DABBSSON DBS1300 User manual

Dabbsson DBS1300
User Manual

DISCLAIMER
Read all safety tips, warning messages, terms of use, and disclaimers carefully. Refer to the
terms of use and disclaimer at https://www.dabbsson.com and stickers on the product
before use. Users take full responsibility for all usage and operations. Familiarize yourself
with the related regulations in your area. You are solely responsible for being aware of all
relevant regulations and using Dabbsson products in a way that is compliant.

CONTENTS
AC Charging
Solar Charging
Car Charging
Using Smart Extra Battery
3.2 LCD Screen
AC oulets
DC outlets
P-Boost and EPS
4.1 Charging DBS1300 6
4.2 Control the product 12
4.3 Charging Your Devices 13
2.1 Usage
1
1. Specifications
2
2. Safety Instructions
4
3. Product Details
6
4. General Product Usage
25
6. FAQS
16
5. App Control
26
7. Troubleshooting
27
8. What’s in the Box
27
9. Storage & Maintenance
28
10. Fcc Statement
3.1 Over View
2.2 Disposal Guide
5
2
4
3
4.4 Parallel Connection Function 14

Net Weight
Capacity
BT
AC (x4)
Parallel(x1) Pure Sine Wave, 1200 Wtotal, 100-120V~ (50/60Hz)
USB-A Fast Charge (x1)
USB-C (x1)
USB-C (x2)
Car Charger
DC5521 Output (x2)
AC Charge
AC Input Voltage
Solar (Car) Charger Input：
Battery Info
Cycle Life
Cell Chemistry
1. Specifications
General Info
Dimensions
Wi-Fi
Output Ports
USB-A (x2)
Input Ports
Approximately 16.5kg (36.4lbs)
1330Wh (25.6V 52Ah)
Supports BDR+EDR: 2402-2480MHz with a maximum of 2.5 dBm
Certification ETL FCC WEEE ROHS CA65
5V 3.0A 9V 2A 12V 1.5A, 18W Max
5/9V 3A 12V 2.5A 15V 2A 20V 1.5A 30W Max Per Port, Total 60W
12.6V 10A, 126W Max
12.6V 4A, 50.4W Max Per Port
LED 2W
1000W Max
LiFePO4
100-120V~ 10A, 50/60Hz
12-60V 12A Max, 400W Max (12V/24V Battery,8A)
Add-on Extra Battery DBS1700B*2, Total 3400Wh
4000 Cycles to 80%+Capacity
362x221x275mm (14.25x8.7x10.8in)
Supports 2.4G: 2412-2472MHz with a maximum of 14.9 dBm
5V 2.4A, 12W Max Per Port, Total 12W
5/9/12/15V 3A, 20V 5A 100W Max
1

Over Voltage Protection
Over Temperature Protection
Low Temperature Protection
Overcurrent Protection
Overload Protection
Short Circuit Protection
Low Voltage Protection
Battery Failure Protection
Protection
Discharge Temperature
Charging Temperature
Storage Temperature
Optimal Operating Temperature 20℃~30℃ (68℉~86℉)
0℃~45℃ (32℉~113℉)
1. Do not use the product near a heat source, such as a fire source or a heating furnace.
2. Avoid contact with any liquid. Do not immerse the product in water or get it wet. Do not
use the product in rain or humid environments.
3. Do not use the product in an environment with strong static electricity or magnetic fields.
4. Do not disassemble the product in any way or pierce the product with sharp objects.
5. Avoid using wires or other metal objects that may result in a short circuit.
6. Do not use unofficial components or accessories. If you need to replace any components or
accessories, visit official Dabbsson channels to check for relevant information.
2.1 Usage
2. Safety Instructions
* Whether the product can be charged or discharged depends on the actual temperature of the battery pack.
Environmental Operating Temperature
-10℃~45℃ (14℉~113℉)
-10℃~45℃ (14℉~113℉)
2

2.2 Disposal Guide
1. If conditions permit, make sure that the battery is fully discharged before disposing of it in a
designated battery recycling bin. The product contains batteries with potentially dangerous
chemicals, so it is strictly prohibited to dispose of it in ordinary trash cans. For more details,
please follow the local laws and regulations on battery recycling and disposal.
2. If the battery cannot be fully discharged due to a product failure, do not dispose of the
battery directly in the battery recycling box. In such cases, contact a professional
battery recycling company for further processing.
3. Please dispose of over-discharged batteries that cannot be recharged.
7. It is highly recommended that third-party accessories are purchased from reliable
distributors and that they match your product’s specifications. Dabbsson is not liable for
abnormality, inconvenience, losses or expenses resulting from defective third-party
accessories.
8. When using the product, please strictly follow the operating environment temperature
specified in this user manual. If the temperature is too high, it may result in a fire or
explosion; if the temperature is too low, the product performance may be severely reduced,
or the product may cease to work.
9. Do not forcibly lock the fan during use or place the product in an unventilated or dusty area.
10. Avoid impact, falls, or severe vibrations when using the product. In case of a severe
external impact, turn off the power supply immediately and stop using the product. Ensure
the product is well fastened during transportation to avoid vibrations and impacts.
11. If you accidentally drop the product into water during use, place it in a safe open area, and
stay away from it until it is completely dry. The dried product should not be used again, and
should be properly disposed of according to Section 2.2 below. If the product catches fire,
we recommend that you use the fire extinguishers in the following order: water or water
mist, sand, fire blanket, dry powder, and finally a carbon dioxide fire extinguisher.
12. Use a dry cloth to clean off dirt on the product ports.
13. Rest the product on a flat surface to avoid damage caused by the product falling over.
If the product is overturned and severely damaged, turn it off immediately, place the
battery in an open area, keep it away from combustible matter and people, and dispose of
it in accordance with local laws and regulations.
14. Ensure that the product is kept out of reach of children and pets.
15. DO NOT connect the smart extra battery to another smart extra battery.
3

