Dacor Discovery EO227 Technical manual

PLANNING
GUIDE
1.3
Specications subject to change without notice. Phone: [phone]www.dacor.com
27 and 30 Inch Wide, Double,
Discovery™Wall Ovens
EO, MOH, MOV
Dedicated Circuit
Required
Total
Connected Load
Approximate
Shipping Weight
240 Vac,
4-wire*, 60 Hz, 50 Amp. 9.25 kW (38.9 Amp.) 415 lbs.
* Two 120 Vac hot (L1 and L2), one neutral, one ground.
PRODUCT DIMENSIONS
G
D
E
F
C
66” (167.6 cm)
Flexible conduit
A
B
1 1/4”
(3.2 cm)
H
Chassis notch
side view
Control panel
front
Top of
chassis
Top of
chassis
Utility
cutout
L
K
J
22 11/16”
(57.6 cm)
WARNING
• Observe all governing codes and ordinances during planning
and installation. Contact your local building department for
further information.
• This appliance must be installed in accordance with the
accompanying installation instructions.
Product tolerances: ±1/16” (±1.6 mm), unless otherwise stated.
Model A B C D E F G H J K L
EO227
27”
(68.6 cm)
51 1/16”
(129.7 cm)
23 3/8”
(59.4 cm)
2 5/16”
(5.9 cm)
7 3/8”
(18.7 cm)
6 3/8”
(16.2 cm)
50 1/2”
(128.3 cm)
25 3/8”
(64.4 cm)
9/16”
(1.4 cm)
1”
(2.5 cm)
1 7/8”
(4.6 cm)
MOH227
MOV227
EO230
30”
(76.2 cm)
28 3/8”
(72.0 cm)
MOH230
MOV230
Document # PG01-002 Revised 10/01/11 Page 1/2

PLANNING
GUIDE
1.4
Specications subject to change without notice. Phone: [phone]www.dacor.com
27 and 30 Inch Wide, Double,
Discovery Wall Ovens
EO, MOH, MOV
NOTES:
1. 24” (61.0 cm) minimum interior cabinet depth.Back of
cabinet may need to be removed.
2. 3/4” (1.9 cm) support platform (flush with cutout).
3. 1/8” (3 mm) minimum clearance from appliance to
adjacent cabinet doors/drawers.
CUTOUT DIMENSIONS
A
B
4“ typical toe kick (shown)
3/4” (1.9 cm)
support platform
Recommended
electrical
location
9 5/8” (24.4 cm)
recommended
(may be altered)
1 ¾“ (4.5 cm) min.
clear to top of
door for heat
exhaust
1“ (2.5 cm) min.
clear to
bottom of
door
C
Model A B C
EO227
50 9/16”
(128.4 cm)
25 1/2”
(64.8 cm)
27”
(68.6 cm)
MOH227
MOV227
EO230
28 1/2”
(72.4 cm)
30”
(76.2 cm)
MOH230
MOV230
Document # PG01-002 Revised 10/01/11 Page 2/2
HANDLE DIMENSIONS - SIDE VIEW
EO - Epicure
®®
MOH/MOV - Millennia
1 1/4”
(3.2 cm)
1 1/4”
(3.2 cm)
3 11/16”
(9.4 cm)
3 5/16”
(8.4 cm)
Cutout tolerances: +1/16” (+1.6 mm), -0, unless otherwise stated.
