
4. Then press /ESC (B5) to exit.
To go back to the main screen, press /ESC.
9. MAKING COFFEE
9.1 Adjusting the coee mill
The coee mill is set by default to prepare coee correctly and
should not require regulating initially.
However, if after making the rst few coees you nd that the
coee is either too weak and not creamy enough or delivery is
too slow (a drop at a time), this can be corrected by calibrating
the coee grinding using the adjustment dial (A5) (g. 6).
Please note:
The grinding adjustment dial must only be turned when the
coee mill is in operation.

13
If the coee is delivered too slowly or not
at all, turn one click clockwise towards 7.
For fuller bodied creamier coee, turn
one click anticlockwise towards 1 (do not
turn more than one click at a time other-
wise the coee could be delivered a drop
at a time).
These adjustments will only be evident after at least 2 cups of
coee have been delivered. If this adjustment does not obtain
the desired result, turn the dial another click.
9.2 Tips for a hotter coee
For hotter coee, you should:
• perform a rinse cycle by pressing /ESC (B15);
• warm the cups with hot water using the hot water function
(see section“12. Delivering hot water”);
• increase the coee temperature in the "Settings" menu
(see section“8.6 General”).
9.3 Making automatic recipes using coee
beans
Important!
Do not use green, caramelised or candied coee beans as they
could stick to the coee mill and make it unusable.
1. Fill the container (A3) (g. 7) with coee beans;
2. Place under the coee spouts (A19):
- 1 cup, if you want to make 1 coee (g. 8);
- 2 cups if you want 2 coees.
3. Lower the spouts as near as possible to the cup. This makes
a creamier coee (g. 9);
4. Then select your required coee:
Directly selected beverages
Recipe Quantity Program-
mable
quantity
Default
aroma
Espresso (B8)
≃ 40 ml from ≃30
to
≃ 80ml
+
Coee (B9)
≃ 180 ml from ≃100
a ≃240ml
+
Long (B10)
≃ 160 ml from ≃115
to ≃250ml
+
Doppio+
(B11)
≃ 120 ml from ≃80
to ≃180ml +
Beverages with coee selectable from the
(B12)
Espresso
Lungo
≃ 120 ml from ≃80
to ≃180ml
+
Ristretto ≃ 30 ml from ≃20
to ≃40ml
+
2 Espresso ≃ 40 ml x
2 cups
--
+
2 Espresso
Lungo
≃ 120 ml
x 2 cups
--
+
2 Ristretto ≃ 30 ml x
2 cups
--
+
5. Preparation begins. A progress bar appears on the display
(B1) and gradually lls as preparation proceeds.
Please note:
• You can prepare 2 cups of RISTRETTO, ESPRESSO or ESPRESSO
LUNGO coee at the same time by pressing "2X" (B3) dur-
ing preparation of single beverages (the image is displayed
for a few seconds at the start of preparation).
• While the machine is making coee, delivery can be inter-
rupted at any time by pressing the selection arrow corre-
sponding to "STOP" (B4).
• At the end of delivery, to increase the quantity of coee in
the cup, just press and hold (within 3 seconds) one of the
coee icons (B8 to B11).
Once the coee has been made, the appliance is ready to make
the next beverage.
Please note:
• Various alarm messages could be displayed while using the
appliance (ll tank, empty grounds container, etc.). Their
meaning is explained in section“19. Displayed messages”.
• For hotter coee, see section“9.2Tips for a hotter coee”.
• If the coee is delivered a drop at a time, too weak and not
creamy enough or too cold, read the tips in section “20.
Troubleshooting”.
• To customise the beverages according to personal taste,
see sections“8.4 Program beverages”and“8.5 Program My
beverages”.
9.4 Temporarily varying the coee aroma
To temporarily vary the aroma of the coee in the automatic
recipes, press (B7):
+
AUTO Custom (if programmed) /
Standard

14
+
EXTRA LIGHT
+
LIGHT
+
MEDIUM
+
STRONG
+
X-STRONG
(see “9.5 Making coee
using pre-ground coee”)
Please note:
• The variation in aroma is not saved and the next time a
beverage is delivered automatically, the appliance selects
the default value (
+
AUTO).
• If a few seconds elapse between temporary customising of
the aroma and delivery of the beverage, the aroma returns
to the default value (
+
AUTO).