3.1 Over View
3. Product Details
LCD Screen
1
LED
23
LIGHT ON/OFF
4
USB-A Output Port（x2）
6
USB ON/OFF
Main Power Button
7
Car Port
8
USB-C 30W Output Port（x2）
9
USB-A Fast Charge Output Port
5
DC5521 Output Port
10
12V DC Power Button
11 12
13
IOT Reset Button
AC Charging Input Port
15
Parallel Port
21
19
AC Power Button
18
Extra Battery Port
Solar/Car Charging Input Port
14
Overload Protection
17
AC Output Port（x4）
20
16
USB-C 100W Output Port
* "Device control port" is only used by the manufacturer for upgrading.
* "AC Output Port” Output port styles vary by country or region.
4
20
19
21
18
16
15
14
17
2
1
5
3
4
6
7
8
10
11
12
13
9
*
DEVICE Control Port
*

3.2 LCD Screen
Error Code
a
Low Temperature Warning
b
High Temperature Warning
c
Overload Warning
d
AC Output Frequency
g
e
Connection Failed AC Output
f
Pairing Indicator
s
Output Power
t
DC Output
h
USB-A Output
i
USB-C Output
j
Solar Panel Indicator
l
Extra Battery Indicator
k
Remaining Charge/Discharge Time
m
Input Power
n
Battery Level Indicator
o
Remaining Battery Percentage
p
Fan Indicator
r
Wi-Fi Status
q
t
q
p
o
nrs
m
a
b
c
df
l
j
i
hk
g
e
Press and hold the IOT button for 3 seconds, and the Wi-Fi icon will flash, indicating that the
product is ready for pairing. If the product pairing is completed, the Wi-Fi icon will stay on.
When charging, the icon rotates clockwise. When the battery level of this product at 0%, AC
and DC output will turn off and this icon will start flashing; When the battery level is 100%, this
icon is the full grid state.
Wi-Fi Status
Battery Level Indicator
5

Dabbsson fast charge technology is specifically for AC charging, offering 1000W of max input
power. You can control the charging power through the Dabbsson App. The default max input
power for the AC charging speed is 400W, which can be modified in the Dabbsson app.
In case of unusual situations where the AC input current remains higher than 20A, the charging
input port will initiate a self-protection function, and the Overload Protection Switch on the
product will automatically pop up. After confirming that there is no product failure, you can
press the Overload Protection Switch to resume charging.
AC Charging
4.1 Charging DBS1300
4. General Product Usage
6

Solar Charging
Users can connect solar panels in series as shown in the figure to recharge the product. The
product supports 12-60V DC input, 12A max current, and 400W max charging power.
You can set the charging power range in the Dabbsson App.
Please use the AC Charging Cable included in the package for fast charging. Do not use other
cables to charge. Plug directly into an AC wall outlet and make sure that the wall output
current is more than 10A. Otherwise, control the charging power through the Dabbsson App.
Dabbsson takes no responsibilities for any consequences caused by failures to follow
instructions, including but not limited to charging with other AC charging cables.
7
AC Charging Cable
Fast Charging
1000W Max Input Power
≈2 hrs Full Charge
Connect XT60 Port
100W Solar Panel
Connection with Solar Panel
MC4 Connection

8
Connect XT60 Port
200W Solar Panel
Connection with Solar Panel
MC4 Connection
Connect XT60 Port
200W Solar Panel (x2)
Connection with Solar Panel
MC4 Connection
When charging the product with a Dabbsson solar panel, follow the instructions of this user
manual to avoid damage to the product.
You can fully charge the product with AC+PV total 1400W Max input in 1.7 hours.
AC+PV Charging
400W Max Solar Panel
AC 1000W
MC4 Connection

