Dacor DWD30 Technical manual

 
PLANNING
GUIDE
DWD, ERWD, EWD, IWD, MRWD,
MWDH, MWDV, OWD, RWDV
24”, 27”, 30”, 36” Wide
Warming Drawers
Document # PG02-002 Revised 01/18/12 Page 1/3
Drawer open
Chassis
5/64"
(2 mm)
23 13/16”
(60.5 cm)
23 3/8”
(59.4 cm)
B
C
OVERALL DIMENSIONS - TOP VIEW
(EWD SERIES SHOWN)
A
10 1/8”
(25.7 cm)
DRAWER FACE DIMENSIONS

3 7/16”
(8.7 cm)
EWD
3 1/4”
(8.3 cm)
MWDH, MWDV,
RWDV
1”
(2.5 cm)
3 1/2”
(8.9 cm)
MRWD30B
(only)
All other MRWD
series
ERWDDWD
1 1/8”
(2.9 cm)
1 7/16”
(3.7 cm)
1”
(2.5 cm)
1”
(2.5 cm)
1”
(2.5 cm)
HANDLE DIMENSIONS - SIDE VIEW
CHASSIS DIMENSIONS
10"
(25.4 cm)
9"
(22.9 cm)
1/2" (1.3 cm)
1/2" (1.3 cm)
Chassis without
drawer inserted
Mounting
hole 9 places
40” (101.6 cm)
3-prong 120 Vac
power cord
Product tolerances: ±1/16” (±1.6 mm) unless otherwise stated
WARMING DRAWER OVERALL DIMENSIONS
Model (A) Drawer Face
Width
(B) Chassis Face
Width
(C) Chassis
Width
DWD30 30” (76.2 cm) 29 5/8” (75.2 cm) 28 1/4” (71.8 cm)
ERWD27 27” (68.6 cm) 26 5/8” (67.6 cm) 25 1/4” (64.1 cm)
ERWD30 30” (76.2 cm) 29 5/8” (75.2 cm) 28 1/4” (71.8 cm)
EWD24 24” (61.0 cm) 23 5/8” (60.0 cm) 22 1/4” (56.5 cm)
EWD27 27” (68.6 cm) 26 5/8” (67.6 cm) 25 1/4” (64.1 cm)
EWD30 30” (76.2 cm) 29 5/8” (75.2 cm) 28 1/4” (71.8 cm)
EWD36 36” (91.4 cm) 35 5/8” (90.5 cm) 34 1/4” (87.0 cm)
MRWD27 26 3/4” (67.9 cm) 26 5/8” (67.6 cm) 25 1/4” (64.1 cm)
MRWD30 29 3/4” (75.6 cm) 29 5/8” (75.2 cm) 28 1/4” (71.8 cm)
MWDH27 27” (68.6 cm) 26 5/8” (67.6 cm) 25 1/4” (64.1 cm)
MWDH30 30” (76.2 cm) 29 5/8” (75.2 cm) 28 1/4” (71.8 cm)
MWDV27 27” (68.6 cm) 26 5/8” (67.6 cm) 25 1/4” (64.1 cm)
MWDV30 30” (76.2 cm) 29 5/8” (75.2 cm) 28 1/4” (71.8 cm)
RWDV30 30” (76.2 cm) 29 5/8” (75.2 cm) 28 1/4” (71.8 cm)
Electrical Circuit Required Total Connected Load Minimum Ambient
Operating Temperature
120 Vac, 60 Hz, 15 Amp.
grounded, dedicated circuit
4.0 Amp. @
120 Vac, 60 Hz. 32°F (0°C)

 
PLANNING
GUIDE
DWD, ERWD, EWD, IWD, MRWD,
MWDH, MWDV, OWD, RWDV
24”, 27”, 30”, 36” Wide
Warming Drawers
Document # PG02-002 Revised 01/18/12 Page 2/3
D
A
DRAWER FACE DIMENSIONS

Chassis
Drawer open F
E
5/16”
(8 mm)
B
C
OVERALL DIMENSIONS - IWD/OWD SERIES
TOP VIEW
CHASSIS DIMENSIONS

40" (101.6 cm)
3 prong
120 Vac power cord
Chassis without
drawer installed
Mounting hole,
** = OWD24 mounting holes
** **
** **
9 places
G
Model (A) Dimension
Drawer Face Width
(B) Dimension
Chassis Width
(C) Dimension
Chassis Face
Width
(D)
Dimension
Drawer Face
Height
(E)
Dimension
Chassis
Depth
(F)
Dimension
Drawer
Depth
(G)
Dimension
Chassis
Height
IWD24 22 5/16” (56.7 cm) 22 1/4” (56.5 cm) 22 3/8” (56.8 cm)
8 15/16”
(22.7 cm)
23 3/8”
(59.4 cm)
23 13/16”
(60.5 cm)
9 1/16”
(23.0 cm)
IWD27 25 5/16” (64.3 cm) 25 1/4” (64.1 cm) 25 3/8” (64.5 cm)
IWD30 28 5/16” (71.9 cm) 28 1/4” (71.8 cm) 28 3/8” (72.1 cm)
OWD24 22 1/2” (57.1 cm) 22 1/2” (57.1 cm) 22 1/2” (57.1 cm) 11 7/8”
(30.2 cm)
20”
(50.8 cm)
18”
(45.7 cm)
11 7/8”
(30.2 cm)
Product tolerances: ±1/16” (±1.6 mm) unless otherwise stated
Electrical Circuit Required Total Connected Load Minimum Ambient
Operating Temperature
120 Vac, 60 Hz, 15 Amp.
grounded, dedicated circuit
4.0 Amp. @
120 Vac, 60 Hz. 32°F (0°C)