9.5 Making coee using pre-ground coee
Important!
• Never add pre-ground coee when the machine is o or it
could spread through the inside of the machine and dirty
it.This could damage the appliance.
• Never use more than 1 level measure (C2) or it could dirty
the inside of the coee machine or block the funnel (A4).
Please note:
If you use pre-ground coee, you can only make one cup of
coee at a time.
1. Press the icon (B7) repeatedly until " " appears
on the display (B1).
2. Make sure the funnel is not blocked, then add one level
measure of pre-ground coee (g. 10).
3. Place a cup under the coee spouts (A19) (g. 8).
4. Then select your required coee:
Directly selected beverages
Recipe Quantity
Espresso (B8) ≃ 40 ml
Coee (B9) ≃ 180 ml
Long (B10) ≃ 160 ml
Beverages with coee selectable from the
(B12)
Espresso Lungo ≃ 120 ml
Ristretto ≃ 30 ml
5. Preparation begins. The beverage selected appears on the
display together with a progress bar which gradually lls
as preparation proceeds.
Important! Making LONG coee :
Halfway through preparation, the message "Add pre-ground
coee" appears on the display (B1). Add one level measure of
pre-ground coee and press OK (B3).
Please note:
If "Energy Saving" mode is active, you may have to wait a few
seconds before the rst coee is delivered.
10. MAKING CAPPUCCINO AND HOT MILK NOT
FROTHED
Danger of burns!
During preparation steam is given o.Take care to avoid scalds.
1. When preparing cappuccino, make the coee in a large
cup;
2. Fill a container (preferably one with a handle to avoid
scalding) with about 100 grams of milk for each cappucci-
no. In choosing the size of the container, bear in mind that
the milk doubles or triples in volume;
Please note:
For a richer denser froth, use skimmed or partially
skimmed milk at refrigerator temperature (about 5°C). To
avoid milk with poor froth or large bubbles, always clean
the cappuccino maker (A20) as described in section “10.2
Cleaning the cappuccino maker after use”.
3. Make sure the cappuccino maker selection ring (A21) is
positioned downwards in the "CAPPUCCINO" position (g.
11);
4. The cappuccino maker can be turned slightly outwards to
allow containers of any size to be used.
Important!
Never use force to turn the cappuccino maker (g. 12). It
could break!
5. Immerse the cappuccino maker in the milk container.
Never immerse the black ring;
6. Press (B12);
7. Press the selection arrows (B2 and B4) until "Steam" is dis-
played between the two dotted lines;
8. Press OK (B5). "Steam" is displayed. After a few seconds,
steam is delivered from the cappuccino maker, giving

15
the milk a creamy frothy appearance and making it more
voluminous;
9. For a creamier froth, rotate the container with slow move-
ments in an upward direction;
10. When the required temperature is obtained, interrupt
steam delivery by pressing the selection arrow correspond-
ing to "STOP".
Danger of burns!
Stop steam delivery before removing the container with the
frothed milk to avoid burns caused by splashes of boiling milk.
11. Add the milk froth to the coee prepared previously. The
cappuccino is ready. Sweeten to taste and, if desired, sprin-
kle the froth with a little cocoa powder.
Please note!
If“Energy saving”is active, you may have to wait a few seconds
before steam is delivered.
10.1 Making hot milk (not frothed)
To make hot milk without froth, proceed as described in the
above section, but with the cappuccino maker selection ring
(A21) positioned upwards in the "HOT MILK" position.
10.2 Cleaning the cappuccino maker after use
Clean the cappuccino maker (A20) each time you use it to avoid
the build-up of milk residues or blockages.
Danger of burns!
When cleaning the cappuccino maker, a little hot water is deliv-
ered. Avoid contact with splashes of water.
1. Deliver a little water by pressing the icon (B6 - g.13).
To interrupt, press the selection arrow (B4) corresponding
to "STOP".
2. Wait a few minutes for the cappuccino maker to cool down.
Turn the cappuccino maker downwards to remove it (g.
14).
3. Move the selection ring (A21) upwards (g. 15) .
4. Remove the connection nozzle downwards (A22 - g. 16) .
5. Make sure the two holes shown by the arrow in g. 17 are
not blocked. If necessary, clean with a pin.