Users can recharge the product through the Car Outlet. It supports 12V/24V car chargers and
an 8A default charging current.
Only charge using the car charger after you’ve started the car.This prevents the car from failing
to start due to insufficient battery power. In addition, please make sure that the cigarette
lighter of the Car Outlet and the Car Charger Input Cable are in good condition. Dabbsson
takes no responsibilities for any losses or damage caused by failures to follow instructions.
Car Charging
A single DBS1300 can be connected to two DBS1700B extra batteries for added capacity.
Refer to the Extra Battery DBS1700B user manual for detailed instructions.
●DBS1300 can expand the capacity by 1 DBS1700B battery pack to 3030Wh.
●DBS1300 can expand the capacity by 2 DBS1700B battery pack to 4730Wh.
Precautions
1. Turn off both the Extra Battery DBS1700B and DBS1300 before plug or unplug the extra
battery.
2. Before using, make sure both DBS1300 and Extra Battery DBS1700B display the extra
battery icon on their LCD screens.
3. Do not touch the metal terminals of the Extra Battery DBS1700B connector. If the metal
terminals need to be cleaned, gently wipe them with a dry cloth.
Using Extra Battery
9
Car Charging Cable
Car Charging
XT60 Port

4. When the DBS1300 power station and DBS1700B expandable battery are not in use, please
remove the connecting cable.
5. To protect the battery from over-discharging，please unplug the cable when the unit is
fully charged or not in use.
DBS1300 DBS1700B DBS1300 DBS1700B
10
DBS1700B DBS1300 DBS1700B
DBS1700BDBS1700B DBS1300

11

4.2 Control the product
Short press the Main Power Button to start the product, the LCD screen lights up and displays
an icon. It will automatically turn off after the product is idle for 5 Minutes.When the device
senses any load change or operation, the display screen will automatically light up. To turn the
display on or off, briefly press the Main Power Button. To turn off the device, long press the
Main Power Button. The default standby time is 2 hours. The device will automatically shut
down when other power buttons are turned off and no other power source is detected within
2 hours. Standby time of AC and DC can be set via the Dabbsson APP.
Product On, Product Off, LCD Screen On
Short Press to Turn On/Long Press to Turn Off
12

4.3 Charging Your Devices
After turning on the main power button, short press
the 12V DC power button to use the 12V DC output
port. Press the button again will turn it off. When the
12V DC power button is turned on, the product does
not automatically turn off.
P-Boost
With Dabbsson P-Boost technology, the product can power a 1600W Max device while the
rated output power remains 1200W, avoiding operation failure due to overload protection.
P-Boost Tips
1. P-Boost is not available when the AC output is turned on in a recharging state.
2. P-Boost is not applicable for all electrical appliances; it’s incompatible with appliances with
strict voltage requirements and a rated power over 1200W. Appliances with voltage
protection (such as precise instruments) are not supported. P-Boost mode is more suitable
for heating devices. Please conduct your own tests with your devices with P-Boost enabled.
12V DC Output Port
Short Press
12V DC Power Button
AC Output Port
After turning on the main power button, short press
the AC power button to use the AC output port. Press
the button again will turn it off.
When there is no load on the AC output port of this
product, the power will be automatically turned off
after 2 hours. In ECO mode, the AC output load is less
than 5W, the AC switch will be automatically turned off
after 12 hours, and the power will be turned off after 2
hours. In STANDBY mode, you can set the current
output time. When you don’t need it, please turn it off
in time to save power.
Short Press
AC Power Button
13

The product supports EPS. When you connect the grid power to the AC Input Port of the
product through an AC cable, you can power electrical devices through the AC Output Port
(AC power will come from the grid and not the power station in this situation). In case of a
sudden blackout, the product can automatically switch to the battery powered supply mode
within 15ms. As a basic UPS function, this function does not support 0ms switching. Please do
not connect the product to any device that requires 0ms UPS, such as data servers and
workstations. Please test and confirm the compatibility before using the product. We
recommend that you only charge one device at a time and avoid using multiple devices at the
same time to avoid overload protection. Dabbsson takes no responsibilities for any device
failures or data losses caused by failures to follow instructions.(When the AC output load is
greater than the input load, only the battery can be used for power supply. Only when the AC
output load is less than the input load, can it be charged while discharging.)
Emergency Power Supply (EPS)
14
4.4 Parallel Connection Function
DBS1300 supports the parallel function, which can increase the output power and expand the
battery capacity. Using our special junction box and connecting wires, two products can be
connected, and the output power will be increased to 2000W, and the battery capacity will be
expanded to 2660Wh. At the same time, this product also supports parallel operation, two
products are respectively connected to two DBS1700B and powered on
(2*DBS1300+4*DBS1700B), at this time the battery can be expanded to 9460Wh. You can use
this product as a home backup power station in case of a power outage.
Reminder: The parallel junction box and connecting wires need to be purchased separately;
for detailed parameters, please refer to the manual of the parallel box.

15

16
Android iOS
2You can download the app on the App
Store and Google Play by scanning the
QR codes below.
3. Download the Dabbsson APP on the official website: www.dabbsson.com
Download Dabbsson APP
1Search for “Dabbsson” in the APP Store
(for iOS devices) or Google Play (for Android devices)
to download the Dabbsson App.
5.App Control
1Connect the mobile phone to home 2.4G Wi-Fi network, open the DABBSSON APP, select
“+Add Device” or the “+” symbol on the upper right corner of the home page.
Connecting the APP to the product
Method 1: Bluetooth Connection Mode

17
2Tap to open BT authorization dialog box and select allow to turn on BT Service. Allow New Connections.
4After the device is found, select Add.
3Wait for the unit to search nearby device.