 
PLANNING
GUIDE
DWD, ERWD, EWD, IWD, MRWD,
MWDH, MWDV, OWD, RWDV
24”, 27”, 30”, 36” Wide
Warming Drawers
Document # PG02-002 Revised 01/18/12 Page 3/3
Warming
drawer
Cooktop
1 1/2" (3.8 cm)
Typical countertop
3/4” min.*
(1.9 cm)
120 Vac
electrical
outlet
A
36" typ.
(91.4 cm)
B
C
A
Warming
drawer
Warming
drawer
B
3/4" min.*
(1.9 cm)
D
3/4" min.*
(1.9 cm)
36" typ.
(91.4 cm) 120 Vac
electrical
outlet
C
C
27"/30"/36" Dacor
single wall oven
Warming
drawer
Warming
drawer
Toe kick
D
C
C
D
120 Vac
elect.
120 Vac
elect.
A
3/4" min.*
(1.9 cm)
Cabinet/countertop tolerances: +1/16” (+1.6 mm), -0 unless otherwise stated
* Bare minimum spacing to allow for ventilation and avoid scraping on DWD, ERWD, EWD, MRWD, MWDH, MWDV and RWDV series models.
** On IWD series models or OWD24 without the optional front panel kit: The chassis and the drawer faceplate are smaller than the cutout.
The custom front panel mounts to the drawer faceplate. The height and width of the custom front panel must exceed the appropriate cutout
dimensions (A and C above) to cover the hole. Allow 1/4" minimum additional space on the top, bottom and sides from the
custom front panel edge to prevent scraping against adjacent doors, drawers and the countertop.
*** OWD24 with optional factory front panel kit only. Bare minimum spacing shown to avoid scraping. Gap above and below
cutout is 3/4” minimum. See ** above for OWD24 with custom front panel.
**** Model EWD36 cannot be installed above or below another warming drawer (any type).
***** Model OWD24 cannot be installed above, below or adjacent to a wall oven or warming drawer (any type).
Model (A) Cutout Width
(B) Min. Width to
Adjacent Doors/
Drawers
(C) Cutout Height (D) Min. Vertical Gap
Between Cutouts Min. Cutout Depth
DWD30 28 1/2” (72.4 cm) 30 1/4” (76.8 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
24” (61.0 cm)
ERWD27 25 1/2” (64.8 cm) 27 1/4” (69.2 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
ERWD30 28 1/2” (72.4 cm) 30 1/4” (76.8 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
EWD24 22 1/2” (57.2 cm) 24 1/4” (61.6 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
EWD27 25 1/2” (64.8 cm) 27 1/4” (69.2 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
EWD30 28 1/2” (72.4 cm) 30 1/4” (76.8 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
EWD36**** 34 1/2” (87.6 cm) 36 1/4” (92.1 cm)* 9 1/8” (23.2 cm) NA
IWD24 22 1/2” (57.2 cm) ** 9 1/8” (23.2 cm) 1 1/16” (2.7 cm)
IWD27 25 1/2” (64.8 cm) ** 9 1/8” (23.2 cm) 1 1/16” (2.7 cm)
IWD30 28 1/2” (72.4 cm) ** 9 1/8” (23.2 cm) 1 1/16” (2.7 cm)
MRWD27 25 1/2” (64.8 cm) 27” (68.6 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
MRWD30 28 1/2” (72.4 cm) 30” (76.2 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
MWDH27 25 1/2” (64.8 cm) 27 1/4” (69.2 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
MWDH30 28 1/2” (72.4 cm) 30 1/4” (76.8 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
MWDV27 25 1/2” (64.8 cm) 27 1/4” (69.2 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
MWDV30 28 1/2” (72.4 cm) 30 1/4” (76.8 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)*
OWD24***** 22 5/8” (57.5 cm) 24 1/4” (61.6 cm)*** 11 15/16” (30.3 cm) NA 20 1/8” (51.1 cm)
RWDV30 28 1/2” (72.4 cm) 30 1/4” (76.8 cm)* 9 1/8” (23.2 cm) 1 1/4” (3.2 cm)* 24” (61.0 cm)
WARNING
• Observe all governing codes and ordinances
during planning and installation. Contact your
local building department for further information.
• This appliance must be installed in accordance
with the accompanying installation instructions.
Mounting platform must be 3/4" (1.9 cm) thick
and support 100 lbs.