6. Replace the connection nozzle, move the selection ring
downwards and put the cappuccino maker back on the
nozzle (g. 18) , turning it clockwise and pushing it upwards
until it is attached.
11. “ ”PROGRAMMING AND SELECTING
In you can select beverages customised to your per-
sonal tastes. If the beverages have not yet been programmed,
the appliance will request the customisation procedure before
proceeding with delivery:
1. Press (B13);
2. Press the selection arrows (B2 and B4) until the required
beverage is displayed between the two dotted lines;
Unprogrammed beverages:
3. Press OK (B3) to select;
4. "Program aroma" appears on the display. Press the selec-
tion arrows (B2 and B4) or (B7) until the required
aroma is selected. Press OK. "Program coee" appears on
the display together with a bar which gradually lls as de-
livery progresses. When the required quantity is reached,
press OK.
5. The appliance then makes the coee. Press OK to interrupt
delivery when the required quantity of coee is reached.
6. "Save parameters?": to save the settings, press OK (other-
wise press ESC - B2 or B5).
8. "Parameters saved" (or "Parameters not saved"). The ap-
pliance is ready for use again.
Programmed beverages:
3. Press OK (B3) to select;
4. Preparation begins according to the previously pro-
grammed settings.
Please note:
Two cups of a beverage can only be selected when the corre-
sponding single beverages have been programmed.
12. DELIVERING HOT WATER
Important! Danger of burns.
Never leave the machine unattended while delivering hot water.
The cappuccino maker (A20) becomes hot while water is being
delivered and must be held by the black ring (A21) only.
1. Place a container under the cappuccino maker (A20) (as
close as possible to avoid splashes).
2. Press (B6 - g. 13). "HOT WATER” appears on the dis-
play (B1), together with a progress bar which lls gradual-
ly as preparation proceeds.
4. The machine delivers about 250 ml of hot water, then de-
livery stops automatically. To interrupt hot water delivery
manually, press the selection arrow (B4) corresponding to
"STOP" again.
Please note!
If “Energy Saving” is active, you may have to wait a few seconds
before hot water and steam are delivered.

16
13. CLEANING
13.1 Cleaning the machine
The following parts of the machine must be cleaned regularly:
- the appliance’s internal circuit;
- coee grounds container (A11);
- drip tray (A15) and condensate tray (A10);
- water tank (A17);
- coee spouts (A19);
- pre-ground coee funnel (A4);
- infuser (A8), accessible after opening the infuser door (A7);
- cappuccino maker (A20 - section “10.2 Cleaning the cap-
puccino maker after use”);
- touch screen (B).
Important!
• Do not use solvents, abrasive detergents or alcohol to clean
the coee machine.With De’Longhi superautomatic coee
machines, you need not use chemical products to clean the
machine.
• None of the components of the appliance can be washed in a
dishwasher with the exception of the drip tray grille (A14).
• Do not use metal objects to remove encrustations or coee
deposits as they could scratch metal or plastic surfaces.
13.2 Cleaning the machine's internal circuit
If the appliance is not used for more than 3/4 days, before using
it again, we strongly recommend switching it on and:
- performing 2/3 rinse cycles (see section“8.1 Rinsing”);
- delivering hot water for a few seconds (section “12. Deliv-
ering hot water”).
Please note:
After cleaning, it is normal for the coee grounds container
(A11) to contain water.
13.3 Cleaning the coee grounds container
When "Empty grounds container" appears on the display (B1),
the grounds container must be emptied and cleaned. The ap-
pliance cannot be used to make coee until you have cleaned
the grounds container (A11). Even if not full, the empty grounds
container message appears on the display 72 hours after the
rst coee has been prepared. For the 72 hours to be calculated
correctly, the machine must never be turned o with the main
switch (A6).
Important! Danger of burns
If you make a number of cappuccinos one after the other, the
metal cup tray (A12) becomes hot. Wait for it to cool down be-
fore touching it and handle it from the front only.
To clean (with the machine on):
• Remove the drip tray (A15) (g. 19), empty and clean.
• Empty the grounds container (A11) and clean thoroughly
to remove all residues left on the bottom.
• Check the condensate tray (A10) (red) and empty if
necessary.
13.4 Cleaning the drip tray and condensate tray
Important!
The drip tray (A15) is tted with a level indicator (A13) (red)
showing the level of water it contains (g. 20). Before the in-
dicator protrudes from the cup tray (A12), the drip tray must
be emptied and cleaned otherwise the water may overow the
edge and damage the appliance, the surface it rests on or the
surrounding area.
To remove the drip tray:
1. Remove the drip tray and coee grounds container (A11)
(g. 19);
2. Remove the cup tray (A12) and drip tray grille (A14), then
empty the drip tray and grounds container and wash all
components;
3. Check the red condensate tray (A10) and empty if
necessary;
4. Replace the drip tray complete with grille and grounds
container.
Important!
When removing the drip tray, the grounds container must be
emptied, even if it contains few grounds.
If this is not done, when you make the next coees, the grounds
container may ll up more than expected and clog the machine.
13.5 Cleaning the inside of the coee machine
Danger of electric shock!
Before cleaning internal parts, the machine must be turned o
(see section“7.Turning the appliance o”) and unplugged from
the mains power supply. Never immerse the coee machine in
water.
1. Check regularly (about once a month) that the inside of the
appliance (accessible after removing the drip tray (A15)
is not dirty. If necessary, remove coee deposits with the
brush supplied and a sponge;
2. Remove all the residues with a vacuum cleaner (g. 21).
13.6 Cleaning the water tank
1. Clean the water tank (A17) regularly (about once a month)
and whenever you replace the water softener lter (C4) (if
provided) with a damp cloth and a little mild washing up
liquid;

17
2. Remove the lter (C4) (if present) and rinse with running
water;
3. Replace the lter (if provided), ll the tank with fresh
water and replace the tank;
4. (Models with water softener lter only) Deliver about
100ml of water.
13.7 Cleaning the coee spouts
1. Clean the coee spouts (A19) regularly with a sponge or
cloth (g. 22A);
2. Check that the holes in the coee spouts are not blocked.
If necessary, remove coee deposits with a toothpick (g.
22B).
13.8 Cleaning the pre-ground coee funnel
Check regularly (about once a month) that the pre-ground
coee funnel (A4) is not blocked. If necessary, remove coee
deposits with a brush.
13.9 Cleaning the infuser
The infuser (A8) must be cleaned at least once a month.
Important!
The infuser may not be extracted when the machine is on.
1. Make sure the machine is correctly turned o (see section
“7. Turning the appliance o”);
2. Remove the water tank (A17);
3. Open the infuser door (A7) (g. 23) on the right side of the
appliance;
4. Press the two coloured release buttons inwards and at the
same time pull the infuser outwards (g. 24);
5. Soak the infuser in water for about 5 minutes, then rinse
under the tap;
Important!
RINSE WITH WATER ONLY
NO WASHING UP LIQUID  NO DISH WASHER
Clean the infuser without using washing up liquid as it
could be damaged.
6. Use the brush to remove any coee residues left in the in-
fuser housing, visible through the infuser door;
7. After cleaning, replace the infuser by sliding it onto the in-
ternal support, then push the PUSH symbol fully in until it
clicks into place;
Please note:
If the infuser is dicult to insert, before insertion, adapt it to the
right size by pressing the two levers (g. 25).
8. Once inserted, make sure the two coloured buttons have
snapped out;
9. Close the infuser door;
10. Put the water tank back.
14. DESCALING
Important!
• Before use, read the instructions and the labelling on the
descaler pack.
• You should use De’Longhi descaler only. Using unsuitable
descaler and/or performing descaling incorrectly may re-
sult in faults not covered by the manufacturer's guarantee.
Descale the machine when "Descale, ESC to cancel, OK to des-
cale (∼45 minutes)" appears on the display (B1).To descale im-
mediately, press OK (B3) and follow the instructions from point
6. To descale the appliance later, press ESC (B5). The symbol
on the display reminds you that the appliance needs descaling.
To access the descaling menu:
1. Turn the appliance on and wait until it is ready for use;
2. Press (B5) to enter the "Settings" menu;
3. Press the selection arrows (B2 and B4) until "Maintenance"
is displayed between the two dotted lines. Press OK (B3);
4. Press OK to select "Descale";
5. Conrm? (∼45 minutes)”. Press OK to conrm;
6. "Remove lter": extract the water tank (A17), remove the
water softener lter (C4) (if present) and empty the water
tank. Press OK;
7. "Pour descaler and water into tank": Pour the descaler into
the tank up to level A (corresponding to a 100ml pack)
marked on the inner surface of the tank, then add water
(one litre) up to level B(g. 26) and put the water tank
back. Press OK;
8. "Empty drip tray": Remove, empty and replace the drip
tray (A15) and grounds container (A11). Press OK;
Please note:
In certain cases, a cooling process lasting several seconds may
take place before moving on to the next point.
9. "Place 1.8L container empty under spouts": Place an empty
container with a minimum capacity of 1.8 litres under the
cappuccino maker (A20) and coee spouts (A19) (g. 27).
Press OK;
Important! Danger of burns
Hot water containing acid ows out of the coee spouts and
hot water spout. Take care to avoid contact with splashes of this
solution.
10. "Descaling underway": The descale programme starts and
the descaler liquid comes out of the cappuccino maker and

18
The descale message is displayed after a period of time estab-
lished according to water hardness.
The machine is set by default for a hardness level of 4. The ma-
chine can also be programmed according to the hardness of the
mains water in the various regions so that the machine needs to
be descaled less often.
15.1 Measuring water hardness
1. Remove the "TOTAL HARDNESS TEST" indicator paper (C1)
from its pack (attached to the English instructions);
2. Immerse the paper completely in a glass of water for one
second;
3. Remove the paper from the water and shake lightly. After
about a minute, 1, 2, 3, or 4 red squares form, depending
on the hardness of the water. Each square corresponds to 1
level;
15.2 Setting water hardness
1. Press (B5) to enter the "Settings" menu;
2. Press the selection arrows (B2 and B4) until "General" is
displayed between the two dotted lines. Press OK (B3;
3. Press the selection arrows until "Water hardness" is dis-
played, then press OK;
4. The current selection appears on the display and the new
selection ashes. Press the selection arrows until the re-
quired new selection is displayed. Press OK.
The new level is saved and the appliance goes back to the "Gen-
eral" menu.
Press /ESC (B5) twice to go back to the main screen.
16. WATER SOFTENER FILTER
Certain models are tted with a water softener lter (C4). If this
is not the case with your model, you are recommended to pur-
chase one from De’Longhi Customer Services.
To use the lter correctly, follow the instructions below.
16.1 Installing the lter
1. Remove the lter (C4) from the packaging.The date indica-
tor disk varies according to the lter provided.
2. Turn the date indicator disk (g. 28) until the next 2
months of use are displayed.
coee spouts. A series of rinses and pauses is performed
automatically to remove all the scale residues inside the
coee machine;
After about 35 minutes, descaling stops;
11. "Rinse tank and ll with water": the appliance is now
ready to rinse with fresh water. Empty the container used
to collect the descaler solution. Extract the water tank,
empty, rinse under running water, ll with fresh water up
to the MAX level and put back in the appliance. Press OK;
12. "Place 1.8L container empty under spouts": place the con-
tainer used to collect the descaler solution empty under
the coee spouts and hot water spout (g. 27) and press
OK";
13. "Rinsing Conrm?": press OK;
14. "Rinsing underway": hot water is delivered rst from the
coee spouts, then from the cappuccino maker;
15. When the water in the tank has run out, empty the con-
tainer used to collect the rinsing water;
16. "Rinse tank and ll with water": extract the water tank and
ll with fresh water up to the MAX level. Press OK;
14. "Insert lter": put the water softener lter (if removed)
back in its housing in the water tank, and replace the tank
in the appliance. Press OK;
15. "Place 1.8L container empty under spouts": Place the con-
tainer used to collect the descaler solution empty under
the cappuccino maker. Press OK;
16. "Rinsing Conrm?": press OK.
17. "Rinsing underway". Hot water comes out of the cappucci-
no maker;
18. "Empty drip tray": At the end of the second rinse, remove,
empty and replace the drip tray (A15) and grounds con-
tainer (A11). Press OK;
19. "Descale complete": press OK;
20. "Fill tank": empty the container used to collect the rinse
water, remove the water tank and ll with fresh water up
to the MAX level, then put back in the appliance.
Descaling is complete.
Please note!
• If the descaling cycle is not completed correctly (e.g. no
electricity) we recommend repeating the cycle;
• After descaling, it is normal for the grounds container
(A11) to contain water;
• If the water tank has not been lled to the MAX level, at
the end of descaling, the appliance requests a third rinse to
guarantee that the descaler solution has been completely
eliminated from the machine's internal circuits.
15. SETTING WATER HARDNESS
soft water (level 1)
hard water (level 3)
very hard water (level 4)
slightly hard water (level 2)

19
Please note
The lter lasts about two months if the appliance is used nor-
mally. If the coee machine is left unused with the lter in-
stalled, it will last a maximum of 3 weeks.
3. To activate the lter, run tap water through the hole in the
lter as shown in g. 29 until water comes out of the open-
ings at the side for more than a minute.;
4. Extract the tank (A17) from the appliance and ll with
water;
5. Insert the lter in the water tank and immerse it complete-
ly for about ten seconds, sloping it and pressing it lightly to
enable the air bubbles to escape (g. 30).
6. Insert the lter in the lter housing (A18) and press as far
as it will go (g. 31);
7. Close the tank with the lid (A16 - g. 32), then replace the
tank in the machine;
When you install the lter, you must notify the appliance of its
presence.
8. Press (B5) to enter the "Settings" menu;
9. Press the selection arrows (B2 and B4) until "Maintenance"
is displayed between the two dotted lines. Press OK (B3);
10. Press the selection arrows until "Install lter" is displayed,
then press OK;
11. Conrm?": press OK;
12. "Hot water, Conrm?": Position a container under the cap-
puccino maker (A20) (min. capacity: 500ml), then press
OK;
13. The appliance begins hot water delivery and the message
"Please wait" is displayed;
14. After the ow of hot water stops, the appliance automati-
cally resets to "Ready for coee" status.
The lter is now active and you can use the coee machine.
16.2 Replacing the lter
Replace the lter (C4) when "Replace lter, ESC to cancel, OK to
replace" appears on the display (B1). To replace immediately,
press OK (B3) and follow the instructions from point 7. To re-
place later, press /ESC (B5). The symbol on the display
reminds you that the lter needs replacing.
To replace the lter, proceed as follows:
1. Extract the tank (A17) and exhausted lter;
2. Take the new lter out of its packet and proceed as illus-
trated in points 2, 3, 4, 5, 6 and 7 in the previous section;
3. Press (B5) to enter the "Settings" menu;
4. Press the selection arrows (B2 and B4) until "Maintenance"
is displayed between the two dotted lines. Press OK;
5. Press the selection arrows until "Replace lter" is dis-
played, then press OK;
6. Conrm?": press OK;
7. "Hot water, Conrm?": Position a container under the cap-
puccino maker (A20) (min. capacity: 500ml), then press
OK;
8. The appliance begins hot water delivery and the message
"Please wait" is displayed;
9. After the ow of hot water stops, the appliance automati-
cally resets to "Ready for coee" status.
The new lter is now active and you can use the coee machine.
Please note!
After two months (see date indicator) or when the appliance has
not been used for 3 weeks, you should replace the lter even if
the message has not yet been displayed.
16.3 Removing the lter
If you want to use the appliance without the lter (C4), you
must remove it and notify the appliance of its removal. Proceed
as follows:
1. Extract the tank (A17) and exhausted lter;
2. Press (B5) to enter the "Settings" menu;
3. Press the selection arrows (B2 and B4) until "Maintenance"
is displayed between the two dotted lines. Press OK (B3);
4. Press the selection arrows until "Remove lter" is dis-
played, then press OK;
5. "Conrm?": press OK to conrm removal. The appliance
goes back to the "Maintenance" menu;
Press /ESC (B5) to exit the menu.
Please note!
After two months (see date indicator) or when the appliance has
not been used for 3 weeks, you should replace the lter even if
the message has not yet been displayed.
17. TECHNICAL DATA
Voltage: 220-240 V~ 50/60 Hz max. 10A
Absorbed power: 1450W
Pressure: 1.5MPa (15 bars)
Max. water tank capacity: 1.8 L
Size LxDxH: 240x440x360 mm
Cord length: 1150 mm
Weight: 9.3 kg
Max. beans container capacity: 300 g
This appliance conforms to EC Regulation 1935/2004
on materials and articles intended to come into contact
with food.
18. DISPOSING OF THE APPLIANCE
The appliance must not be disposed of with house-
hold waste, but taken to an authorised waste separa-
tion and recycling centre.
